Burkert 8041 Manuel utilisateur

Operating Instructions

Bedienungsanleitung

Manuel d’utilisation

Type 8041

Insertion electromagnetic flowmeter

Magnetisch-induktives Durchfluss-Messgerät, Insertion

Débitmètre électromagnétique à insertion

We reserve the right to make technical changes without notice.

Technische Änderungen vorbehalten.

Sous réserve de modications techniques.

Operating Instructions 2306/05_EU-ML 00559777 / Original_EN

Type 8041

1. ABOUT THESE OPERATING INSTRUCTIONS ....................... 5

1.1. Symbols used ................................................................ 5

1.2. Denition of the word "device" ..................................... 5

2. INTENDED USE....................................................................... 6

3. BASIC SAFETY INFORMATION ............................................... 6

4. GENERAL INFORMATION ...................................................... 8

4.1. Manufacturer's address and international contacts .... 8

4.2. Warranty conditions....................................................... 8

4.3. Information on the Internet............................................ 8

5. DESCRIPTION......................................................................... 8

5.1. Area of application......................................................... 8

5.2. General description ....................................................... 8

5.2.1. Construction ............................................................ 8

5.2.2. Operating principle................................................... 9

5.3. Description of the rating plate....................................... 9

5.4. Symbols on the device ................................................ 10

6. TECHNICAL DATA ................................................................. 10

6.1. Conditions of use......................................................... 10

6.2. Standards and directives............................................. 11

6.2.1. Conformity to the Pressure Equipment Directive... 11

6.2.2. UL-Certication ...................................................... 11

6.3. Mechanical data .......................................................... 12

6.4. Dimensions of device .................................................. 13

6.5. Fluid data ..................................................................... 13

6.6. Electrical data .............................................................. 15

6.7. Electrical connections data......................................... 16

6.8. K-factors....................................................................... 16

7. QUICK INSTALLATION .......................................................... 17

8. INSTALLATION ...................................................................... 19

8.1. Safety instructions....................................................... 19

8.2. Installation onto the pipe............................................. 19

8.2.1. Recommendations for installing the 8041 on

the pipe .................................................................. 19

8.2.2. Installation into the pipe of a 8041 with a G2" nut. 22

8.2.3. Installation into the pipe of a 8041 with a

clamp connection .................................................. 23

Contents

english

8.3. Wiring ........................................................................... 23

8.3.1. Wiring the 4...20mA output ................................... 26

8.3.2. Wiring the frequency output................................... 27

8.3.3. Wiring the relay output........................................... 28

9. ADJUSTMENT AND COMMISSIONING ............................... 30

9.1. Safety instructions....................................................... 30

9.2. Description of the electronic board ............................ 31

9.3. General diagram of the Read and

Parameterizing modes................................................. 33

9.4. Selecting the frequency of the main supply ............... 35

9.5. Filter selection.............................................................. 35

9.6. Selecting the measurement range .............................. 36

9.7. Calibrating the ow zero point .................................... 36

9.8. Calibrating the full scale .............................................. 39

9.9. Setting the parameters of the relay output................. 42

9.9.1. Choosing the switching way of the relay output.... 43

9.9.2. Viewing and setting the low and high switch-

ing thresholds......................................................... 45

9.9.3. Viewing and setting the time delay before

switching................................................................ 48

10. MAINTENANCE AND TROUBLESHOOTING...................... 51

10.1.Safety instructions....................................................... 51

10.2.Cleaning the device ..................................................... 51

10.3.Cleaning the electrodes............................................... 51

10.4.Replacing the seal on a device with G2" nut.............. 52

10.5.If you encounter problems .......................................... 52

11. SPARE PARTS AND ACCESSORIES .................................. 56

12. PACKAGING, TRANSPORT ................................................ 57

13. STORAGE ............................................................................ 57

14. DISPOSAL OF THE DEVICE................................................ 57

english

Type 8041

About these Operating Instructions

1. ABOUT THESE OPERATING

INSTRUCTIONS

The Operating Instructions describe the entire life cycle of the

device. Please keep these Operating Instructions in a safe place,

accessible to all users and any new owners.

The Operating Instructions contains important safety

information.

Failure to comply with these instructions can lead to hazardous

situations. Pay attention in particular to the chapters "3. Basic

safety information" and "2. Intended use".

▶Whatever the version of the device, the Operating Instructions

must be read and understood.

▶When the symbol is marked inside or outside the device,

carefully read the Operating Instructions.

1.1. Symbols used

DANGER

Warns against an imminent danger.

▶Failure to observe this warning results in death or in serious

injury.

WARNING

Warns against a potentially dangerous situation.

▶Failure to observe this warning can result in serious injury or

even death.

CAUTION

Warns against a possible risk.

▶Failure to observe this warning can result in substantial or

minor injuries.

NOTICE

Warns against material damage.

indicates additional information, advice or important

recommendations.

refers to information contained in these Operating

Instructions or in other documents.

▶Indicates an instruction to be carried out to avoid a danger, a

warning or a possible risk.

→Indicates a procedure to be carried out.

Indicates the result of a specic instruction.

1.2. Denition of the word "device"

The word "device" used within these Operating Instructions

refers to the owmeter type 8041.

english

Type 8041

Intended use

2. INTENDED USE

Use of the device that does not comply with the instructions

could present risks to people, nearby installations and the

environment.

The 8041 owmeter is intended exclusively to measure the

ow rate in liquids.

▶Use this device in compliance with the characteristics and

commissioning and use conditions specied in the contrac-

tual documents and in the Operating Instructions.

▶Never use the owmeter type 8041 for security applications.

▶Protect this device against electromagnetic interference,

ultraviolet rays and, when installed outdoors, the eects of

climatic conditions.

▶Protect this device against electromagnetic interference,

ultraviolet rays and, when installed outdoors, the eects of

climatic conditions.

▶Only operate a device in perfect working order.

▶Requirements for the safe and proper operation of the device

are proper transport, storage and installation, as well as

careful operation and maintenance.

▶Only use the device as intended.

3. BASIC SAFETY INFORMATION

This safety information does not take into account any contin-

gencies or occurrences that may arise during installation, use

and maintenance of the device.

The operating company is responsible for the respect of the local

safety regulations including sta safety.

Risk of injury due to high pressure in the installation.

▶Stop the circulation of uid, cut o the pressure and drain

the pipe before loosening the process connections.

Risk of injury due to electrical voltage.

▶If a 18...36VDC powered version is installed either in a wet environ-

ment or outdoors, all the electrical voltages must be of max. 35VDC.

▶Shut down the electrical power source of all the conductors

and isolate it before carrying out work on the system.

▶Observe all applicable accident protection and safety regula-

tions for electrical equipment.

Risk of injury due to high uid temperatures.

▶Use safety gloves to handle the device.

▶Stop the circulation of uid and drain the pipe before loosen-

ing the process connections.

Risk of injury due to the nature of the uid.

▶Respect the prevailing regulations on accident prevention

and safety relating to the use of aggressive uids.

english

Type 8041

Basic safety information

Various dangerous situations

To avoid injury take care:

▶to prevent any unintentional power supply switch-on.

▶to ensure that installation and maintenance work are carried

out by qualied, authorised personnel in possession of the

appropriate tools.

▶to guarantee a dened or controlled restarting of the pro-

cess, after a power supply interruption.

▶not to use the device for the measurement of gas ow rates.

▶not to use the device in explosive atmospheres.

▶not to use the device in an environment incompatible with

the materials it is made of.

▶not to subject the device to mechanical loads.

▶not to make any modications to the device.

▶to use the device only if in perfect working order and in

compliance with the instructions provided in these Operating

Instructions.

▶to observe the general technical rules when installing and

using the device.

NOTICE

The device may be damaged by the uid in contact with.

▶Systematically check the chemical compatibility of the

component materials of the device and the uids likely to

come into contact with it (for example: alcohols, strong or

concentrated acids, aldehydes, alkaline compounds, esters,

aliphatic compounds, ketones, halogenated aromatics or

hydrocarbons, oxidants and chlorinated agents).

NOTICE

Elements / Components sensitive to electrostatic discharges

▶This device contains electronic components sensitive to

electrostatic discharges. They may be damaged if they are

touched by an electrostatically charged person or object.

In the worst case scenario, these components are instantly

destroyed or go out of order as soon as they are activated.

▶To minimise or even avoid all damage due to an electro-

static discharge, take all the precautions described in the

EN61340-5-1norm.

▶Also ensure that you do not touch any of the live electrical

components.

english

Type 8041

General information

4. GENERAL INFORMATION

4.1. Manufacturer's address and

international contacts

To contact the manufacturer of the device, use following

address:

Bürkert SAS

Rue du Giessen

BP 21

F-67220 TRIEMBACH-AU-VAL

You may also contact your local Bürkert sales oce.

The addresses of our international sales oces are available on

the internet at: country.burkert.com.

4.2. Warranty conditions

The condition governing the legal warranty is the conforming use

of the device in observance of the operating conditions specied

in these Operating Instructions.

4.3. Information on the Internet

You can nd the Operating Instructions and technical data sheets

regarding the type8041 at: country.burkert.com.

5. DESCRIPTION

5.1. Area of application

The device is used to measure the ow of neutral or slightly

aggressive uids with a conductivity of more than 20µS/cm in

DN06 to DN400 pipes.

5.2. General description

5.2.1. Construction

The device comprises an electronic module and a PVDF or

stainless steel measurement sensor.

The ow sensor comprises two electrodes and a magnetic

system.

The connection of the device to the process is made depending

on the version, either by a G2" nut or a clamp.

Electrical connection is made via two cable glands on a 6-pin

terminal block.

The device requires an 18...36VDC power supply and has:

• a frequency output,

• a relay output,

• a 4...20mA current output.

english

Type 8041

Description

5.2.2. Operating principle

The magnetic system in the ow sensor generates a magnetic

eld in the uid, perpendicular to the ow direction, see Fig.1.

The electrodes on the ow sensor ensure electrical contact with

the uid. When the uid ows over them, a voltage is measured

between the two electrodes. This voltage is proportional to the

uid velocity.

Fig.1: Operatingprincipleoftheowsensor

5.3. Description of the rating plate

FLOW: 8041 SST LONG SUPPLY: 18-36V... 220mA

PULSE: 5-36V... 100mA REL: 30V~ or 60V...

I-OUT: 4-20mA IP65 FLUID: PN16; –15/150°C

S/N 1234

00561607 W46MA

Made in France

1314

1. Measured value and type

of the device

2. Specication of the ow

sensor

3. Specication of the pulse

output

4. Specication of the relay

output

5. Power supply / Max.

consumption

6. Fluid nominal pressure and

uid temperature range

7. Manufacturing code

8. Conformity marking

9. Warning: Before using the

device, take into account

the technical specica-

tions described in the

Operating Instructions

10. Certication

11. Protection class of the

device

12. Specication of the current

output

13. Serial number

14. Article number

Fig.2: Rating plate of the device (example)

english

Type 8041

Technical data

5.4. Symbols on the device

Symbol Description

Direct current

Alternating current

Earth terminal

Protective conductor terminal

6. TECHNICAL DATA

6.1. Conditions of use

Ambient temperature –10...+60°C

Air humidity <80%, non condensated

Height above see

level

max. 2000m

Operating conditions Continuous

Equipment mobility Fixed

Use Indoor and outdoor

(Protect the device against electro-

magnetic interference, ultraviolet rays

and, when installed outdoors, against

the eects of climatic conditions)

Installation category CategoryI according to UL/EN61010-1

Degree of pollution Degree2 according to UL/EN61010-1

Protection class

according to

IEC/EN60529

IP651), with cable connected and

cable gland tightened and cover

screwed on to the electronic module

1) not evaluated by UL
