Bticino 375006 Manuel utilisateur

375006

375007

375008

375009

04/21-01 PC

LE12696AA

BTicino SpA – Viale Borri, 231 – 21100 Varese – Italy – www.bticino.com

Dimensional data 375006

* Recommended height, unless different regulations are specified.

Installation 375006

To ensure proper operation, the Fingerprint Reader must be installed in a location protected from rain.

384 mm

149 mm

2 mm 58 mm

90 – 130 cm

160 – 165 cm

149 mm

384

60 mm

Dimensional data 375007

* Recommended height, unless different regulations are specified.

Installation 375007

To ensure proper operation, the Fingerprint Reader must be installed in a location protected from rain.

414,4 mm

183,6 mm

90 – 130 cm

160 – 165 cm

2 mm 58 mm

184 mm

415

60 mm

Dimensional data 375008

* Recommended height, unless different regulations are specified.

Installation 375008

To ensure proper operation, the Fingerprint Reader must be installed in a location protected from rain.

82 mm

232

62 mm

231,5 mm

81,4 mm

90 – 130 cm

160 – 165 cm

2 mm 60 mm

Dimensional data 375009

* Recommended height, unless different regulations are specified.

Installation 375009

To ensure proper operation, the Fingerprint Reader must be installed in a location protected from rain.

90 – 130 cm

160 – 165 cm

231,5 mm

81,4 mm

2 mm 57 mm

Read carefully before use and keep for future reference

Touching the units with wet hands is forbidden

Using liquid cleaners or aerosols is forbidden

Blocking the ventilation openings is forbidden

Modifying the devices is forbidden

Removing protective parts from the devices is forbidden

Installing the units near liquids and powders is forbidden

Installing the units near heat sources is forbidden

Installing the units near harmful gases, metal dusts or similar is forbidden

Fastening the units on unsuitable surfaces is forbidden

Warnings and consumer rights

Risk of devices falling because the surface on which they are installed collapses or inappropriate installation

Switch the power supply OFF before any work on the system

Caution: Installation, conguration, starting-up and maintenance must be performed exclusively by

qualied personnel.

Check that the wall installation has been carried out correctly

Lay out the wires respecting the standards in force

Connect the power supply wires as indicated

Use only the items indicated in the technical specications for any system expansions

84 mm

178

59 mm
