BT RELATE SMS Manuel utilisateur

User Guide

BT RELATE SMS

This product is intended for connection to analogue

public switched telephone networks and private

switchboards in the United ingdom.

*YOU MUST

SUBSCRIBE TO YOUR

NETWORK PROVIDER’S

CALLER DISPLAY SERVICE FOR

THIS FEATURE AND FOR SMS TO WORK.

FOR SMS YOU MUST NOT WITHHOLD

YOUR NUMBER. A FEE MAY BE PAYABLE.

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Please open this page for an ‘at a glance’

guide to your BT Relate SMS.

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Please open this page for a further

‘at a glance’ guide to your BT Relate SMS.

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

123

456

789

Calls

Redial Dial

Undo





SMS

Calls T Relate SMS

Secrecy

Pause

SMS

At a glance

Calls light

Flashes when you have

unviewed calls in the

Calls list.

Redial button

To redial a number from

the redial list.

Calls button

Press to access the

Calls List.

Undo button

To return to the previous

display screen.

Press repeatedly to return

to standby.

button

To delete an incorrect

digit/character.

To delete Directory

entries, Calls list entries

and SMS messages.

Secrecy button

Use to turn secrecy on/off.

R button

For use with a

switchboard/PBX and

BT Calling features,

see page 39 and 22.

Pause button

Press to enter a pause

in a stored number.

SMS button

Press to access the SMS

menu options.

# button

To change from upper to

lower case when storing

names and writing SMS

text messages.

M1- M5 buttons

Direct memory buttons.

✔Button

Press to confirm a setting.

Menu button

To access the menu

options.

Dial button

To dial a displayed

number.

Directory button

Press to access the

Directory.

or buttons

Use to scroll backwards

and forwards through the

menu options.

SMS light

Flashes when you have

unviewed SMS text messages

Handset park

When the phone is wall

mounted you can hang

the handset here if you

need to leave the phone

during a call.

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Standby screen

Time

Total Calls

list entries

Date

Total SMS

text messages

Quick guide to display icons

Displayed when the batteries are low and need replacing.

Indicates that secrecy is on.

NEW Displayed when you have new Calls list entries.

REPT Indicates that a number stored in the Calls list has called more than once.

002 Shows you which Calls list entry or which SMS message you are currently viewing,

e.g. number 2.

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Menu Structure

MAIN MENU

SMS MENU

CALLS MENU

SET CONTRAST

SMS PROVIDERS

12/24H FORMAT

SET CLOC

AUDIBLE ALERT

WRITE MESSAGE?*

INBOX

OUTBOX

DIRECTORY MENU

WRITE MESSAGE?

NEW?

SAVE TO?

REPLY?

FORWARD?

DELETE?

DELETE ALL?

SAVE TO?

FORWARD?

DELETE?

DELETE ALL?

SAVE TO?

EDIT?

DELETE?

DELETE ALL?

SAVE TO?

DRAFTS

EDIT?

DELETE?

DELETE ALL?

SAVE TO (M1 – M5)?

DELETE?

DELETE ALL?

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

At a glance 1

Quick guide to display icons 2

Menu structure 3

Introduction 5

Safety information 6

Setting up 7

Using your elate SMS 10

Making and receiving calls 10

Call timer 11

Redial 11

Ringer volume 11

Secrecy 12

Display contrast 12

12/24 Hour Clock 12

Time and date display 13

SMS message audible alert on/off 13

5 Name and number direct memories 14

Character map 15

100 Name and number directory 17

BT Calling Features 22

Caller Display 22

Calls list 22

SMS Text Messaging 26

Using SMS 27

Character map 27

Write and send an SMS message 28

Receiving an SMS message 30

Delivery of SMS messages 31

SMS Service Centre numbers 36

Sending SMS text messages from

mobile phones 37

General information 38

Guarantee 38

If you have to return your product 38

Technical information 38

Switchboard compatibility 39

Help 40

SMS Service Conditions 42

Wall mounting template 49

Index 50

In this guide

Note

There is a detailed INDEX at the end of this guide, see page 50.

Note

In this user guide, we’ve included helpful tips and

useful notes. They are shown in a white box like this.

INTRODUCTION

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Introduction

Your Rel te SMS is designed for e se of use nd m de to the high st nd rds set by BT.

You c n expect your Rel te SMS to provide m ny ye rs of qu lity service. Ple se re d the

instructions c refully before use nd keep this user guide for future reference.

Unp cking your Rel te SMS

Check that your Relate SMS is complete.

If anything is missing, please contact your place of

purchase immediately.

Relate SMS telephone

Handset and cord

Telephone line cord

4 x AA batteries

Desk mounting plinth

Wall plugs and screws

For your records

For guarantee purposes proof of purchase is required,

so please keep your receipt.

Date of purchase:

Place of purchase:

Serial number:

(on the underside of the base unit)

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

SAFETY INFORMATION

S fety inform tion

Gener l

Do not dismantle the telephone. This could

expose you to high voltages or other risks.

Never dispose of batteries in a ﬁre. There is

a serious risk of explosion and/or the release

of highly toxic chemicals.

Cle ning

Simply clean your Relate SMS with a damp

(not wet) cloth, or an anti-static wipe.

Never use household polish, as this will

damage the product.

Never use a dry cloth as this may cause a

static shock.

Environment l

Do not expose to direct sunlight.

Do not stand your product on carpets or other

surfaces which generate fibres, or place it in

locations preventing free flow of air over its

surfaces.

Do not submerge any part of your product

in water and do not use it in damp or humid

conditions, such as in bathrooms.

Do not expose your product to ﬁre, explosive or

other hazardous conditions.

There is a slight chance that your phone could be

damaged by an electrical storm. We recommend

that you unplug the telephone line cord for the

duration of the storm.

SETTING UP

Relate SMS User Guide ~ Issue 2 ~ 2nd Edition ~ 20th August ’03 ~ 5538

Setting up

Follow these steps to set up your Rel te SMS re dy for use.

Open the battery compartment on the back of your

telephone by pushing in the plastic clip and lifting off

the battery cover. Then insert the batteries as shown.

Replace the battery compartment cover.

Pl n the loc tion

Situate your Relate SMS close enough to the

telephone socket so that the line cord will reach.

Do not situate the product in the bathroom or other

humid areas.

Note

If you are replacing batteries you will need to remove

the desk mounting plinth (if attached) to gain access

to the battery compartment.

Note

When your batteries are close to becoming completely

flat, will flash in the top left corner of the

display. If you do not replace the batteries they

will become totally discharged and your display

will not work.

1Install the batteries

The display on your Relate SMS is powered by 4 x AA

batteries.

Make sure the phone is not plugged into the phone

socket.
