BT Mini Hub Manuel utilisateur
Welcome
BT Mini Hub Kit user guide
What’s in the box
This handy kit is a great way to extend broadband
round your home.
Here’s what’s in this guide
What’s in the box 2
What an extended network looks like 3
How to set up and get connected 4
Troubleshooting 6
How to reset your kit 9
Need some help? 10
Other information 11
Thanks again for choosing BT.
Hello
BT Mini Hub BT Mini Connector
BT Mini Hub Kit
user guide
Welcome
BT Mini Hub Kit user guide
Ethernet cable
(yellow ends) for a
wired connection
2
What an extended network looks like
Got a bundle, like BT Smart Hub
or BT TV, too?
Set up your Smart Hub rst
before setting up anything else.
Internet BT Smart Hub BT Mini Connector BT Mini Hub
Connect your devices wirelessly,
or with an Ethernet cable
BT Smart Hub BT Mini Hub Kit YouView box
Have a quick look at what’s what below.
Then turn the page and follow the set-up steps.
3For more help, go to bt.com/help/minihub
Connect the Mini Connector
1Plug one end of the Ethernet cable into any
Ethernet port on your Smart Hub.
2Plug the other end into one of the Ethernet ports
on top of your Mini Connector.
3Plug the Mini Connector directly into a
power socket on the wall and switch on.
The Power and Ethernet lights will come on.
1
How to set up and get connected
Connect to your
Hub’s Wireless:
Select your Wireless Network:
BTHub6-ABCD
1
Enter your Wireless
Password/key:
8888wwwwwWWW
2
Admin Password for
Hub Manager:
8888WWWW
Power
On | Off
Power
Factory
Reset
USB Gig Ethernet
1 2 3 4
Broadband
Mini Connector
Smart Hub
Using extension leads
You can use power extension leads but you need
to connect them like this:
No free extra socket?
Plug your device or
BT Smart Hub into
the Connector
Power light
Ethernet light
4
Connect your devices
You’ll need your Mini Hub’s wireless network name
and password. They’re on the back of your Mini Hub.
If your device supports WPS,
just press (WPS) on
your Mini Hub. It’s a quick
way to connect.
BT Mini Hub Settings
Plug in the Mini Hub
Go to the part of your home where you want to
improve your wireless signal. Then plug the Mini
Hub into a power socket on the wall and switch
the socket on. Check that the Mini Hub is also on.
The Power light will come on rst then, within a
minute, the Wireless and Data lights too.
2 3
BT Mini Hub Settings
BT Mini Hub Settings
You’ll need this card
for step 3.
Connect to your BT Mini Hub’s Wireless:
Wireless Network names:
2.4 GHz: BTMiniHub-XXX
5 GHz: BTMiniHub-XXX-5
Wireless Password/key:
XXXXXXXXXXX
Admin Password : 8888WWWW
All done.
WPS
Know your networks
The Mini Hub is dual-band, so you’ll see two
network names on the card, one for the 2.4GHz
band and one for the 5GHz band. The wireless
password is the same for both.
Don’t want to use wireless?
Using an Ethernet cable, connect your device to
either Ethernet port on the top of the Mini Hub.
Power light
Data light Wireless light
Mini Hub
5For more help, go to bt.com/help/minihub
Troubleshooting
Power
Power
WirelessEthernet DataData
Your BT Mini Connector lights
(see page 7)
Your BT Mini Hub lights
(see page 8)
6
What the lights on your BT Mini Connector mean
Light Colour Status What’s happening
Power Blue On Connector running normally
Flashing Connector resetting, synchronising or sleeping. Give it a couple of minutes
–O No power. Check everything’s on. Still no light?
Go to bt.com/help/miniconnector
Ethernet Blue On Connector running normally, sending or receiving data
–O Not connected. Check that the Ethernet cable is plugged into Connector
and Smart Hub. For set-up, see page 4
Data Blue
Orange
Red
On Connector is connected to network.
Transfer speeds: blue is high; orange is medium; red is low.
Slow speed? Check your set-up on page 4.
For tips on improving your speed, go to bt.com/help/miniconnector
–O No connection to network or sleeping. You might need to restart and/or
reset your kit. See page 9
7For more help, go to bt.com/help/minihub
What the lights on your BT Mini Hub mean
Light Colour Status What’s happening
Power Blue On Mini Hub running normally
Flashing Mini Hub resetting, synchronising or sleeping. Give it a couple of minutes
–O No power. Check everything’s on. Still no light? Go to bt.com/help/minihub
Wireless Blue On Wireless enabled, sending or receiving data
Orange Flashing WPS is connecting. If it doesn’t, use your wireless password on the Mini Hub
Orange On Wireless security o for 2.4GHz or 5GHz band.
For help, go to bt.com/help/minihub
–O Wireless isn’t on. If you haven’t turned wireless o, you might need to
restart and/or reset your kit. See page 9
Data Blue
Orange
Red
On Mini Hub is connected to network.
Transfer speeds: blue is high; orange is medium; red is low.
Slow speed? Check your set-up on page 5.
For tips on improving speed, go to bt.com/help/minihub
–O No connection to network or sleeping. You might need to restart and/or
reset your kit. See page 9
8
How to reset your kit
If your Mini Hub or Mini Connector stops working or
becomes unpaired, turn it o and then on to restart it.
If it still isn’t working, reset to factory settings using
these steps.
1Make sure the Mini Hub or Mini Connector is
plugged in and the power socket is switched on.
2Press and hold (Add) on the Mini Connector
for more than 15 seconds, or the F. Reset button
on the Mini Hub for one second to go back to
its original settings.
Give it a couple of minutes. If everything’s
okay, the Power, Data, Ethernet and Wireless
lights will come on.
Remember: if you reset your Mini Hub, you’ll lose
any settings that you might’ve changed, like your
wireless network name or wireless password.
BT Mini Hub Settings
BT Mini Hub Settings
Mini Connector Mini Hub
Stuck?
Find out how to get in touch with us on page 10.
9For more help, go to bt.com/help/minihub
Need some help?
Go to bt.com/help/minihub or bt.com/help
A quick way to get help, all day and every day.
Chat to us at bt.com/chat
We’re here to help seven days a week between
7am and 11pm.
Get help from other users
Join the conversation in The BT Community Forum
at bt.com/community
Call us
If you need to talk, give us a ring on 0800 111 4567.
We’re usually less busy between 12pm and 6.30pm.
When you call, make sure you’re next to your Mini
Hub with a computer or device.
You can also call 0330 123 4567 from a mobile.
All numbers starting 0330 are charged at a national
rate and are included in any free minutes as part of
your mobile contract. Some mobile operators allow
free use of 0800 numbers.
