BSeen X E-bike Manuel utilisateur

X e-bike Owner’s

Manual

INTRODUCTION

Thank you for purchasing our bSeen product.

bSeen is an indicator light kit developed for electric scooters, electric

bicycles and any other vehicle that lacks of indicators, and light warning

systems.

Sold as a “do it yourself” kit, bSeen is a powerful and reliable system,

based on the latest technologies.

At the heart of the system, a micro-controller was programmed for the

most basic tasks, such as right and left turn, and other functions such as

hazard warning lights, horn and headlight control.

bSeen LED units are extremely bright, and can be seen during the day.

LED units are manufactured in-house and carefully inspected to ensure

their waterproof properties.

bSeen handlebar switch unit is easy to operate, with all controls you need

to control your indicator system.!

BOX CONTENTS

Inside your bSeen kit box you will ﬁnd:

1 x ECU (Electronic Control Unit)

1 x Handlebar Control Unit

4 x LED units with cable tail

1 x Power lead

12 x Heat shrink sleeves

ECU (Electronic Control Unit)

Handlebar Control Unit

Amber LED Units (rear)

White LED Units (front)

SYSTEM SPECIFICATIONS

ECU

LED units

Handlebar Control

System Functions!

• Input voltage: 18V - 78V DC

• Main board operating voltage: 9V DC

• Outputs voltage: 12V DC regulated

• Power consumption in standby mode: 14mA

• Heat resistant PVC box

• Dimensions: 50mm (L) x 40mm (W) x 33mm (H)

• Weight: 100g

• Maximum operating voltage: 12.7V

• Maximum output power: 2.1W

• Electronic circuit type: Chip on board

• Colour: Cool White (front units), Amber (rear

units)

• IP66 rated waterproof

• Dimensions: 55mm (L) x 15mm (W) x 3.5mm

(H)

• Headlight switch (ON/OFF), Left/Right turn

switch, horn switch.

• LED monitoring for headlight and turning

signals

• Headlight ON/OFF (headlight sold separately)

• Horn ON/OFF time limited to 1.5sec

consecutive buzz (horn sold separately)

• Left Turn

• Right Turn

• Hazard Lights

• Presence/Daytime Front Lights

BASIC INSTALLATION DIAGRAM

Handlebar Control Unit

Front Right LED Unit

Front Left LED Unit

Rear Left LED Unit

Rear Right LED Unit

ECU

BSEEN ELEMENTS’ LOCATION!

Handlebar Control Unit

mounted on the left or right

side of the handlebar.

Front LED

indicators

mounted on

the fork

Rear LED

indicators

mounted on

the rear

frame/fork

ECU mounted - hidden

on the frame

INSTALLATION

bSeen X e-bike was designed to be ﬁtted on your e-bike, and it uses your

bike’s battery power to operate.

PROCEED WITH CAUTION AND READ CAREFULLY

The installation of the bSeen X kit requires electric skills, such as

soldering and stripping electrical wires.

If you’re not familiar with such proceedings, ask for support from your

bicycle dealer or from an automotive electrician expert.

Damage to the bSeen ECU, LED units and/or Handlebar Control Unit

due to faulty connections, short circuits or polarity inversions, will not be

covered by warranty.

Please keep in mind, modiﬁcations to your e-bike can void its warranty.

Make sure you read and understand your e-bike’ manufacturer warranty

terms, and proceed with bSeen’s kit installation with caution.

INSTALLATION - HANDLEBAR CONTROL UNIT

Remove your left or right handlebar grip, and once removed, install the

bSeen Handlebar Control Unit in place. Be sure to tighten the hexagonal

screw located at the back of the unit:

The Handlebar Control Unit is supplied with a 2 metres cable length and a

Higo connector. The cable runs along with the brake and gear line, to the

place where you decided to ﬁt the ECU (bSeen Control Unit):

Tighten the hexagonal screw located on the back of the unit

INSTALLATION - REAR LED UNITS & CABLE MANAGEMENT

Rear LED units (indicators) can be ﬁtted on both sides of the rear frame/

forks.

Each LED unit is supplied with a 3M VHB double tape pad, designed for

automotive industry and resistant to all kinds of weather conditions.

Find the best place to ﬁt each indicator. These should be facing the trafﬁc

behind your e-bike, so your turning intentions can be seen by other road

users.

Peel the double tape on the back of the LED, and stick the LED unit in

place. The bonding process will take up to 24 hours to complete. You can,

however, use the e-bike normally, after ﬁnishing your installation. This

won’t interfere with the bonding process.

Left indicator

Right indicator

Run the LED units’ cables through the e-bike’s frame to the place where

you decided to ﬁt the ECU.

In the picture bellow, the cables are ﬁxed with the same 3M VHB double

tape on the interior of the the chain stays, and then it was used cable ties

to secure the cable to through the rear brake line.

LED units’ cables

Chain Stay
