Quick Setup Guide

How to use the printer, see the User’s Guide on the CD-ROM.

Setting Up the Machine

Installing the Printer Driver

Laser Printer

HL-2140

HL-2150N

Before you can use the printer, you must set up the hardware and install the driver. Please

read this ‘Quick Setup Guide’ for proper set up and installation instructions.

Keep this ‘Quick Setup Guide’ and the supplied CD-ROM in a convenient place for quick and

easy reference at all times.

Version 0

Symbols used in this guide

Warning

Electrical Hazard

Hot Surface

Caution

Warnings tell you what to do

to prevent possible personal

injury.

Electrical Hazard icons alert

you to a possible electrical

shock.

Hot Surface icons warn you

not to touch machine parts

that are hot.

Cautions specify procedures

you must follow or avoid to

prevent possible damage to

the printer or other objects.

Improper Setup

Note

User's Guide

Network User's Guide

Improper Setup icons alert

you to devices and

operations that are not

compatible with the printer.

Notes tell you how you should

respond to a situation that

may arise or give tips about

how the current operation

works with other features.

Indicates reference to the

User's Guide or Network

User's Guide which is on the

CD-ROM we have supplied.

Table of Contents

Safety Precautions ....................................................................................................................................... 2

To Use the Printer Safely ........................................................................................................................ 2

Regulations ............................................................................................................................................. 4

Getting Started

Carton Components ..................................................................................................................................... 5

Control panel................................................................................................................................................ 6

Printer LED Indications ................................................................................................................................ 6

Supplied CD-ROM ....................................................................................................................................... 7

STEP 1 –

Setting Up the Machine

Installing the drum unit and toner cartridge assembly.................................................................................. 8

Loading paper in the paper tray ................................................................................................................... 9

Printing a test page .................................................................................................................................... 10

STEP 2 –

Installing the Printer Driver

Windows®

For USB interface cable users .................................................................................................................. 12

For network interface cable users (HL-2150N users) ............................................................................... 14

For Peer-to-Peer network printer users ............................................................................................... 14

For shared network printer users ......................................................................................................... 16

Macintosh®

For USB interface cable users .................................................................................................................. 18

For network interface cable users (HL-2150N users) ............................................................................... 20

For Network Users (For HL-2150N)

BRAdmin Light utility (For Windows®users).............................................................................................. 22

BRAdmin Light utility (For Mac OS®X users)............................................................................................ 23

Web Based Management (web browser)................................................................................................... 24

Network default settings............................................................................................................................. 24

Print the Printer Settings Page................................................................................................................... 24

Consumables

Consumables ............................................................................................................................................. 25

Repacking Information

Shipment of the printer............................................................................................................................... 26

Troubleshooting

Chapter 6 of the User’s Guide on the CD-ROM

Safety Precautions

To Use the Printer Safely

Warning

There are high voltage electrodes inside the printer. Before you clean the inside of the printer, make sure that

you have turned off the power switch and unplugged the printer from the AC power outlet.

DO NOT handle the plug with wet hands. Doing this might cause an electrical shock.

After you have just used the printer, some internal parts of the printer will be extremely hot. DO NOT touch the

shaded parts shown in the illustration when you open the front or back cover of the printer.

DO NOT remove or damage the caution labels located on or around the fuser.

DO NOT use a vacuum cleaner to clean up scattered toner. Doing this might cause the toner dust to ignite

inside the vacuum cleaner, potentially starting a fire. Please carefully clean the toner dust with a dry, lint-free

cloth and dispose of it according to local regulations.

Inside the printer

(Front View)

Inside the printer

(Back View)

Safety Precautions

DO NOT use flammable substances or any type of spray to clean the inside or outside of the machine. Doing

this may cause a fire or electrical shock. Refer to the User's Guide for how to clean the machine.

Safety Precautions

Regulations

Radio interference (220-240 volt model only)

This printer follows EN55022 (CISPR Publication

22)/Class B.

IEC 60825-1 specification (220 to 240 volt model

only)

This printer is a Class 1 laser product as defined in

IEC 60825-1+A2: 2001 specifications. The label

shown below is attached in countries where it is

needed.

This printer has a Class 3B laser diode which

produces invisible laser radiation in the laser unit. You

should not open the laser unit under any

circumstances.

Caution

Use of controls or adjustments or performance of

procedures other than those specified herein may

result in hazardous radiation exposure.

Internal laser radiation

IMPORTANT - For Your Safety

To ensure safe operation, the supplied three-pin plug

must be inserted only into a standard three-pin power

outlet that is properly grounded through the normal

household wiring.

Extension cords used with this printer must be three-

pin plug type and correctly wired to provide proper

grounding. Incorrectly wired extension cords may

cause personal injury and equipment damage.

The fact that the equipment operates satisfactorily

does not imply that the power is grounded and that

the installation is completely safe. For your safety, if

in any doubt about the effective grounding of the

power, call a qualified electrician.

This product should be connected to an AC power

source within the range indicated on the rating label.

DO NOT connect it to a DC power source. If you are

not sure, contact a qualified electrician.

Disconnect device

You must install this printer near a power outlet that is

easily accessible. In case of an emergency, you must

disconnect the power cord from the power outlet to

shut off the power completely.

Caution for LAN connection (For HL-2150N users)

Connect this product to a LAN connection that is not

subjected to over voltages.

Maximum radiation power: 10 mW

Wave length: 780 - 800 nm

Laser class: Class 3B

Getting Started

Carton Components

Carton components may vary from one country to another.

Save all packing materials and the printer carton in case for any reason you must ship your printer.

1 Face-down output tray support flap 1 (Support flap 1)

2 Control panel

3 Manual feed paper guide

4 Manual feed slot

5 Manual feed slot cover

6 Paper tray

7 Front cover

8 Power switch

9 Ventilation hole

10 Face-down output tray

The Network interface cable is not standard accessories. Please purchase them, if you intend to use.

USB cable

• Please make sure you use a USB 2.0 interface cable that is no longer than 6 feet (2 meters).

• Your printer has a USB interface that is compatible with the USB 2.0 specification. This interface is also

compatible with Hi-Speed USB 2.0; however, maximum data transfer rate will be 12 Mbits/s. The printer can

also be connected to a computer that has a USB 1.1 interface.

• DO NOT connect the interface cable at this time. Connecting the interface cable is done during the printer

driver installation process.

When you use a USB cable, make sure you connect it to the USB port of your computer and not to a USB

port on a keyboard or non-powered USB hub.

Network cable (For HL-2150N users)

• Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast

Ethernet Network.

CD-ROM

(including User’s Guide

and Network User’s Guide)

Quick Setup Guide

Drum unit and toner

cartridge assembly

AC power cord

Getting Started

Control panel

For the details of the control panel, see Chapter 4 of the User’s Guide on the CD-ROM.

Printer LED Indications

1The LED will blink in a pattern of ON for 1 second and then OFF for 1 second.

2The LED will blink in a pattern of ON for 0.5 seconds and then OFF for 0.5 seconds.

3The LED will blink in a pattern of ON for 2 seconds and then OFF for 3 seconds.

1Toner LED

The Toner LED indicates when the toner is low or at the end of its life.

2Drum LED

The Drum LED indicates when the drum is nearing the end of its life.

3Error LED

The Error LED indicates when the printer is in one of the following

states:

No paper / Paper jam / Cover open

4Ready LED

The Ready LED will flash depending on the printer status.

Go button

Wake-up / Error recovery / Form feed / Job Cancel / Reprint

: Blinking : ON : OFF

Printer LED OFF Sleep Warming up

Cooling down 1

Ready Receiving

data 2

Print Data

remaining 2

Toner

Drum

Error

Ready

(Blue)

Dimmed

Printer LED Toner low 3Toner life

end

Drum near

end of life 3

Cover open

Paper jam 2

No paper Drum Error 2Service

call 2

Toner

(Yellow)

Drum

(Yellow)

Error

(Red)

Ready

(Blue)

User's Guide

Chapter 5 Chapter 5 Chapter 5 Chapter 6 Chapter 6 Chapter 4 Chapter 4

Getting Started

Supplied CD-ROM

You can find a variety of information on the CD-ROM.

Windows®

Install Printer Driver

Install the printer driver.

Install Other Drivers or Utilities

Install optional drivers, utilities and Network

management tools (For HL-2150N users).

Documentation

View the Printer User’s Guide and Network User's

Guide (For HL-2150N) in HTML format.

You can also view the manuals in PDF format by

accessing the Brother Solutions Center.

The User’s Guide and Network User’s Guide in HTML

format will be installed automatically when you install

the driver. Click the Start button, All Programs 1,

your printer, and then User’s Guide in HTML format.

If you do not want to install the User’s Guide, choose

Custom setup from Install Printer Driver, and

uncheck User’s Guides in HTML format when you

install the driver.

1Programs for Windows®2000 users

Brother Solutions Center

The Brother Solutions Center

(http://solutions.brother.com) is a one-stop resource

for all your printer support needs. Download the latest

drivers and utilities for your printers, read FAQs and

troubleshooting tips, or learn about printer solutions.

Supplies Information

Visit our web site for original/genuine Brother supplies

at http://www.brother-cn.net/supply.html

Macintosh®

Install Printer Driver

Install the printer driver.

Documentation

View the Printer User’s Guide in HTML format.

You can also view the User’s Guide in PDF format by

accessing the Brother Solutions Center.

Brother Solutions Center

The Brother Solutions Center

(http://solutions.brother.com) is a one-stop resource

for all your printer support needs. Download the latest

drivers and utilities for your printers, read FAQs and

troubleshooting tips, or learn about printer solutions.

Supplies Information

Visit our web site for original/genuine Brother supplies

at http://www.brother-cn.net/supply.html.

Note

For visually impaired users, we have prepared an HTML file on the

supplied CD-ROM: readme.html. This file can be read by Screen

Reader ‘text-to-speech’ software.

Setting Up the Machine

STEP 1

1 Installing the drum unit and

toner cartridge assembly

Improper Setup

DO NOT connect the interface cable.

Connecting the interface cable is done when

installing the driver.

1Open the front cover.

2Unpack the drum unit and toner cartridge

assembly.

3Rock it from side to side several times to

distribute the toner evenly inside the assembly.

4Put the drum unit and toner cartridge assembly

into the printer.

5Close the front cover of the printer.

Autres manuels pour LASER PRINTER HL-2140

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Brother Imprimante

Brother

Brother GTX pro Manuel d'instructions

Brother

Brother HL-2070N Instructions d'installation

Brother

Brother HL-3140CW Manuel utilisateur

Brother

Brother HL-3170CDW Manuel

Brother

Brother HL-1060 Series Manuel utilisateur

Brother

Brother 7050N - HL B/W Laser Printer Manuel utilisateur

Brother

Brother HL-5240L Manuel utilisateur

Brother

Brother m-PRINT MW-260 Manuel utilisateur

Brother

Brother HL-6050 Manuel utilisateur

Brother

Brother HL-2280DW Manuel utilisateur

Brother

Brother HL-2220 Manuel utilisateur

Brother

Brother MFC-J4335DW Manuel utilisateur

Brother

Brother HL-3160CDW Manuel utilisateur

Brother

Brother Work Smart MFC-J650dw Instructions de montage

Brother

Brother HL-1070 - B/W Laser Printer Manuel utilisateur

Brother

Brother TD-4420TN Manuel utilisateur

Brother

Brother 2600CN - HL Color Laser Printer Manuel utilisateur

Brother

Brother HL-L5000D Manuel utilisateur

Brother

Brother DCP-J1050DW Manuel technique

Brother

Brother HL-2280DW Guide d'installation

Brother

Brother MFC490CW - Color Inkjet - All-in-One Instructions d'utilisation et de sécurité

Brother

Brother m-PRINT MW-100 Manuel utilisateur

Brother

Brother GT-3 Series Instructions de montage

Brother

Brother HL-L5210DN Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
