Brother HL-L5100DNT Manuel utilisateur

Unpack the machine and check the components

NOTE:

• The available connection interfaces vary depending on the model.

• You must purchase the correct interface cable for the interface you

want to use.

USB cable

We recommend using a USB 2.0 cable (Type A/B) that is no

more than 2 metres long.

Network cable

(For HL‑L5100DN(T) / HL‑L5200DW(T) / HL‑L6200DW /

HL‑L6250DN / HL‑L6300DW(T) / HL‑L6400DW(T))

Use a straight‑through Category 5 (or greater) twisted‑pair cable.

Parallel cable

(For HL‑L5000D)

Use the parallel cable provided with the machine. If the parallel

cable is not provided with the machine in your country or region,

please contact Brother customer service or your local Brother

dealer to purchase the optional parallel cable (PC‑5000).

• The illustrations in this Quick Setup Guide show the HL‑L5200DW

and the HL‑L6400DW.

Remove the packing materials and install the drum unit and toner cartridge assembly

Load paper in the paper tray

Connect the power cord and turn the machine on

Select your language (if needed)

Drum Unit and Toner

Cartridge Assembly

(pre‑installed in models

HL‑L5000D /

HL‑L5100DN(T) /

HL‑L5200DW(T) /

HL‑L6200DW /

HL‑L6300DW(T) /

HL‑L6400DW (For Oceania))

Drum Unit

(pre‑installed in models

HL‑L6250DN /

HL‑L6400DW (Except for Oceania) /

HL‑L6400DWT)

Inbox Toner Cartridge

(models HL‑L6250DN /

HL‑L6400DW (Except for Oceania) /

HL‑L6400DWT)

Installation CD‑ROM AC Power Cord

Quick Setup Guide Product Safety Guide Reference Guide

(only for certain models)

For LCD models

Adjust the paper

guides.

Back Front

HL‑L5000D / HL‑L5100DN(T) / HL‑L5200DW(T) / HL‑L6200DW / HL‑L6300DW(T) / HL‑L6400DW (For Oceania)

Remove the orange part.Discard the silica gel pack.

For Touchscreen models

1. Press ▼ or ▲ to select [General Setup], and

then press OK.

2. Press OK to select [Local Language].

3. Press ▼ or ▲ to select your language, and then

press OK.

4. Press Cancel.

1. On the machine’s Touchscreen, press

[Settings] > [General Setup] >

[Local Language].

2. Press your language.

3. Press .

Remove the orange part.

HL‑L6250DN / HL‑L6400DW (Except for Oceania) / HL‑L6400DWT

Remove the orange part.

Quick Setup Guide

HL‑L5000D / HL‑L5100DN / HL‑L5100DNT / HL‑L5200DW /

HL‑L5200DWT / HL‑L6200DW / HL‑L6250DN / HL‑L6300DW /

HL‑L6300DWT / HL‑L6400DW / HL‑L6400DWT

Read the Product Safety Guide first, then read this Quick

Setup Guide for the correct installation procedure.

Not all models are available in all countries.

The latest manuals are available at the Brother Solutions

Center: solutions.brother.com/manuals.

Watch our Video FAQs for

help with setting up your

Brother machine:

solutions.brother.com/videos.

D004S9001‑00

Version 0

Connect your machine and install software

Macintosh/Windows®computer without CD‑ROM drive

Download the full driver and software package from the

Brother Solutions Center.

(Macintosh) solutions.brother.com/mac

(Windows®) solutions.brother.com/windows

Finish

Print using your mobile device (not available for HL‑L5000D)

Follow the on‑screen instructions

to continue installation.

NOTE:

If connection is unsuccessful, see Cannot set up

your machine? below.

Download “Brother iPrint&Scan” to start using your machine with mobile

devices.

solutions.brother.com/ips

NOTE:

If the Brother screen does not appear automatically, click

(Start) > Computer (My Computer).

(For Windows®8: click the (File Explorer) icon on

the taskbar, and then go to Computer (This PC).)

Double‑click the CD‑ROM icon, and then double‑click

start.exe.

Windows®computer with CD‑ROM drive For HL‑L5000D

For other models

AirPrint is available for OS X and iOS users.

For more information, see the AirPrint Guide on your model’s Manuals

web page.

solutions.brother.com/manuals

Cannot set up your machine?

Wired network

USB/Parallel

Wireless network

Disconnect the cable. Restart your machine,

computer and/or mobile

device.

Repeat .

Go to Alternate wireless

configuration method (Setup Wizard).

1. Restart your wireless access point/router.

Alternate wireless configuration method (Setup Wizard)

a. Press ▲ or ▼ to select the [Network] option, and

then press OK.

b. Press ▲ or ▼ to select the [WLAN] option, and

then press OK.

c. Press ▲ or ▼ to select the [Setup Wizard]

option, and then press OK.

d. When [WLAN Enable?] appears, press ▲ to

select [On].

4. Select the SSID.

To use with your computer uu Step Connect your

machine and install software

3. Connect your machine to your wireless network.

For Touchscreen models

> [Setup Wizard] > [Yes].

The LCD displays [Connected].

For LCD models

SSID: XXXXXXX

Network key: XXXX

To use with your mobile device uu Print using your

mobile device (not available for HL‑L5000D)

2. Find the SSID and Network key.

5. Enter the Network key.

NOTE:

For information on how to enter text,

see the printed Reference Guide.

Choose your Connection Type:

Brother support website http://support.brother.com
