Brother DCP-130C Manuel utilisateur

STEP 1

STEP 2

Setup is Complete!

Quick Setup Guide

Setting Up the Machine

Installing the Driver & Software

DCP-130C

Before you can use the machine, you must set up the hardware and install the software.

Please read this Quick Setup Guide for the correct setup procedure and installation instructions.

Keep this Quick Setup Guide, the User’s Guide and the supplied CD-ROM in a convenient place for

quick and easy reference at all times.

Setting Up the Machine

STEP1

1 Removing the protective

parts

1Remove the protective tape and film covering

the scanner glass.

2Remove the foam bag containing the ink

cartridges from on top of the paper tray.

Improper Setup

DO NOT connect the USB cable. Connecting

the USB cable is done during the software

installation process.

2 Loading paper

1Pull the paper tray completely out of the

machine and lift the output paper tray cover (1).

Setting Up the Machine

STEP1

4Check that the paper is flat in the tray.

5Gently adjust the paper side guides with both

hands and the paper length guide to fit the

paper.

Note

Be careful that you do not push the paper in too

far; it may lift at the back of the tray and cause

paper feed problems.

7Slowly push the paper tray completely into the

machine.

8While holding the paper tray in place, pull out

the paper support ( ) until it clicks, and then

unfold the paper support flap ( ).

Setting Up the Machine

3 Connecting the power cord

1Connect the power cord.

Improper Setup

DO NOT connect the USB cable. Connecting

the USB cable is done during the software

installation process.

Note

The control panel warning LED will stay on until

you have installed the ink cartridges.

4 Choosing your language

Select Language

Press OK Key

Press OK.

2Press aor bto choose your language and

press OK.

English e

Select ab &OK

3If your language is chosen, press a(Yes).

English?

a.Yes b.No

5 Installing the ink cartridges

Warning

If ink gets in your eyes, wash them out with water

at once, and if irritation occurs consult a doctor.

No Cartridge

Setting Up the Machine

STEP1

Preparing System

Approx 4 Minutes

Cleaning

Please Wait

Mbrother

XXXX

Setting Up the Machine

6 Print quality check

Set Paper and

Press Start

2Make sure paper is loaded in the paper tray.

Press Colour Start.

3Check the quality of the four colour blocks on

the sheet.

(black/ yellow/ cyan/ magenta)

Is Quality OK?

aYes bNo

5Do one of the following:

If all lines are clear and visible, press

a(Yes) to finish the quality check.

If you can see missing short lines, press

b(No) and go to step 6.

6The LCD asks you if the print quality is OK for

black and colour. Press a(Yes) or b(No).

Black OK?

aYes bNo

Color OK?

aYes bNo

After pressing a(Yes) or b(No) for both black

and colour, the LCD shows:

Start Cleaning?

aYes bNo

7Press a(Yes), the machine will then start

cleaning the colours.

8After cleaning is finished, press Colour Start.

The machine starts printing the Print Quality

Check Sheet again and goes back to step 3.

OK Poor

Setting Up the Machine

STEP1

7 Setting the LCD contrast

1Press Menu.

2Press aor bto choose 0.Initial Setup,

and then press OK.

3Press aor bto choose 2.LCD Contrast,

and then press OK.

4Press aor bto choose Dark or Light.

5Press OK.

6Press Stop/Exit.

8 Setting the date and time

1Press Menu.

2Press aor bto choose 0.Initial Setup,

and then press OK.

3Press aor bto choose 1.Date/Time, and

then press OK.

4Press arepeatedly to enter the last two digits

of the year, and then press OK.

Year:2007

(e.g. Enter 07for 2007.)

5Press arepeatedly to enter the two digits for

the month, and then press OK.

Month:03

(e.g. Enter 03for March.)

6Press arepeatedly to enter the two digits for

the day, and then press OK.

Day:01

(e.g. Enter 01for the first day of the month.)

7Press arepeatedly to enter the two digits for

the hour in 24-hour format, and then press OK.

Time:15:XX

(e.g. Enter 15for 3:00 P.M.)

8Press arepeatedly to enter the two digits for

the minute, and then press OK.

Time:15:25

(e.g. Enter 15, 25for 3:25 P.M.)

Note

You can increase or decrease the number rapidly

by holding down aor b.

9Press Stop/Exit.

Now go to

Windows®

Macintosh®

Installing the Driver & Software

STEP2

Follow the instructions on this page for your operating system and interface.

For the latest drivers and documentations and to find the best solution for your problem or question, access the Brother Solutions Center

directly from the driver or visit http://solutions.brother.com.

For USB Interface Users

(For Windows®98/98SE/Me/2000 Professional/XP/XP Professional x64 Edition)...... 8

For USB Interface Users

(For Mac OS®X 10.2.4 or greater) ................................................................................. 10

The screens for Windows®in this Quick Setup Guide are based on Windows®XP.

The screens for Mac OS®in this Quick Setup Guide are based on Mac OS®X 10.4.

Installing the Driver & Software

STEP2

Windows®

USB

Windows®

For USB Interface Users

(For Windows

98/98SE/Me/2000 Professional/XP/XP Professional

x64 Edition)

1Disconnect the machine from the power socket

and from your computer, if you already

connected an interface cable.

2Turn on your PC.

(For Windows®2000 Professional/XP/

XP Professional x64 Edition, you must be

logged on with Administrator rights.)

3Put the supplied CD-ROM into your CD-ROM

drive. If the model name screen appears,

choose your machine. If the language screen

appears, choose your language.

4The CD-ROM main menu will appear. Click

Install MFL-Pro Suite.

5After reading and accepting the ScanSoft®

PaperPort®SE License Agreement, click Yes.

6The installation of PaperPort®SE will

automatically start and is followed by the

installation of MFL-Pro Suite.

7When the Brother MFL-Pro Suite Software

License Agreement window appears, click Yes

if you agree to the Software License

Agreement.

8Choose Standard, and then click Next. The

installation continues.

9When this screen appears, go to the next step.

Improper Setup

Make sure that the cable does not restrict the

cover from closing, or an error may occur.

Installing the Driver & Software

Windows®

USB

Windows®

14 Turn on the machine by connecting the power

cord.

The installation of the Brother drivers will

automatically start. The installation screens

appear one after another. Please wait, it will

take a few seconds for all the screens to

appear.

15 When the On-Line Registration screen is

displayed, make your selection and follow the

on-screen instructions.

16 Click Finish to restart your computer.

(After restarting the computer, for Windows®

2000 Professional/XP/XP Professional x64

Edition, you must be logged on with

Administrator rights.)

The MFL-Pro Suite has been installed and

the installation is now complete.
