BROSA Leo Arc Floor Lamp Manuel utilisateur

Leo Arc

Floor Lamp

A S S E M B LY GU I D E

V4

FOR YOUR SAFETY

Lift, don’t drag. This protects

your ﬂoor and product.

Avoid loose screws. Tighten

ﬁxtures every few months.

Assembly requires 2 people.

It's always easier with a

friend.

Contact our support online

or call 1300 027 672.

Check the assembly guide

for required components.

?

Assembling this product on

a soft surface protects its

ﬁnish.

Safety

1. For indoor use only.

2. Follow instructions carefully. Any deviations may be hazardous, or

void your warranty.

3. If the external ﬂexible cable is damaged, it should be replaced

immediately by a certiﬁed electrician.

4. Never use a bulb of a greater wattage than recommended.

5. To replace the bulb, unplug the lamp from its power source and

allow it to cool ﬁrst. Then change the bulb, plug it in and switch it on.

6. This product is not suitable for children under 14 years of age.

7. Periodically check and re-tighten all screws and fasteners.

8. Switch oﬀ and wipe down your lamp with a clean cloth as needed.

9. Firmly secure all pieces. Small parts may present a choking hazard.

Notes:

1. Bulb is not included.

MAX.60W E27

220-240V ~ 50Hz

Components

HardwareHardware

Before you get started, check you have all of the pieces below.

If anything’s missing, we’ll sort it out right away. Simply visit:

www.brosa.com.au/pages/product-return-and-parts-request

A x 1 B x 1

②

③

①Stand x 1

Shade x 1

Base Plate x 1

Base Weight x 1

④

Step 1 Unscrew the nut from the bottom of the stand ①with

the spanner B.

Remove the nut along with the spring washer and ﬂat

washer.

Keep the removed parts for the following assembly.

B

①

B x 1

Step 2 Fit the base plate ③ into the rod on the bottom of

the stand followed by the base weight ④ and make

sure the rod protrudes from the bottom of the base

weight.

Fit the ﬂat washer onto the rod followed by the spring

washer and then the nut. Tighten the nut using the

spanner B.

③

④

B

B x 1

Step 3 Unscrew the threaded rods from the connector

properly using the Allen key A but do not remove

them completely as shown in diagram below.

A x 1

A

Step 4 Insert the upper part of the stand into the connector

and make sure it sits in the connector ﬁrmly.

Tighten the rods with the Allen key A again.

A

A x 1

Step 5 Unscrew the shade ring and remove it from the bulb

holder.

Step 6 Attach the shade ② to the bulb holder.

Attach the shade ring to the bulb holder again and

screw it until the shade is tight and secure.

②
