Bromic Soldering Iron
SUITED TO D.I.Y SOLDERING
APPLICATIONS
ELECTRICAL
25W, 40W & 80W*
CAUTION
Important: Read these instructions carefully before use. Familiarize yourself with the Electric
Solder Iron before connecting it to power. Keep these instructions for future reference.
THE SOLDER IRON MUST BE USED IN ACCORDANCE WITH THE FOLLOWING:
• The soldering tip is hot and can cause serious burns
• Disconnect from power socket after use
• Use safety glasses when soldering
• Soldering irons reach a high temperature during operation and should be handled with
extreme care so as to reduce the risk of fires or burns
• The soldering iron’s heating element may smoke slightly during the first
10-minutes of us as it dries; this is normal
• Never file the specially-plated tip
Operating Instructions
SAFETY WARNINGS
1. The appliance is not a toy, and must be kept out of children’s hands.
2. Before cleaning the appliance or changing the filter, always remove the power lead
plug from the socket. Unscrewing the housing is not permitted.
3. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
2www.bromic.com
MAINTENANCE:
If the power cord is damaged in any way, it must be replaced immediately by a service
agent or suitably qualified person.
TIP REPLACEMENT & DRESSING:
Note: Tip replacement or cleaning should only be done when the iron is at room
temperature. The tip can be changed or replaced by unscrewing the knurled nut barrel
assembly. It is essential that the iron is switched o and allowed to cool before and after
this operation, as damage may result if the iron is left on without the tip inserted. After
removing the tip, blow out any remaining oxide dust that may have formed in the tip
retaining area of the barrel. Care should be taken to avoid getting dust in your eyes.
Replace the tip and tighten the knurled nut barrel assembly using only hand pressure.
Pliers should only be used to tighten the nut if loosening occurs when the iron is hot.
Care should be taken not to over tighten the nut, as this may damage the element.
GENERAL CLEANING:
The iron may be cleaned with a damp cloth using small amounts of liquid detergent.
Never submerse the iron in liquid or allow any liquid to penetrate the case.
KEEP OUT OF REACH OF CHILDREN
POWER SUPPLY:
240V AC
Output: 25W, 40W or 80W*
Cable Length: 1.35m
Applications:
20W and 40W (ceramic heat element): Radio controls, hobbies and crafts, small electrical parts
80W model (*Mica heat element): Household electrical appliances, capacitors and heavy-duty
soldering applications requiring more heating power.
APPROVAL:
SAA-151950-EA approval for Electrical Equipment (25W and 40W)
AS/NZS 60335.2.45:2012; AS/NZS 60335.1:2011 standards
SAA-151950-EA approval for Electrical Equipment (80W)
AS/NZS 60335.2.45:2012; AS/NZS 60335.1:2011 standards
3
www.bromic.com
Iron-clad,
chrome-plated
long life tip
Fast-heat ceramic
element reduces
wait time
Heat resistant
handle with
anti-slip grip
Resting stand
included
Lightweight and
compact design
80W
*Mica heating
element
25W / 40W
Ceramic heating
element
Anti-slip
grip
Anti-slip
grip
Iron-clad,
chrome-plated
long life tip
1.5m
power
cord
SOLDERING IRON
ELECTRICAL 25W, 40W & 80W
HOW TO SOLDER:
1. File o any dirt, rust or paint on the part you wish to solder.
2. Heat the part with the electric soldering iron.
3. Apply rosin-based solder to the part and allow the heated
surface to melt solder, forming a solid connection.
Note: When using non-rosin based solder, be sure to apply a
soldering flux paste to the part before applying solder.
4. Wait for the solder to cool and harden before moving the
soldered part.
4
BROM IC®
PLUMBING & GAS
A member of the Bromic Group
HEAD OFFICE
10 Phiney Place, Ingleburn NSW
2565 Australia
T : 1300 276 642
NZ : 05 08 276 642
F: 1300 735 115
W: www.bromic.com.au
4
BROM IC
®
PLUMBING & GAS
A member of the Bromic Group
HEAD OFFICE
10 Phiney Place, Ingleburn NSW
2565 Australia
T : 1300 276 642
NZ : 05 08 276 642
F: 1300 735 115
W: www.bromic.com.au
V1.0 2017/06/14
