Issued test report consists of 33 Pages Page 1 (33)
Test report no.: EMC_381EN328_2002
ETSI EN 300 328 V1.4.1 (2002-11)
ETSI EN 300 328-2 V1.2.1 (2001-12)
(BCM94306CB)
FCC LISTED, REG. NO.: 101450
&
RECOGNIZED BY INDUSTRY CANADA
IC – 3925
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 2 (33)
Table of Contents
1 General information
1.1 Notes
1.2 Testing laboratory
1.3 Details of applicant
1.4 Application details
1.5 Test item
1.6 Test standards
2 Technical test
2.1 Summary of test results
2.2 Test report
1 General information
1.1 Notes
The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM
Inc. USA does not assume responsibility for any conclusions and generalisations drawn from the test
results with regard to other specimens or samples of the type of the equipment represented by the test
item. The test report may only be reproduced or published in full. Reproduction or publication of
extracts from the report requires the prior written approval of the CETECOM Inc USA.
TEST REPORT PREPARED BY:
EMC Engineer: Harpreet Sidhu
1.2 Testing laboratory
CETECOM Inc.
411 Dixon Landing Road, Milpitas, CA-95035, USA
Phone: +1 408 586 6200 Fax: +1 408 586 6299
E-mail: [email protected]
Internet: www.cetecom.com
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 3 (33)
1.3 Details of applicant
Name : Broadcom corporation
Street : 190 Mathilda Place
City / Zip Code : Sunnyvale, 94086
Country : USA
Contact : Chris McGough
Telephone : 408-922-5810
Tele-fax : 408-543-3399
e-mail : cmcgough@broadcom.com
1.4 Application details
Date of receipt of application : 2002-12-16
Date of receipt test item : 2002-11-21
Date of test : 2002-12-06/13 and 2003-01-02
1.5 Test item
Manufacturer : See Applicant
Model No. : BCM94306CB
Description : 54g Wireless Lan cardbus PC card
Additional information
Frequency : 2412MHz – 2472MHz
Type of modulation : DSSS / OFDM (orthognal frequency division multiplexing)
Number of channels : 13
Antenna : 1dBi antenna
Power supply : From Host
Output power : 16.09dBm (40.64mW) max. EIRP
Extreme temp. Tolerance : 0 to +70oC
1.6 Test standards: ETSI EN 300 328 V1.4.1 (2002-11)
ETSI EN 300 328-2 V1.2.1 (2001-12)
Note: All radiated measurements were made in all three orthogonal planes. The values
reported are the maximum values.
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 4 (33)
2 Technical test
2.1 Summary of test results
No deviations from the technical specification(s) were ascertained in the course of the tests
Performed
Final Verdict:
(only “passed” if all single measurements are “passed”) Passed
Technical responsibility for area of testing:
2003-01-10 EMC & Radio Lothar Schmidt (Manager)
Date Section Name Signature
Responsible for test report and project leader:
2003-01-10 EMC & Radio Harpreet Sidhu (EMC Engineer)
Date Section Name Signature
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 5 (33)
2.2 Test report
TEST REPORT
Test report no. : EMC_381EN328_2002
(BCM94306CB)
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 6 (33)
TEST REPORT REFERENCE
LIST OF MEASUREMENTS PAGE
EFFECTIVE ISOTROPIC RADIATED POWER CLAUSE 5.2.1 7
PEAK POWER DENSITY CLAUSE 5.2.2 9
FREQUENCY RANGE CLAUSE 5.2.3 13
SPURIOUS EMISSIONS CLAUSE 5.2.4 16
RECEIVER SPURIOUS EMISSIONS CLAUSE 5.3.2 24
TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS 28
PHOTOGRAPHS 29
BLOCK DIAGRAMS 32
Note: The clause numbers are referenced to ETSI EN 300 328 V1.4.1 (2002-11)
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 7 (33)
EFFECTIVE ISOTROPIC RADIATED POWER CLAUSE 5.2.1
EIRP is calculated by method described under sub clause 7.2.1.2, using following formulae;
P = A + G + 10 log (1/x);
Where;
A = Average power (measured)
Freq.(MHz) Average Power measured using wide band Power meter (dBm)
2412 13.9
2442 14.4
2472 14.4
G = Antenna gain = 1dBi (Provided by Broadcom)
x = Duty cycle = 0.945 (measured)
x = Txon / Txon + Txoff
Txon 2.08msec
Txon + Txoff 2.2msec
x 0.945
10log(1/x) 0.24
Worst case variance (delts) at extreme temperatures from nominal power measured at 23ºC
(Provided by Broadcom)
Freq.(MHz) Delta in dB @ 0ºC Delta in dB @ +70ºC
2412 +0.01 +0.27
2442 +0.45 +0.29
2472 +0.21 +0.07
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 8 (33)
EFFECTIVE ISOTROPIC RADIATED POWER CLAUSE 5.2.1
TRANSMITTER POWER (dBm)
EIRP
TEST CONDITIONS
Low frequency
2412MHz
Mid frequency
2442MHz
High frequency
2472MHz
Tnom( 23 )0C Vnom (3.3) Pk 15.14 Pk 15.64 Pk 15.64
Tmin( 0 )0C Vnom(3.3) Pk 15.15 Pk 16.09 Pk 15.85
Tmax( +70 )0C Vnom(3.3) Pk 15.41 Pk 15.93 Pk 15.71
Av – Average power during Burst
LIMITS: CLAUSE 5.2.1
Under all test conditions ≤20dBm / -10dBW / 100mW
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 9 (33)
PEAK POWER DENSITY CLAUSE 5.2.2
For DSSS Systems
Peak Power Density (dBm/MHz)
TEST CONDITIONS
Low frequency
2412MHz
Mid frequency
2442MHz
High frequency
2472MHz
Tnom( 23 )0C Vnom (3.3) 8.04 9.35 8.22
Under normal test conditions only
≤-20dBW/MHz (10dBm/MHz)
CETECOM Inc.
Test report no.:EMC_381EN328-2002 Issue date:2003-01-10 Page 10 (33)
PEAK POWER DENSITY CLAUSE 5.2.2
Lowest Channel: 2412MHz
Notes: -51.96 dBm/Hz is added with 60dB to compensate for the dBm/MHz, therefore 8.04dBm/MHz.
