BREIL 3S10 Manuel utilisateur

Instruction book pag. 1 •Mode d’emploi pag. 15

Gebrauchsanleitung pag. 29 •Manuale di funzionamento pag. 43

Manual de instrucciones pag. 57

3S10

CHRONO ALARM

MULTIFUNCTION

Thank you very much for purchasing a BREILWATCH.To ensure its correct use,

please read these instructions carefully.

In order to be able to make full use of the guarantee service (subject to the

guarantee terms), please ensure that the Breil international guarantee card is

supplied with the watch at the time of purchase.

Nous vous remercions de la préférence que vous nous avez accordée en achetant

une montre BREIL. En vue d'une utilisation correcte de celle-ci, lire attentivement

les instructions contenues dans ce livret.

Lors de l'achat, contrôlez que la montre soit accompagnée de la garantie qui devra

être présentée pour obtenir les prestations qui y sont décrites.

Wir danken Ihnen für dasVertrauen, daß Sie uns mit dem Kauf einer BREIL

QUARTZ-Uhr erwiesen haben. Damit Sie Ihre Uhr immer einwandfrei gebrauchen

können, möchten wir Sie bitten, die in dieser Gebrauchsanleitung enthaltenen

Anweisungen gewissenhaft zu lesen.

Beim Kauf sollten Sie kontrollieren, ob Ihnen zusammen mit der Uhr auch die

Garantiekarte ausgehändigt wurde, denn diese Karte müssen Sie vorlegen, um die

darin genannten Leistungen in Anspruch nehmen zu können.

Vi ringraziamo per la preferenza accordataci con l’acquisto di un orologio BREIL.

Per un corretto uso dello stesso,Vi preghiamo leggere attentamente le istruzioni

contenute in questo libretto.

Al momento dell’acquisto controllate che insieme all’orologioVi venga fornita

anche la garanzia, da presentare per ottenere le prestazioni in essa descritte.

Le agradecemos su preferencia por un reloj BREIL. Para poder utilizar

correctamente el reloj, le rogamos leer atentamente las instrucciones contenidas

en este folleto.

Al comprarlo, controle que junto al reloj le sea entregada la garantía que debe ser

presentada para obtener los servicios que en la misma se describen.

When reading this instruction booklet, keep the watch diagram on the

left unfolded and in full view.The symbols (A, B, etc.) on the diagram

are those referred to in the section describing the operating instructions.

Pendant la lecture de ce mode d'emploi, gardez le schéma d'illustration

de la montre ci-contre ouvert et bien en vue. Les symboles (A, B, etc.)

utilisés dans les différents chapitres du mode d'emploi correspondent à

ceux indiqués sur ce schéma.

Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend

gezeigte Übersichtsdarstellung der Uhr ausklappen und im Blick

behalten. Die in den einzelnen Abschnitten der Gebrauchsanleitung

verwendeten Zeichen (A, B, usw.) entsprechen den Kennzeichnungen

in dieser Übersicht.

Durante la lettura di questo manuale di istruzioni, tenere lo schema

illustrativo dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.)

usati nelle sezioni delle istruzioni sul funzionamento corrispondono a

quelli indicati in questo schema.

Mientras lee este manual de instrucciones, mantenga el esquema

ilustrativo del reloj aquí presentado al lado izquierdo, abierto y bien

visible. Los símbolos (A, B, etc.) utilizados en las secciones de

instrucciones sobre el funcionamiento, corresponden a los que se

utilizan en este esquema.

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

6 217

(1)

(2)

(3)

ALM

(ON)

(OFF)

CONTENT GB

AMAIN COMPONENTS

SETTINGTHETIME

SETTINGTHE ALARM

SWITCHINGTO CHRONOGRAPH MODE

CHRONOGRAPH OPERATION

MEASURINGTIMESWITH HANDICAP

USINGTHE CHRONOGRAPH AS A COUNTER

USINGTHE MINUTE COUNTER

TACHYMETER: (some models only)

TELEMETER: (some models only)

RAPID DATE CORRECTION

LOW BATTERY INDICATOR

PRECAUTIONS AND USEFUL INFORMATION

TECHNICAL DATA

MAIN COMPONENTS

Hour hand

Minute hand

Continuous second hand

or CHR second hand

CHR hour hand

CHR minute hand

CHR 1/50th second hand

or minute counter

Tachymeter (some models only)

CHR start/stop button

CHR reset button

1Crown

(0) normal position

(1) alarm time indicator/rapid

date correction

(2) time adjustment/time

reset/energy economiser switch

Correct time indication/

CHR indication button

Alarm button

(ON) alarm on

(OFF) alarm off

Legend: CHR = chronograph

SETTINGTHETIME

Pull out the crown 훿to position (2), the second hand momentarily returns to "0". (if

this does not happen, press button 훽to perform the operation manually)

Tu rn the crown anticlockwise to adjust the hour and minute hands forward to the

correct time, and clockwise to move them backwards.

Tu r ning the crown rapidly also increases the speed of the adjustment.To stop the fast

resetting motion, turn the crown slowly. By turning the crown slowly, the adjustment

is carried out in steps of 20 seconds.

Restart the watch by pushing the crown back to position (0).

•

SETTINGTHE ALARMC

The watch must be in the normal time mode.

The normal time and alarm time are indicated by the same minute and second hands.

•

Switching to alarm time indication

Moving the alarm switch (ALM) (1) to ON and pulling the crown out one stop, the hour

hand and minute hand move rapidly in a clockwise direction and stop at the alarm set

time. A confirmation "bip" is heard.

•

Alarm ON/OFF

Pulling the alarm button out activates the alarm (ON), pressing it back in de-activates it

(OFF). Pushing the button also stops the alarm when sounding.

* When the alarm is set, it goes off twice a day (a.m. and p.m.) for 20 seconds

each time.

Resetting the alarm time

Rotate the crown 훿anticlockwise to advance the hands and clockwise to move them

backwards.Turning the crown rapidly also increases the speed of the adjustment.To

stop the fast resetting motion, turn the crown slowly. By turning the crown slowly, the

adjustment is carried out in steps of one minute.

Switching from alarm time to normal time

When the crown 훿is moved to its normal position, the minute hand moves rapidly

anticlockwise and stops to indicate the minutes of the current hour. A confirmation

"bip" is heard.

SWITCHINGTO CHRONOGRAPH MODED

•

If button is pressed while the watch is in normal time mode, a confirmation "bip" is

heard.The second hand moves rapidly to 0 and the watch is in chronograph mode.

If button is pressed while the watch is in chronograph mode, a confirmation "bip" is

heard.The watch has returned to normal time mode.

CHRONOGRAPHE

1. Normal chronograph use

After having measured three minutes in chronograph mode, the 1/50th second hand

stops at 0, but the chronograph continues to measure the time.The exact time is then

displayed at the moment the chronograph is stopped by pressing button 훽

2. Cumulative measuring

START RESETSTOP

START STOP RESTART STOP

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

12 2

60 10

.00

.40

.80

.60

500

400

300

250

220

200

180

170

160

150

140

100

110 120 130

The watch can be used to time events by attributing handicaps or fixed time

supplements (up to a maximum of 59 seconds and 98 hundredths).

Proceed as follows:

•

MEASURINGTIMESWITH HANDICAPF

Pull the crown out to the second stop (position 2).

Repeatedly press buttons 훽and 훾to advance the second hand and 1/50th second

hand to reach the required supplementary time.

Push the crown back to its original position(0)

When the timing is finished, remember to reset the chronograph hands back to their

original position "0" in order to prevent future incorrect measurements

The 1/50th second hand can be used as a numerical counter (e.g. counting the number

of completed track circuits) while the watch is registering normal time.

•

USINGTHE CHRONOGRAPH

AS A COUNTER

Press button 훾for each count (maximum 50).The numerical total is

progressively displayed.

After using the counter, return the hand to "0" by pressing button twice.
