BREIL 1S13 Manuel utilisateur

(0) (1) (2)

421

(C)

When reading this instruction booklet, keep the watch diagram on the left unfolded

and in full view. The symbols (A, B, etc.) on the diagram are those referred to in the

section describing the operating instructions.

Pendant la lecture de ce mode d’emploi, gardez le schéma d’illustration de la montre

ci-contre ouvert et bien en vue. Les symboles (A, B, etc.) utilisés dans les différents

chapitres du mode d’emploi correspondent à ceux indiqués sur ce schéma.

Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend gezeigte

Übersichtsdarstellung der Uhr ausklappen und im Blick behalten. Die in den

einzelnen Abschnitten der Gebrauchsanleitung verwendeten Zeichen (A, B, usw.)

entsprechen den Kennzeichnungen in dieser Übersicht.

Durante la lettura di questo manuale di istruzioni, tenere lo schema illustrativo

dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.) usati nelle sezioni delle

istruzioni sul funzionamento corrispondono a quelli indicati in questo schema.

Mientras lee este manual de instrucciones, mantenga el esquema ilustrativo del

reloj aquí presentado al lado izquierdo, abierto y bien visible. Los símbolos (A, B,

etc.) utilizados en las secciones de instrucciones sobre el funcionamiento,

corresponden a los que se utilizan en este esquema.

Durante a leitura deste manual de instruções, mantenha o esquema ilustrativo do

relógio aberto e à vista do lado esquerdo. Os símbolos (A, B, etc.) usados nas secções

das instruções de funcionamento, correspondem aos indicados neste esquema.

CONTENTS

MAIN COMPONENTS

SETTING THE TIME

SETTING THE DATE

PRECAUTIONS AND USEFUL INFORMATION

GUARANTEE TERMS AND CONDITIONS

ENGLISH

If your watch has a locking screw-type crown, first unscrew the crown.

MAIN COMPONENTS

Hour hand

Minute hand

Second hand

(some models only)

SETTING THE

Stop the second hand at “0” by pulling out the crown (C) to position (1)

(position (2) if the model has a date display).

Tu rn the crown to adjust the hands to the correct time.

Restart the watch by pushing the crown (C) back to position (0).

SETTING THE DATE (some models only)

Pull out the crown (C) to position (1)

Rotate the crown until the required date appears.

Put the crown (C) back to position (0)

Date

(some models only)

Crown

(C)

The words “WATER RESISTANT” may sometimes be abbreviated to “WATER RESIST”.

WATER RESISTANT

50M (5bar)

WATER RESISTANT

—

A—

—

Indication

Dial Case

Spray, sweat,

light rain,

washing, etc.

Swimming,

etc.

Use in

YES

PRECAUTIONS AND USEFUL INFORMATION

In order to prevent water coming into contact with the internal mechanism, never pull

the crown out when the watch is wet.

If any watches designed for sportswear or use in water come into contact with salt

water or heavy sweating, they should be rinsed in fresh water and dried thoroughly.

Contact with water may cause a deterioration in the quality of some leather straps.

–

CWATER RESISTANT YES YES

DWATER RESISTANT

100M (10bar) WATER RESISTANT YES YES

WATER RESISTANT

200M (20bar) or more

WATER RESISTANT YES YES

Degree of water

resistance

*Always keep the crown in its normal position. *Fully tighten crown screw

Skin-diving Scuba diving

Water

Water-resistance

characteristics

Not water resistant. Must be kept away from water and moisture

Average water resistance. Can withstand spray, sweat,

light rain, washing, etc. during daily use

Suitable for skin-diving

As the internal parts of the watch can retain moisture, when the outside

temperature is lower than the inside, the watch glass may mist-up. This

phenomenon is purely temporary and should not create any problems. However,

if it persists for any length of time, the watch should be checked by the shop

where it was purchased or by the nearest Authorised Service Centre.

–

NO NO Can be worn while swimming but not diving

YES NO

Suitable for scuba diving

YES YES

Impact

This watch can withstand normal everyday impacts and shocks and those normally

imparted by non-contact sports such as golf and baseball. Serious damage, however,

may result if the watch is dropped or subjected to severe shock.

Magnetic fields

This watch is antimagnetic up to 60 gauss, and is therefore not affected by magnetic

fields produced by normal domestic appliances. If used near strong magnetic fields, its

operation may be temporarily affected.

Chemicals and gases

Avoid wearing the watch in the presence of strong gases or chemical substances.

Parts of the watch may discolour, dissolve or even break if brought into contact with

benzol or petroleum based products such as solvents, thinners, detergents,

adhesives etc.

Pay special attention to avoiding contact with chemicals.

The watch case and strap may discolour if they come into contact with mercury from a

broken thermometer or other equipment.

Keeping the watch clean

Use an absorbent soft cloth to clean off any dirt or damp from the watch glass.

Wearing the watch when the strap or back of the case is dirty can cause skin irritation.

Keeping the watch clean also keeps shirt cuffs clean.

Cleaning the watch strap.

•

Periodic inspection

In order to guarantee long trouble-free operation, it is advisable to have the watch

checked by an authorised assistance centre once every 12 months or two years.

If your watch is fitted with a quartz movement

Temperature

Do not leave the watch exposed to direct sunlight or temperature extremes for long

periods of time.

Long exposure, in fact, may adversely affect the operation of the watch and actually

shorten battery life, causing it to gain or lose time and affect its other functions.

Static electricity

The integrated circuits present inside the watch are sensitive to static electricity. If the

watch is exposed to intense electrical fields, the time display may temporarily lose

some of its accuracy.

Keep batteries out of the reach of children

In order to improve the product, the technical specifications may be modified without

prior notice.

Metal bands: use a toothbrush and soapy warm water to wash the dirt off.

Plastic or rubber straps: wash with water. Do not use solvents.

Leather straps: gently rub the face of the strap using a soft dry cloth. Clean the

opposite side with a cloth and alcohol.

INDEX

PIECES PRINCIPALES

COMMENT REGLER L’HEURE

COMMENT REGLER LA DATE

PRECAUTIONS D’UTILISATION ET INFORMATIONS UTILES

CONDITIONS DE VALIDITÉ DE LA GARANTIE

FRANÇAIS

Table des matières
