Braun Syncro 7510 Manuel utilisateur
Type 5493
Type 5494
+
-
+
7520
7516
7510
KURTZ DESIGN 11.10.2000
Syncro
MN
7515
7505
5494460_S 1 Seite 1 Dienstag, 23. Januar 2001 3:46 15
Internet:
www.braun.com
5-494-460/00/II-01
GB/KOR
Printed in Germany
5494460_S 2 Seite 1 Donnerstag, 25. Januar 2001 12:38 12
7
KURTZ DESIGN 11 .10.00
Syncro 7520 Syncro 7516
Syncro 7510
Syncro 7505
7505
7
7510
Syncro 7515
+
–
7
8
7515
4
2
1
3
5
6
7
+–
8
9
10
4
No. 7000
7520
Syncro
Syncro
Syncro
Syncro
7
7516
5494460_S 3 Seite 1 Dienstag, 23. Januar 2001 3:47 15
4
Our products are designed to meet the highest standards
of quality, functionality and design. We hope you enjoy
your new Braun shaver.
Important
Only use the power supply cord set provided.
A damaged cord must be replaced immediately.
Description
1 Foil protection cap 7 Charging light
2 Shaver foil (green)
3 Cutter block 8 Low-charge light
4 Foil release button (red) 7520, 7515 only
5 Long hair trimmer 9 Pilot light
6 Switch 10 Shaver socket
Technical specifications:
•
Wattage via cord set: 7 W
•
Power supply via cord set: 100-240 V
2
/50 or 60 Hz
(automatic adaptation)
•
Shaver input voltage: 12-24 V
Charging the shaver
•
First charging: Using the power supply cord set,
connect the shaver to the mains with the switch
on position «0» and charge it for at least 4 hours
(plug might get warm).
•
Once the shaver is completely charged, shave without
the cord until fully discharged. Then recharge to full
capacity again (subsequent charges will take about
1 hour).
•
A full charge will give up to 50 minutes of cordless
shaving time depending on your beard growth.
However, the maximum battery capacity will only be
reached after several charging/discharging cycles.
•
Best environmental temperature range for charging is
15 °C to 35°C.
Indicator lights
•
The pilot light shows that the shaver is connected to
the mains.
+35°C
+15°C
210
7570
English
5494460_S 4-14 Seite 4 Donnerstag, 25. Januar 2001 12:22 12
5
•
The green charging light shows that the shaver is being
charged. When the rechargeable battery is fully charged,
the charging light flashes or goes off.
If later on, the charging light comes on again, this indi-
cates that the shaver is being recharged to maintain its
full capacity.
•
Models 7520 and 7515 only:
The red low-charge light flashes when the battery
capacity has dropped below 20%, provided the shaver
is switched on. The remaining capacity will then be
sufficient for 2 to 3 shaves.
Shaving
Switch positions
0 = Off (switch is locked)
Press and push up the switch to operate the shaver:
1 = Shaving with the pivoting head
The pivoting cutting system automatically adjusts
to every contour of your face
2 = Shaving with the pivoting head locked at an angle
(to permit shaving in difficult areas, e.g. under the
nose)
3 = The long hair trimmer is activated
(for trimming sideburns, moustache and beard)
Shaving with the cord
If the rechargeable battery is discharged, you may also
shave with the shaver connected to the mains via the
power supply cord set.
(If the shaver does not run immediately, charge it with
the switch on position «0»for approx. 1 minute.)
Tips for the perfect shave
•
We recommend that you shave before washing,
as the skin tends to be slightly swollen after
washing.
•
Hold the shaver at right angles (90°) to the skin.
•
Stretch your skin and shave against the direction
of beard growth.
•
Replace the shaver foil and cutter block every
1
1
/
2
years, or when the parts are worn, to ensure
optimum shaving performance.
+
21
21
a
u
t
o
m
a
t
i
c
l
o
c
k
2
1
3
5494460_S 4-14 Seite 5 Donnerstag, 25. Januar 2001 12:22 12
6
Keeping your shaver in top shape
Automated cleaning
The Braun Clean&Charge (only with models 7520, 7516
and 7510) automatically takes care of all cleaning and
lubrication needs of your shaver. Please refer to separate
use instructions.
Manual cleaning
For easy cleaning after each shave, switch the shaver
off. Press the release buttons to lift the shaver foil
(do not remove the foil completely).
Switch on the shaver
for approx. 5-10 seconds so that the shaved stubbles can
fall out.
For a thorough cleaning (weekly), remove the shaving
foil and tap it out on a flat surface. Using the brush,
clean the cutter block and the inner area of the pivoting
head. About every four weeks, clean the cutter block
with Braun cleaning agents.
If your skin is very dry and you notice a reduced operation
time of the shaver, apply a drop of light machine oil onto
the shaver foil.
Replacing the shaving parts
The shaver foil and cutter block are precision parts that,
in time, are subject to wear. Replace your foil and cutter
block every 18 months and get a 25% better shave.*
(Shaver foil and cutter block: part no. 7000)
(* Overall evaluation from Braun users comparing their
shave with new parts and those used for 18 months.)
Preserving the cell unit
•
In order to maintain the optimum capacity of the
rechargeable battery, the shaver has to be fully dis-
charged (by shaving) every 6 months approximately.
Then recharge the shaver to full capacity again.
This reconditions the rechargeable battery.
•
Do not expose the shaver to temperatures of more than
50 °C for longer periods of time.
oil
10
10
7000
7000
Syncro
5494460_S 4-14 Seite 6 Donnerstag, 25. Januar 2001 12:22 12
7
Accessories
available at your dealer or Braun Service Centres:
•
Braun Clean&Charge
•
Shaver foil and cutter block
(part no. 7000)
•
Wall holder
Environmental notice
This appliance is provided with nickel-hydride recharge-
able batteries. To protect the environment, do not dis-
pose of the appliance in the household waste at the end
of its useful life. Open the housing as shown, remove
and dispose of the batteries at your retail store or at
appropriate collection sites according to national or
local regulations.
Subject to change without notice.
This product conforms to the EMC-Require-
ments as laid down by the Council Directive
89/336/EEC and to the Low Voltage Regulation
(73/23 EEC).
7XXX
12
4
5 6
3
5494460_S 4-14 Seite 7 Donnerstag, 25. Januar 2001 12:22 12
8
Guarantee
Your Braun product comes complete with a 1 year
guarantee that commences on the date of purchase.
For you to obtain service within the guarantee period you
must retain your sales receipt as proof of purchase.
Please ensure you store your sales receipt in a safe
place.
Within the guarantee period we will repair, free of charge,
any defects in the appliance resulting from faults in
materials or workmanship, but may, at our discretion,
choose to exchange specific parts or replace the complete
appliance.
This guarantee does not cover: damage arising from
improper use (kinks in the shaver foil, breakage), normal
wear and defects that have a negligible effect on the value
or operation of the appliance.
The guarantee becomes void if repairs are undertaken by
unauthorised persons and if original Braun parts are not
used.
The guarantee is valid for 12 months from the original date
of purchase as per your sales receipt.
The guarantee on any repairs or exchanges made under
guarantee expires at the end of this period.
For UK only:
This guarantee in no way affects your rights under statutory
law.
5494460_S 4-14 Seite 8 Donnerstag, 25. Januar 2001 12:22 12
9
+35°C
+15°C
210
7570
5494460_S 4-14 Seite 9 Donnerstag, 25. Januar 2001 12:22 12
10
+
21
21
a
u
t
o
m
a
t
i
c
l
o
c
k
2
1
3
5494460_S 4-14 Seite 10 Donnerstag, 25. Januar 2001 12:22 12
