Bounty Hunter Fast Tracker Manuel utilisateur

OWNER’S MANUAL

The Basics

of Metal Detecting

Your Fast Tracker Metal Detector is a MOTION metal detector; movement over

an object is required in order for the machine to detect an object and emit a tone.

The Fast Tracker has eliminated the two most difficult aspects of detecting -

ground balancing and target tuning. Both of these functions are automatic. With

only two operating knobs, you are on the Fast Track to finding buried treasure!

CAUTION:

FOR OUTDOOR USE ONLY:

• If demonstrating indoors, beware of interference from electromagnetic

fields.

• If interference occurs, the detector will chatter or beep erratically.

• To avoid interference, turn the sensitivity down, turn off lights and

appliances, or use outdoors.

DO NOT TEST ON THE FLOOR

Most floors contain metal, which will interfere with the target’s signal.

USE 9 volt ALKALINE batteries ONLY.

ACCESSORIES

FOR COMPLETE DETAILS VISIT WWW.DETECTING.COM • 1-800-413-4131

Carry Bag

Rugged double-stitched construction - CBAG-W

Pouch & Digger Combo

Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W

Bounty Hunter Stereo Headphones

Use with Bounty Hunter metal detectors. Lightweight and adjustable with

true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor,

4’ cable.

HEAD-W

Pin Pointer

Pinpoints the exact location of buried metal objects. Audio signal indicator

and vibrator. Runs on 1 – 9-Volt Battery. PIN POINTER-W

Sand Scoop

Large scoop with filtering holes. Made of strong plastic. SAND SCOOPBH

Coil Covers

Protect your coil from abrasion and damage.

10” Coil Cover – 10COVER

8” Coil Cover – 8COVER-N

4” Coil Cover – 4COVER

Replacement/Accessory Search Coils

10” Magnum Coil – 10COIL

8” Replacement Standard Coil – 8COIL-N

4” Gold Nugget Coil – 4COIL

9” Heavy-Duty Digging Tool

Metal blade with comfortable plastic handle and depth gauge TROWEL-2

Digging Tool

Light and practical wide blade digging tool. TROWEL-W

Bounty Hunter T-Shirt

100% cotton with Bounty Hunter®Logo. Sizes – LG, XL & XXL

Bounty Hunter Baseball Cap

One size fits all, with Bounty Hunter®logo.

Gold

Prospecting Kits

MFAST Rev.3 092612

TREASURE HUNTER’S CODE OF ETHICS:

• Always check Federal, State, County and local laws before searching.

• Respect private property and do not enter private property without the owner’s permission.

• Take care to refill all holes to leave no damage.

• Remove and dispose of any and all trash and litter found.

• Appreciate and protect our inheritance of natural resources, wildlife and private property.

• Act as an ambassador for the hobby; use thoughtfulness, consideration and courtesy at all

times.

• Never destroy historical or archaeological treasures.

• All treasure hunters may be judged by the example you set; always conduct yourself with

courtesy and consideration of others

First Texas Products, LLC

1465-H Henry Brennan

El Paso, TX 79936

(915) 633-8354

FIRST TEXAS PRODUCTS, LLC

5-YEAR LIMITED WARRANTY

Published by First Texas Products, L.L.C.

Bounty Hunter®is a registered trademark of First Texas Products, L.L.C.

www.detecting.com

Bounty Hunter Metal Detectors are warranted against

defects in workmanship or materials under normal use for

five years from date of purchase to the original user. Liability

in all events is limited to the purchase price paid. Liability

under this Warranty is limited to replacing or repairing, at

our option, any Bounty Hunter Detector returned, shipping

cost prepaid, to First Texas Products, LLC. Damage due to

neglect, accidental damage or misuse of this product is not

covered by this warranty.

Proof of purchase is required to make a claim under this warranty.

NOTE TO CUSTOMERS OUTSIDE THE U.S.A.

This warranty may vary in other countries, check with your distributor for details.

Factory warranty follows the channel of distribution.

Warranty does not cover shipping costs.

According to FCC part 15.21 Changes or Modifications made to this device not expressly approved by the party

responsible for compliance could void the users authority to operate this equipment.

215

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Fast Demonstration . . . . . . . . . . . . . . . . . . . . . .6

Using headphones . . . . . . . . . . . . . . . . . . . . . . .7

Basic Operation . . . . . . . . . . . . . . . . . . . . . . .7-8

In the field techniques . . . . . . . . . . . . . . . . .9-10

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .10

Care and manintenance . . . . . . . . . . . . . . . . . .11

Metal detecting applications . . . . . . . . . . . . . .12

Treasure Hunter’s Code of Ethics . . . . . . . . . . .15

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Accessories . . . . . . . . . . . . . . . . . . . . .Back Cover

TABLE OF CONTENTS

FAST TRACKER FEATURES

NOTES

Padded

Armrest

S-Rod

Handle System

Discriminate Control Detector

Stand

Comfort Hand-grip

Headphone Jack

Sensitivity Control

Interchangeable

Coil System

7" Waterproof Coil

314

EASY ASSEMBLY

Searchcoil

Cable

Upper

Stem

Control

Housing

Plug

Lower

Stem

Assembling your Fast Tracker Metal

Detector is easy and requires no

tools. Just follow these steps:

●

1Using the supplied bolt and

knurled knob, attach the

search coil to the lower stem.

●

Press the button on the upper end

of the lower stem and slide the

lower stem into the upper stem.

Adjust the stem to a length

that lets you maintain a com-

fortable upright posture, with

your arm relaxed at your

side. Maintain the search coil

about 1 inch above the

ground as you sweep.

●

3Wind the search coil cable

around the stem. Leave

enough slack in the cable to let

you adjust the coil when you

are hunting on uneven

ground. Then tighten the knob

at the end of the search coil.

Note:

To adjust the coil,

simply loosen the knob.

●

4Insert the coil’s plug into the

matching connector on the

control housing. Be sure the

holes and pins line up correctly.

Caution:

• Do not force the plug in.

Excess force will cause damage.

• To disconnect the cable, pull

out the plug. Do not pull on

the cable.

Button side

Lower

Stem

Upper

Stem

413

NOTES

METAL DETECTING APPLICATIONS

COIN SHOOTING

Searching for coins is the most popular metal detecting application. We receive testimonials

every day from BOUNTY HUNTER users finding very old coins — many times from the

1800’s or earlier — in old school yards, parks, and even their own back yards.

To adjust your detector for coin shooting, you want to click on the ALL METAL control

knob to about the 1:00 position. Find an older pull tab, and adjust the discrimination

control to the point where you hear a broken, in-between, sound. At this setting,

you have eliminated all iron objects, and will be aware of the presence of pull tabs,

as they usually induce this broken tone.

Long-buried coins can often be detected deeper than newer coins. As an old coin

oxidizes, it creates a magnetic halo in the soil, effectively increasing the size of its

magnetic signature, and its detectability.

JEWELRY HUNTING

Keep the discrimination control at the 11:00 setting for jewelry hunting. Many gold

rings will register similar to pull-tabs. Beware that you will dig up many pull tabs in

the search for gold rings. Both pull-tabs and gold rings can induce a low tone. Keep

the discrimination control at the lower, 11:00, setting so that you do not eliminate

small gold rings from detection.

Some gold rings can induce a double beep whereas most pull-tabs will not. To

achieve the double beep, move the coil very slowly over the buried target at differing

angles. You can sometimes achieve a double beep as the search coil passes over

two sides of the ring.

Necklaces can be very difficult to detect. Silver rings will induce a high tone. Highly

oxidized trash items can also induce high tones.

RELIC HUNTING

A relic is a historical object, sometimes of great value. Relics are often made of iron or

bronze. Therefore, keep your discrimination control turned off, in the 100%

counterclockwise position. In this ALL METAL mode, you will detect all types of metal,

including trash items. You must limit you relic-hunting activity to areas where you have

a reasonable suspicion of finding an ancient object. Visit the local library to learn of

historical events which occurred in the area. Remember to always obtain permission

before searching property which is not your own.

CACHE HUNTING

A cache, pronounced “cash”, is a hidden store of valuables. Years ago, many people

stashed valuables in cans, bags, and metal chests. They often buried them or hid them

in the walls or floors of their homes. Search old homes or camp sites to locate caches.

Caches are very rare and hard to find. Cache hunting requires the ALL METAL mode;

so keep the discrimination control turned off.

HOUSEHOLD APPLICATIONS

Lost keys or machine parts, underground pipes, and property markers can all be located

using the ALL METAL mode. Keep the discrimination control in the off position.

BATTERIES

Use ALKALINE batteries only.

Follow these steps to install the batteries.

●

1Carefully remove the battery compartment door by pressing

the release clip on the right side of the door.

●

2Snap one battery on to each of the terminals and place the

batteries inside the compartment.

The battery compartment is a tight fit. Insert batteries

with the terminals facing inward. See illustration.

●

Replace the compartment door by first inserting the hinge on

the side opposite of the release clip.

●

Then, press down firmly on the clip side until the battery door

snaps into place.

Batteries

terminals

facing inwards

Release

Clip

CARE AND MAINTENANCE

Your Fast Tracker Metal Detector is an example of superior design and

craftsmanship. The following suggestions will help you care for your

metal detector so that you can enjoy it for years.

Handle the metal detector gently

and carefully. Dropping it can

damage electronic components.

Use and store the metal detector

only in normal temperature

environments. Extreme

temperatures can shorten the

life of electronic devices and

distort or melt plastic parts.

Wipe the metal detector with a

damp cloth occasionally to keep

it looking new. Do not use harsh

chemicals, cleaning solvents, or

strong detergents to clean the

metal detector.

The coil is waterproof and may

be submerged into either fresh or

salt water. Be careful to prevent

water from entering the control

housing. After using the coil in

salt water, rinse it with fresh

water to prevent corrosion of the

metal parts.

Here is a quick way to demonstrate the basic features of your FAST TRACKER.

Supplies Needed

a. A small nail d. A nickel

b. A small piece of foil e. A dime

c. A quarter f. A penny

Position your Fast Tracker

Keep the detector away from metal objects.

Have a friend hold the detector while you pass the objects over the search coil.

Or, hang the detector over the edge of a chair or table, away from walls,

floors and other metal objects.

Remove your jewelry and watch (they also contain metal)

Demonstrate It!

Click the power on, and turn the Sensitivity Knob to

the 2:00 or 3:00 position.

b. Click the right knob (Discriminate) off. 100%

to the left.

c. Sweep all of the objects back and forth over the

search coil.

NOTICE the SINGLE TONE

d. Sweep the nail back and forth over the search coil.

While sweeping, click the Discriminate Control

(right knob) on.

Turn the Discriminate Control until the nail is no

longer detected.

You have “discriminated out” the nail.

Now pass the nickel with the Discriminate control in

the 1:00 or 2:00 position.

NOTICE the LOW TONE.

f. Pass the Quarter.

NOTICE the HIGH TONE.

g. Pass all of the objects, while moving the

Discriminate Control to

differing positions.

NOTICE the DIFFERENT TONES, or

NO TONE at all.

FAST DEMONSTRATION

TROUBLESHOOTING

The following troubleshooting steps may assist you in case you’re having prob-

lems with your Detector.

YOUR DETECTOR IS EMITTING ERRATIC SIGNALS WHEN YOU’RE IN THE FIELD.

Your SENSITIVITY may be set too high. Try reducing the SENSITIVITY slightly until

the false signals stop.

Remember to swing your coil slowly. Some inconsistent signals will occur on highly

rusted metals. If the signal does not repeat after successive passes of the coil over the

same area, then the target is usually not worthwhile.

Natural and man-made electromagnetic fields can cause interference.

YOUR DETECTOR IS NOT STABLE AND HAS A PULSING, DISTORTED TONE

INSTEAD OF A CLEAR TONE.

This can occur if you’re operating near another detector or near power lines that can

interfere with the detector’s operating frequency.

YOUR DETECTOR IS EMITTING A CONSTANT LOUD TONE OR

CONSTANT REPEATING TONES

This usually occurs when the batteries are low. Try replacing your batteries with

two new alkaline batteries.

KEEP 2 DETECTORS AT LEAST 20ft APART

If 2 detectors are in close proximity, interference between the two may cause your

detector to emit erratic signals.

PINPOINTING

Accurate pinpointing takes practice and is best accomplished by “X-ing” the sus-

pected target area.

●

1Once a buried target is identified by a good

tone response, continue sweeping the coil over

the target in a narrowing side-to-side pattern.

●

2Take visual note of the place on the ground

where the “beep” occurs as you move the coil

slowly from side to side.

●

3Stop the coil directly over this spot on the

ground.

●

4Now move the coil straight forward and

straight back towards you a couple of times.

●

5Again make visual note of the spot on the ground at which the “beep” occurs.

●

6If needed, “X” the target at different angles to “zero in” on the exact spot on

the ground at which the “beep” occurs.

IN THE FIELD TECHNIQUES OPERATION

The Fast Tracker is a MOTION metal detector; the search coil must be in

motion over the targeted object in order for the machine to detect the

object and emit a tone. Motion is required in order for the detector to

automatically GROUND BALANCE. All soil and sand is different,

containing varying amounts of naturally occurring minerals. As you

sweep the search coil over the ground, your metal detector is constantly

READING and AVERAGING the ground’s mineralization, in order to

differentiate between the naturally occurring ground minerals and a metal

target.

Adjust the SENSITIVITY

After powering the unit on, turn the left

knob, SENSITIVITY, 100% clockwise. If

the detector chatters or emits erratic

sounds, reduce the sensitivity by turning

the knob to the left. The detector will

work well at the 2:00 or 3:00 position.

This adjustment is necessary due to

electromagnetic interference.

Household appliances, lighting fixtures,

outdoor power lines (overhead and buried) all emit electromagnetic fields.

Electromagnetic energy also occurs naturally in the environment. Your

metal detector creates its own magnetic field; so you need to adjust your

SENSITIVITY to compensate for any interference.

USING HEADPHONES

Using headphones (not included) improves battery life, and prevents the

sounds from annoying bystanders.

It also allows you to hear subtle changes in the sound more clearly,

particularly if searching in a noisy location. For safety reasons, do not use

headphones near traffic or where other dangers are present.

This device is to be used with interconnecting cables/headphone cables

shorter than three meters.

10 7

IN THE FIELD TECHNIQUES

SWEEP TECHNIQUE

Sweep the search coil in a slow, consistent, side-to-side motion. The detector’s

circuitry is constantly calculating the ground’s mineralization. A steady,

consistent coil speed is required for the detector to make an accurate calculation.

Keep the search coil about one inch above the ground. Keep the coil even with

the ground. Do not raise the coil at the ends of your sweep.

TONE RESPONSE

Only dig up targets that induce repeatable tones. Each time you pass the search

coil over a possible target, you should hear the same tone. If the tone does not

repeat on each pass, varies in tone, or varies in location, then the target is

usually not of value.

Inconsistent tones are evidence of high oxidation (rusted metal) or irregularly

shaped trash items.

Note, however, that multiple tones may be evidence of multiple targets.

If you cannot pinpoint the location of a very strong signal, lift the coil higher off

of the ground until a weaker, but more precise signal is heard.

For very weak signals, try moving the coil in short, rapid sweeps, closer to the

ground.

CORRECT WRONG

WHAT

READS

LIKE THIS

…MAY

ACTUALLY

BE THIS

OPERATION

Select the MODE OF OPERATION

The Fast Tracker has two operating modes, ALL METAL and DISCRIMINATION.

ALL-METAL

To enter the ALL METAL mode, click the right knob (Discriminate) off, 100%

counterclockwise. In the full counterclockwise position, you will detect all

types of metal.

In the ALL METAL mode, your detector will emit only one tone, regardless of the

type of metal detected. It will detect low-grade metals like iron (a nail) or

aluminum (foil). It will also detect more valuable items like silver, copper, and gold.

APPLICATIONS:

Use the ALL METAL mode for household applications, such as finding

property markers or lost objects like keys or machine parts.

ALL METAL is also useful for gold prospecting. Be aware that you need to

search in an area where gold has been found in the past.

ALL METAL is also preferred for relic hunting. Many relics are made of iron.

You must be in the ALL METAL mode to detect iron.

Maximum depth detection is achieved in the ALL METAL mode.

DISCRIMINATION

Click the Discriminate Control (right Knob) on to enter the DISCRIMINATION mode.

Discrimination is the elimination of certain metals from detection, and the

classification of targeted metals using audio feedback. See chart below.

As the chart illustrates, iron and steel will be discriminated out, inducing no

audio response. Nickels and gold items will induce a low tone. Silver,

copper, and brass will induce a high tone. Many pull-tabs (but not all) will

induce a “broken” tone. To achieve the broken tone, set the discriminate

control at the approximate center position, about 12:00.

Depth of detection is slightly reduced in the DISCRIMINATION mode.

TONE MODE AUDIO RESPONSES

RESPONSE

Iron & Steel

LOW

TONE

Gold & Nickel

BROKEN

TONE

Old & New Pull Tabs

HIGH

TONE

Copper, Silver & Brass

Autres manuels pour Fast Tracker

Table des matières

Autres manuels Bounty Hunter Détecteur de métaux

Bounty Hunter

Bounty Hunter Pilot Manuel utilisateur

Bounty Hunter

Bounty Hunter Sharp Shooter II Manuel utilisateur

Bounty Hunter

Bounty Hunter THE COMMANDO Manuel utilisateur

Bounty Hunter

Bounty Hunter Platinum Manuel utilisateur

Bounty Hunter

Bounty Hunter PIONEER 202 Manuel utilisateur

Bounty Hunter

Bounty Hunter Surveyor Manuel utilisateur

Bounty Hunter

Bounty Hunter Tracker IV Manuel utilisateur

Bounty Hunter

Bounty Hunter GOLD DIGGER Series Manuel utilisateur

Bounty Hunter

Bounty Hunter Prospector Manuel utilisateur

Bounty Hunter

Bounty Hunter PINPOINTER Manuel utilisateur

Bounty Hunter

Bounty Hunter Junior Manuel utilisateur

Bounty Hunter

Bounty Hunter Land Ranger PRO Manuel utilisateur

Bounty Hunter

Bounty Hunter Elite 2200 Manuel utilisateur

Bounty Hunter

Bounty Hunter Ultra Mag Sharp Shooter Manuel utilisateur

Bounty Hunter

Bounty Hunter PIONEER EX Manuel utilisateur

Bounty Hunter

Bounty Hunter Land Star Manuel utilisateur

Bounty Hunter

Bounty Hunter Gold Manuel utilisateur

Bounty Hunter

Bounty Hunter Land Ranger PRO Manuel utilisateur

Bounty Hunter

Bounty Hunter Snooper 2 Manuel utilisateur

Bounty Hunter

Bounty Hunter pioneer 101 Manuel utilisateur

Bounty Hunter

Bounty Hunter Legacy 1000 Manuel utilisateur

Bounty Hunter

Bounty Hunter Fortune Hunter Manuel utilisateur

Bounty Hunter

Bounty Hunter Platinum Manuel utilisateur

Bounty Hunter

Bounty Hunter Sharp Shooter II Manuel utilisateur

Manuels Détecteur de métaux populaires d'autres marques

Garrett

Garrett MAGNASCANNER CS 5000 Manuel utilisateur

Valex

Valex 1800200 Manuel utilisateur

Gauss

Gauss MIL MD Manuel utilisateur

Velleman

Velleman CS130 Manuel utilisateur

Sears

Sears 321.596370 Manuel utilisateur

Eriez

Eriez X8 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-22 Manuel utilisateur

Zircon

Zircon MetalliScanner m60c Manuel utilisateur

nalanda

nalanda MD027 Manuel utilisateur

REV Ritter

REV Ritter CB-7005 Manuel utilisateur

Minelab

Minelab F1A4 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs F70 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-12 Manuel utilisateur

GOLDEN MASK

GOLDEN MASK 5 Manuel utilisateur

Grizzly

Grizzly YM 203 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs 1280-X Aquanaut Manuel utilisateur

Treasure Cove

Treasure Cove Vibra-Probe 560 Manuel utilisateur

Accurate Locators

Accurate Locators XL16 IMAGER Manuel utilisateur
