OWNER’S MANUAL

The

Quick

Silver is an

easy to use detector. The most difficult

aspects of metal detecting have been

automated.

However if you are new to the hobby, we strongly

recommend that you:

1) Adjust the Sensitivity to a low setting in the

event of false signals. The detector powers on a

3/4 sensitivity; increase to full sensitivity after you have

become familiar with the detector.

2) Do not use indoors. This detector is for outdoor use only. Many

household appliances emit electromagnetic energy, which can

interfere with the detector. If conducting an indoor demonstration,

turn the sensitivity down and keep the search coil away from

appliances such as computers, televisions and microwave ovens.

If your detector beeps erratically, turn off appliances and lights.

Also keep the search coil away from objects containing metal, such

as floors and walls.

3) Read this manual. Most importantly, review the Quick-Start Demo

(p.6) and Basic Operation (p. 8-12).

4) Use 9-volt ALKALINE batteries only.

Do not use Heavy Duty or ordinary Zinc-carbon Batteries.

ACCESSORIES

FOR COMPLETE DETAILS VISIT WWW.DETECTING.COM • 1-800-413-4131

Carry Bag

Rugged double-stitched construction - CBAG-W

Pouch & Digger Combo

Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W

Bounty Hunter Stereo Headphones

Use with Bounty Hunter metal detectors. Lightweight and adjustable with

true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor,

4’ cable.

HEAD-W

Pin Pointer

Pinpoints the exact location of buried metal objects. Audio signal indicator

and vibrator. Runs on 1 – 9-Volt Battery. PIN POINTER-W

Sand Scoop

Large scoop with filtering holes. Made of strong plastic. SAND SCOOPBH

Replacement/Accessory Search Coils

10” Magnum Accessory Coil – 10COIL

8” Replacement Standard Coil – 8COIL-N

4” Accessory Coil – 4COIL

Coil Covers

Protect your coil from abrasion and damage.

10” Coil Cover – 10COVER

8” Coil Cover – 8COVER-N

4” Coil Cover – 4COVER

9” Heavy-Duty Digging Tool

Metal blade with comfortable plastic handle and depth gauge TROWEL-2

Digging Tool

Light and practical wide blade digging tool. TROWEL-W

Bounty Hunter T-Shirt

100% cotton with Bounty Hunter®Logo. Sizes – LG, XL & XXL

Bounty Hunter Baseball Cap

One size fits all, with Bounty Hunter®logo.

Gold

Prospecting Kits

MQSI REV.3 102912

192

TABLE OF CONTENTS

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Quick-Start Demo . . . . . . . . . . . . . . . . . . . . . .7-8

Basic Operation

Powering Up . . . . . . . . . . . . . . . . . . . . . . . .9

The Display . . . . . . . . . . . . . . . . . . . . . .9-10

Operating Controls . . . . . . . . . . . . . . . . . . . . . .11

Environmental Conditions . . . . . . . . . . . . . . . .12

Audio Target Identification . . . . . . . . . . . . . . .13

Depth Select (Sensitivity Adjustment) . . . . . . .14

In The Field Techniques . . . . . . . . . . . . . . .15-16

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . .17

Metal Detecting Applications . . . . . . . . . . . . . .18

Treasure Hunter’s Code of Ethics . . . . . . . . . . .19

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Accessories . . . . . . . . . . . . . . . . . . . . .Back Cover

5-YEAR LIMITED WARRANTY

The Quick Silver metal detector is warranted against defects in materials and

workmanship under normal use for five years from the date of purchase to the origi-

nal owner.

Damage due to neglect, accidental damage, or misuse of this product is not cov-

ered under this warranty. Decisions regarding abuse or misuse of the detector

are made solely at the discretion of the manufacturer.

Proof of Purchase is required to make a claim under this warranty.

Liability under this Warranty is limited to replacing or repairing, at our option, the

metal detector returned, shipping cost prepaid to First Texas Products. Shipping

cost to First Texas Products is the responsibility of the consumer.

To return your detector for service, please first contact First Texas for a Return

Authorization (RA) Number. Reference the RA number on your package and

return the detector within 15 days of calling to:

First Texas Products L.L.C.

1465-H Henry Brennan Dr.

El Paso, TX 79936

Phone: 915-225-0333

NOTE TO CUSTOMERS OUTSIDE THE U.S.A.

This warranty may vary in other countries, check with your distributor for details.

Warranty does not cover shipping costs.

According to FCC part 15.21 Changes or Modifications made to this device not expressly approved by

the party responsible for compliance could void the users authority to operate this equipment.

This device complies with FCC Part 15 Subpart B Section 15.109 Class B.

except for the inclusion of brief quotations in a review.

Published by First Texas Products, L.LC.

Bounty Hunter®is a registered trademark of First Texas Products, L.L.C.

www.detecting.com

1465-H Henry Brennan • El Paso, TX 79936 • (915) 633-8354

TREASURE HUNTER’S CODE OF ETHICS:

• Always check Federal, State, County and local laws before searching.

• Respect private property and do not enter private property without the owner’s permission.

• Take care to refill all holes and leave no damage.

• Remove and dispose of any and all trash and litter found.

• Appreciate and protect our inheritance of natural resources, wildlife and private property.

• Act as an ambassador for the hobby, use thoughtfulness, consideration and courtesy at all times.

• Never destroy historical or archaeological treasures.

• All treasure hunters may be judged by the example you set; always conduct yourself with

courtesy and consideration of others

TERMINOLOGY

The following terms are used throughout the manual, and are standard

terminology among detectorists.

ELIMINATION

Reference to a metal being "eliminated" means that the detector will

not emit a tone, nor light up an indicator, when a specified object

passes through the coil’s detection field.

DISCRIMINATION

When the detector emits different tones for different types of metals,

and when the detector "eliminates" certain metals, we refer to this

as the detector "discriminating" among different types of metals.

Discrimination is an important feature of professional metal

detectors. Discrimination allows the user to ignore trash and

otherwise undesirable objects.

RELICA relic is an object of interest by reason of its age or its association

with the past. Many relics are made of iron, but can also be made

of bronze or precious metals.

IRON Iron is a common, low-grade metal that is an undesirable target in

certain metal detecting applications. Examples of undesirable iron

objects are old cans, pipes, bolts, and nails.

Sometimes, the desired target is made of iron. Property markers,

for instance, contain iron. Valuable relics can also be composed of

iron; cannon balls, old armaments, and parts of old structures and

vehicles can also be composed of iron.

FERROUS

Metals which are made of, or contain, iron.

PINPOINTING

Pinpointing is the process of finding the exact location of a buried

object. Long-buried metals can appear exactly like the surrounding

soil, and can therefore be very hard to isolate from the soil.

PULL-TABS

Discarded pull-tabs from beverage containers are the most bothersome

trash items for treasure hunters. They come in many different shapes

and sizes. Pull-tabs can be discriminated, but some other valuable

objects can have a magnetic signature similar to pull-tabs, and will also

be eliminated when discriminating out pull-tabs.

GROUND BALANCE

Ground Balancing is the ability of the detector to ignore, or "see

through," the earth’s naturally occurring minerals, and only sound

a tone when a metal object is detected.

METAL DETECTING APPLICATIONS

COIN SHOOTING:

The most popular metal detecting activity.

Find coins where people congregate frequently. Many detectorists revisit the

same areas again and again to find a never-ending treasure trove as people

continue to lose valuables every day. Parks, fairgrounds, and play ares are

good choices. The most valuable old coins are frequently found in abandoned

home sites, or if you live on an older property, maybe in your own backyard.

Control settings required. Target-Rejected al least 2-Xs to eliminate iron,

foil, and old pull tabs. Target-Rejected all 3-Xs if you want to find only

copper and silver. If you search for nickels, remember that you will also

encounter some newer pull-tabs. Some newer pull-tabs have a magnetic

signal indistinguishable from nickel.

RELIC HUNTING:

The most effective relic hunting is best accomplished after conducting historical

research. Visit your local library, or check the internet, for historical events in

your area. You can target specific areas and gain valuable insight into your local

history. Remember to ask permission and respect laws regarding private and

government property.

Control settings required. No X’s should be displayed. Do not

discriminate out any types of metals as many of the oldest relics contain

iron.

JEWELRY HUNTING:

This is the most challenging treasure hunt. Gold rings will register in the same

range as pull-tabs. Necklaces will register with zinc and foils. You will dig up

many trash items in your search for jewelry, but jewelry hunting holds the

most potential for reward. Please pick up ant throw away those pull-tabs to

help clean the environment.

Control settings required. Target-Reject only the 1st X; eliminate IRON

only.

JEWELRY HUNTING:

A cache, pronounced “cash,” is a buried or hidden valuable stored inside a

case, can, strong gox, or bag. A cache could be the loot from a bank robbery

or someone’s life savings. Caches can be hidden in floors or walls of an old

house, or buried nearby.

Control settings required. No X’s should be display. The container

holding the treasure will frequently be a ferrous object, so you want to

detect all types of metal objects.

174

ASSEMBLY

TROUBLESHOOTING GUIDE

SYMPTOM CAUSE SOLUTION

Detector chatters • Using detector • Use detector

or beeps erratically indoors outdoors only

• Using detector near • Move away

power lines

from power lines

• Using 2 detectors in • Keep 2 detectors

close proximity at least 30’ apart

• Highly oxidized • Only dig up

buried object repeatable

signals

• Environmental •

Reduce sensitivity

electromagnetic until erratic

interference signals cease

Constant low tone •

Discharged batteries

• Replace batteries

constant repeating

• Wrong type of • Use only 9V

tones

batteries alkaline batteries

LCD does not lock • Multiple targets •

Move coil slowly

on to one target ID present at different angles

or detector emits • Highly oxidized

multiple tones target

• Sensitivity set • Reduce sensitivity

too high

No power, no • Dead batteries • Replace batteries

sounds

• Cord not connected •

Check connections

securely

• Not moving •

Sweep search coil

Search Coil from side-to-side

TROUBLESHOOTING

Adjusting the Arm Rest

The arm rest may be moved

forward or backwards by

removing the single screw and

nut, and then repositioning the

2-piece arm rest. Users with

shorter arms may find the arm

rest more comfortable in the

forward position. In order to

move the arm rest backwards,

the plastic plug must be

removed from the aluminum

tube.

Arm Rest Strap (not included)

Some users prefer to use a strap

when swinging the detector

vigorously, in order to hold the

detector secure against the arm.

The strap may be purchased as

an optional accessory.

The detector can also be used

without the strap with no

compromise to detector balance

and stability under most

conditions.

Knurled

Knob

Nut

Screw

Cable

Plug

Hand-grip

S-Rod

Armrest

Coil

Cable

Search Coil

Optional Arm Strap

Swing the search coil slowly,

overlapping each sweep as you

move forward. It is important to

sweep the coil at a consistent speed

over the ground as you search. After

identifying a target, your sweep

technique can help in identifying both

the location and the nature of the

target. If you encounter a weak

signal, try moving the coil in short,

rapid sweeps over the target zone;

such a short rapid sweep may

provide a more consistent target

identification.

Most worthwhile objects will

respond with a repeatable tone. If

the signal does not repeat after

sweeping the coil directly over the

suspected target a few times, it is

more than likely trash metal.

Crossing the target zone with

multiple intersecting sweeps at

multiple angles is another way to

verify the repeatability of the signal,

and the potential of the buried target.

To use this method, walk around the

target area in a circle, sweeping the

coil across the target repeatedly,

every 30 to 40 degrees of the circle,

about ten different angles as you

walk completely around the target. If

a high-tone target completely

disappears from detection at a given

angle, chances are that you are

detecting oxidized ferrous metals,

rather than a silver or copper object.

If the tone changes at different

angles, you may have encountered

multiple objects. If you are new to

the hobby, you may want to dig all

targets at first. With practice in the

field, you will learn to better discern

the nature of buried objects by the

nature of the detector’s response.

You may encounter some false

signals as you proceed. False signals

occur when the detector beeps, but

no metal target is present. False

signals can be induced by

electromagnetic interference,

oxidation, or highly mineralized

ground soils. If the detector beeps

once, but does not repeat the signal

with several additional sweeps over

the same spot, there is probably no

target present.

When searching very trashy ground,

it is best to scan small areas with

slow, short sweeps. You will be

surprised just how much trash metal

and foil you will find in some areas.

The trashiest areas have been

frequented by the most people, and

frequently hold the most promise for

finding the most lost valuables.

Also maintain the search coil

positioned just above the surface of

the ground, without making contact

with the ground. Making contact with

the ground can cause false signals.

WHAT

READS

LIKE THIS

…MAY

ACTUALLY

BE THIS

IN THE FIELD TECHNIQUES ASSEMBLY

Assembling your Quick Silver Metal

Detector is easy and requires no

tools. Just follow these steps:

●

1Using the supplied bolt and

knurled knob, attach the

search coil to the lower stem.

●

Press the button on the upper end

of the lower stem and slide the

lower stem into the upper stem.

Adjust the stem to a length

that lets you maintain a com-

fortable upright posture, with

your arm relaxed at your

side. Maintain the search coil

about 1 inch above the

ground as you sweep.

●

3Wind the search coil cable

around the stem. Leave

enough slack in the cable to let

you adjust the coil when you

are hunting on uneven

ground. Then tighten the knob

at the end of the search coil.

Note:

To adjust the coil,

simply loosen the knob.

●

4Insert the coil’s plug into the

matching connector on the

control housing. Be sure the

holes and pins line up correctly.

Caution:

• Do not force the plug in.

Excess force will cause damage.

• To disconnect the cable, pull

out the plug. Do not pull on

the cable.

IN THE FIELD TECHNIQUES

When pinpointing a target, try drawing an “X”,

as illustrated, over where the tone is induced.

PINPOINTING

Accurate pinpointing takes practice

and is best accomplished by

“X-ing” the target area.

1. Once a buried target is indicated

by a good tone response,

continue sweeping the coil over

the target in a narrowing

side-to-side pattern.

2. Take visual note of the place on

the ground where the “beep”

sounds.

3. Stop the coil directly over this

spot on the ground.

4. Now move the coil straight

forward and straight back

towards you a couple of times.

5. Again make visual note of the

spot on the ground at which

the “beep” sounds.

6. If needed, “X” the target at

different angles to “zero in” on

the exact spot on the ground at

which the “beep” sounds.

COIL MOVEMENT

When swinging the coil, be

careful to keep it level with the

ground about one inch from the

surface. Never swing the coil like

a pendulum.

TARGET DEPTH ESTIMATION

After verifying a desirable

target, pass the coil again, but

raise the coil 1” over the

ground, progressively higher

with each sweep. Note the coil

elevation at which the signal

disappears. With practice, you

will be able to approximate

target depth.

CORRECT

WRONG

IMPORTANT: Always use ALKALINE batteries only.

Do not use heavy duty batteries.

DON’T MIX OLD AND NEW BATTERIES

Always remove the batteries for prolonged storage.

CHECK THE BATTERIES if your detector exhibits any of the following

symptoms:

●

1The unit does not turn on.

●

2Low speaker volume.

●

Unit beeps continuously or erratically.

The LOW BATTERY indicator will come on and stay on if the batteries

are discharge. You may notice erratic beeping if using with LOW

BATTERY illuminated.

IMPORTANT: Your Quick Silver metal detector requires two 9-Volt

ALKALINE batteries.

Follow these steps to install the batteries.

●

1Carefully remove the battery compartment door by pressing the release

clip on the right side of the door.

●

2Snap one

battery onto

each of the

terminals and

place the bat-

teries inside the

compartment.

Insert booth of

the batteries

with terminals

facing inward.

●

Replace the

compartment

door by carefully

inserting oppo-

site side of clip

first. Then press

BATTERIES

Release

Clip

Both Batteries

teminals

facing in

714

DEPTH SELECT (Sensitivity Adjustment)

Upon power-up, the detector defaults to 3/4 sensitivity. To increase to full

sensitivity, press the DEPTH SELECT touchpad once.

ELECTROMAGNETIC INTERFERENCE

The principle use for the Sensitivity Control is to eliminate

Electromagnetic Interference (EMI).

A hobby metal detector is an extremely sensitive device; the search coil

creates its own magnetic field and acts like an antenna. If your detector

beeps erratically when the search coil is motionless, the unit is probably

detecting another electromagnetic field.

Common sources of EMI are electric power lines, both suspended and

buried, motors, and household appliances like computers and

microwave ovens. Some indoor electronic devices, such as dimmer

switches used on household lighting, produce severe EMI and can cause

the detector to beep erratically. Other metal detectors also produce their

own electromagnetic fields; so if detecting with a friend, keep two metal

detectors at least 20 feet apart.

If the detector beeps erratically, REDUCE THE SENSITIVITY by using the

Depth Select Control.

SEVERE GROUND CONDITIONS

A secondary use for the Sensitivity Control is to reduce false detection

signals caused by severe ground conditions. While your Quick Silver

contains circuitry to eliminate the signals caused by most naturally

occurring ground minerals, 100% of all ground conditions cannot be

anticipated. Highly magnetic soils found in mountainous and gold-

prospecting locations can cause the detector to emit tones when metal

objects are not present. High saline content soils and sands can also

cause the detector to false.

If the detector emits false, non-repeatable, signals, REDUCE THE

SENSITIVITY.

MULTIPLE TARGETS

If you suspect the presence

of deeper targets beneath a

shallower target, reduce the

sensitivity to eliminate the

detection of the deeper

targets, in order to properly

locate and identify the

shallower target.

QUICK-START DEMONSTRATION

I. Supplies Needed

• A Medium-Size Nail • A Quarter

•A Nickel • A Zinc Penny (dated after 1982)

II. Position the Detector

a. Place the detector on a

table, with the search coil

hanging over the edge.

(or better, have a friend

hold the detector, with

the coil off the ground)

b. Keep the search coil

away from walls, floors,

and metal objects.

c. Remove watches, rings and other jewelry or metal objects from

hands and wrists.

d. Turn off appliances or lights that cause electromagnetic

interference.

e. Pivot the search coil back toward the detector body.

III. Power Up

Press the ON touchpad.

The detector will beep

several times and the

sensitivity setting will

be indicated on the

right of the display. Two

illuminated segments

indicates 3/4 sensitivity.

IV. Wave each Object over

the Search Coil (

pass the flat side of the coins parallel to the coil)

a.Notice a different tone for each object.

Low Tone: Nail

Medium Tone: Nickel & Zinc Penny

High Tone: Quarter

b.Motion is required. Objects must be in motion over the

search coil to be detected.

V. Press the TARGET REJECT

touchpad

AUDIO TARGET IDENTIFICATION

While the LCD (Liquid Crystal Display) is very accurate in identifying

buried objects, the user in the field does not always maintain the display

screen in his field of vision. Therefore, we have incorporated an audio

feedback mechanism to alert the user to the nature of buried objects.

This audio feedback system first alerts the user to the presence and

classification of objects, whose nature and location can be confirmed

using the LCD display.

The detector will sound one of three different tones, depending on the

type of metal detected.

BASS TONE

Ferrous objects, such as iron and steel, will induce a bass tone.

The smallest gold objects can also induce a bass tone.

MEDIUM TONE

Pull-tabs, newer pennies (post-1982), larger gold objects, zinc,

small brass objects, and most bottle screw caps will induce

medium tones. Many recent vintage foreign currencies will

induce medium tones. Medium tone objects will illuminate the

two center target indicators.

HIGH TONE

Silver and copper coins, larger brass objects, older pennies (pre-

1982), and highly oxidized metals will induce high tones.

Quarters, dimes and other precious coins fall into this category.

Audio Target Identification (ATI) classifies metals into four categories.

LOW TONE

Nails, Bottle Caps,

& Smaller Gold

MEDIUM TONE

Old & New Pull Tabs, Zinc

Pennies (Post 1982), Nickel,

Larger Gold Objects

HIGH TONE

Copper, Silver & Brass

Copper Pennies (Pre 1982)

a. An “X” will appear under

the IRON segment.

b. The “X” tell us that Iron

has been eliminated from

detection.

VI. Wave the Nail over the

Search Coil

a. The Nail will not be

detected.

b. The Nail has been "Discriminated Out."

VII. Wave the Quarter, Penny, and Nickel over the Search Coil

These non-ferrous objects will be detected with their own

distinctive tones.

VIII. Press the TARGET

REJECT

touchpad again

Another “X” will

illuminate under “AL ZN”.

IX. Wave all objects over the

Search Coil

The Zinc Penny will not be detected. make sure the penny is post-

1982; these are made of Zinc. CAUTION: some zinc pennies

within 1/2” of the coin surface will induce a high tone.

X. Press the TARGET REJECT touchpad again

a. A third “X” appears.

b. Pass all object over the search coil.

The nail, penny, and nickel are all eliminated from detection.

XI. Press the TARGET REJECT touchpad to return the detector to all-

metals detection, with no “X”s illuminated.

QUICK-START DEMONSTRATION

USING HEADPHONES

Using headphones (not included) improves battery life, and prevents the

sounds from annoying bystanders.

It also allows you to hear subtle changes in the sound more clearly, particularly

if searching in a noisy location. For safety reasons, do not use headphones

near traffic or where other dangers are present. This device is to be used with

interconnecting cables/headphone cables shorter than three meters.

BASIC OPERATION

ENVIRONMENTAL CONDITIONS

WATER HUNTING: Your Quick Silver is ideal for damp grass and shallow

water spots. the search coil is waterproof; the case and case-to-cable

connection is not. Be careful to keep the detector body dry.

In saltwater, keep the search coil from contact with the ground. Contact

with saltwater sands will cause the detector to beep falsely. For best

result in saltwater, eliminate IRON to reduce false signals caused by

conductive beach sands. Coil sweep technique is also important in

saltwater; keeping the coil submerged is better than dunking and lifting.

The detector needs time to readjust to the conductive salt water.

RED CLAY: The red clay earth found in the southwestern U.S. may

require a reduction in the DEPTH SELECT level if encountering false

signals. Coil sweep technique is also more critical in red clay; keep the

coil level with the ground. Do not lift the coil at the ends of your sweep.

Review coil sweep technique on page 15.

RED SANDS: Red sand found in desert locations will react like red clays,

so fallow the same precautions as outlined in the paragraph above.

BLACK SANDS: The most promising gold prospecting locations can

contain large amounts of black sand. This black sand is the most

demanding detecting environment, and frequently requires a detector

costing thousands of dollars for the best results. Your Quick Silver will still

function in these conditions, but will usually require operation at reduced

sensitivity levels. If you receive constant false signals, reduce the

sensitivity or move to another area.

SAND: Dry beach sands are no problem for the Quick Silver. if the sand

is damp with saltwater, however, follow the precautions outlined under

saltwater above.

HOT AND COLD: Be patient if moving immediately between hot and

cold environments, like taking your detector from your air-conditioned

home into a blazing summer sun. The search coil is constructed of

copper wire which will expand and contract with temperature change.

Your detector may require 10 to 15 minutes to stabilize to the ambient

temperature.

BASIC OPERATION

POWERING UP

Press the ON touch pad.

All display indicators will illuminate momentarily

The inverted-pyramid depth-selection indicator on the right of the

display will stay illuminated.

UNDERSTANDING THE DISPLAY

●

1DEPTH SELECT

The detector default to 3/4

sensitivity, indicated by two

illuminated segments. To change

the depth range of the detector,

and thus its sensitivity to more

deeply buried objects, use the

DEPTH SELECT touch pad. each

touch of DEPTH SELECT toggles

the detector among three different sensitivity settings. The detector is

at maximum depth capability when three depth segments are

illuminated on the right of the display.

At the maximum depth setting, the detector will detect a coin-sized

object buried approximately 6 1/2 inches beneath the surface. With

two depth segments illuminated, the detector’s depth range will be

reduced to 80%, and with one depth segment illuminated, the range

will be reduces to 65%.

A more detailed explanation of depth selection is found on page 14.

●

2LOW BATTERY

The LOW BATTERY indicator will illuminate when the 9-volt batteries

are discharged to a level of 6.8 volts.

Replace the batteries as soon as

possible after receiving th e low

battery indication. The detector

will begin to beep erratically and

operate unreliably if continuing

use with discharged batteries.

To save on batteries, check each

battery individually, as the two

batteries can discharge at different

rates. When LOW BATTERY

illuminates, it is possible that only one of the batteries requires

replacement.

Under normal conditions, a set of batteries will last for approximately

16 hours in the field, depending upon the brand of battery. 9

1110

●

4REJECTED TARGET

When “X” appears under a target

category, objects falling into this

category are eliminated from

detection. This feature is commonly

referred to as target discrimination.

With each press of the REJECT

TARGET touch ad, you will

progressively eliminate, from left to

right, the common, less desirable, targets. When all three “X” are

illuminated, the next press will erase all “X”s, returning the detector to

all-metal detection status, where all types of metals will be detected.

OPERATING CONTROLS

The Quick Silver is the most automated, easy-to-operate, professional

metal detector ever designed. It is designed for those who are new to the

hobby providing maximum basic target discrimination, while requiring

minimal operator adjustment.

DEPTH SELECT

With each press of the DEPTH SELECT

touch pad, the detector toggles among

three different depth-detection levels.

Each of these sensitivity levels is

identified through the 3-segment depth-

select icon on the right of the display.

When three segments are illuminated,

the detector is at maximum sensitivity. As you press the DEPTH SELECT

touch pad, the detector toggles among the three different sensitivity levels.

A more detailed explanation of depth selection is found on page 14.

TARGET REJECT

Upon power-up, all types of metals are

detected. The TARGET REJECT touch

pas allows the user to eliminate

undesirable metals from detection.

With each press of the REJECT TARGET

touch pad, unwanted metals are

progressively eliminated, from left to right on the display. When all three

“X”s are illuminated, the next press will erase all “X”s, returning the detector

to all-metal detection status, where all types of metals will be detected.

BASIC OPERATION BASIC OPERATION

●

3PROBABLE TARGET

The four categories depicted across the top of the display

indicate the probable identification of buried, detected metal

objects. The search coil must be in motion over an object to

be detected. Alternatively, you can pass an object over a

motion less search coil to test your detector. One of the four

target indicators will illuminate, indicating the probable

identification of the object. The indicator will remain

illuminated until another object is detected.

You will encounter a never-ending variety of buried metal

objects. It is therefore impossible to accurately identify all

buried metal objects. The target identification system will

accurately identify the most common items.

Commonly-found object are classified into the four categories as

follows:

IRON ------------------------------------------------

Ferrous objects

Metals composed mostly or

entirely of iron

Most very small metals objects

Small foil pieces; small gold

pieces.

AL 5¢ ------------------------------------------------

Large gold rings

Newer pull-tabs (those which

stay connected to can)

Nickels

Large Aluminum Pieces

AL ZN ------------------------------------------------

Post-1982 pennies (are made of

zinc, some zinc pennies will register

as coins within 1” of the coil). -Zinc

coins, such as recent foreign

currency -Most bottle screw caps. -

Large foil pieces. -Many rings; most

gold rings. -Older pull-tabs (those

which detach from the can)

COINS ------------------------------------------------

Silver coins, like dimes and

quarters. -Copper pennies (pre-

1982). -Very large metal objects

like manhole covers.

Autres manuels pour Quick Silver

Table des matières

Autres manuels Bounty Hunter Détecteur de métaux

Bounty Hunter

Bounty Hunter Surveyor Manuel utilisateur

Bounty Hunter

Bounty Hunter DISCOVERY 2200 Manuel utilisateur

Bounty Hunter

Bounty Hunter metal detector Manuel utilisateur

Bounty Hunter

Bounty Hunter Lone Star Manuel utilisateur

Bounty Hunter

Bounty Hunter Mach-1 Manuel utilisateur

Bounty Hunter

Bounty Hunter Elite 2200 Manuel utilisateur

Bounty Hunter

Bounty Hunter Challenger Manuel utilisateur

Bounty Hunter

Bounty Hunter THE COMMANDO Manuel utilisateur

Bounty Hunter

Bounty Hunter Platinum Manuel utilisateur

Bounty Hunter

Bounty Hunter TimeRanger Manuel utilisateur

Bounty Hunter

Bounty Hunter PIONEER 505 Manuel utilisateur

Bounty Hunter

Bounty Hunter DISCOVERY 3300 Manuel utilisateur

Bounty Hunter

Bounty Hunter Legacy 2500 Manuel utilisateur

Bounty Hunter

Bounty Hunter Tracker IV Manuel utilisateur

Bounty Hunter

Bounty Hunter Time Ranger Manuel utilisateur

Bounty Hunter

Bounty Hunter VLF Manuel utilisateur

Bounty Hunter

Bounty Hunter Sharp Shooter II Manuel utilisateur

Bounty Hunter

Bounty Hunter Fortune Hunter Manuel utilisateur

Bounty Hunter

Bounty Hunter Ultra Mag Sharp Shooter Manuel utilisateur

Bounty Hunter

Bounty Hunter Treasure detector Manuel utilisateur

Bounty Hunter

Bounty Hunter PIONEER EX Manuel utilisateur

Bounty Hunter

Bounty Hunter Legacy 1000 Manuel utilisateur

Bounty Hunter

Bounty Hunter Tracker I Manuel utilisateur

Bounty Hunter

Bounty Hunter Quick Draw II Manuel utilisateur

Manuels Détecteur de métaux populaires d'autres marques

Garrett

Garrett MAGNASCANNER CS 5000 Manuel utilisateur

Valex

Valex 1800200 Manuel utilisateur

Gauss

Gauss MIL MD Manuel utilisateur

Velleman

Velleman CS130 Manuel utilisateur

Sears

Sears 321.596370 Manuel utilisateur

Eriez

Eriez X8 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-22 Manuel utilisateur

Zircon

Zircon MetalliScanner m60c Manuel utilisateur

nalanda

nalanda MD027 Manuel utilisateur

REV Ritter

REV Ritter CB-7005 Manuel utilisateur

Minelab

Minelab F1A4 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs F70 Manuel utilisateur

Steinberg Systems

Steinberg Systems SBS-MD-12 Manuel utilisateur

GOLDEN MASK

GOLDEN MASK 5 Manuel utilisateur

Grizzly

Grizzly YM 203 Manuel utilisateur

Fisher Research Labs

Fisher Research Labs 1280-X Aquanaut Manuel utilisateur

Treasure Cove

Treasure Cove Vibra-Probe 560 Manuel utilisateur

Accurate Locators

Accurate Locators XL16 IMAGER Manuel utilisateur
