1 Getting Started

Install and wire the AutoDome according to the Bosch AutoDome Modular Camera System

Installation Manual. A typical system includes a keyboard, matrix switcher, monitor, and

appropriate wiring connections. Please refer to the individual product manuals for complete

installation and setup instructions for each of the system components.

1.1 Powering On

When you turn the AutoDome power on there is a ten (10) second pause before the dome

starts its homing phase. During the homing phase the camera pans left and right and tilts up

and down. It also adjusts the lens focus. The entire homing phase lasts approximately 40

seconds and ends with a splash screen.

Figure 1.1 Sample VG4 Startup Splash Screen

The splash screen displays the type of AutoDome, the camera installed, the firmware levels for

various files, and the current IP address (if the AutoDome contains the IP Communications

module). The (P) to the right of the AtuoDome series indicates that the AutoDome contains

the optional modules for maintaining internal pressure.

1.2 Establishing AutoDome Control

The most common ways to interface with the AutoDome are:

– Using a keyboard and on-screen display (OSD) menus. This method is the most common

and is covered in this manual.

– Using the AutoDome Configuration Tool software running on a PC with Bilinx or the RS-

232/485 communication protocol. Refer to the CTFID User Manual for instructions.

– Using a PC-based graphical user interface (GUI) such as the Bosch DiBos 8 software.

Refer to the DiBos 8 User Guide for instructions.

– Using the Bosch IP Web interface included with the IP Communications Module.

Bosch Security Sys. AutoDome(r)

500 Series(P)

Day/Night 26X

SC Boot

FPGA

Lang. Table

VCA_boot

IP-Panel

IP Address

Subnet Mask

No Heater

FastAddress: Not Set

1.10.00.02/1.07.58.02

2.00.00.00

1.05.00.01

1.13.01.05

1.00.00.01

1.02.00.01

3.50.50.09

10. 25.118.111

255.255.248. 0

4en | Getting Started VG4 AutoDome Modular Camera System

F.01U.133.267 | 6.0 (IP4) | 2009.06 User’s Manual Bosch Security Systems, Inc.

1.2.1 Basic Keyboard Operation

The following tables summarize the basic operations for a standard keyboard and the

functions available to control an AutoDome camera.

Table 1.1 Typical Keyboard Functions

Table 1.2 Typical Keyboard Controls for an AutoDome Camera

1.2.2 Keyboard Commands

Keyboard control commands are composed of a sequence of three (3) inputs with the

following convention: 1) a Function key + 2) a Command number key(s) + 3) the Enter key.

– Depending on the type of keyboard, the control function keys are labeled:

ON or AUX ON

OFF or AUX OFF

SET or SET SHOT

SHOT or SHOW SHOT

– Command numbers range from 1 to 999. See Chapter 6: Keyboard Commands by Number

for a complete list of keyboard commands.

–TheEnter key can also be labeled with the 8 symbol.

For example, the keyboard command to make the AutoDome pan 360º continuously is:

ON-1-ENTER(press the ON key, then press the number 1key, and then press ENTER.)

Typical

Keyboard

Features

Usage

Function Keys Selects a specific control setting.

Number Keys Inputs a number from 0 to 9.

Camera Key Selects a camera number.

Enter Key Inputs a selection.

Focus Key Sets the lens focus or makes a menu selection in OSD mode.

Iris Key Sets the lens iris setting or makes a menu selection in OSD mode.

Key LEDs Indicates an active key.

LCD Displays the current status.

Joystick Controls a pan/tilt/zoom (PTZ) AutoDome camera.

Dome Operation How to control

To Pan Side to Side Move the joystick left or right.

To Tilt Up and Down Move the joystick forward and back.

To Zoom In Twist the joystick clockwise.

To Zoom Out Twist the joystick counterclockwise.

NOTICE! The convention used for control key commands in this manual is ON, OFF, SET, and

SHOT. Refer to your keyboard manual for the key naming conventions.

VG4 AutoDome Modular Camera System Ge t t i n g S t a r t e d | e n 5

Bosch Security Systems, Inc. User’s Manual F.01U.133.267 | 6.0 (IP4) | 2009.06

1.3 Setting the Camera Address

Once the AutoDome power is turned on and homing is complete, you must set the camera

address. You may also want to assign a password and customize some of the AutoDome

default settings.

1.3.1 FastAddress

FastAddress is an AutoDome feature that allows you to set or change a camera address using

the keyboard and on-screen menus.

There are three (3) FastAddress commands:

–ON-999-ENTER: Displays and programs all cameras without an address in the system.

–ON-998-ENTER: Displays and programs all cameras with or without an address in the

system.

–ON-997-ENTER: Displays the current address status of all cameras in the system

simultaneously.

To set an address for a camera without an address:

1. Select the camera number you want to FastAddress. The system displays the camera

number on the keyboard and the image on the corresponding monitor.

2. Press #-ENTER (where #is the camera number without an address).

3. Press ON-999-ENTER to invoke an on-screen display of cameras on the system without

an address.

4. Follow the on-screen instructions. You receive an on-screen confirmation when the

FastAddress is complete.

To change or clear an address for a camera with an address:

1. Select the camera number you want to FastAddress. The system displays the camera

number on the keyboard and the image on the corresponding monitor.

2. Press #-ENTER (where #is the camera number with an address).

3. Press ON-998-ENTER to invoke an on-screen display of all cameras on the system, with or

without an address.

4. Follow the on screen instructions. You receive an on-screen confirmation when the

FastAddress is complete.

NOTICE! You do not need to set a camera address if using Bilinx or Ethernet communication.

See the AutoDome Installation Manual to configure an AutoDome for Bilinx or Ethernet

operation.

NOTICE! If a keyboard is set to a camera number that already has an address, that camera

also responds to this command.

NOTICE! FastAddress is stored in nonvolatile memory and does not change if the power is

turned off or if the default settings are restored.

6en | Getting Started VG4 AutoDome Modular Camera System

F.01U.133.267 | 6.0 (IP4) | 2009.06 User’s Manual Bosch Security Systems, Inc.

1.4 Setting Passwords

Passwords are used to control access to locked command menus. Unlocked commands are

available to all users. Passwords are four (4) digits in length.

1.4.1 Special Passwords

To set or change a password (locked command):

1. Press OFF-90-ENTER to turn off the command lock.

2. Press SET-802-ENTER to access the password menu.

3. Tilt the joystick up or down to choose a number. Tilt the joystick right to move to the next

number position.

4. Follow the on-screen instructions and save the password. You receive an on-screen

confirmation.

Password Security Level

0000

(default)

Enables security and requires a user to enter the unlock command

OFF-90-ENTER before invoking a locked command.

9999 Disables all security and allows all users to access locked commands.

Autres manuels pour VG4-200 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bosch Caméra de sécurité

Bosch

Bosch FLEXIDOME IP panoramic 6000 Series Manuel utilisateur

Bosch

Bosch VEZ Series Manuel utilisateur

Bosch

Bosch DINION IP starlight 7000 HD Manuel utilisateur

Bosch

Bosch EX72MX4V0922-N Manuel utilisateur

Bosch

Bosch VKC 4075 Manuel utilisateur

Bosch

Bosch DINION IP thermal 8000 Manuel utilisateur

Bosch

Bosch MIC IP fusion 9000i Manuel utilisateur

Bosch

Bosch AUTODOME IP 5000 HD NEZ-5 Series Manuel utilisateur

Bosch

Bosch VEN-650V05-2A3 Manuel utilisateur

Bosch

Bosch LTC 0440 Series Manuel utilisateur

Bosch

Bosch FLEXIDOME NIN-63013 Manuel utilisateur

Bosch

Bosch FlexiDome NDN-832 Manuel utilisateur

Bosch

Bosch VG4-100 Series Manuel utilisateur

Bosch

Bosch KBE-495V28-20N Manuel utilisateur

Bosch

Bosch NWD-495V03-20P Manuel utilisateur

Bosch

Bosch Diniop IP - NWC-0455 Manuel utilisateur

Bosch

Bosch NBN-498-11P Manuel utilisateur

Bosch

Bosch LTC-0485-21 Manuel utilisateur

Bosch

Bosch VEZ-5000 Manuel utilisateur

Bosch

Bosch VEZ-400 Series Manuel utilisateur

Bosch

Bosch NPD-5512-Z30 Manuel utilisateur

Bosch

Bosch Camera Manuel utilisateur

Bosch

Bosch BasicDome Serien Manuel utilisateur

Bosch

Bosch LTC 1311/20 FlexiDome I Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
