Bosch VDC-275 Manuel utilisateur

Indoor Dome Camera

VDC-275 / VDN-276

en Installation Manual

Table of Contents | en 3

| |

Table of Contents

1Safety 5

1.1 Safety precautions 5

1.2 Important safety instructions 6

1.3 FCC & ICES compliance 8

1.4 UL certification 9

1.5 Bosch notices 10

2 Introduction 11

2.1 Features 11

3 System Information 12

3.1 Unpacking 12

4 Camera controls 13

4.1 Menu navigation 13

4.2 Monitoring and switches 13

5 Installation 14

5.1 Parts 14

5.2 Mounting the unit 15

5.2.1 Camera mounting 15

5.3 Connections 16

5.3.1 Make the connections 16

5.4 Adjusting the camera 17

6 Camera menus 18

6.1 Main SETUP menu 20

6.2 Lens menu 21

6.3 Shutter/AGC menu 21

6.3.1 Auto setup 21

6.3.2 Manual setup 22

6.4 White balance menu 23

4en | Table of Contents

| |

6.4.1 ATW (auto trace white balance) 23

6.4.2 Push 23

6.4.3 User1 WB 24

6.4.4 User2 WB 24

6.4.5 Anti CR 24

6.4.6 Manual WB 25

6.4.7 Push lock (hold) 25

6.5 Backlight 25

6.6 Picture adjustment menu 26

6.7 ATR menu (digital WDR) 26

6.8 Motion detection menu 27

6.9 Privacy menu 28

6.10 Day /Night menu 29

6.10.1 Auto 29

6.10.2 Color 29

6.10.3 B/W 30

6.11 NR (noise reduction) menu 30

6.12 Camera ID menu 31

6.13 Synchronisation menu 32

6.14 Language 32

6.15 Camera reset 32

6.16 Return 32

6.17 Next 32

6.18 Save all 33

6.19 Exit 33

6.20 White pixel menu 33

7Troubleshooting 34

7.1 Resolving problems 34

8 Technical Data 35

8.1 Specifications 35

Indoor Dome Camera Safety | en 5

Bosch Security Systems Installation Manual AM18-Q0609 | v1.0 | 2012.01

1Safety

1.1 Safety precautions

DANGER!

High risk: This symbol indicates an imminently hazardous

situation such as "Dangerous Voltage" inside the product.

If not avoided, this will result in an electrical shock, serious

bodily injury, or death.

WARNING!

Medium risk: Indicates a potentially hazardous situation.

If not avoided, this could result in minor or moderate bodily

injury.

CAUTION!

Low risk: Indicates a potentially hazardous situation.

If not avoided, this could result in property damage or risk of

damage to the unit.

CAUTION!

The Low Voltage power supply unit must comply with EN60950

/ UL60065. The power supply must be a SELV-LPS unit or a

SELV - Class 2 unit (Safety Extra Low Voltage - Limited Power

Source).

CAUTION!

Installation should only be performed by qualified service

personnel in accordance with the National Electrical Code or

applicable local codes.

6en | Safety Indoor Dome Camera

AM18-Q0609 | v1.0 | 2012.01 Installation Manual Bosch Security Systems

1.2 Important safety instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8. Do not install unit near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider

than the other. A grounding type plug has two blades and a

grounding prong. The wide blade and third prong are

provided for your safety. I the provided plug does not fit

into your outlet, consult an electrician for replacement of

the obsolete outlet.

10. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the

point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to service personnel. Servicing is

required when the apparatus has been damaged in any

way, such as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

Indoor Dome Camera Safety | en 7

Bosch Security Systems Installation Manual AM18-Q0609 | v1.0 | 2012.01

WARNING!

To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

CAUTION!

Apparatus shall not be exposed to dripping or spashing and no

objects filled with liquids, such as vases, shall be placed on the

apparatus.

8en | Safety Indoor Dome Camera

AM18-Q0609 | v1.0 | 2012.01 Installation Manual Bosch Security Systems

1.3 FCC & ICES compliance

FCC & ICES Information

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a commercial

environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following

measures:

– reorient or relocate the receiving antenna;

– increase the separation between the equipment and

receiver;

– connect the equipment into an outlet on a circuit different

from that to which the receiver is connected;

– consult the dealer or an experienced radio/TV technician

for help.

Intentional or unintentional modifications, not expressly

approved by the party responsible for compliance, shall not be

made. Any such modifications could void the user's authority to

operate the equipment. If necessary, the user should consult

the dealer or an experienced radio/television technician for

corrective action.

Indoor Dome Camera Safety | en 9

Bosch Security Systems Installation Manual AM18-Q0609 | v1.0 | 2012.01

1.4 UL certification

Disclaimer

Underwriter Laboratories Inc. ("UL") has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested fire, shock and/or casualty

hazards as outlined in UL's Standard(s) for Safety for Information

Technology Equipment, UL 60065. UL Certification does not

cover the performance or reliability of the security or signaling

aspects of this product.

UL MAKES NO REPRESENTATIONS, WARRANTIES, OR

CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY SECURITY OR

SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.

Disposal - Your Bosch product was developed and

manufactured with high-quality material and components that

can be recycled and reused. This symbol means that

electronic and electrical appliances, which have reached the

end of their working life, must be collected and disposed of

separately from household waste material. Separate collecting

systems are usually in place for disused electronic and

electrical products. Please dispose of these units at an

environmentally compatible recycling facility, per European

Directive 2002/96/EC

10 en | Safety Indoor Dome Camera

AM18-Q0609 | v1.0 | 2012.01 Installation Manual Bosch Security Systems

1.5 Bosch notices

Optical elements

Optical elements are sensitive and should be protected at all

times. Do not allow objects to come into contact with glass

surfaces and do not touch optical elements with your fingers.

This manual is the intellectual property of Bosch Security

Systems and is protected by copyright.

Trademarks

All hardware and software product names used in this

document are likely to be registered trademarks and must be

treated accordingly.

Note

This manual has been compiled with great care and the

information it contains has been thoroughly verified. The text

was complete and correct at the time of printing. The ongoing

development of the products may mean that the content of the

user guide can change without notice. Bosch Security Systems

accepts no liability for damage resulting directly or indirectly

from faults, incompleteness or discrepancies between the user

guide and the product described.

More information

For more information please contact the nearest Bosch Security

Systems location or visit www.boschsecurity.com
