Bosch NBN-498-11P Manuel utilisateur

Dinion2X IP Camera

NBN-498

en Installation and Operation Manual

Dinion2X IP Camera Table of Contents | en 3

Bosch Security Systems Installation and Operation Manual AR18-10-B006 | v1.1 | 2010.06

Table of Contents

1Safety 8

1.1 Safety precautions 8

1.2 Important safety instructions 9

1.3 Connection in applications 10

1.4 FCC & ICES compliance 11

1.5 UL certification 13

1.6 Bosch notices 14

1.7 Copyrights 15

2 Introduction 16

2.1 Features 16

3 System Information 18

3.1 Overview of functions 18

3.1.1 Progressive scan 18

3.1.2 Day/Night function 18

3.1.3 Wide dynamic range 18

3.1.4 Tri-streaming 19

3.1.5 ONVIF (Open Network Video Interface Forum) 19

3.1.6 Audio 19

3.1.7 Alarm I/O 19

3.1.8 Tamper detection and motion detectors 19

3.1.9 Video encoding 19

3.1.10 Multicast 19

3.1.11 Power-over-Ethernet 20

3.1.12 Encryption 20

3.1.13 Receiver 20

3.1.14 Recording 20

3.1.15 Snapshots 20

3.1.16 Backup 20

3.1.17 Configuration 20

3.2 Operation with external systems 22

4en | Table of Contents Dinion2X IP Camera

AR18-10-B006 | v1.1 | 2010.06 Installation and Operation Manual Bosch Security Systems

4 Planning 24

4.1 Unpacking 24

4.2 System requirements 25

4.3 Install players 26

5 Installation 27

5.1 Network (and power) connector 27

5.2 Power connector 28

5.3 Alarm and relay connector 29

5.4 Audio connectors 30

5.5 Video service monitor connector 31

5.6 Data connector 32

5.7 Lens mounting 33

5.8 Mounting the camera 34

5.9 Using the camera install menu 35

5.10 Back focus adjustment 35

5.11 Lens adjustment 36

5.11.1 DC-iris lens 36

5.11.2 Manual-iris lens 36

5.11.3 Video-iris lens 37

5.12 Reset button 37

6 Camera set-up 38

6.1 Camera menu navigation 38

6.2 Install menu 39

6.2.1 Pre-defined modes 39

6.2.2 Lens Wizard submenu 40

6.2.3 Network submenu 41

6.2.4 Defaults submenu 41

6.3 Day/Night switching 42

7 Browser connection 43

7.1 System requirements 43

7.2 Establishing the connection 44

7.2.1 Password protection in camera 44

Dinion2X IP Camera Table of Contents | en 5

Bosch Security Systems Installation and Operation Manual AR18-10-B006 | v1.1 | 2010.06

7.3 Protected network 44

7.4 Connecting to a hardware decoder 45

7.4.1 Alarm connection 45

7.5 Connection established 46

7.5.1 LIVEPAGE 46

7.5.2 RECORDINGS 46

7.5.3 SETTINGS 46

8 Basic Mode 48

8.1 Basic Mode menu tree 48

8.2 Device Access 49

8.2.1 Camera name 49

8.2.2 Password 49

8.3 Date/Time 50

8.4 Network 51

8.5 Encoder Profile 52

8.6 Audio 52

8.7 Recording 52

8.7.1 Storage medium 52

8.8 System Overview 52

9 Advanced Mode 53

9.1 Advanced Mode menu tree 53

9.2 General 55

9.2.1 Identification 55

9.2.2 Password 55

9.2.3 Date/Time 56

9.2.4 Display Stamping 58

9.3 Web Interface 60

9.3.1 Appearance 60

9.3.2 LIVEPAGE Functions 61

9.3.3 Logging 62

9.4 Encoder 63

9.4.1 Privacy Masks 63

9.4.2 Encoder Profile 63

9.4.3 Encoder Streams 67

6en | Table of Contents Dinion2X IP Camera

AR18-10-B006 | v1.1 | 2010.06 Installation and Operation Manual Bosch Security Systems

9.5 Audio 68

9.6 Camera 69

9.6.1 Mode 69

9.6.2 ALC 70

9.6.3 Shutter/AGC 71

9.6.4 Day/night 72

9.6.5 Enhance 73

9.6.6 Color 74

9.6.7 Installer Options 75

9.7 Recording 77

9.7.1 Storage Management 77

9.7.2 Recording Profiles 80

9.7.3 Retention Time 81

9.7.4 Recording Scheduler 82

9.7.5 Recording Status 83

9.8 Alarm 84

9.8.1 Alarm Connections 84

9.8.2 Video Content Analyses (VCA) 87

9.8.3 VCA configuration- Profiles 88

9.8.4 VCA configuration - Scheduled 94

9.8.5 VCA configuration - Event triggered 96

9.8.6 Audio Alarm 97

9.8.7 Alarm E-Mail 98

9.8.8 Alarm Task Editor 100

9.9 Interfaces 101

9.9.1 Alarm input 101

9.9.2 Relay 101

9.9.3 COM1 102

9.10 Network 103

9.10.1 Network 103

9.10.2 Advanced 107

9.10.3 Multicasting 108

9.10.4 JPEG Posting 109

9.10.5 Encryption 110

9.11 Service 111

9.11.1 Maintenance 111

9.11.2 Licenses 113

Dinion2X IP Camera Table of Contents | en 7

Bosch Security Systems Installation and Operation Manual AR18-10-B006 | v1.1 | 2010.06

9.11.3 System Overview 113

10 Operation via the browser 114

10.1 Livepage 114

10.1.1 Processor load 114

10.1.2 Image selection 115

10.1.3 View Control 115

10.1.4 Digital I/O 115

10.1.5 System Log / Event Log 115

10.1.6 Saving snapshots 115

10.1.7 Recording video sequences 116

10.1.8 Running recording program 116

10.1.9 Audio communication 116

10.2 Recordings page 117

10.2.1 Controlling playback 117

11 Troubleshooting 119

11.1 Function test 119

11.2 Resolving problems 120

11.3 Customer service 122

12 Maintenance 123

12.1 Testing the network connection 123

12.2 Communication with Terminal Program 123

12.3 Repairs 125

12.3.1 Transfer and disposal 125

13 Technical Data 126

13.1 Specifications 126

13.1.1 Dimensions 129

13.1.2 Accessories 130

Glossary 131

8en | Safety Dinion2X IP Camera

AR18-10-B006 | v1.1 | 2010.06 Installation and Operation Manual Bosch Security Systems

1Safety

1.1 Safety precautions

DANGER!

High risk: This symbol indicates an imminently hazardous

situation such as "Dangerous Voltage" inside the product.

If not avoided, this will result in an electrical shock, serious

bodily injury, or death.

WARNING!

Medium risk: Indicates a potentially hazardous situation.

If not avoided, this could result in minor or moderate bodily

injury.

CAUTION!

Low risk: Indicates a potentially hazardous situation.

If not avoided, this could result in property damage or risk of

damage to the unit.

Dinion2X IP Camera Safety | en 9

Bosch Security Systems Installation and Operation Manual AR18-10-B006 | v1.1 | 2010.06

1.2 Important safety instructions

Read, follow, and retain for future reference all of the following

safety instructions. Follow all warnings on the unit and in the

operating instructions before operating the unit.

1. Clean only with a dry cloth. Do not use liquid cleaners or

aerosol cleaners.

2. Do not install unit near any heat sources such as radiators,

heaters, stoves, or other equipment (including amplifiers)

that produce heat.

3. Never spill liquid of any kind on the unit.

4. Take precautions to protect the unit from power and

lightning surges.

5. Adust only those controls specified in the operating

instructions.

6. Operate the unit only from the type of power source

indicated on the label.

7. Unless qualified, do not attempt to service a damaged unit

yourself. Refer all servicing to qualified service personnel.

8. Install in accordance with the manufacturer's instructions

in accordance with applicable local codes. Use only

attachments/accessories specified by the manufacturer.

Equipment change or modification could void the user's

guarantee or authorization agreement.

10 en | Safety Dinion2X IP Camera

AR18-10-B006 | v1.1 | 2010.06 Installation and Operation Manual Bosch Security Systems

1.3 Connection in applications

Power lines: An outdoor system should not be located in the

vicinity of overhead power lines, electrical lights, or power

circuits, or where it may contact such power lines or circuits.

When installing an outdoor system, extreme care should be

taken to keep from touching power lines or circuits, as this

contact may be fatal.

U.S.A. models only - refer to the National Electrical Code Article

820 regarding installation of CATV systems.

12 VDC / 24 VAC power source: This unit is intended to

operate with a limited power source. The unit is intended to

operate at either 12 VDC or 24 VAC (if PoE is not available).

User supplied wiring must be in compliance with electrical

codes (Class 2 power levels). If 24 VAC is used, do not ground

the 24 VAC supply at the terminals or at the unit's power supply

terminals.

PoE: Use only approved PoE devices. Power-over-Ethernet can

be connected at the same time as a 12 VDC or 24 VAC power

supply.

CAUTION!

The Low Voltage power supply unit must comply with EN/UL

60950. The power supply must be a SELV-LPS unit or a SELV -

Class 2 unit (Safety Extra Low Voltage - Limited Power Source).
