Bosch EX36 Manuel utilisateur

EX36 Corner-mount No-grip

Camera

EX36 | EX36N

en Instruction Manual

Corner-mount No-grip Camera Table of Contents | en 3

Bosch Security Systems, Inc. Instruction Manual F.01U.172.707 | 3.0 | 2011.02

Table of Contents

1Safety 4

1.1 Important Safety Instructions 4

1.2 Bosch Contact Information 7

2 Description 8

2.1 Unpacking 8

2.2 Parts List 8

2.2.1 Parts Included with the Product 8

2.2.2 User-Supplied Parts 9

3 Installation 10

3.1 Initial Preparations 10

3.2 Faceplate Removal 10

3.3 Input Power Connections 12

3.4 Mounting the Camera Housing 13

3.5 Camera - Directional Adjustment 15

3.6 LED Adjustments (EX36N only) 16

3.6.1 Power Adjustments 16

3.7 Lens Replacement 17

3.8 Camera Re-assembly 18

4 Technical Information 19

4.1 Troubleshooting - Camera 19

4.2 Troubleshooting - LEDs 20

4.3 General Specifications 21

4en | Safety Corner-mount No-grip Camera

F.01U.172.707 | 3.0 | 2011.02 Instruction Manual Bosch Security Systems, Inc.

1Safety

1.1 Important Safety Instructions

– Read and follow all instructions.

– Keep these instructions.

– Heed all warnings.

– Do not use this apparatus near water.

– Clean with a dry cloth only.

– Do not block any ventilation openings. Install in

accordance with manufacturer instructions.

– Do not install near any heat sources such as radiators, heat

registers, stoves or other apparatus (including amplifiers)

that produces heat.

– Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong is provided for your safety. If the provided plug

does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

– Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and where

the power exits from the unit.

– Only use attachments and accessories specified by the

manufacturer.

– Use only with the manufacturer specified cart, stand,

tripod, bracket or table. If moving the cart and apparatus

combination, use caution to avoid injury from tip overs.

– Unplug this apparatus during lightning storms or when

unused for long periods of time.

– Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in any

way, such as power supply cord or plug is damaged, liquid

has been spilled or objects have fallen onto or into the

apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

Corner-mount No-grip Camera Safety | en 5

Bosch Security Systems, Inc. Instruction Manual F.01U.172.707 | 3.0 | 2011.02

NOTICE!

For best results, please read this Instruction Booklet prior to

installing the EX36(N) camera.

WARNING!

CSA Certified/UL Listed CLASS 2 power adaptors must be used

in order to comply with electrical safety standards.

NOTICE!

This product has been certified by CSA International to include

the healthcare facility requirements of UL 2044.

EU Directives covered by this declaration:72/9/EC Low

Voltage Directives89/336/EEC Electromagnetic

Compatibility Directive

WARNING!

This installation should be made by a qualified service person

and conform to all local codes. Bosch Security Systems, Inc.,

will not be responsible for injuries or damages resulting from

the improper installation or use of any camera sold by Bosch,

its agents, distributors, or dealers.

6en | Safety Corner-mount No-grip Camera

F.01U.172.707 | 3.0 | 2011.02 Instruction Manual Bosch Security Systems, Inc.

FCC Information

This equipment has been tested and found to comply with the

limits for a digital device, pursuant to part 15 of the FCC rules.

These limits are designed to provide reasonable protection

against harmful interference in a residential installation. As part

of its normal operation, this device can generate radio

frequency energy and if not installed and used in accordance

with the installation manual may cause interference to radio

communications. However, there is no guarantee that

interference will not occur on a particular installation. If the

device does cause interference to radio or television reception,

the user is encouraged to try to correct the problem by one or

more of the following measures:

– Fit Ferrite beads on all cable to and from the power supply

box, within the box walls.

– Route the composite cable between the camera and the

power supply in steel conduit piping over the entire run of

the cable up to and including connection to a deep conduit

base fitted under the camera and a conduit fitting adaptor

in the wall of the PSU box.

– Contact a Bosch Service Center for further advice.

Corner-mount No-grip Camera Safety | en 7

Bosch Security Systems, Inc. Instruction Manual F.01U.172.707 | 3.0 | 2011.02

1.2 Bosch Contact Information

If this unit needs service, contact the nearest Bosch Security

Systems Service Center for authorization to return and for

shipping instructions.

USA

Repair Center

Telephone: 800-566-2283

Fax: 800-366-1329

E-mail: [email protected]

Customer Service

Telephone: 888-289-0096

Fax: 585-223-9180

E-mail: [email protected]

Technical Support

Telephone: 800-326-1450

Fax: 585-223-3508 or 717-735-6560

E-mail: [email protected]

Canada

Telephone: 514-738-2434

Fax: 514-738-8480

Europe, Middle East, Africa Region

Repair Center

Telephone: 31 (0) 76-5721500

Fax: 31 (0) 76-5721413

E-mail: RMADesk.STService@nl.bosch.com

Asia Region

Repair Center

Telephone: 65 63522776

Fax: 65 63521776

E-mail: [email protected]

Customer Service

Telephone: 86 (0) 756 7633117 or

86 (0) 756 7633121

Fax: 86 (0) 756 7631710

E-mail: [email protected]

Warranty and additional information

For additional information and warranty queries, please contact

your Bosch Security Systems representative or visit our website

at www.boschsecurity.com.

8en | Description Corner-mount No-grip Camera

F.01U.172.707 | 3.0 | 2011.02 Instruction Manual Bosch Security Systems, Inc.

2 Description

The EX36(N) Night Vision Camera has been designed with tilt

on its faceplate to allow corner mounting and t provide better

angle views in small rooms. The housing and faceplate consist

of tough materials to withstand damage in hostile environments

such as prison cells and psychiatric wards.

The smooth compact housing allows for tight installations

without exposed wiring or mounting screws, while separate

windows for the camera lens and LEDs result in a perfect

picture without light rebound.

A photocell circuit is used to provide automatic on/off infrared

operation.

The voltage regulator circuit allows for 12 VDC or 24 VAC

operation, and a range in between. This regulator also provides

protection from voltage surges, transient spikes, and reverse

voltage.

2.1 Unpacking

This electronic equipment should be unpacked and handled

with care. Check the parts list below and confirm that all items

are included. Inspect the equipment thoroughly to ensure that

nothing was damaged in transit.

Contact a Bosch Service Center if a problem is noted. Please

refer to Section 1.2 Bosch Contact Information, page 7 for

contact information in your area.

2.2 Parts List

2.2.1 Parts Included with the Product

The following items are supplied with the unit:

– EX36(N) camera assembly

– installation instruction booklet

– Plastic bag containing one hex key for removal of faceplate

mounting screws

Corner-mount No-grip Camera Description | en 9

Bosch Security Systems, Inc. Instruction Manual F.01U.172.707 | 3.0 | 2011.02

2.2.2 User-Supplied Parts

The following items are required for installation but are not

supplied:

– mounting hardware

– mounting tools

10 en | Installation Corner-mount No-grip Camera

F.01U.172.707 | 3.0 | 2011.02 Instruction Manual Bosch Security Systems, Inc.

3 Installation

3.1 Initial Preparations

– Determine the operating voltage at the installation site.

– Determine the optimum location for the camera. Refer to

Section 3.4 Mounting the Camera Housing.

– All units have been tested prior to shipment. After the

wiring has been reconnected, check the unit’s operation

before installation.

– Follow these installation steps in sequence:

3.2 Faceplate Removal

You must remove the faceplate prior to installation in order to

reach the mounting holes. You may need to change the

directional angle of the lens. Refer to Figure 3.1.

1. Place the camera housing on a flat surface.

2. Use the supplied hex key to remove the six screws holding

the faceplate into the housing.

3. Remove the square foam cushion attached to the camera

lens.

Installation Step PAGE

Faceplate Removal Page 10

Input Power Connections Page 12

Mounting the Camera Housing Page 13

Camera - Directional Adjustment Page 15

LED Adjustments Page 16

Camera Re-Assembly Page 18
