Bosch GLM 80 Professional Guide rapide

IMP RTANT: IMP RTANT : IMP RTANTE:

Read Before Using Lire avant usage Leer antes de usar

perating/Safety Instructions

Consignes de fonctionnement/sécurité

Instrucciones de funcionamiento y seguridad

1-877-B SCH99 (1-877-267-2499) www.boschtools.com

Call Toll Free for

Consumer Information

& Service Locations

Pour obtenir des informations

et les adresses de nos centers

de service après-vente,

appelez ce numéro gratuit

Llame gratis para

obtener información

para el consumidor y

ubicaciones de servicio

For English Version Version française Versión en español

See page 6 Voir page 35 Ver la página 62

GLM 80

GLM 80 + R 60

GLM 250 VF

Professional

GLM250 VF

Professional

GLM 80

10 11 12

1617

-2-

90°

min

max

-3-

180º 90º 180º

-4-

180º

90º

180º

90º

-5-

2 607 990 031

0 601 079 010

2 607 001 391

-6-

-7-

LASE ADIATION. AVOID

DI ECT EYE EXPOSU E. DO

NOT stare into the laser light source. Never

aim light at another person or object other

than the workpiece. Laser light can damage

your eyes.

ead all instructions. Failure to follow all instructions

listed below may result in electric shock, fire and/or

serious injury.

Do not direct the laser beam at persons or animals and do

not stare into the laser beam yourself. This tool produces laser

class 2 laser radiation and complies with 21 CFR 1040.10 and

1040.11 except for deviations pursuant to Laser Notice No.

50, dated June 24, 2007. This can lead to persons being blinded.

General Safety Rules

WARNING

Working safely with the

measuring tool is possible only

when the operating and safety

information are read completely

and the instructions contained

therin are strictly followed.

Never make warning labels on

the Measuring tool

unrecognizable.

Never aim the beam at a

workpiece with a reflective

surface. Bright shiny reflective

sheet steel or similar reflective

surfaces are not recommended for

laser use. Reflective surfaces

could direct the beam back toward

the operator.

Take care to recognize the

accuracy and range of the

device. Measurement may not

be accurate if used beyond the

rated range of the device.

Use of controls or adjustments

or performance of procedures

other than those specified

herein may result in hazardous

radiation exposure.

The use of optical instruments

with this product will increase

eye hazards.

Have the measuring tool

repaired only through qualified

specialist using original spare

parts. This ensures that the safety

of the measuring tool is

maintained.

Do not allow children to use the

measuring tool without

supervision. They could

unintentionally blind other persons.

Do not point the laser beam at

persons or animals and do not

look into the laser beam

Safety Rules

WARNING

yourself, not even from a large

distance.

Do not use the laser viewing

glasses as safety goggles. The

laser viewing glasses are used for

improved visualization of the laser

beam, but they do not protect

against laser radiation.

Do not use the laser viewing

glasses as sun glasses or in

traffic. The laser viewing glasses

do not afford complete UV

protection and reduce color

perception.

WA NING: Be sure to read and

understand all instructions in this

manual before using this product.

Failure to follow all instructions

may result in hazardous radiation

exposure, electric shock, fire,

and/or bodily injury.

CAUTION: Use of controls or

adjustments or performance of

procedures other than those

specified in this manual, may result

in hazardous radiation exposure.

CAUTION: The use of optical

instruments with this product will

increase eye hazard.

IMPO TANT: The following labels

are on your measuring tool for

your convenience and safety. They

indicate where the laser light is

emitted by the level. ALWAYS BE

AWARE of their location when

using the level.

ALWAYS: Make sure that any

bystanders in the vicinity of use

are made aware of the dangers of

looking directly into the

measuring tool.

DO NOT remove or deface any

warning or caution labels.

Removing labels increases the risk

of exposure to laser radiation.

DO NOT stare directly at the laser

beam or project the laser beam

directly into the eyes of others.

Serious eye injury could result.

DO NOT place the measuring tool

in a position that may cause

anyone to stare into the laser

beam intentionally or

unintentionally. Serous eye injury

could result.

DO NOT use any optical tools

such as, but not limited to,

telescopes or transits to view the

laser beam. Serious eye injury

could result.

DO NOT operate the measuring

tool around children or allow

children to operate the measuring

tool. Serious eye injury could

result.

ALWAYS turn the measuring tool

“OFF” when not in use. Leaving

the measuring tool “ON” increases

the risk of someone inadvertently

staring into the laser beam.

DO NOT operate the measuring

tool in combustible areas such as

Safe Operating Procedures

-8-

in the presence of flammable

liquids, gases or dust.

ALWAYS position the measuring

tool securely. Damage to the

measuring tool and/or serious injury

to the user could result if the

measuring tool falls.

ALWAYS use only the accessories

that are recommended by the

manufacturer of your measuring

tool. Use of accessories that have

been designed for use with other

measuring tools could result in

serious injury.

DO NOT leave measuring tool “on”

unattended in any operation mode.

ALWAYS repair and servicing

must be performed by a qualified

repair facility. Repairs performed

by unqualified personnel could

result in serious injury.

DO NOT use this measuring tool

for any purpose other than those

outlined in this manual. This could

result in serious injury.

DO NOT disassemble the

measuring tool. There are no user

serviceable parts inside.

Disassembling the laser will void

all warranties on the product. Do

not modify the product in any way.

Modifying the measuring tool may

result in hazardous laser radiation

exposure.

In case of damage and improper

use of the battery, vapors may

be emitted. Provide for fresh air

and seek medical help in case

of complaints. The vapors can

irritate the respiratory system.

WA NING: Batteries can

explode or leak, and can cause

injury or fire. To reduce this risk:

ALWAYS follow all instructions

and warnings on the battery label

and package.

DO NOT short any battery

terminals.

DO NOT dispose of batteries

in fire.

KEEP batteries out of reach of

children.

Electrical Safety Procedures

-9-

Safety Warnings for Battery Chargers

Keep the battery

charger away from

rain or moisture. Penetration of

water in the battery charger

increases the risk of an electric

shock.

Do not charge other batteries. The

battery charger is suitable only for

charging Bosch lithium ion

batteries within the listed voltage

range. Otherwise there is danger

of fire and explosion.

Keep the battery charger clean.

Contamination can lead to danger

of electric shock.

Before each use, check the

battery charger, cable and plug.

If damage is detected, do not use

the battery charger. Never open

the battery charger yourself. ave

repairs performed only by a

qualified technician and only

using original spare parts.

Damaged battery chargers,

cables and plugs increase the risk

of an electric shock.

Do not operate the battery

charger on easily inflammable

surfaces (e.g., paper, textiles, etc.)

or surroundings.The heating of

the battery charger during the

charging process can pose a fire

hazard.

Before using

battery charger,

read all instructions and

cautionary markings on (1)

battery charger, (2) battery

pack, and (3) product using

battery.

Use only the charger which

accompanied your product or

direct replacement as listed in

the catalog or this manual. Do

not substitute any other charger.

Use only Bosch approved

chargers with your product. See

Functional Description and

Specifications.

Do not disassemble charger or

operate the charger if it has

received a sharp blow, been

dropped or otherwise damaged

in anyway. Replace damaged

cord or plugs immediately.

Incorrect reassembly or damage

may result in electric shock or fire.

Do not recharge battery in

damp or wet environment. Do

not expose charger to rain or

snow. If battery case is cracked

or otherwise damaged, do not

insert into charger. Battery short

or fire may result.

Charge only Bosch approved

rechargeable batteries. See

Functional Description and

Specifications. Other types of

WARNING

-10-
