en ULC Installation Manual
Control Panels ULC Installation Guide | en 3
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
1 ULC Installation Guide
During any ULC installation described within this document,
follow all rules for safe installation specified in the CEC
(Canadian Electrical Code).
Control panels
Use this guide with the following control panel models (unless
otherwise stated) and the model’s installation guide:
– B9512G/B9512G-E v3.02.006 and higher
– B8512G/B8512G-E v3.02.006 and higher
– B6512
– B5512/B5512E v3.02.007 and higher
– B4512/B4512E v3.02.007 and higher
– B3512/B3512E v3.02.007 and higher
The listed control panels are approved as ULC-S559 Fire Alarm
Signal Communicators.
Notice!
Control panel mounting
For mounting on the exterior of vault, safe, or stockroom, install
a vibration detector (s304, 8.1.5).
Combination ULC-S559 and ULC-S304 control panels
The following control panel models can be configured as
combination control panels:
– B9512G/B9512G-E v3.02.006 and higher
– B8512G/B8512G-E v3.02.006 and higher
When used a combination control panel, Fire and Burg points
must reside in separate areas.
Keypads
Use this guide with the following keypad models and the
model’s installation guide:
– B915/B915I v1.00.017 or higher
– B920 v1.05.004 or higher
Transformers
For transformers, use:
4en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
– B9512G/B9512G-E, B8512G/B8512G-E. Plug-in or hardwire
120 VAC primary, 16.5 VAC 37-40 VA secondary Class 2
Power Limited CSA/cUL listed.
– B6512, B5512/B5512E, B4512/B4512E, B3512/B3512E.
Plug-in 120 VAC primary, 18 VAC 22 VA secondary class 2
power limited CSA/cUL Listed. Hardwire 120 VAC primary,
16.5 VAC 40 VA secondary Class 2 Power Limited CSA/cUL
listed.
Refer to Compatible transformers, page 15.
Install with ULC Listed devices where applicable.
Wiring
Use unshielded cable only.
Copyright
This document is the intellectual property of Bosch Security
Systems, Inc. and is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document
are likely to be registered trademarks and must be treated
accordingly.
Bosch Security Systems, Inc. product manufacturing dates
Use the serial number located on the product label and refer to
the Bosch Security Systems, Inc. website at http://
www.boschsecurity.com/datecodes/.
1.1 Requirements
Key:
P = Programmable
R = Required
O = Optional
E = Enable
Control Panels ULC Installation Guide | en 5
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Requirements
CAN/ULC S303 -
Local
Burglary
CAN/ULC S304 -
Signal Receiving
Centre and Premise
CAN/ULC S545 -
Residential
Fire
ULC-ORD C1023 -
Household
Burglary
ULC-ORD C1076 -
Proprietary
Burglary
CAN/ULC S559 -
Fire Signal Receiving
Centres and Systems
Minimum battery
standby
24 hours 24
hours
24
hours
24 hours 4 hours 4
hours
Battery size1B6512/B5512/B4512/B3512: 1 x 12 V/7 Ah, 1 x 12 V/18
Ah, 2x 12 V/7 Ah B9512G/B8512G: 2x 12 V/18 Ah2
Entry delay ≤ 45 sec P N/A N/A ≤ 45
sec
≤ 45
sec
Exit delay ≤ 45 sec P N/A N/A ≤ 60
sec
≤ 45
sec
Minimum Bell
cutoff time
P P 5 min N/A34 min N/A
Communicator E E E E E E
AC power 4 4 4 5 4 4
Tamper
protection
R R O O O R
Enclosures For compatible enclosures, refer to Compatibilities,
page 9.
1 Select battery capacity based on calculated AUX current consumption for
the system, including all accessories.
2 Do not use 2 x 12 V/18 Ah with a Solex 16.5 VAC 37 VA transformer.
3 Bell should not sound.
4 Plug-in transformer, optional hardwired connection.
5 In ULC-S559 applications, the control panel AC input shall be hard-wired
in accordance with Sec. 32 of CSA C22.1, Canadian Electrical Code..
6en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Communication Channel Security (applicable to Commercial
Burglary/Financial installations)
Notice!
Active and passive communication
Systems are passive-only communication systems when the
only communication method is over PSTN using the B430
module.
Systems that use the on-board Ethernet, B426 module, or a
cellular module are active or passive communication systems
depending on the programmed poll rates.
Applicable for both IP and cellular communication.
Requirement Parameter
Supervision interval for IP and
Cellular communication is 200
seconds (UL)
Panel Wide Parameters > Enhanced
Communications > Receiver Supervision
Time set to 200 seconds
Supervision interval for IP and
Cellular communication is 180
seconds (ULC)
Panel Wide Parameters > Enhanced
Communications > Receiver Supervision
Time set to Custom, Poll Rate set to 89,
ACK Wait Time set to 15, and Retry Count
set to 5
Passive
levels*
Transmitters and supervision Receivers Risk
Levels
P1 For transmitters at the protected
premises and supervision of
communication channels, refer to the
figures in Fire monitoring communication
systems wiring diagrams, page 18.
D6600 or
D6100IPv6
Low
P2 Medium
P3 High
*Test the transmission on each communication channel every 24 hours.
Control Panels ULC Installation Guide | en 7
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Passive
levels*
Transmitters and supervision Receivers Risk
Levels
The telephone service should be of a type that provides for timed release
disconnect. In order to give the digital alarm communicator transmitter
(dialer) the ability to disconnect an incoming call to the protected
premises.
Active
levels*
Transmitters and
supervision
Receivers Risk
Levels
Backup
requirements
for network
equipment
A1 For transmitters at the
protected premises and
supervision of
communication channels,
refer to the figures in Fire
monitoring communication
systems wiring diagrams,
page 18.
D6600 or
D6100IPv6
Low 24 hr standby
or dialer as
backup
A2 Medium
A3 High
A4 Very
high
24 hr standby
*Check-in/polling signal required every 180 seconds.
For equipment used at the protected premises intended to facilitate
communications (hubs, routers, NIM, cable modems) 24-hour backup
power is required. Where such cannot be facilitated a secondary (backup)
communication channel is required.
For using private, corporate, and high speed data networks, network
access and domain access policies must restrict unauthorized network
access, and “spoofing” or “denial of service” attacks. Select the internet
service providers that have redundant servers/systems, backup power,
routers with firewalls enabled, and methods to identify and protect
against “denial of service” attacks.
For using public switched and wireless data networks, communication
channels must be facilitated such that the communicator will restrict
unauthorized access which could otherwise compromise security.
8en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Fire Monitoring Communication Systems
Refer to Wiring, page 15. The central station receiver must
receive fire alarms in 60 seconds and trouble signals in 90
seconds.
Type Transmitters and supervision Receivers
Passive1For transmitters at the protected premises
and supervision of communication
channels, refer to the figures in Fire
monitoring communication systems wiring
diagrams, page 18.
D6600 or
D6100IPv6
Active2
1Test the transmission on each communication channel every 24 hours.
2Check-in/polling signal required every 90 seconds.
To monitor a complete fire system, each ULC labeled intrusion system
must be connected to a ULC labeled fire alarm control panel. The system
must transmit system fire alarms, and supervisory and troubles signals to
the central station receiver.
Programming
You must follow the notes in the installation and programming
sections describing the system configurations for ULC Listed
installations.
Protecting the control panel – Burglary
The local control panel and local power supply must be
protected in one of the following ways:
– The control panel and power supply must be located within
the area of greatest protection on a tamper protected
circuit.
– When arming, each area must arm the area that is
protecting the control panel and any external power supply
running an audible device. This might require duplicate
protection armed by each area. Access to this protected
area, without causing an alarm, requires that all areas are
disarmed.
Control Panels ULC Installation Guide | en 9
Bosch Security Systems B.V. 2019.06 | 02 | F.01U.321.698
Additionally, the protected area for the control panel must be
programmed so that it cannot be bypassed, and must be
installed in accordance with CAN/ULC-S302 or CAN/ULC-S310.
User information
Inform the users of and note the following in the owner’s
manual:
– Service organization name and telephone number
– The programmed exit time
– The programmed entry time
– Safety precautions specified for the connected equipment.
1.2 Compatibilities
Accessory compatibility
The following table lists accessories that are compatible with
the control panel. An X in a column indicates the accessory is
compatible with the standard.
Model
number
Desc-
ription
CAN/ULC S303 -
Local
Burglary
CAN/ULC S304 -
Signal Receiving
Centre and Premise
CAN/ULC S545 -
Residential
Fire
ULC-ORD C1023 -
Household
Burglary
ULC-ORD C1076 -
Proprietary
Burglary
CAN/ULC S559 -
Fire Signal Receiving
Centres and Systems
Keypads
B915/
B915I*
Basic X X X X X X
B920* 2-line X X X X X X
B921C*1Capacit
ive
X X
B925F* Fire/
Burg
X X X X X
B926F* Fire X
10 en | ULC Installation Guide Control Panels
2019.06 | 02 | F.01U.321.698 Bosch Security Systems B.V.
Model
number
Desc-
ription
CAN/ULC S303 -
Local
Burglary
CAN/ULC S304 -
Signal Receiving
Centre and Premise
CAN/ULC S545 -
Residential
Fire
ULC-ORD C1023 -
Household
Burglary
ULC-ORD C1076 -
Proprietary
Burglary
CAN/ULC S559 -
Fire Signal Receiving
Centres and Systems
B930* ATM
style
X X X X X
B942/
B942W*
Touch
screen
X X X X X
Transformers, batteries, power supplies, etc.
B520 Power
supply
X X X X X
D122/
D122L
Battery
harnes
s
Suitable for use on approved applications.
D135A Low-
battery
discon
nect
Suitable for use on approved applications
D126
(12.0
VDC, 7
Ah)
Battery Suitable for use on approved applications.
D1218
(12 V,
18 Ah)
Battery Suitable for use on approved applications.
D1640-
CA
Transfo
rmer
Suitable for use on approved applications in Canada.
Autres manuels pour B9512G
5
Ce manuel convient aux modèles suivants
10
Table des matières
Autres manuels Bosch Panneau de contrôle
Bosch
Bosch HPC 400 Manuel utilisateur
Bosch
Bosch DS3MX-E-U Manuel utilisateur
Bosch
Bosch Rexroth VAM 10.2 Manuel technique
Bosch
Bosch B9512G Guide de dépannage
Bosch
Bosch D9412GV3 Manuel utilisateur
Bosch
Bosch Rexroth VAM 10.1 Manuel technique
Bosch
Bosch D7024 Manuel utilisateur
Bosch
Bosch B9512G Manuel utilisateur
Bosch
Bosch Rexroth IndraControl VDP 08.3 Manuel utilisateur
Bosch
Bosch MPC-xxxx-C Series Manuel utilisateur
Bosch
Bosch Ultima 862 Manuel utilisateur
Bosch
Bosch Rexroth IndraControl VAM 11.1 Manuel technique
Bosch
Bosch Solution 880 Manuel utilisateur
Bosch
Bosch D9412GV4 Mode d'emploi
Bosch
Bosch ICP-CC488 Manuel utilisateur
Bosch
Bosch Solution 64 Instructions de montage
Bosch
Bosch AMAX panel 2100 Manuel utilisateur
Bosch
Bosch ICP-CC404 Manuel utilisateur
Bosch
Bosch FPD-7024 Guide de démarrage rapide
Bosch
Bosch K2200 Series Manuel utilisateur
