Bosch Solution 2000 Manuel utilisateur

Control Panel

Solution 2000 / 3000

en User's Guide

Control Panel Table of contents | en 3

Bosch Security Systems, Inc. User's Guide 2017.09 | 04 | F.01U.298.028

Table of contents

1Introduction 5

2Specifications 6

3Codepad Introduction 7

3.1 Codepad 7

3.2 Codepad Indicators 7

3.3 Audible Indications 9

4Operation with TEXT LCD Codepad 10

5Operation with ICON LCD Codepad 12

5.1 Arming the System 12

5.1.1 Forced Arming 12

5.1.2 Arming in AWAY Mode 12

5.1.3 Arming in STAY Mode 1 13

5.1.4 Arming in STAY Mode 2 13

5.1.5 Programming STAY Mode 2 Bypass Zones 14

5.2 Disarming the System 14

5.3 Arming/Disarming Areas 14

5.4 User Codes 15

5.4.1 Adding User/Radio Codes 15

5.4.2 Deleting User/Radio Codes 16

5.5 Codepad Alarms 16

5.5.1 Codepad Duress Alarm 16

5.5.2 Codepad Panic Alarm 16

5.5.3 Codepad Fire Alarm 17

5.5.4 Codepad Medical Alarm 17

5.5.5 Codepad PIN Error (Access Denied) 17

5.6 Isolating Zones 17

5.6.1 Standard Isolating 17

5.6.2 Code to Isolate 17

5.7 Fault Analysis Mode 18

5.7.1 Fault Descriptions 19

5.8 Date and Time 20

5.9 Turning Outputs On/Off 20

5.10 Reset Latching Outputs 21

5.11 Telco Arm/Disarm Sequence (Call Forward On/Off) 21

5.11.1 Telco Arm Sequence 21

5.11.2 Telco Disarm Sequence 21

5.12 Testing 22

5.12.1 Horn Speaker Test 22

5.12.2 Bell Test 22

5.12.3 Strobe Test 22

5.12.4 Walk Test Mode 22

5.12.5 Test Report 23

5.13 Event Memory 23

5.14 Day Alarm 23

5.15 Codepad ID / Buzzer Tone 23

5.16 Remote Arming by Telephone 24

5.17 Domestic Dialing 24

5.17.1 Acknowledging Domestic Calls 24

4en | Table of contents Control Panel

2017.09 | 04 | F.01U.298.028 User's Guide Bosch Security Systems, Inc.

5.17.2 Programming Domestic Telephone Numbers 25

5.17.3 Disable Domestic Dialing 25

6Glossary of Terms 26

Control Panel Introduction | en 5

Bosch Security Systems, Inc. User's Guide 2017.09 | 04 | F.01U.298.028

1 Introduction

Congratulations on selecting the Solution 2000 / Solution 3000 Control Panel to protect you

and your property. To obtain the most from your unit, take time to read through this manual

and familiarize yourself with the numerous outstanding operating features of this system. In all

aspects of planning, engineering, styling, operation, convenience, and adaptability, we have

sought to anticipate your every possible requirement.

Programming simplicity and speed were some of the major considerations and we believe that

our objectives in this area were more than satisfied.

This manual explains all aspects of operating the control panel. All system parameters and

options are detailed; however, suitability is left up to the individual. Every system can be

tailored to meet all requirements quickly and easily.

6en | Specifications Control Panel

2017.09 | 04 | F.01U.298.028 User's Guide Bosch Security Systems, Inc.

2 Specifications

Temperature Range 0℃ to +50℃

Humidity 20% to 90%

Power Source TF008 Plug Pack – 240 V/18 VAC @ 1.3A

Stand-By Current 65 mA

Current Draw in Alarm Condition 115 mA

Current Draw in Alarm Condition with

Codepad

105 mA

Back-Up Battery 7 Ah/12 VDC Rechargeable Sealed Lead Acid

Battery

Supplier Code N771

Tab.2.1: Specifications

Notice!

Test the sirens, strobe, and zones at weekly intervals.

Control Panel Codepad Introduction | en 7

Bosch Security Systems, Inc. User's Guide 2017.09 | 04 | F.01U.298.028

3 Codepad Introduction

3.1 Codepad

IUI – SOL -TEXT IUI – SOL – ICON

1 2 3

5 6

STAY # AWAY

1 2 3 4 5 6 7 8

OFF

3.2 Codepad Indicators

Codepad indicator

icons

Status Definition

ZONE 1 – 8 for

Solution 2000

ZONE 1 – 16 for

Solution 3000

On Zone is unsealed.

Off Zone is sealed.

Flashing Fast (0.25 sec

on/0.25 sec off)

Zone is in alarm condition.

Flashing Slow (1 sec on/1

sec off)

Zone is manually isolated or selected to

be isolated.

AWAY

On System is armed in AWAY Mode.

Off System is not armed in AWAY Mode.

Flashing twice a sec with

STAY indicator

Setting STAY Mode 2 bypass zones.

8en | Codepad Introduction Control Panel

2017.09 | 04 | F.01U.298.028 User's Guide Bosch Security Systems, Inc.

Codepad indicator

icons

Status Definition

STAY

On System is armed in STAY Mode 1 or

STAY Mode 2.

Off System is not armed in STAY Mode 1 or

STAY Mode 2.

Flashing twice a sec Zone isolating mode

Flashing twice a sec with

AWAY indicator

Setting STAY Mode 2 zones.

Flashing once every 3 sec Day alarm status – day alarm turned on.

On System is disarmed.

MAINS

On AC MAINS power normal.

Flashing AC MAINS supply has failed.

FAULTS

On There is a system fault that needs to be

rectified.

Off The system is normal, there are no

faults.

Flashing There is a system fault that needs to be

acknowledged.

Programming Mode

Flashing These two indicators flash when you

enter Installer’s Programming Mode or

use any Master Code function.

The OFF indicator lights when the

system is disarmed and flashes when a

zone becomes unsealed when

disarmed. The indicator stops flashing

when all zones are sealed.

The ON indicator lights when the

system is armed and flashes when an

alarm occurs. The indicator is reset

after a valid User Code is entered.

Tab.3.2: Icon Indicators

Control Panel Codepad Introduction | en 9

Bosch Security Systems, Inc. User's Guide 2017.09 | 04 | F.01U.298.028

3.3 Audible Indications

The table below defines the audible indicators given out by the codepad buzzer.

Audible Indicator Definition

One short beep A button/key was pressed on the codepad, or Exit Time ended

when armed in STAY Mode 1 or STAY Mode 2.

Two short beeps The system accepted your code.

Three short beeps The requested function was executed.

One long beep Indicates the last 10 seconds of Exit Time when armed in AWAY

Mode, or the requested operation was denied or aborted.

Indicates codepad panic/fire/medical alarm operation.

One beep every sec Walk Test Mode is currently active.

One short beep every min There is a system fault waiting to be acknowledged.

One beep every 4 sec. During Auto Arming Pre-Alert Time, the warning before

automatic arming takes place.

One beep every 2 sec. During Exit Time when armed in AWAY Mode.

Tab.3.3: Audible Indicators

10 en | Operation with TEXT LCD Codepad Control Panel

2017.09 | 04 | F.01U.298.028 User's Guide Bosch Security Systems, Inc.

4 Operation with TEXT LCD Codepad

Users with authority levels enter their own user menu via TEXT LCD codepad.

1. Enable Text codepad and confirm that the system is in disarmed status.

2. To enter User Menu, enter the user code (Default = 2580) followed by the [-] key.

3. Select the menu and operate according to the menu prompt

Command

User Code

Inquire

System

Zone bypass

Test

Fault analysis1

Event recall

Cloud status

Set date & time

Day alarm

Arm/disarm seq.

Modem call init.

Domestic phone

Version display

System reset

Arm

AWAY arm

STAY1 arm

STAY2 arm

AWAY arm all

Horn speaker1

Bell test2

Strobe test

Walk test

Test report

Output on/off

Access

2User code

User name

User Allocate

User property

System

Wireless

System option

Keyfob RFID3

Home message1

[185]

[2920]

[534]

[1500]

[2500]

Zone

Zone name

STAY2 zone

[2536]

[381]

Without any codes, users can enter the general menu by pressing [-] key.
