R 30/35/40 HE combi plus Condensing boiler

6 720 610 598 - 00.2O

ZWBR 7-30 R 30 GC-Number: 47 311 79

ZWBR 11-35 R 35 GC-Number: 47 311 80

ZWBR 11-40 R 40 GC-Number: 47 311 81

6 720 610 598 GB (03.11) TD

Contents

6 720 610 598 GB (03.11)

Contents

Excellence comes as standard 4

Safety precautions 5

1General notes 7

2Controls 11

3Operatingthe Appliance 12

3.1 Preparation 12

3.2 Switching the Appliance On/Off 14

3.3 Switching on the Central Heating 15

3.4 Controlling Central Heating 15

3.5Combination Boilers: Setting Hot Water Temperature 16

3.6System boiler with Storage Tank 17

3.7Summer Mode, Hot Water Only (Combi Appliances) 18

3.8 Frost protection (Combi Appliances) 19

3.9 Fault Condition 19

4Text Display 20

4.1 General Description 20

4.2 Programming 20

4.2.1 Deleting a setting 23

4.2.2Resetting all parameters to their original settings 23

4.3 Menu structure 24

4.4Setting the time/day 25

4.4.1Setting the time and day 25

4.4.2 Holidays 25

4.5 Heating 27

Contents

6 720 610 598 GB (03.11) TD

4.5.1 Heating program 27

4.5.2 Setting the Economy temperature (if TR2 is connected) 28

4.5.3 Manual operating mode (if TR2 is not connected) 29

4.6 Hot water 30

4.6.1 Hot water program 31

4.6.2 Hot water immediately (System models) 31

4.7 i Info 32

4.8Settings 33

4.8.1 Heating (if TR 2 is connected) 33

4.8.2 Hot Water (Storage Tank, System boiler models only) 33

4.8.3 Service 33

4.9 Individual timer programmes 36

5Faultfinding 37

6Tipsonsaving energy 38

7General Information 39

8Maintaining your appliance 40

9Service 40

10 Fault or breakdown 41

11 Your guarantee 42

12 Guarantee registration 43

13 Operating Instructions Quick Reference 44

Excellence comes as standard

6 720 610 598 GB (03.11)

Excellence comes as standard

Thank you for purchasing an R 30/R 35/R 40 condensing appli-

ance.

The R 30/R 35/R 40 Series has been developed by the Heat Sys-

tems Ltd. Group and the strictest quality control standards are

demanded throughout every stage of production.

Indeed, the Heat Systems Ltd. Group have led the field in innova-

tive appliance design and performance for many years.

The result is that your new R 30/R 35/R 40appliance offers you

the very best of everything – quality, efficiency, economical run-

ning costs, proven reliability and value for money.

What’s more, you also have the assurance of our no nonsense

2yearparts and labour guarantee.

And it’s backed up by Worcester Heat Systems Ltd. - Offering a

complete maintenance scheme to keep your boiler operating at

peak condition and efficiency.

No wonder that more and more people are agreeing that when it

is gas, it has to be a Worcester Heat Systems Ltd. Condensing

appliance.

Benchmark

The “Benchmark” initiative is the new code of practice to encour-

age the correct installation, commissioning and servicing of

domestic central heating boilers and system equipment.

The “log-book” is a vital document that must be completed by the

installer at the time of installation. It confirms that the boiler has

been installed and commissioned according to the manufacturers

instructions.

Without the completion of the “log-book”, manufacturers may

refuse to respond to a call–out from a householder, who will be

advised that he or she must call back the installer, who has not ful-

filled his obligations to record the information required by the ini-

tiative.

Safety precautions

6 720 610 598 GB (03.11) TD

Safety precautions

Gas Safety (Installation and Use) Regulations 1998

It is the law that all gas appliances are installed by a competent

person in accordance with the above regulations. Failure to install

appliances correctly could lead to prosecution. It is in your inter-

est, and that of safety, to ensure compliance with the law.

If you smell gas:

BTurn off gas service cock at the meter.

BOpen all doors and windows.

BDo not operate any electrical switches.

BDo not smoke.

BExtinguish any naked flames.

BCall your gas company.

If you smell fumes from the appliance:

BSwitch off appliance.

BOpen windows and doors.

BInform your heating engineer.

Fitting and modifications

BFitting of the appliance or any modifications to the appliance

may only be carried out by a competent person.

BFlue systems must not be modified in any way.

Maintenance

BWe recommend that you take out a maintenance contract

with a competent installer and have the appliance serviced at

regular intervals.

BEnsure that your Service Engineer uses only genuine spare

parts!

Safety precautions

6 720 610 598 GB (03.11)

Combustible materials

BDo not store or use any combustible materials (paper, thin-

ners, paints etc.) in the vicinity of the appliance.

Health and safety

BThis appliance contains no asbestos products.

BThere is no potential hazard due to the appliance being electri-

cally unsafe.

BThere are no substances used in the construction that are a

potential hazard in relation to the COSHH Regulations (Con-

trol of Substances Hazardous to Health Regulations 1988).

Ventilation Air/Ambient Air

BKeep ventilation air/ambient air free of corrosive substances

(e. g. halogenated hydrocarbons which contain chlorine or flu-

orine compounds). In this way corrosion can be prevented.

General notes

6 720 610 598 GB (03.11) TD

1General notes

To get the best from your appliance please read these instructions

carefully.

Sealed heating systems

The appliance is fitted to a sealed heating system which is pre-

pressurised. Your installer will tell you of the minimum and maxi-

mum pressure which must be indicated on the pressure gauge.

Check regularly that the pressure is maintained and contact your

installer or maintenance engineer if there is a permanent signifi-

cant drop in the pressure. If the system loses pressure it should

be repressurised and the cause of the fall investigated.

Central heating systems

During the first few hours of operation of the central heating sys-

tem, check that all radiators are being heated at an even rate. If the

top of a radiator is at a lower temperature than the bottom then it

should be vented by releasing air through the venting screw at the

top of the radiator. Ask your installer to show you how this is done.

Repeated venting will reduce the quantity of water in the system

and this must be replenished for safe and satisfactory operation

of the appliance.

Should water leaks be found in the system or excessive venting is

required then a service engineer must be contacted to inspect the

installation and rectify any fault.

Only additives that are compatible with aluminium may be used in

the system. Any incompatible additive used will invalidate the

guarantee.

Condensate drain

This is a condensing appliance and the terminal will, at times, give

out a plume of water vapour. This is quite normal.

The appliance produces quantities of condense which is dis-

charged regularly through the siphon.

General notes

6 720 610 598 GB (03.11)

Clearances

Your installer will have provided adequate space around the appli-

ance for safety and servicing access. Do not restrict this space

with the addition of cupboards, shelves etc. next to the appliance.

Room thermostat

A room temperature controller may be fitted to control the central

heating. Refer to the instructions supplied with the thermostat for

information of siting and setting.

Cylinder thermostat - System boilers

The cylinder thermostat should be set to 60°C which will be sat-

isfactory for bathing/washing in normal circumstances.

Thermostatic radiator valves

It is recommended that this type of valve is fitted to all the radiators

except one, usually the radiator where the room temperature con-

troller is fitted. They should conform to the requirements of

BS2767:10.

Showers, bidets, taps and mixing valves – Combination

Boilers

Standard hot and cold taps and mixing valves must be suitable for

operating at mains pressure. Thermostatically controlled or pres-

sure equalising shower valves will guard against the flow of water

at too high a temperature.

Hot and cold mains fed water can be supplied directly to an over-

rim flushing bidet subject to local water company requirements.

Left-hand side 10 mm

Right-hand side 10 mm

In Front 600 mm

Above Casing (Vert. Flue) 200 mm

Above Flue Turret 30 mm

Below 200 mm

Table 1

General notes

6 720 610 598 GB (03.11) TD

With all mains fed systems the flow of water from individual taps

will vary with the number of outlets operated simultaneously and

the cold water mains supply pressure to the property.

Flow balancing using “ball-o-fix” type valves is recommended to

avoid an excessive reduction in flow to individual outlets.

For further information contact Worcester Heat Systems Ltd.

Technical Services Department.

Hot and cold flow – Combination Boilers

The flow of water demanded from both hot and cold service out-

lets is dependent upon the mains supply, it may not be possible in

some installations to operate all outlets simultaneously.

Water mains failure – Combination Boilers

If there is a failure of the mains water supply then no water will be

available at a tap or shower until the mains supply is restored. The

appliance will still operate in the central heating mode.

Use in hard water areas – Combination Boilers

In exceptionally hard water areas a device to prevent scale forma-

tion may be fitted. Installation of a scale inhibitor assembly should

be in accordance with the requirements of the local water com-

pany. An isolating valve should be fitted to allow for servicing.

Alternatively the maximum temperature of the domestic hot water

may be reset to about 45 °C which will reduce the risk of scale

formation in these hard water areas.

Ventilation

This is a room sealed appliance and does not require any air for

combustion from inside the house. If the appliance is fitted into a

cupboard or a compartment is built around the appliance after

installation then the compartment must be separated from the

boiler space by a perforated non-combustible partition as

described in BS 6798.

Notwithstanding the requirements of BS 6798, there is no need

for ventilation openings to be provided in the compartment

because of the low heat loss from the casing.

General notes

6 720 610 598 GB (03.11)

Do not allow the flue terminal fitted on the outside wall to become

obstructed or damaged.

Pump

The pump is a fully modulating type to which the parameters have

been set by the manufacturer and must not be adjusted.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bosch Chaudière

Bosch

Bosch Worcester Greenstar Utility ErP+ 32/50 Manuel utilisateur

Bosch

Bosch Worcester Greenstar 24i junior Manuel utilisateur

Bosch

Bosch WH17 Manuel utilisateur

Bosch

Bosch Worcester Danesmoor Utility Regular ErP+... Guide de l'utilisateur

Bosch

Bosch TR4000 18 EB Manuel utilisateur

Bosch

Bosch Condens 7000 WP Manuel utilisateur

Bosch

Bosch ZBR16-3A Manuel utilisateur

Bosch

Bosch Greenstar Series Mode d'emploi

Bosch

Bosch WORCESTER Danesmoor Utility Regular 2022+... Guide de l'utilisateur

Bosch

Bosch Condens 8300i W Manuel utilisateur

Bosch

Bosch GB125 Manuel utilisateur

Bosch

Bosch KM3211WH Manuel utilisateur

Bosch

Bosch SSB800 SA Mode d'emploi

Bosch

Bosch GWH C 920 ES Manuel utilisateur

Bosch

Bosch Uni Condens 8000 F Manuel utilisateur

Bosch

Bosch C950ES Manuel utilisateur

Bosch

Bosch Tronic 1000 T Manuel d'utilisation

Bosch

Bosch Buderus SB625WS Manuel utilisateur

Bosch

Bosch Worcester Greenstar Utility Manuel utilisateur

Bosch

Bosch Worcester Greenstar CDi Conventional Series Manuel utilisateur

Bosch

Bosch FS 100 Manuel utilisateur

Bosch

Bosch Worcester GREENSTAR CDi CLASSIC REGULAR ErP... Guide de l'utilisateur

Bosch

Bosch Worcester GREENSTAR HEATSLAVE EXTERNAL 12/18 Manuel utilisateur

Bosch

Bosch WORCESTER DANESMOOR UTILITY 12/14 Guide de l'utilisateur

Manuels Chaudière populaires d'autres marques

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuel utilisateur

Radijator

Radijator BIO max 23.1 Manuel utilisateur

Brunner

Brunner BSV 20 Manuel utilisateur

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuel utilisateur

Potterton

Potterton 50e Fiche technique

UTICA BOILERS

UTICA BOILERS TriFire Manuel utilisateur

Joannes

Joannes LADY Series Manuel

ECR International

ECR International UB90-125 Manuel d'instructions

Froling

Froling FHG Turbo 3000 Manuel utilisateur

Froling

Froling P4 Pellet 8 - 105 Manuel utilisateur

U.S. Boiler Company

U.S. Boiler Company K2 Manuel utilisateur

Henrad

Henrad C95 FF Manuel utilisateur

NeOvo

NeOvo EcoNox EF 36 Manuel utilisateur

Potterton

Potterton PROMAX SL 12 Manuel utilisateur

Eco Hometec

Eco Hometec EC 25 COMPACT Manuel utilisateur

Viessmann

Viessmann VITODENS 200 Mode d’emploi

Baxi

Baxi Prime 1.24 Manuel utilisateur

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuel utilisateur
