BOREA PastLS1 Manuel utilisateur
PastLS1 Qseven carrier
board for Rakun LS1
$HeadURL: https://svn.borea.si/svn/docs/rakun/rakun_pastls1/B01088/docs/ astLS1_DS.fodt $
$Rev: 1047 $ $Date: 2016-04-07 10:34:34 +0200 (čet, 07 apr 2016) $
Version 1.1
TABLE OF CONTENTS
1 GENERAL....................................................................................................... 7
1.1 About this document....................................................................................7
1.2 Revision history........................................................................................... 7
2 INTRODUCTION............................................................................................. 8
2.1 Device overview.......................................................................................... 8
2.2 Features...................................................................................................... 8
3 INSTALLATION GUIDE................................................................................. 10
4 ARCHITECTURE........................................................................................... 12
4.1 Block diagram........................................................................................... 12
4.2 USB connection........................................................................................ 12
4.3 UART connection...................................................................................... 13
5 JUMPERS......................................................................................................14
5.1 Boot select jumper 15............................................................................. 14
5.2 USB direction jumpers 8 and 11........................................................... 14
5.3 USB mode jumpers 12 and 13..............................................................15
5.4 UART to USB selection jumpers 16 and 17.......................................... 15
6 LED INDICATORS......................................................................................... 16
7 CONNECTOR DETAILS................................................................................ 17
7.1 Qseven connector 7................................................................................ 18
7.2 ower supply connector SW1................................................................... 21
7.3 Ethernet connector CON1......................................................................... 21
7.4 Micro SD card connector J1...................................................................... 22
7.5 I2C connector 3...................................................................................... 22
7.6 SATA connector J6.................................................................................... 23
7.7 SATA power connector 18....................................................................... 23
7.8 HDMI connector 1................................................................................... 24
7.9 USB 3.0 HOST connector J4.....................................................................25
7.10 USB OTG connector J5...........................................................................25
7.11 Mini CI-e connector 2..........................................................................26
7.12 Quicc Engine connector 10................................................................... 27
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
7.13 G IO1/EC3 connector 9....................................................................... 28
7.14 G IO2/EC2 connector 14..................................................................... 29
7.15 MikroBUS connector 4+ 5....................................................................30
7.16 UART connector 6.................................................................................30
7.17 Debug console connector J7................................................................... 31
7.18 AUX SerDes connectors J8, J2, J3.........................................................31
8 APPENDIX A: PHY OARD ADD-ON OARD..............................................33
8.1 Architecture............................................................................................... 33
8.2 Jumpers.................................................................................................... 34
8.2.1 Ethernet Mode jumper 1.....................................................................34
8.2.2 Address jumper 2............................................................................... 34
8.3 LED indicators........................................................................................... 34
8.4 Connector details...................................................................................... 35
8.4.1 EC connector 4.................................................................................. 35
8.4.2 Ethernet connector 5.......................................................................... 35
9 APPENDIX : MIKRO US SLOT................................................................. 36
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
ILLUSTRATION INDEX
Illustration 2.1: astLS1........................................................................................ 8
Illustration 3.1: Installation...................................................................................10
Illustration 4.1: Block diagram............................................................................. 12
Illustration 4.2: USB connection.......................................................................... 13
Illustration 4.3: UART connection........................................................................ 13
Illustration 5.1: osition of jumpers..................................................................... 14
Illustration 6.1: LED indicator.............................................................................. 16
Illustration 7.1: osition of connectors.................................................................17
Illustration 7.2: osition of connectors.................................................................17
Illustration 8.1: HYBoard add-on....................................................................... 33
Illustration 8.2: Block diagram of HYBoard....................................................... 33
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
INDEX OF TABLES
Table 1.1: Revision history.................................................................................... 7
Table 3.1: Default jumper positions..................................................................... 10
Table 5.1: Boot select jumper 15.......................................................................14
Table 5.2: USB direction jumpers 8 and 11.....................................................15
Table 5.3: USB mode jumpers 12 and 13....................................................... 15
Table 5.4: UART to USB selection jumpers 16 and 17...................................15
Table 6.1: LED indicators.................................................................................... 16
Table 7.1: Qseven edge connector type.............................................................. 18
Table 7.2: Qseven edge connector pinout........................................................... 20
Table 7.3: ower supply connector type..............................................................21
Table 7.4: ower supply connector pinout...........................................................21
Table 7.5: Ethernet connector type......................................................................21
Table 7.6: Ethernet connector pinout...................................................................21
Table 7.7: Ethernet LEDs.................................................................................... 21
Table 7.8: Micro SD card connector type............................................................22
Table 7.9: Micro SD card connector pinout..........................................................22
Table 7.10: I2C connector type........................................................................... 22
Table 7.11: I2C connector pinout......................................................................... 22
Table 7.12: SATA connector type........................................................................ 23
Table 7.13: SATA connector pinout..................................................................... 23
Table 7.14: SATA power connector type..............................................................23
Table 7.15: SATA power connector pinout........................................................... 23
Table 7.16: HDMI connector type........................................................................ 24
Table 7.17: HDMI connector pinout..................................................................... 24
Table 7.18: USB 3.0 connector type.................................................................... 25
Table 7.19: USB 3.0 connector pinout................................................................. 25
Table 7.20: USB OTG connector type................................................................. 25
Table 7.21: USB OTG connector pinout.............................................................. 25
Table 7.22: Mini CIe connector type..................................................................26
Table 7.23: Mini CIe connector pinuot...............................................................26
Table 7.24: QUICC Engine connector type..........................................................27
Table 7.25: QUICC Engine connector pinout.......................................................27
Table 7.26: G IO1/EC3 connector type.............................................................. 28
Table 7.27: G IO1/EC3 connector pinout........................................................... 28
Table 7.28: G IO2/EC2 connector type.............................................................. 29
Table 7.29: G IO2/EC2 connector pinout........................................................... 29
Table 7.30: Microbus connector type...................................................................30
Table 7.31: Microbus connector pinout................................................................30
Table 7.32: UART connector type....................................................................... 30
Table 7.33: UART connector pinout.................................................................... 30
Table 7.34: Debug console connector type......................................................... 31
Table 7.35: Debug console connector pinout...................................................... 31
Table 7.36: AUX SerDes connector type............................................................. 31
Table 7.37: AUX SerDes 1 connector pinout....................................................... 31
Table 7.38: AUX SerDes 2 connector pinout....................................................... 32
Table 7.39: AUX SerDes 3 connector pinout....................................................... 32
Table 8.1: Ethernet mode selection jumper 1.................................................... 34
Table 8.2: UART to USB selection jumpers 16 and 17...................................34
Table 8.3: Ethernet LEDs.................................................................................... 34
Table 8.4: EC connector type.............................................................................. 35
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
Table 8.5: EC connector extended pinout...........................................................35
Table 8.6: Ethernet connector type......................................................................35
Table 8.7: Ethernet connector pinout...................................................................35
Table 9.1: Currently available Click boards from Mikroelektronika......................36
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
1 GENERAL
1.1 ABOUT THIS DOCUMENT
This document defines the hardware architecture of the RakunLS1 Qseven module.
1.2 REVISION HISTORY
Revision Date Notes
1.0 8. June 2015 Initial version
1.1 20. August 2015 Major rewrite, pinouts added
Table 1.1: Revision history
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
2 INTRODUCTION
2.1 DEVICE OVERVIEW
astLS1 is Qseven carrier board that in addition to standard Qseven features supports additional interfaces
provided by Borea RakunLS1 Qseven module.
RakunLS1 module can be strictly Qseven compliant or can be configured to expose Freescale QorIQ
specific interfaces. In such RakunLS1 module configurations modified carrier board must be used to fully
utilize module interfaces.
Illustration 2.1: PastLS1
2.2 FEATURES
Qseven slot
Supports Qseven standard 2.0 + additional proprietary pins used for QorIQ specifics, present on a
RakunLS1 board.
Ethernet Interfaces
10/100/1000Mb/s Ethernet port, IEEE1588
•2x RGMII ports (multiplexed with G IOs and other interfaces) available on pin headers
•2x SGMII ports available on debug connectors
•Ethernet add-on board for RGMII ports available. Supports 1000BaseT and 1000BaseX
US Interfaces
Single USB port. Works as:
•USB 3.0 routed to USB 3.0 connector or
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
•USB 2.0 routed to USB 3.0 connector or
•USB 2.0 routed to m CIe slot or
•USB OTG routed to USB OTG connector
SATA
SATA 3.0 with power connector 5V
HDMI Interface
HDMI 1.3
SD card
MicroSD slot. Rakun supports booting from SD
PCIe Interface
Mini CIe slot with CIe 0 lane from Qseven and USB
Normal, half and extended size supported
UARTs
Four 16450/16650 compatible UARTs with FIFOs. CMOS levels interfaces. Two of them can be routed to the
USB2UART converter.
Two additional QUICCEngine UART interfaces.
Debug console
USB to UART converter implemented on board for easier C connectivity
UART1 or UART2 from Qseven can be routed to the console
GPIO
Two G IO connectors with 26 G IO signals available
G IO1 interface is multiplexed with RGMII, CAN, USB2
G IO2 interface is multiplexed with RGMII, IEEE1588, WM
QUICCEngine
Two UCCs, supporting TDM, HDLC, Bisync, UART, Transparent …
QE interface is multiplexed with I2S, S/ DIF, G IO, HDMI.
Mikro US
MikroBus module slot for extension purposes (S I, UART, I2C). Allows connecting many of the shelf
extension boards.
Aux SerDes
Remaining three SerDes lanes from Qseven (Lane 0 is used for CIe) are available on auxiliary testing
connectors. SATA type connectors. Available interfaces:
•Up to 3x CIe
•Additional SATA
•2x SGMII
Power Supply
5V DC, 2A Input
Onboard regulators for 1.5V and 3.3V.
Typical power consumption depends on application. ower consumption without USB, Qseven board and
mini CIe board: 8mA.
Physical
hysical Dimensions: 143 × 92 mm.
Environment
Storage: -65ºC to +150ºC
Operation: -40ºC to +85ºC
Humidity: 5% to 90% Non-Condensing
Electrostatic Discharge Tolerance: 2KV
b free, ROHS compliant
astLS1 Qseven carrier board for Rakun LS1
Version 1.1
3 INSTALLATION GUIDE
Before start, perform the steps described below. Check figure 7.1 for the position of connectors and figure
5.1 for the position of jumpers.
1. Attach RakunLS1 and (optionally) HYBoard add-on as shown in figure below:
Illustration 3.1: Installation
2. Check presence of the following jumpers:
Jumper Setting Function
13 1 – 2 USB is connected to USB connectors
12 1 – 2 USB is connected to USB connectors
11 1 – 2 USB is connected to USB3.0 connector
8 1 – 2 USB is connected to USB3.0 connector
15 1 – 2 SD Boot
16 2 – 3 Console is UART2
17 2 – 3 Console is UART2
Table 3.1: Default jumper positions
3. Install uSD card with boot image to uSD slot.
4. Attach C to Console connector with USB cable. Start terminal application on C. Set it to 115200 kb/s, 8
bit, no parity, one stop bit (115200 8N1).
5. Optionally attach Ethernet, HDMI, USB.
astLS1 Qseven carrier board for Rakun LS1
Table des matières
Manuels Conseil des transporteurs populaires d'autres marques
CTJ
CTJ TX2 Manuel utilisateur
Amfeltec
Amfeltec AngelShark Series Manuel utilisateur
Advantech
Advantech CPC-2420 Manuel d'installation et d'exploitation
Bob's Space Racers
Bob's Space Racers BSR-3000 Manuel utilisateur
RTimes
RTimes Z509 Manuel utilisateur
mikroElektronika
mikroElektronika Clicker 2 Manuel utilisateur
