User Manual

Nvidia Jetson Series Carrier board

Aetina AN310

Document Change History

Version

Date

Description

Authors

2018/07/27

Initial Release.

Eric Chu

2018/11/20

Update Software & BSP part

Eric Chu

- 1 -

1. Introduction

AN310 is a small form factor carrier board. Support for NVIDIA® Jetson™ TX2 and Jetson™ TX1.

You can quickly emulate the functionality of your desired end product for software

development and hardware verification.

To build a functional prototype of your target system you will need:

•Nvidia TX1/TX2/TX2i module

(Aetina’s P/N: NSO-MD-TX1/NSO-MD-TX2/NSO-MD-TX2i)

•Nano-ITX carrier board (Aetina’s P/N: AN310)

•Power adaptor 12-19 DC/5A

Note: Partial support TX2i function.

1.1 Features

•Specifically designed for high performance and low-power envelope AI computing

Additional driver to support Embedded peripheral modules for multiple I/O expansion

capability

•On-board 1x HDMI, 2x CAN BUS and 1x Mini Card to support rich multimedia.

•Extended temperature range -40°C to 85°C

•Suitable for general robotics, UAV, industrial inspection, medical imaging and deep

learning.

•1x 60pin connector to support Aetina MIPI CSI-II adapter

1.2 Board

•8-layer printed circuit board(PCB)

•Physical dimensions: 87mm x 70mm

•High-Bandwidth Digital Content Protection (HDCP) support

- 2 -

2. Board Specification

Specification

AN310 Description

Module Compatibility

Nvidia Jetson TX1 / Nvidia Jetson TX2

GPU

Jeston TX1 :

-Nvidia MaxwellTM, 256 CUDA cores.

Jetson TX2 :

-Nvidia PascalTM, 256 CUDA cores.

CPU

Jetson TX1:

-Quad ARM® A57/2MB L2

Jetson TX2:

-HMP Dual Denver 2/2MB L2 + Quad ARM® A57/2MB L2

Jetson TX2i(Industrial Grade):

-HMP Dual Denver 2/2MB L2 + Quad ARM® A57/2MB L2

Dimension

87mm x 70mm

Display

-1 x HDMI

Audio

-HDMI Integrated

Ethernet

-1 x Gigabit Ethernet(10/100/1000)

USB

-2 x USB3.0 Type A

-1 x USB OTG Micro AB

SD CARD

-Micro SD CARD Slot

UART

-1 x UART

RS232

-1 x RS232

I2C

-1 x I2C

GPIO

-5 x GPIO

CAN Bus

-2 x CAN (TX2/TX2i support only)

Input Power

-+12-19V / 5A DC input

Operating Temperature

--40°C to + 85°C (Standard)

Storage Temperature

--40°C to + 125°C

Warranty

-14 Months

- 3 -

3. Block Diagram

3.1 Board Placement

Nvidia Jetson module

RJ-45 GbE

HDMI

GBE_MDI

RS232

Debug

UART

UART1

UART0

USB2.0 Micro AB OTG

USB3.0 x2 STACK MODE

Micro SD

CARD

USB2.0

USB_SS0/SS1

SDMMC

Power

On/Off

Reset

Recovery

Header

PWRBTN#

SYS_RESET#

FORCE_RECOVERY

FAN_PWMOUT

DP1

GPIO

GPIO_1/2/3/4/5

AT/ATX

Switch

CAN BUS

CAN1/2

VDD IN

Europblock

CSI

adapter

I2C

MIPI CSI

12nes

llLanes

UART

Optional

- 4 -

TX1/TX2 Module Connector

Compatible with Jetson TX2i/TX2/TX1

HDMI

Type A

Power Input

Euroblock connector

USB3.0

Type A

USB2.0 OTG

Micro-AB

LAN

RJ45

MIPI CSI2 extension connector

CN9

Compatible with mPCIe and mSATA

Front Panel

I2C / AC OK

Extension IO

CN21

CAN0/1

- 5 -

3.2 Mechanical Dimensions

- 6 -

4. Connectors and Pin-outs

4.1 J1

* In order to boot up the system, pleas quickly short-circuit Pin1 and Pin2.

4.2 J2

*Disable Pin1 and Pin2 can enable Auto power on function.

4.3 J4

Pin Define

Power On

GND0

Reset

GND1

Recovery

GND2

Sleep

GND3

LED+

LED-

Pin Define

AC OK

GND

SOC_LED+

GND

+3V3

I2C_GP1_DAT_3V3

GND

I2C_GP1_CLK_3V3

Pin Define

UART0_RXD_HDR_3V3

RS232_RXD

UART0_TXD_HDR_3V3

RS232_TXD

UART0_RTS_HDR_3V3

RS232_RTS

UART0_CTS_HDR_3V3

RS232_CTS

GND0

GND1

GPIO1

GND2

GPIO2

GND3

GPIO3

GND4

GPIO4

GND5

GPIO5

GND6

- 7 -

*GPIO Pin define.

H/W

Name

Sysfs GPIO(TX1)

Sysfs GPIO(TX2)

GPIO_1

GPIO15_AP2MDM_READY

Motion Interrupt (3.3V)

GPIO173

GPIO488

GPIO_2

GPIO8_ALS_PROX_INT

(3.3V)

GPIO187

GPIO388

GPIO_3

GPIO11_AP_WAKE_BT

AP Wake Bt GPIO

GPIO63

GPIO389

GPIO_4

GPIO16_MDM_WAKE_AP

Modem Wake AP GPIO

GPIO184

GPIO481

GPIO_5

GPIO20_AUD_INT

Modem Wake AP GPIO

GPIO38

GPIO397

4.4 CN21

CN21 Pin number

Define

PIN 1

CAN0H

PIN 2

CAN1H

PIN 3

CAN0L

PIN 4

CAN1L

PIN 5

CAN0_STBY

PIN 6

CAN1_STBY

PIN 7

CAN0_ERR

PIN 8

CAN1_ERR

PIN 9

CAN_WAKE

PIN 10

GND

- 8 -

5. Accessary (Optional)

ACE-CAM6C

CA-A01 6xCSI-2 Camera Carrier Board with FPC connector

E7W9000000020

AN310 Cable kit(CAN bus / UART / RS232 / Front panel / GPIO / I2C)

9Z1253232020

TX1/TX2 Active Heat Sink

9Z2XX4141010

TX1/TX2 Passive Heat Sink

7W8000000040

US Power Cord SVT 18AWG Cable 1800mm Black 105 °C

9Z3BC0000020

100-240V 60W 12V 5A Adapter

Passive Heat Sink

Active Heat Sink

Cable kit

12V/5A 60W Adapter

6 x MIPI CSI-II Camera Board
