High-Fidelity

Ceiling Speakers

Models HFCS1

and HFCS1LP

Installation and Use Manual

Product Description

Thank you for choosing Bogen’s High-Fidelity Ceiling Loudspeakers. Please familiar-

ize yourself with the product by reading and reviewing the descriptions and diagrams

in this manual.

Bogen’s coaxial 2-way hi-fi ceiling speakers deliver unsurpassed performance and

value. The HFCS1(LP)’s steel back can and front exit venting allow for deep bass

response, enhancing the quality and intelligibility of both speech and music. The

HFCS1LP uses a smaller, low-profile back can that allows for a greater range of instal-

lations.

Both speakers can be installed either in suspended ceiling structures or hard

surfaces (such as sheetrock).They come ready to install with integral swinging arm

clamps. An optional mounting bracket (TBCR) is available for additional support

(recommended for all suspended ceiling applications).The bracket can also be used

for new construction ceilings, providing a cutout guide behind the sheetrock surface

and as a C-ring to stiffen the edges of the cutout opening.

A variety of speaker power levels are easily selected via a front panel rotary switch.

Settings for both 70V and 100V high-impedance systems, as well as a low-impedance

(16-ohm) position, are provided.

The HFCS1(LP) features a removable snap-lock input connector, providing easy

wire connection for input as well as loop-through to the next speaker.

IMPORTANT

The HFCS1 and HFCS1LP are not outdoor speakers. Do not expose the speakers

to rain or moisture.The HFCS1 and HFCS1LP should only be installed by qualified

personnel.

Product Diagrams

Front Drawing (grille removed)

1. Coaxial Driver Assembly

2. Bass Tuning Vents (x2, HFCS1,

x1, HFCS1LP)

3. Grille Retention Groove

4. Power Tap Selection Switch

5. Mounting Clamp Screws (x4)

Rear Drawing

6. Metal Back Can

7. Snap-Lock Input Connector

8. Mounting Clamps (x4)

Rear Drawing (terminal cover)

9.Terminal Covers (2 identical halves)

10. Eyelets (x2)

11. Mounting Screws (x4)

12.Wire Exit Slot

13. Conduit Knockout (x2)

Front Drawing

(grille removed)

Rear Drawing

(terminal cover)

Installation

The HFCS1and HFCS1LP can be installed in a variety of ceiling environments.The

use of the TBCR (Tile Bridge Support Ring) accessory may be desired for many of

these.

For suspended ceilings, the use of a TBCR is strongly recommended to

help support and distribute the weight of the speaker.

In new construction installations the TBCR, installed before sheetrock, acts as a

routing template that ensures an accurate and neat hole for installation.The TBCR

can also be used as a support ring in retrofit applications to better distribute the

speaker’s clamping forces.

1. Begin by cutting a 10-¾" circular hole where the speaker will be installed. If

using a TBCR, then follow its installation instructions for the specific type of envi-

ronment the speaker is being installed in.

2. Make electrical connections to the pluggable terminal strip and plug it onto the

speaker. See Speaker Wiring section.

3. Install terminal cover plates, if necessary or desired, using 4 screws. See the

Terminal Covers section if using conduit or if it is required to secure the speaker

directly to the structure (typically for suspended ceilings).

4. Remove the speaker’s grille (if neccessary). See Speaker Grille Installation &

Removal section.

5. Set the power level using the rotary selector switch on the front panel. Refer to

the Selecting Power Levels section for instructions on selecting the power level.

6. Position the swing-out clamps so that they are against the body of the speaker

and insert the speaker into its opening in the ceiling.

7. Tighten the clamps by turning the clamping screws clockwise. Do not over-tighten

the clamps - only tighten until the speaker is fairly snug in the mounting hole. If

using an electric driver, set the clutch on the driver to the lowest setting.

8. (Re)install the speaker’s grille. See Speaker Grille Installation & Removal section.

IMPORTANT

• The HFCS1requires a minimum of 11" of vertical clearance between the

FRONT of the mounting surface and any other structure for the speaker to

fit.The HFCS1LP requires a minimum of 6-¾" of vertical clearance.

• Before cutting the full hole, use a smaller exploratory hole to determine if

there are any obstructions.

• The edge of the hole must be a minimum of 1-¼" away from any side obstruc-

tions to ensure that they will not interfere with the action of the clamps.

Speaker Wiring

All wiring should be done prior to installation

and then plugged into the rear of the speaker.

Wiring is terminated at a snap-lock input con-

nector. There are two positive and two nega-

tive terminals to accommodate daisy-chaining

of speakers in a system.

Daisy-Chaining

The snap-lock input connector allows for easy

daisy-chaining of speakers by providing a sec-

ond terminal of each polarity. See the figures

to the right and below for correct wiring for

daisy-chaining of terminals.

Speaker Polarity

Keep the same polarity terminals wired together to ensure correct speaker polari-

ty. In order to provide the best possible sound, all speakers in a system need to be

pushing out and pulling in at the same time. Therefore all must be wired with the

same polarity.

If the connections to one speaker in a system are reversed from the others, that

speaker’s movement will be out of polarity with the other speakers.This results in a

loss of low frequency response and will effect the overall performance of the system.

Terminal Covers

• The two terminal cover halves are attached to the back of the speaker using 4

screws. It is important that all 4 screws be used to mount the covers.

• A slot between the two halves allows the wire to exit the speaker while

protecting the connections.The cover's eyelets can be used to anchor the wire

using a wire tie if desired.

• If local codes require the use of a conduit for connections or strain relief of the

connections, a knockout can be removed and a proper fitting installed for the

particular situation.

• Eyelets are provided on the terminal covers to provide a means of securing the

speaker to the structure. It is important that all 4 terminal cover screws be

installed in this application.A Bogen Model CK10 cable will accomplish this.

Selecting Power Levels

The front-mounted selector switch is used to

set the appropriate power level or impedance

for your system. Using a small, flat-blade

screwdriver, turn the knob until the slot points

to the power level you require.

70V/100V Systems

Both power setting scales for 70V and 100V

systems are labeled on the speakers. On the

100V scale, the last position clockwise is marked

with a symbol. Do not use this position in

100V systems.

16-ohm Systems

The fully counterclockwise position of the setting switch is the 16-ohm position.This

setting is suitable for use with low-impedance amplifiers that typically support 4- or

8-ohm speakers.The speaker’s higher, 16-ohm impedance makes it easier to combine

multiple speakers into series-parallel networks while keeping the total system

impedance at a level suitable for low-impedance amplifiers.

Speaker Grille Installation & Removal

Installation

The speaker grille fits tightly! Push the speaker grille

in until it can go no further. Then, slap around the

edge of the grille to seat the grille.The grille is prop-

erly seated when it is flush with the edge of the bezel.

Removal

Insert a pocketknife blade between the grille and the

bezel about 1/4" deep and then gently pry the grille

upwards. Do this in multiple places around the

circumference of the grille to free the grille.

Specifications

*Half-Space Response, 16-ohm input

† Front panel, switch-selected.

SPECIFICATIONS HFCS1 HFCS1LP

Frequency Response (-10 dB)*65 Hz to 19 kHz 78 Hz to 19 kHz

LF Driver 6-1/2" (165mm) Polypropylene Cone

HF Driver 3/4" (20mm) Polycarbonate Dome

Sensitivity (1W/1M) 89 dBspl (Average 100 Hz - 10 kHz)

Impedance Ratings Low (16 ohms) / High (70V/100V)

Power Input (Max.) 75W @ 16 ohms; 32W @ 70V/100V

Power Settings (in watts)†70V: 32, 16, 8, 4, 2, 1 / 100V: 32, 16, 8, 4, 2

Baffle Material Fire-rated (94VO) ABS

Back Can Material Heavy-Gauge Plated Steel

Terminations 4 Terminal Snap-Lock Input Connector

Product Weight 9 lb. 7-3/4lb.

Speaker Dimensions 12-5/16" dia x 12" D 12-5/16" dia. x 7-3/4" D

Minimum Vertical Clearance

Requirement 11"6-

3/4"

Included Accessories Input Terminal Cover (2 Halves); (4) Screws; (1) Snap-Lock Input

Connector

Optional Accessories Tile Bridge Support Ring (TBCR); Cable Kit (CK10)

Baffle Ring & Grille Color Off-white

50 Spring Street, Ramsey, NJ 07446, U.S.A.

Tel. 201-934-8500, Fax: 201-934-9832, www.bogen.com

Accessories

TBCR (Tile Bridge Support Ring)

The TBCR is a combination tile bridge and support ring that assists in securing the

HFCS1(LP), and in distributing the weight of the speaker in various types of installa-

tions.

CK10 (Cable Kit, 10')

The CK10 is a 10-foot cable with one looped end and an adjustable cable clamp. It

is suitable for use as a safety cable (see Terminal Covers on page 3).

Limited Warranty

Bogen High Fidelity Ceiling Speakers, models HFCS1 and HFCS1LP, are warranted to

be free from defects in material or workmanship for three (3) years from the date of sale

to the original purchaser. Any part of the product covered by this warranty that, with nor-

mal installation and use, becomes defective will be repaired or replaced by Bogen, at our

option, provided the product is shipped insured and prepaid to: Bogen Factory Service

Department, 50 Spring Street, Ramsey, NJ 07446, USA. The product will be returned to

you freight prepaid. This warranty does not extend to any of our products that have been

subjected to abuse, misuse, improper storage, neglect, accident, improper installation or

have been modified or repaired or altered in any manner whatsoever, or where the seri-

al number or date code has been removed or defaced.

THE FOREGOING LIMITED WARRANTY IS BOGEN’S SOLE AND EXCLUSIVE WAR-

RANTYAND THE PURCHASER’S SOLEAND EXCLUSIVE REMEDY. BOGEN MAKES

NO OTHER WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, AND ALL

IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE ARE HEREBY DISCLAIMED AND EXCLUDED TO THE MAXIMUM

EXTENT ALLOWABLE BY LAW. Bogen’s liability arising out of the manufacture, sale or

supplying of products or their use or disposition, whether based upon warranty, contract,

tort or otherwise, shall be limited to the price of the product. In no event shall Bogen be

liable for special, incidental or consequential damages (including, but not limited to, loss

of profits, loss of data or loss of use damages) arising out of the manufacture, sale or

supplying of products, even if Bogen has been advised of the possibility of such dam-

ages or losses. Some States do not allow the exclusion or limitation of incidental or con-

sequential damages, so the above limitation or exclusion may not apply to you. This war-

ranty gives you specific legal rights, and you may also have other rights which vary from

State to State.

8/10/2004

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bogen Intervenants

Bogen

Bogen SM4T Manuel utilisateur

Bogen

Bogen NEAR Orbit OCS1 Mode d’emploi

Bogen

Bogen HFSF1 Manuel utilisateur

Bogen

Bogen IH8A Manuel utilisateur

Bogen

Bogen HFCS1LP Mode d’emploi

Bogen

Bogen MPS1B Manuel utilisateur

Bogen

Bogen FMH15T Manuel utilisateur

Bogen

Bogen Easy Design CS1EZ Manuel utilisateur

Bogen

Bogen SP58A Manuel utilisateur

Bogen

Bogen Easy Design CS1EZ Manuel utilisateur

Bogen

Bogen CSD2X2 Manuel utilisateur

Bogen

Bogen PRO BP12DSP Mode d’emploi

Bogen

Bogen Nyquist NQ-S1810CT-G2 Manuel utilisateur

Bogen

Bogen Quantum S810QIPPG8U Manuel utilisateur

Bogen

Bogen Nyquist NQ-S1810CT-G2 Feuille d'instructions

Bogen

Bogen AMT-12 Guide des dimensions

Bogen

Bogen IH-8A Manuel utilisateur

Bogen

Bogen 14018 Manuel utilisateur

Bogen

Bogen G8G Manuel utilisateur

Bogen

Bogen Bogen NEAR ORBIT OPS1 Mode d’emploi

Bogen

Bogen Quantum WBS810QIP Manuel utilisateur

Bogen

Bogen CSD1X2VR Manuel utilisateur

Bogen

Bogen SPT-5A Manuel utilisateur

Bogen

Bogen BAH Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
