Blue Sky Network D2000 Manuel utilisateur

D2000 (P/N 100340)

IRIDIUM SATELLITE PACKET DATA TERMINAL

Installation Guide

Document Part # 100341

Revision A

Blue Sky Network May 2009

Page ii D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Doc# 100341

permission of Blue Sky Network.

Blue Sky Network reserves the right to change or update specifications without notice.

Publication Date: May 2009

Information in this manual is current as of publication or revision date. Specifications and operational

details are subject to change without notice, at the discretion of Blue Sky Network, LLC.

This manual is available in PDF format at www.blueskynetwork.com, or by request at

support@blueskynetwork.com or sales@blueskynetwork.com.

www.blueskynetwork.com

Phone: +1-858-551-3894

Fax: +1-858-551-3891

1298 Prospect Street, Suite 1D

La Jolla, CA 92037

May 2009 Blue Sky Network

100322 D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Page iii

REVISION HISTORY

Revision Number

Date

Author

Document

Number

Notes

May 2009

Randy Warner / Kelly

Musgrove

100341

Configuration

Update

Blue Sky Network May 2009

Page iv D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Doc# 100341

TABLE OF CONTENTS

INTRODUCTION .............................................................................................................1

APPLICATION ..................................................................................................................1

OVERVIEW ......................................................................................................................1

SYSTEM DESCRIPTION & OPERATION .......................................................................2

D2000 NETWORK DESCRIPTION.......................................................................................2

IRIDIUM SATELLITE NETWORK...........................................................................................3

GPS SATELLITE NAVIGATION SYSTEM ..............................................................................3

D2000 OVERVIEW..........................................................................................................4

SPECIFICATIONS..............................................................................................................4

FEATURES ......................................................................................................................4

ANTENNA CONFIGURATIONS:............................................................................................4

FRONT PANEL .................................................................................................................5

BACK PANEL ...................................................................................................................5

INSTALLATION .................................................................................................................5

ANTENNAS ......................................................................................................................8

AVIATION ANTENNA (AT1621-62W-SMAF-SMAF-000-03-26-NM):..................................8

AVIATION ANTENNA SPECIFICATIONS ................................................................................9

MARINE ANTENNA (AT1621-162W-SMAF-SMAF-000-03-26-NM):................................10

MARINE ANTENNA SPECIFICATIONS ................................................................................11

LAND ANTENNA (AT1621-262W-SMAF-SMAF-000-03-26-NM): ...................................12

LAND ANTENNA SPECIFICATIONS ....................................................................................13

ANTENNA & ANTENNA CABLE INSTALLATION ....................................................................14

ANTENNA CABLE ROUTING CONSIDERATIONS ..................................................................14

D2000 WIRING DIAGRAM ..............................................................................................15

POWER INPUT AND ACCESSORIES...................................................................................16

POWER CONNECTIONS ..................................................................................................16

POWER OPTIONS ........................................................................................................17

POWER-UP TEST .........................................................................................................19

SERVICE ACTIVATION.................................................................................................20

PRODUCT WARRANTY................................................................................................21

May 2009 Blue Sky Network

Doc# 100341 D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Page 1

INTRODUCTION

Application

This guide is applicable to the following components:

Part Number

Component Description

100340AD

D2000AD Packet Data Terminal (aviation firmware)

100340MD

D2000MD Packet Data Terminal (land/mobile firmware)

100297

D2000 Power Cigarette Lighter Adapter

100298

D2000 Power Supply Adapter (110/220V sources)

AT1621-62W-TNCF-

SMAF-000-03-26-NM

Iridium/GPS Combined Antenna (aviation)

AT1621-62W-SMAF-

SMAF-000-03-26-NM

Iridium/GPS Combined Antenna (land/mobile)

AT1621-162W-SMAF-

SMAF-000-03-26-NM

Iridium/GPS Combined Antenna (marine)

Notes

Overview

The information contained in this manual describes the features, functions, technical

characteristics, components, installation considerations and setup procedures for

Blue Sky Network’s D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL.

Information, drawings and wiring diagrams contained in this manual are

intended as a reference for engineering planning only. Drawings and wiring

diagrams contained herein do not represent any specific vehicle or vessel

installation. It is the installer’s responsibility to create installation drawings

specific to the asset.

Blue Sky Network May 2009

Page 2D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Doc# 100341

SYSTEM DESCRIPTION & OPERATION

D2000 Network Description

The Blue Sky Network’s D2000 is an Iridium Satellite Packet Data Terminal. Roughly

the size of a car stereo, it can easily be installed on a marine vessel, land vehicle, or

aircraft for instant global tracking and 2-way data communications.

All data services are managed by the customer through our web-based SkyRouter

portal. SkyRouter offers global asset tracking, account management features, such

as user authorization, asset settings, messaging and billing information. Access to

SkyRouter is highly secure and password protected.

May 2009 Blue Sky Network

Doc# 100341 D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Page 3

Iridium Satellite Network

The Iridium Satellite System is the only current provider of truly global, mobile

satellite voice and data solutions with complete coverage of the Earth including

oceans, airways and Polar regions. Through a constellation of 66 low-earth orbiting

(LEO) satellites operated by Boeing, Iridium delivers essential communications

services to and from remote areas where terrestrial communications are not

available. The service is perfectly suited for the transportation industry as well as

industrial applications such as heavy construction, defense/military, emergency

services, maritime, mining, forestry, oil and gas.

Satellites ............................... 66 (plus 6 in-orbit backup satellites)

Orbital Planes ....................... 6

Orbit Altitude ......................... 485 miles (780 kilometers)

Inclination of Orbital Plane .... 86.4 degrees

Orbital Period........................ 100 minutes, 28 seconds

Satellite Weight..................... 1,500 pounds (689 kilograms)

Spot Beams .......................... 48 per satellite (30 miles in diameter per beam)

GPS Satellite Navigation System

The Global Positioning System (GPS) is a worldwide radio-navigation system

formed from a constellation of satellites and their ground stations.

GPS uses these "man-made stars" as reference points to calculate positions

accurate to a matter of meters.

GPS satellite signals are processed in a GPS receiver, enabling the receiver to

compute position, velocity and time. GPS receivers have been miniaturized to just a

few integrated circuits, and are becoming very economical, which makes the

technology accessible to virtually everyone.

While there are thousands of civil users of the GPS system world-wide, the system

was designed for the U. S. military. GPS is funded and operated by the U. S.

Department of Defense (DOD).

Blue Sky Network May 2009

Page 4D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Doc# 100341

D2000 OVERVIEW

Specifications

Height 3.0 inches (7.62 cm)

Width 6.5 inches (16.51 cm)

Depth 7.5 inches (19.05 cm)

Weight 2.2 pounds (1Kg)

Power Requirements 10VDC - 33VDC

Nominal Current 0.5A Continuous, 1.5A Peak (12V, battery charging)

Operating Temperature Range -20 degrees C to + 60 degrees C

Altitude Up to 50,000 feet

Iridium SBD Frequency L-Band

GPS Frequency L-Band

Laptop/PDA I/O Ethernet Port

Sensor Data I/O 1 Serial Port (RS-232)

Antenna Connectors:

Aviation: TNC jack for Iridium, SMA jack for GPS

Land: SMA jack for Iridium, SMA jack for GPS

Marine: SMA jack for Iridium, SMA jack for GPS

Vibration and Humidity Tests SAE 1455

Features

Worldwide - The D2000 is a truly global satellite communication solution. Using the

Iridium Satellite Network, Blue Sky has exploited an efficient and cost effective

communication delivery system.

GPS - The D2000 has an integrated 12 channel GPS receiver. Users can define

position reporting intervals and other operating parameters either locally, or remotely

through the SkyRouter portal.

Asset Tracking - Directly from our web-portal, SkyRouter (www.blueskynetwork.com),

users can view the location of one or a fleet of mobile assets. Tracking data can also

be utilized by third party tracking solutions.

Portability - The D2000 may be used as a portable unit.

Antenna Configurations:

The D2000 100340AD version (for aviation) utilizes a TNC jack for the Iridium

antenna and an SMA jack for an amplified GPS antenna for enhanced signal levels

in challenging RF environments.

The D2000 100340MD version (for land/marine) utilizes a SMA jack for the Iridium

antenna and an SMA jack for an amplified GPS antenna for enhanced signal levels

in challenging RF environments.

May 2009 Blue Sky Network

Doc# 100341 D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Page 5

Front Panel

A. 4-Way Menu Navigation

Button

B. LCD Display Screen

C. Quick Position / Mayday

Alert Button

D. OK (Enter) Button

E. Numerical Pad

F. Clear Button

Back Panel

100340- Combined Antenna Configuration

A. Antenna Connector (TNC)

B. Antenna Connector (SMA)

C. Circular Power Connector

D. Power Switch

E. Serial Port

F. Maintenance Port (for

firmware upgrade)

G. Ethernet Port

Installation

The location of the D2000 is at the discretion of the user, but consideration should be given

to space, environmental conditions and distance from the antenna. The Optional U-Shaped

Mounting Bracket (p/n 100307-3, below) can be provided with the unit and should assist the

installer with placing the unit in a dashboard, ceiling or other available space (please call

Blue Sky Network for ordering information). The D2000 has a pair of notches in each side

(top and bottom) of the unit, allowing a solid link of the Mounting Bracket on the D2000.

Blue Sky Network May 2009

Page 6D2000 IRIDIUM SATELLITE PACKET DATA TERMINAL Doc# 100341

The Mounting Bracket can be assembled directly into any surface with the appropriate

mounting holes, or can be used with the optional suction mount, as shown below. Using the

suction mount option with the D2000 allows for higher mechanical flexibility and better

visualization of the front panel.
