Black Box ACXC8FHS Manuel utilisateur

STEP X - Name of Step

24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BL ACKBOX.COM

DKM FXC COMPACT SERIES

KVM

SWITCHES

QUICK START GUIDE

STEP 1 - Check the Package Contents

WHAT'S INCLUDED

Your package should contain the following

items. If anything is missing or damaged,

contact Black Box Technical Support

at 877-877-2269 or info@blackbox.com

• COMPACT KVM MATRIX SWITCH

• (1) POWER CORD PER BUILT-IN POWER

SUPPLY UNIT

• (1) RJ-45/RS-232 ADAPTER

• MOUNTING ACCESSORIES

• THIS QUICK START GUIDE

OPTIONAL: DOWNLOAD USER MANUAL

For product specifications and regulatory

information, refer to the User Manual. You can

download this document from our web site.

1. Go to www.blackbox.com

2. Enter the part number (for example,

ACXC8FHS) in the search box.

3. Click on the product in the “Product Results”

page.

4. Click on the “Support” tab on the product

page, and select the document you wish to

download.

If you have any trouble accessing the Black Box

site to download the manual, you can contact

our Technical Support at 877-877-2269

or inf[email protected]

STEP 2 - Set Up the System Matrix

FIRST-TIME USERS

If you are a first-time user, we recommend that

your set up the system in a single room. This

will allow you to identify and solve any cabling

problems and experiment with your system

more conveniently.

MATRIX SETUP

1. Connect a CON unit to an I/O port of the

matrix switch for its configuration.

2. Connect a keyboard, mouse, and monitor to

the CON unit.

3. Connect the matrix switch and the CON unit

to the power supply.

4. Open the On-Screen Display (OSD) using the

following hotkey combination:

Press <Left-Shift> twice rapidly, then <o> and

subsequently <esc>.

5. Log in to the Configuration menu with

administrator rights using the default account:

user name: admin

password: admin

6. Configure your system as required.

7. Optional: Establish a network connection

between the matrix switch and the software

tool so you can set an extended configuration

(refer to the user manual).

Default IP adress: 192.168.100.99

DHCP is deactivated by default.

NOTE: When installing several matrices at the

same time, we strongly recommend that you

install them in sequence and assign unique IP

addresses to avoid IP address conflicts.

NOTE: If you wish to enable the Java Tool,

you will need to enable this in the

Configuration Menu under System.

STEP 3 - Set Up the Extenders

EXTENDER SETUP

1. Connect the CON units to the matrix using

the interconnect cables (CATx).

2. Connect the CON units to the input devices

to be used (for example, keyboard and mouse).

3. Connect the power supply units to the CON

units.

4. Check the basic function of the CON unit by

opening the OSD with the hotkey combination:

Press <Left-Shift> twice rapidly, then <o>

Close the OSD by pressing <Left-Shift> +

<esc>

5. Connect the source (computer, CPU) to the

CPU unit of the extender using the provided

connection cables.

6. Connect the CPU unit to the matrix using the

interconnect cables (CATx).

7. Connect the power supply units to the CPU

units.

8. Start the system.

STEP 4 - Contact Technical Support (Optional)

BEFORE CONTACTING TECH SUPPORT

Make sure you have read the user manual, and

then installed and set up your KVM matrix as

recommended.

SUPPORT CHECKLIST

Please have the following information

available before you call:

1. Company name, phone number, and email.

2. Type and serial number of the device (see

bottom of device).

3. Nature, circumstances, and duration of the

problem.

4. Involved components (such as graphic

source/CPU, OS, graphic card, monitor,

USB-HID/USB 2.0 devices, interconnect

cable).

5. Results from any testing you have done.

SHIPPING CHECKLIST

1. To return your device, contact Black Box

Technical Support at 877-877-2269 or info@

blackbox.com to get a Return Material

Authorization (RMA) number.

2. Package your device carefully, preferably

using the original box. Add all pieces you

received originally.

3. Note your RMA number visibly on your

shipment.

NOTE: Devices sent without an RMA number

cannot be accepted.

CONTACTING TECHNICAL SUPPORT

Via phone: 877-877-2269

Via email: info@blackbox.com

STEP X - Name of Step
