Black Box ServView Manuel utilisateur
JUNE 2001
KVT109A
FREE tech support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746.
Mailing address: Black Box Corporation, 1000 Park Dr., Lawrence, PA 15055-1018
© Copyright 2001. Black Box Corporation. All rights reserved.
Customer Support Information:
1
THE SERVSWITCH™ FAMILY
Welcome to the ServSwitchTM Family!
Thank you for purchasing a BLACK BOX®ServSwitch™Brand product! We
appreciate your business, and we think you’ll appreciate the many ways that your
enhanced keyboard/video/mouse system will save you money, time, and effort.
That’s because our ServSwitch family is all about breaking away from the
traditional, expensive model of computer management. You know, the one-size-
fits-all-even-if-it-doesn’t model that says, “One computer gets one user station, no
more, no less.” Why not a single user station (monitor, keyboard, and mouse) for
multiple computers—even computers of different platforms? Why not a pair of
user stations, each of which can control multiple computers? Why not multiple
user stations for the same computer?
With our ServSwitch products, there’s no reason why not. We carry a broad line
of robust solutions for all these applications. Do you have just two PCs, and need
an economical alternative to keeping two monitors, keyboards, and mice on your
desk? Or do you need to share dozens of computers, including a mix of IBM®PC,
RS/6000®, Apple®Macintosh®, Sun Microsystems®, and SGI®compatibles among
multiple users with different access levels? Does your switch have to sit solidly on a
worktable and use regular everyday cables? Or does it have to be mounted in an
equipment rack and use convenient many-to-one cables? No matter how large or
small your setup is, no matter how simple or how complex, we’re confident we
have a ServSwitch system that’s just right for you.
The ServSwitch™family from Black Box—the one-stop answer for all your KVM-
switching needs!
*
This manual will tell you all about your new ServSwitch™ ServView, including
how to install, operate, and troubleshoot it. For an introduction to the ServView,
see Chapter 2. The ServView product code covered in this manual is:
KVT109A
2
SERVSWITCH™ SERVVIEW
TRADEMARKS USED IN THIS MANUAL
BLACK BOX and the logo are registered trademarks, and ServSwitchis a
trademark, of Black Box Corporation.
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
IBM, PS/2, and RS/6000 are registered trademarks of International Business
Machines Corporation.
Sun Microsystems is a registered trademark of Sun Microsystems, Inc. in the
United States and other countries.
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.
3
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA
RADIO-FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Shielded PC-equipment cables must be used with this equipment to maintain
compliance with radio frequency energy emission regulations and ensure a suitably
high level of immunity to electromagnetic disturbances.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
FCC/IC STATEMENTS
4
SERVSWITCH™ SERVVIEW
EUROPEAN UNION DECLARATION OF CONFORMITY
This equipment complies with the requirements of the European EMC Directive
89/336/EEC with respect to the EN 55022 (Class A) and EN 55024 standards, as
well as the Low Voltage Directive 73/23/EEC with respect to the EN 60950
standard.
5
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.
NOM STATEMENT
6
SERVSWITCH™ SERVVIEW
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
7
TABLE OF CONTENTS
Contents
Chapter Page
1. Specifications ............................................................................................. 8
2. Introduction ............................................................................................. 10
3. Safety Considerations .............................................................................. 11
4. Installation ................................................................................................ 12
4.1 The Complete Package ..................................................................... 12
4.2 Assembling and Installing the ServView .......................................... 13
4.3 Connecting the Cables ..................................................................... 16
5. Operation ................................................................................................. 18
5.1 Getting Started .................................................................................. 18
5.2 The TFT’s On-Screen Display .......................................................... 19
6. Maintenance and Troubleshooting ........................................................ 21
6.1 Maintenance ...................................................................................... 21
6.2 Calling Black Box .............................................................................. 21
6.3 Shipping and Packaging ................................................................... 22
8
SERVSWITCH™ SERVVIEW
1. Specifications
Compliance: CE (EN 55022 Class A, EN 55024, EN 60950);
CISPR 22 Class A, CISPR 24, IEC 950;
FCC Part 15 Subpart J Class A, IC Class/classe A
Interface: Proprietary composite of VGA compatible video and
IBM PS/2 compatible keyboard and two-button mouse
Resolution: Up to 1024 x 768 noninterlaced
Refresh Rate: Up to 75 Hz
Maximum
Distance: Up to 25 ft. (7.6 m) to the attached CPU or KVM switch
depending on cable quality
Connectors: Both rear-mounted;
(1) HD15 female for composite I/O;
(1) IEC 320 male power inlet
Maximum
Altitude: Operating: 10,000 ft. (3048 m);
Storage: 30,000 ft. (9144 m)
Temperature
Tolerance: Operating: 32 to 104˚F (0 to 40˚C);
Storage: –4 to +140˚F (–20 to +60˚C)
Humidity
Tolerance: Operating: 10 to 90% noncondensing;
Storage: 5 to 95% noncondensing
Audible Noise: Less than 60 dBA
Thermal
Dissipation: Up to 25,000 BTU/hr. maximum
Enclosure: Steel and high-impact plastic (rackmount rails are steel)
Grounding: Chassis-grounded
Fuse: 250 V, 2.0 A maximum
9
CHAPTER 1: Specifications
Power: From utility-power (mains) outlet, through detachable
power cord and IEC 320 male inlet, to internal
transformer:
Input voltage: 100 to 250 VAC;
Input frequency: 50 to 60 Hz, single-phase;
Input current: From 0.5 amps at 250 VAC to 0.7 amps
at 100 VAC;
Consumption: 24 watts maximum
Size: Chassis only:
1.65"H x 16.5"W x 17.5"D (4.2 x 41.9 x 44.5 cm);
Chassis with mounting-rail assembly attached:
1.65"H x 17.5"W x 24"D (4.2 x 44.5 x 61 cm)
Weight: 12.5 lb. (5.7 kg)
