Black Box MTU9230 Manuel utilisateur

Black Box Network Services

464 Basingstoke Road, Reading, Berkshire, RG2 0BG

Tech: 0118 965 6000 | www.blackbox.co.uk

BLACK BOX®

White

with

5th black

diamond

User Manual

E3/DS3 Fibre Extender

CONTENTS

1noitcudortnI1

1tscudorp

ehttuobA1.1

2ytefaS2.1

2ytilibitapmoCcitengamortcelE3.1

2noitaralceD22055NE4.1

2noitaralceDCCF5.1

2evitceriDEEEW6.1

3ylppuSrewoP7.1

5erudecorPnoitallatsnI&gnikcapnU2

5.tnempiuqeehttcepsnidnakcapnU1.2

2. 2 Optional rackm 5erudecorpgnitnuo

6tinuCFehtpurewoP3.2

2. 4 Connect the Custom 6.stropkrowteNdnare

2. 5 Optionally connec 6yalermralaehtt

retrevnocerbiFot3SD/3E

7lenapraeR1.3

7rotcennocrewoP1.1.3

7ya

lermralalanretxE2.1.3

8smralADEL3.1.3

3.1.4 Unbalanced BNC E3/DS-3 G.703 Customer port 8

9sehctiws-tib&lenapesaB2.3

013-SD/3E1.2.3

01pooLtseT2.2.3

01tuodliuBeniL3.2.3

3.2.4 Scrambler - current version serial no 60128 and above 10

3.2.5 Scrambler - old version serial no 60127 and below 10

snoitacificepS

3.3

Introduction

1 INTRODUCTION

1.1 About the products

The Black Box range of Fibre Converters tabulated below provide a simple economic

way of converting from one type of transmission medium to another. Examples include:

Electrical signals on copper to optical signals on fibre, and vice-versa.

Single-mode optical fibre to multimode and vice-versa.

Model Customer Interface Line Interface

MTU9230 E3/DS-3 G.703 via BNC 75 ohm Dual SC Multi-mode fibre

MTU9240 E3/DS-3 G.703 via BNC 75 ohm Dual SC Single-mode short haul fibre

Introduction

The MTU9230/MTU9240 have been designed to be plug and go, conforming to appropriate

standards, physically very compact, and rack mountable in sets of 2 using a dual face plate,

or 18 units in a rack mount kit for large installations. FC units often enable substantial

savings to be made in cable costs by utilising the cheapest effective cable type without

incurring the costs of additional router or switch interfaces.

We are continually developing new models, so if the interface combination required

is not listed in this guide, please contact us.

1.2 Safety

Where electrical signal cabling is connected to the units, do not connect to cabling which

would be required by BS6701 to be equipped with over-voltage protection. Electrical signal

ports should only be connected to SELV ports on other equipment in accordance with

EN60950 clause 2.3.

1.3 Electromagnetic Compatibility

In order to ensure EMC compliance all electrical signal and data cables and connectors must

use a screened connector shell with a screened cable. The cable screen must be terminated

to the screened connector shell and not connected to any pins of the connector. Failure to

use the correct connector may compromise EMC compliance.

1.4 EN55022 Declaration

FC units are a Class A product. In a domestic environment it may cause radio interference

in which case the user may be required to take adequate measures.

1.5 FCC Declaration

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will be required to correct

the interference at its own expense.

1.6 WEEE Directive

Both units are covered by Directive 2002/96/EC (OJ:L37/24/2003) on waste electrical and

electronic equipment (The WEEE Directive). Units must therefore not be disposed of in

a standard landfill.

Introduction

1.7 Power Supply

Both units are powered by an internal mains-fed power supply. The mains input voltage is

100-250VAC, 50/400Hz. An alternative -48VDC power supply is available on all units as a

custom order item. The power consumption of each model in the range is shown below,

together with the current consumption over the operating voltage ranges.

An alternative -48VDC or -24 VDC power supply is available on most units as a custom order

item.

The supply definition of the -48VDC supply is minus 36 to minus 72 VDC, 200-100 mA. DC

power is supplied via a 3 pin Buccaneer socket fitted to the rear panel.

The supply definition of the -24VDC supply is minus 12 to minus 36 VDC, 700-125 mA. DC

power is supplied via a 2 pin Buccaneer socket fitted to the rear panel. The surrounding label

is cloured blue for the -12V/-24 option.

A Buccaneer plug is supplied with the unit for customer’s own wiring. The connections are

labelled on the rear panel of the unit as shown in the schematics below.

Pin1

-48V

Pin5

Pin3

VDC IN

40-72V/200mA

Pin2

DC IN

12-24V/700mA

Pin5

12-24V

Figure 1. 3 Buccaneer DC sockets

The units must be connected to safety earth for correct operation. The FC power supply

should be connected to a supply socket that is physically located close to the unit and is

easily accessible.

The power consumption of the units is shown below, together with the current

consumption over the operating voltage ranges.

power consumption

Product Watts Power

Consumption

100-250 VAC

Current Range

-36 to -72 VDC

Current Range

-12 to -36 VDC

Current range

MTU9230 & MTU9240 6.0 60 - 25 200 - 100 600-200

Introduction

Safety Notes: Excessive voltages are present inside the unit. There are no user serviceable

parts inside the unit, and the cover should not be removed by unqualified personnel. The unit

must not be exposed to damp or condensing conditions.

Unpacking & Installation Procedure

2 UNPACKING & INSTALLATION PROCEDURE

2. 1 Unpack and inspect the equipment.

The carton should contain a single unit and for UK models, a power cable.

If there is any visible damage, do not attempt to connect the device. Contact your Supplier

or Black Box Technical support for advice and assistance.

2. 2 Optional rackmounting procedure

Rackmounting kit Part No MTU9000M-RACK may be used to mount two FC units side by

side in a 19” rack. First remove the two rear panel screws securing each unit’s lid. Fasten the

2 units to the rack mount adaptor plate using the screws that you have removed, as shown in

the illustrations below.

ALARM

EXT

Alarm

STM-1 MULTIMODE

STM1 G.703

Remove screw Remove screw

Figure 2.1 Unit rear panel

Then secure the rack mounting plate complete with the two units to the 19” rack using

the locating holes at the ends of the adaptor plate. The recessed twin unit rack will accept

either AC or DC FC models.

ALARM

EXT

Alarm

STM-1 MULTIMODE

STM1 G.703

LARM

EXT

Alarm

STM-1 MULTIMODE

STM1 G.703

Figure 2.2 Twin unit rack mounting

If you wish to use the optional 18 unit mounting rack, instructions are provided with the rack,

part number MTU9000M-18RACK-AC (AC Mains) or MTU9000M-18RACK-DC (DC Supply).

Unpacking & Installation Procedure

2. 3 Power up the units

The unit requires 100-250 VAC, 50-60 Hz AC supply, drawing less than 50mA when

operating.

Alternatively, a -48VDC power supply is available as another option for all models.

The DC power options are -36 to -72 VDC (-48VDC), or -12 to -36 VDC (-24VDC), using a

Buccaneer type connector. See Section1 for further details on power consumption.

Plug a power cable into the back of the unit and switch on. Check that the Alarm LED on

the rear panel is illuminated red or green, flashing or steady. If the LED is off, power is not

being supplied to the unit.

2. 4 Connect the Customer and Network ports.

When all the ports are connected, the Alarm LED should give a steady Green display. Set-

up information for both models is contained in each section of this manual.

2. 5 Optionally connect the alarm relay

Many units offer an Alarm relay to provide an external warning of problems which may

arise. The interface is presented on an RJ45 connector, and offers both normally open and

normally closed contacts. Maximum contact rating is 1.5 Amp at 125 VDC. Normal is the

powered up, non-alarmed state. The connections are shown in the table below:

Figure 2.3 Alarm relay pinout

Pin Contact

1 Normally closed

2 Normally open

3 Common

4 Not connected

5 Not connected

6 Not connected

7 Not connected

8Not connected

E3/DS3 to Fibre converter

5 E3/DS3 TO FIBRE CONVERTER

5.1 Rear panel

The E3/DS-3 line is connected via a pair of BNC connectors on the rear panel. The fibre

connection is via a Dual SC connector on the rear panel.

ALARM

EXT

MULTIMODE

LINE

Alarm

GRN

Figure 5.1 MTU9230 rear panel

5.1.1 Power connector

AC mains power is supplied via an IEC connector. The units have an integral power supply

operating over the range 100-250 VAC. It draws less than 50mA of current when operating.

Alternative -48 VDC and -24VDC power supplies are available. See Section 1 of this manual

for further details of this option and consumption data.

The units must be connected to safety earth for correct operation. The MTU9230 power

supply should be connected to a supply socket that is physically located close to the unit and

is easily accessible.

5.1.2 External alarm relay

Both models offer an Alarm relay to provide an external warning of problems which may

arise. The interface is presented on an RJ45 connector, and offers both normally open and

normally closed contacts. Maximum contact rating is 1.5 Amp at 125 VDC. Normal is the

powered up, non-alarmed state. The connections are shown in the table below:

Figure 5.2 Alarm relay pinout

Pin Contact

1 Normally closed

2 Normally open

3 Common

4 Not connected

5 Not connected

6 Not connected

7 Not connected

8 Not connected

E3/DS3 to Fibre converter

5.1.3 LED Alarms

There is a single multi-state alarm LED mounted on the rear panel. Its status options are

shown below:

Figure 5.3 LED status

5.1.4 Unbalanced BNC E3/DS-3 G.703 Customer port

The customer equipment is connected to the BNC connectors at the rear of the unit:

Figure 5.4 BNC connection

Cable lengths should be restricted to those defined below:

Figure 5.5 Cable lengths

Note: The total maximum attenuation of each of the cables attached to the BNC (network)

port must not exceed 6dB when measured at 1024 MHz. The frequency/attenuation

characteristic of the cables attached to this port shall follow a root frequency law.

LED Status Indication

Off No mains power present

Red steady E3/DS-3 Alarm

Red/Off flashing E3/DS-3 and Fibre Alarm

Green/Off flashing Fibre Alarm

Green steady Status OK

Pin Function

Tip Signal

Ring Shield

Cable E3 Max Length

(metres)

DS-3 Max Length

(metres)

UR202 180 155

RG59U 150 130

BT2002 160 140

BT2003 165 140

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Extenseur

Black Box

Black Box VX1000 Series Manuel utilisateur

Black Box

Black Box ACU1007A Manuel utilisateur

Black Box

Black Box MT195A-T1 Manuel utilisateur

Black Box

Black Box ServSwitch ACU5010A Manuel utilisateur

Black Box

Black Box IC400A Manuel utilisateur

Black Box

Black Box ServSwitch Duo KV6EXTB-R2 Manuel utilisateur

Black Box

Black Box AC1000A-R3 Manuel utilisateur

Black Box

Black Box IC406A Manuel utilisateur

Black Box

Black Box Extreme T LB323A Manuel utilisateur

Black Box

Black Box ACX1MR Series Manuel utilisateur

Black Box

Black Box AC1059A Manuel utilisateur

Black Box

Black Box AVS-HDB-TX Manuel utilisateur

Black Box

Black Box Wizard MultiMedia Plus Manuel utilisateur

Black Box

Black Box ServSwitch ACU5013A Manuel utilisateur

Black Box

Black Box Abeo G.703 LAN Instructions d'installation et d'utilisation

Black Box

Black Box ACU5800A Wizard DP Instructions de montage

Black Box

Black Box ServSwitch ACS235A Manuel utilisateur

Black Box

Black Box LB510A-R2 Manuel utilisateur

Black Box

Black Box ACX1MR Series Manuel utilisateur

Black Box

Black Box LB320A Manuel utilisateur

Black Box

Black Box AVS-HDB-4TX Manuel utilisateur

Black Box

Black Box LBPD01A-KIT Manuel utilisateur

Black Box

Black Box LB300A Manuel utilisateur

Black Box

Black Box AC163A Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
