Black Box AVX-DVI-TP-100M Manuel utilisateur

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.

call 724-746-5500) • FREE technical support 24 hours a day, 7 days

a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:

Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

BL A C K B O X®

Extends your PC DVI transmission distance up to

330 feet (100 m).

Includes two compact units: transmitter and receiver.

Extended Range DVI-D Extender with Audio and RS-232

AVX-DVI-TP-100M

724-746-5500 | blackbox.com

Page 2

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks

of BB Technologies, Inc.

UL is a registered trademark of Underwriters Laboratories.

Any other trademarks mentioned in this manual are acknowledged

to be the property of the trademark owners.

724-746-5500 | blackbox.com Page 3

FCC and IC RFI Statements/NOM Statement

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY

CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy,

and if not installed and used properly, that is, in strict accordance with the

manufacturer’s instructions, may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A computing

device in accordance with the specifications in Subpart B of Part 15 of FCC rules,

which are designed to provide reasonable protection against such interference

when the equipment is operated in a commercial environment. Operation of this

equipment in a residential area is likely to cause interference, in which case the

user at his own expense will be required to take whatever measures may be nec-

essary to correct the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise

emission from digital apparatus set out in the Radio Interference Regulation

of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de classe A prescrites dans le

Règlement sur le brouillage radioélectrique publié par Industrie Canada.

Normas Oficiales Mexicanas (NOM)

Electrical Safety Statement

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

724-746-5500 | blackbox.com

Page 4

NOM Statement

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,

etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más

allá a lo descrito en las instrucciones de operación. Todo otro servicio

deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe

colocar en libreros o gabinetes que impidan el flujo de aire por los orificios

de ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo

del tipo descrito en el instructivo de operación, o como se indique en el

aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las

lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no

sea usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

724-746-5500 | blackbox.com Page 5

NOM Statement

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com

Page 6

Safety Instructions

The Extended Range DVI-D Extender has been tested for conformance to safety

regulations and requirements, and has been certified for international use.

However, like all electronic equipment, the extender should be used with care.

Please read and follow the safety instructions to protect yourself from possible

injury and to minimize the risk of damage to the unit.

• Follow all instructions and warnings marked on this unit.

• Do not attempt to service this unit yourself, except where explained in this

manual.

• Provide proper ventilation and air circulation and do not use near water.

• Keep objects that might damage the device away from it and be sure to place

this unit on a stable surface.

• Use only the power adapter and power cords and connection cables designed

for this unit.

• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the

power to the device before cleaning.

724-746-5500 | blackbox.com Page 7

Table of Contents

1. Specifications ................................................................................................8

2. Overview ..............................................................................................10

2.1 Introduction......................................................................................10

2.2 Features ............................................................................................10

2.3 What’s Included................................................................................10

2.4 Hardware Description....................................................................... 11

2.4.1 Transmitter............................................................................ 11

2.4.2 Receiver.................................................................................13

3. Hardware Installation .................................................................................15

4. Cable ..............................................................................................16

Appendix. Troubeshooting...............................................................................17

A.1 Contacting Black Box........................................................................17

A.2 Shipping and Packaging ...................................................................17

724-746-5500 | blackbox.com

Page 8

Chapter 1: Specifications

1. Specifications

Audio Support — Stereo 2-channel analog audio

Approvals — Converter Unit: FCC, CE, RoHS, WEEE

Power Supply: UL®, FCC

Compliance — HDMI, DVI 1.1, HDCP

Computer Interface — DVI-D

ESD Protection — Human body model: ±19 kV (air-gap discharge) and ±12 kV

(contact discharge);

Core chipset: ±8 kV

Equalization — Automatic

Heat Dissipation — 3.41 BTU/hr.

Input DDC Signal — 5 volts p-p, TTL

Input TMDS Signal — 1.2 volts p-p

Maximum Distance between TX and RX — 328 ft. (100 m) using

CAT5e/CAT6/CAT7 cable

Operating System Support — All known operating systems, all known

hardware that supports/follows the HDMI/DVI spec

Rackmount Kits — Wallmount brackets and hardware included

RS-232 Support — Transmitter: Acts as DCE device;

Receiver: Acts as DTE device;

RX and TX: additional control signals not supported

Video Bandwidth — 340 MHz (10.2 Gbps)

Video Support — 480p/720p/1080p60/1920x1200 @ 60 Hz/

1600 x 1200 @60 Hz

Connectors — Transmitter: (1) DVI F input, (1) 3.5-mm audio input, (1) 2.5-mm

barrel connector for power, (1) RJ-45 8P8C output, (1) RS-232 DB9 F for

serial extension;

Receiver: (1) DVI F output, (1) 3.5-mm audio output, (1) 2.5-mm barrel

connector for power, (1) RJ-45 8P8C input, (1) RS-232 DB9 M for serial

extension

Indicators — (2) LEDs on both the transmitter and receiver: Power, Link

Temperature Tolerance — Operating: 32 to 104° F (0 to 40° C)

Operating Humidity — 90%, noncondensing

724-746-5500 | blackbox.com Page 9

Chapter 1: Specifications

Power — Source: Desktop power supply; Power supply cord length: 4 ft.

(12.8 m);

For both the transmitter and receiver: AC input: 100–240 VAC, 50–60 Hz,

0.8 A,

Consumption: 20 W;

Output: 5 VDC, 4 A

Size — Each unit: 1.3"H x 4.1"W x 3"D (3.2 x 10.5 x 7.6 cm)

Weight — Each unit: 0.9 lb. (0.4 kg)

724-746-5500 | blackbox.com

Page 10

Chapter 2: Overview

2. Overview

2.1 Introduction

The Extended Range DVI-D Extender extends your PC DVI transmission distance

up to 330 ft. (100 m) at up to 1920 x 1200 or 1080p resolution. With the

extender, users can transmit high quality digital video from PC applications over

one inexpensive CAT5e/6/7 LAN cable to a remote monitor or projector, instead

of using short and expensive DVI cables. You can disconnect the monitor, place

it in a remote location, and reconnect it without rebooting the operating sys-

tem. The XR DVI Extender also supports serial port RS-232 (TXD and RXD)

control.

The extender includes two compact units: a transmitter and a receiver. The

transmitter unit connects to your PC DVI output and serial port, such as COM1,

and the receiver unit connects to a monitor with serial control (such as touch

panels). While successfully connected, the two LED lights on the RJ-45 connec-

tor will blink.

2.2 Features

• Complies with DVI 1.0 standard.

• Supports EDID and HDCP bypass.

• Extends the transmission length from the sources up to 330 ft. (100 m) at

1920 x 1200 or 1080p resolutions.

• Features auto equalization.

• Supports HDTV resolutions and VESA standards.

• Supports serial port RS-232 (TXD and RXD) control.

• Direct plug-in at TX and wall-mounting with screws at RX.

2.3 What’s Included

Your package should contain the following items. If anything is missing or

damaged, contact Black Box Technical Support at 724-746-5500 or

info@blackbox.com.

• (1) DVI Transmitter with built-in wallmount brackets

• (1) DVI Receiver with built-in wallmount brackets

• (2) 5-VDC, 4-A power supplies with power cords

• (4) screws

• This user manual

Table des matières

Autres manuels Black Box Extenseur

Black Box

Black Box AVX-HDMI2-FO-HDB-KIT Manuel utilisateur

Black Box

Black Box Wizard AVU5001A Manuel utilisateur

Black Box

Black Box SerSwitch ACS260A-U-MM Manuel utilisateur

Black Box

Black Box ACS2228A Fiche technique

Black Box

Black Box ServSwitch ACU1022A Manuel utilisateur

Black Box

Black Box ServSwitch ACUR004A Manuel utilisateur

Black Box

Black Box LWE100A Manuel utilisateur

Black Box

Black Box ServSwitch Wizard ACU5012A Manuel utilisateur

Black Box

Black Box AC1031A-R2-2 Manuel utilisateur

Black Box

Black Box EMERALD PE SH Manuel utilisateur

Black Box

Black Box LMC5178A Manuel utilisateur

Black Box

Black Box Wizard ACU50 A Series Manuel utilisateur

Black Box

Black Box IC401A Manuel utilisateur

Black Box

Black Box KVX Series Instructions d'utilisation

Black Box

Black Box ServSwitch II ACS250A Manuel utilisateur

Black Box

Black Box ACS4001A series Fiche technique

Black Box

Black Box LBPS310A-KIT Manuel utilisateur

Black Box

Black Box ServSwitch Wizard ACU5050A-R2 Manuel utilisateur

Black Box

Black Box MDR3242A Manuel utilisateur

Black Box

Black Box VX-HDB2-KIT Manuel utilisateur

Black Box

Black Box LB200A Manuel utilisateur

Black Box

Black Box ServSwitch ACX300 Manuel utilisateur

Black Box

Black Box AC555A Manuel utilisateur

Black Box

Black Box LR0005A-KIT Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
