MODEL/MODELO

❍ D2030

❍ D2530

DIGITAL ADVANTAGE® IRON

PLANCHA DIGITAL ADVANTAGE®

Customer Care Line:

USA 1-800-231-9786

Accessories/Parts (USA)

1-800-738-0245

For online customer service

and to register your product, go to

www.prodprotect.com/applica

Servicio para el cliente:

México 01-800 714-2503

Accesorios/Partes (EE.UU)

1-800-738-0245

Para servicio al cliente y para

registrar su garantía, visite

www.prodprotect.com/applica

When using your iron for the ﬁrst time, you may

notice water residue inside the unit. This is normal.

Cuando use su plancha por primera vez, notará que

hay agua adentro de la plancha. Esto es normal.

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS

When using your iron, basic safety precautions should always be followed,

including the following:

❍ READ ALL INSTRUCTIONS BEFORE USING

❍ Use iron only for its intended use.

❍ To protect against a risk of electric shock, do not immerse the iron in

water or other liquids.

❍ The iron should always be turned to the minimum (min) setting

before plugging or unplugging from outlet. Never yank cord to

disconnect from the outlet; instead grasp plug and pull to disconnect.

❍ Do not allow cord to touch hot surfaces. Let iron cool completely

before putting away. Loop cord loosely around iron when storing.

❍ Always disconnect iron from electrical outlet when filling with water

or emptying, and when not in use.

❍ Do not operate iron with a damaged cord, or if the iron has been

dropped or damaged. To avoid the risk of electric shock, do not

disassemble the iron; take it to a qualified service person for

examination and repair, or call the appropriate toll-free number

on the cover of this manual. Incorrect reassembly can cause a risk

of electric shock when the iron is used.

❍ Close supervision is necessary for any appliance being used by or

near children. Do not leave iron unattended while connected or on an

ironing board.

❍ Burns can occur from touching hot metal parts, hot water or steam.

Use caution when you turn a steam iron upside down or use the

surge of steam – there may be hot water in the reservoir. Avoid rapid

movement of iron to minimize hot water spillage.

❍ The iron must not be left unattended while it is connected to the

supply mains.

❍ The plug must be removed from the socket-outlet before the water

reservoir is filled with water.

❍ The iron must be used and rested on a stable surface.

❍ When placing the iron on its stand, ensure that the surface on which

the stand is placed is stable.

❍ The iron is not to be used if it has been dropped, if there are visible

signs of damage or if it is leaking.

ENGLISH

SPECIAL INSTRUCTIONS

❍ To avoid a circuit overload, do not operate another high-wattage

appliance on the same circuit.

❍ If an extension cord is absolutely necessary, a cord rate at

15-ampere cord should be used. Cords rated for less amperage

may overheat. Care should be taken to arrange the cord so that it

cannot be pulled or tripped over.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the

other). To reduce the risk of electric shock, this plug is intended to fit

into a polarized outlet only one way. If the plug does not fit fully into

the outlet, reverse the plug. If it still does not fit, contact a qualified

electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw

to prevent removal of the outer cover. To reduce the risk of fire or

electric shock, do not attempt to remove the outer cover. There are

no user-serviceable parts inside. Repair should be done only by

authorized service personnel.

Note: If the power supply cord is damaged, it should be replaced by

qualified personnel; in Latin America, by an authorized service center.

Product may vary slightly from what is illustrated.

1. Spray nozzle

2. Water-fill opening

3. Digital display

4. Power / temperature setting button

5. Steam button

6. Spray button

7. Power indicator light

8. Heel rest

9. Water tank

10. Variable steam dial



















How to Use

This appliance is intended for household use only.

GETTING STARTED

• Remove any labels, stickers or tags attached to the body or soleplate of the iron.

Important: For warranty verification, do not remove the line cord sticker.

• Please go to www.prodprotect.com/applica to register your warranty.

Note: Use ordinary tap water for ironing. Do not use water processed through a home

softening system.

Important: For optimum performance, let the iron stand for 90 seconds before

beginning to iron.

FILLING WATER TANK

1. Tilt the iron and using a clean measuring cup, pour water into water-fill opening

until the water reaches the MAX mark on the water tank. Refill as needed.

Note: If you need to add water while ironing, unplug the iron and follow above steps.

SELECTING A TEMPERATURE SETTING

1. Plug in the iron. The power indicator light turns on and a beep sounds;

Temperature setting 1 (ACRYL) appears in the digital display.

2. To select a temperature setting, press the temperature setting button below the

digital display until you reach your desired setting–from 1 to 7.

3. The digital display will show the setting number and

fabric type; these will flash on the display until the

set temperature is reached (A).

4. When your set temperature is reached, the iron will

keep once and the word “READY” will appear in

the display. The temperature setting, number and

“READY” will be displayed as you iron.

Note: See the fabric guide on the iron and read garment's label

to help you determine which temperature setting to use (B).

Tip: If unsure of a garment’s fiber, test a small area (on an

inside seam or hem) before ironing.

5. To change temperature settings while ironing, just push the

temperature button. When a lower setting is selected, fabric

type will flash until the iron temperature has lowered to the

correct level for that setting. The iron will beep once and

"READY" will appear in the bottom of the display window.

IRONING WITH STEAM

1. For steam ironing, be sure the water tank is filled to MAX.

2. Turn the variable steam dial to the appropriate steam

setting for your fabric (C).

Note: See the fabric guide on the iron and read garment's label

to help you determine which steam setting to use.

3. For optimum performance when using steam, stand iron

on its heel rest until the selected temperature setting is

reached.

4. When finished ironing, turn the variable steam dial to the steam off setting.

ENGLISH

SURGE OF STEAM

Horizontal

Tip: Use to remove stubborn creases.

1. With the water tank filled to the MAX mark, set temperature setting and variable

steam to the appropriate settings for your fabric. See fabric guide on the iron and read

garment's label to help you determine fabric type.

2. For best performance, press the steam button at 5-second intervals.

3. When finished ironing, turn the variable steam dial to the steam off setting and

unplug the iron.

Important: Always stand the iron on its heel rest when powered on but not in use.

Vertical

Tip: Use for removing wrinkles from hanging clothes and drapes.

1. With the water tank filled to the MAX mark, set temperature setting and variable

steam to the appropriate settings for your fabric. See fabric guide on the iron and read

garment's label to help you determine fabric type.

2. Hang the garment to be steamed on a clothes hanger. (Curtains or drapes can be

steamed once they are hung.)

3. Hold the iron close to, but not touching, the fabric.

4. Pull the fabric tight in your free hand and pump the steam button as you move the

iron over the fabric.

5. When finished ironing, turn the variable steam dial to the steam off setting and

unplug the iron.

DRY IRONING

1. To iron without steam, set the variable steam dial to steam off .

USING SPRAY

Tip: Use to dampen tough wrinkles at any setting.

1. Be sure the iron is filled with water.

2. On first use, pump the spray button several times.

10-MINUTE AUTO SHUTOFF

The automatic shutoff feature in your iron works as follows:

• Once the iron reaches appropriate temperature, it will turn off after 10 minutes of

inactivity. Before turning off, the iron will beep once and “AUTO OFF” will flash in the

digital display.

• Once turned off, the digital display will go dark, but the words “AUTO OFF” will

continue to show in the display.

• As soon as you pick up the iron, it will beep once and start heating again to the set

temperature setting. Wait for iron to reheat completely before resuming operation.

• To turn the iron off manually, press the power / temperature setting button for

2 seconds; this can be done from any temperature setting.

EMPTYING WATER TANK (OPTIONAL)

Note: It is not necessary to empty the water after each use.

1. Unplug the iron and let it cool.

2. To empty the water, hold the iron over a sink with the tip pointing down. Water will

empty out the water-fill opening.

ENGLISH

Care and Cleaning

This product contains no user serviceable parts. Refer service to qualified service

personnel.

CLEANING

1. Make sure iron is unplugged and has cooled completely. Wipe the soleplate

and outer surfaces with a soft cloth dampened with water and mild household

detergent. Never use abrasives, heavy-duty cleansers, vinegar or scouring pads

that may scratch or discolor the iron.

2. After cleaning, steam iron over an old cloth to remove any residue from the steam

vents.

AUTO CLEAN® SYSTEM

To keep the steam vents free of any buildup, follow these instructions when the word

“CLEAN” appears in the digital display:

1. Fill the water tank well below the MAX line. Plug in the iron.

2. Press the temperature setting button to 6 and stand the iron on its heel rest. Allow

it to heat about 3 minutes.

3. Unplug the iron and hold over a sink with the soleplate facing down.

4. Move and hold the variable steam dial in the CLEAN position. Be careful, as

hot water and steam will come out of the steam vents.

5. Continue to hold the variable steam dial to CLEAN until all the water has emptied.

If necessary, rock iron side-to-side and front-to-back.

6. When finished, move the variable steam dial to steam off , stand the iron on its

heel rest and plug it in. Heat for about 2 minutes to dry out any remaining water.

STORING

1. Unplug the iron and let it cool completely.

2. Check that the variable steam dial is set to steam off .

3. Store iron on its heel rest. Storing iron on its soleplate can cause leaks or damage.

NEED HELP?

For service, repair or any questions regarding your appliance, call the appropriate

800 number on the cover of this book. Please DO NOT return the product to the

place of purchase. Also, please DO NOT mail product back to manufacturer, nor

bring it to a service center. You may also want to consult the website listed on the

cover of this manual.

TWO-YEAR LIMITED WARRANTY

(Applies only in the United States and Canada)

What does it cover?

• Any defect in material or workmanship provided; however, Applica’s liability

will not exceed the purchase price of product.

For how long?

• Two years from the date of original purchase with proof of such purchase.

What will we do to help you?

• Provide you with a reasonably similar replacement product that is either new

or factory refurbished.

How do you get service?

• Save your receipt as proof of date of sale.

• Visit the online service website at www.prodprotect.com/applica, or call toll-

free 1-800-231-9786, for general warranty service.

• If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

• Damage from misuse, abuse or neglect

• Products that have been modiﬁed in any way

• Products used or serviced outside the country of purchase

• Glass parts and other accessory items that are packed with the unit

• Shipping and handling costs associated with the replacement of the unit

• Consequential or incidental damages (Please note, however, that some

states do not allow the exclusion or limitation of consequential or incidental

damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

• This warranty gives you speciﬁc legal rights. You may also have other rights

that vary from state to state or province to province.

is a registered trademark of The Black & Decker Corporation,

Towson, Maryland, USA

Made in People’s Republic of China

Printed in People’s Republic of China

Por favor lea este instructivo antes de usar el producto.

INSTRUCCIONES IMPORTANTES

DE SEGURIDAD

Cuando se usan aparatos eléctricos, siempre se deben respetar las

siguientes medidas básicas de seguridad:

❍ POR FAVOR LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.

❍ A fin de protegerse contra el riesgo de un choque eléctrico, no

sumerja la plancha en agua ni en ningún otro líquido.

❍ La plancha siempre debe estar en la posición de calor mínimo antes

de enchufar o desconectarla del tomacorriente. Nunca tire del cable

para desconectar la plancha del tomacorriente; sujete el enchufe y

hale con cuidado.

❍ No permita que el aparato entre en contacto con superficies

calientes. Espere que la plancha se enfríe por completo antes de

guardarla. Para guardar, enrolle el cable holgadamente en torno a

la plancha.

❍ No permita que el cable cuelgue del borde de la mesa o del

mostrador ni que entre en contacto con las superficies calientes.

❍ Siempre desconecte la plancha del tomacorriente cuando no esté en

uso y antes de llenar o vaciar el tanque de agua.

❍ No use la plancha si tiene averiado el cable, si la ha dejado caer o

presenta cualquier otro daño. Para evitar el riesgo de un choque

eléctrico, no desarme ni trate de reparar la plancha personalmente.

Acuda a un centro de servicio autorizado para que la examinen,

reparen o ajusten, o llame gratis al número correspondiente en la

cubierta de este manual. El reensamblaje o reparación incorrecta

podría ocasionar el riesgo de incendio, choque eléctrico, o lesiones

a las personas al usar el aparato nuevamente.

❍ Todo aparato eléctrico usado en la presencia de los niños o por

ellos mismos requiere la supervisión de un adulto. No desatienda la

plancha cuando esté conectada o sobre la tabla de planchar.

❍ Las partes metálicas calientes de este aparato, al igual que el agua

caliente o el vapor pueden ocasionar quemaduras. En vista de que

puede haber agua caliente en el tanque, tenga cuidado al invertir

una plancha de vapor o al bombear el botón de vapor. Evite los

movimientos rápidos de la plancha para disminuir el goteo de agua

caliente.

❍ El hierro no debe dejarse desatendido mientras esté conectado a la

red de alimentación.

ESPAÑOL

❍ El enchufe debe ser retirado de la toma de corriente antes de que el

depósito de agua esté lleno de agua.

❍ La plancha debe ser utilizada y apoyada sobre una superficie estable.

❍ Al depositar la plancha en su soporte, asegúrese de que la superficie

sobre la que se colocará el soporte es estable.

❍ El hierro no debe ser utilizado si se ha caído, si hay signos visibles de

daños o si tiene fugas.

INSTRUCCIONES ESPECIALES

❍ Para reducir la posibilidad de una sobrecarga eléctrica, no opere otro

aparato de alto consumo en el mismo circuito.

❍ Si es indispensable el uso de un cable de extensión, se debe usar uno

con régimen nominal de 15 amperios. Los cables de menor amperaje

se pueden sobrecalentar. Se debe tener cuidado de acomodar el cable

de manera que no interfiera para que nadie se tropiece ni lo pueda

halar.

CONSERVE ESTAS INSTRUCCIONES.

Este aparato eléctrico es para uso doméstico solamente.

ENCHUFE POLARIZADO

Este aparato cuenta con un enchufe polarizado (un contacto es más ancho que

el otro). A fin de reducir el riesgo de un choque eléctrico, este enchufe encaja

en un tomacorriente polarizada en un solo sentido. Si el enchufe no entra en el

tomacorriente, inviértalo y si aun así no encaja, consulte con un electricista.

Por favor no trate de alterar esta medida de seguridad.

TORNILLO DE SEGURIDAD

Advertencia: Este aparato cuenta con un tornillo de seguridad para evitar

la remoción de la cubierta exterior del mismo. A fin de reducir el riesgo de

incendio o de choque eléctrico, por favor no trate de remover la cubierta

exterior. Este producto no contiene piezas reparables por el consumidor.

Toda reparación se debe llevar a cabo únicamente por personal de servicio

autorizado.

Nota: Si el cordón de alimentación esta dañado, en América latina debe

sustituirse por personal calificado o por el centro de servicio autorizado.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Black & Decker Fer

Black & Decker

Black & Decker ALL-TEMP STEAM D6000 Instructions d'installation

Black & Decker

Black & Decker X750R Manuel utilisateur

Black & Decker

Black & Decker First Impressions ICR100 Series Instructions d'installation

Black & Decker

Black & Decker SteamXpress AS200 Instructions d'installation

Black & Decker

Black & Decker Digital Evolution D5000 Instructions d'installation

Black & Decker

Black & Decker SteamAdvantage AS770 Series Instructions d'installation

Black & Decker

Black & Decker IR1370C Manuel utilisateur

Black & Decker

Black & Decker IR34V Mise à jour du firmware

Black & Decker

Black & Decker Quick 'N Easy M305 Instructions d'installation

Black & Decker

Black & Decker XPRESS STEAM IR05XC Manuel utilisateur

Black & Decker

Black & Decker IR2010 Manuel utilisateur

Black & Decker

Black & Decker First Impressions AS900 Series Instructions d'installation

Black & Decker

Black & Decker Avant Steam F980 Instructions d'installation

Black & Decker

Black & Decker ProFinish X700 Series Instructions d'installation

Black & Decker

Black & Decker SteamAdvantage AS185 Instructions d'installation

Black & Decker

Black & Decker SteamAdvantage AS100 Series Instructions d'installation

Black & Decker

Black & Decker X750 Manuel utilisateur

Black & Decker

Black & Decker IR0175W Instructions d'installation

Black & Decker

Black & Decker PI9000 Instructions d'installation

Black & Decker

Black & Decker Digital Evolution D5000 Manuel utilisateur

Black & Decker

Black & Decker BXIR2403E Manuel utilisateur

Black & Decker

Black & Decker PRESS 'N GO IR100 Instructions d'installation

Black & Decker

Black & Decker ProFinish X800 Series Instructions d'installation

Black & Decker

Black & Decker IR1160S Instructions d'installation

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
