SRP-E300/302

Command Manual

Ver. 1.01

http://www.bixolon.com

SRP-E300/302

Ver. 1.01 BIXOLON

- 2 -

■Contents

1. Notice........................................................................................................................................................................................................3

2. Control Commands List in Alphanumeric Order...................................................................................................................................4

2-1 Command Description Items ................................................................................................................................................................6

2-2 Details of Control Commands...............................................................................................................................................................7

SRP-E300/302

Ver. 1.01 BIXOLON

- 3 -

1. Notice

This document contains proprietary information of BIXOLON Corporation and its affiliates. You may utilize the information solely for the

purpose of facilitating authorized sales and service of, or developing software and similar products for authorized use with, BIXOLON

products, provided that such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose

without the prior written permission of BIXOLON Corporation. BIXOLON has no liability for loss or damage arising from or relating to your

use of or reliance on the information in the document.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product

specifications and/or user manual content may be changed without prior notice.

SRP-E300/302

Ver. 1.01 BIXOLON

- 4 -

2. Control Commands List in Alphanumeric Order

No.

Command

Function

No.

Command

Function

Horizontal tab

ESC R

Specify an international character set

Print and line feed

ESC S

Select standard mode

Form feed (in page mode)

ESC T

Select print direction in page mode

Print and carriage return

ESC V

Turn 90°clockwise rotation mode on/off

CAN

Cancel the print data in page mode

ESC W

Set print area in page mode

DLE EOT

Transmit real-time status

ESC \

Set relative print position

DLE DC4

Generate pulse at real-time

ESC a

Set position alignment

ESC SP

Set the character right space

ESC d

Print and feed n lines

ESC !

Set print mode

ESC i

Partial cut

ESC $

Set absolute print position

ESC m

Partial cut

ESC %

Select/cancel user-defined character set

ESC p

Generate pulse

ESC &

Define user-defined character set

ESC t

Select character code table

ESC *

Specify bit image mode

ESC v

Transmit paper sensor status

ESC -

Turn underline mode on/off

ESC {

Turn upside-down print mode on/off

ESC 2

Select default line spacing

FS p

Print NV bit image

ESC 3

Set line spacing

FS q

Define NV bit image

ESC =

Select peripheral device

GS !

Select character size

ESC ?

Cancel user-defined characters

GS $

Set absolute vertical print position in

page mode

ESC @

Initialize printer

GS ( A

Execute test print

ESC D

Set horizontal tab positions

GS ( L

GS 8 L

Select graphics data

ESC E

Turn emphasized mode on/off

GS ( k

Specify and print the symbol

ESC G

Turn double-strike mode on/off

GS *

Define downloaded bit image

ESC J

Print and feed paper

GS /

Print downloaded bit image

ESC L

Select page mode

GS :

Start/end macro definition

ESC M

Select character font

GS B

Turn white/black reverse print mode on/off

SRP-E300/302

Ver. 1.01 BIXOLON

- 5 -

No.

Command

Function

GS H

Select print position of HRI characters

GS I

Transmit printer ID

GS L

Set left margin

GS V

Select cut mode and executes a partial cut

GS W

Set print area width

GS ^

Execute macro

GS a

Enable/Disable Automatic Status Back (ASB)

GS f

Select font for HRI characters

GS h

Set bar code height

GS k

Print bar code

GS r

Transmit status

GS v 0

Print raster bit image

GS w

Set bar code width

BS M

Select device font type

BS V

Select cut mode and executes a

partial/full cut

SRP-E300/302

Ver. 1.01 BIXOLON

- 6 -

2-1 Command Description Items

Command

Function:

Command function outline

Code:

Command format expressed in ASCII, hexadecimal, and decimal codes

Range:

Argument value (Setting range) for the command

Default:

Initial argument value for the command

Description:

Detailed command function description

Remarks:

Additional information about using the command

Differences:

Variations depending on the printer model

SRP-E300/302

Ver. 1.01 BIXOLON

- 7 -

2-2 Details of Control Commands

Function:

Horizontal tab

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This command moves the print position to the next horizontal tab position. If the next horizontal tab position is not

specified, this command will be void.

Remarks:

■The horizontal tab position is set by <ESC> D.

■With the underline mode turned on, the underline printing is not applied to the tab space created by this command.

Differences:

None

SRP-E300/302

Ver. 1.01 BIXOLON

- 8 -

Function:

Print and line feed

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This command prints the data in the print buffer and feeds one line based on the current set line spacing in standard

mode.

Remarks:

■In page mode, the printer does not perform actual printing, but moving only the print position to the next line.

Differences:

None

SRP-E300/302

Ver. 1.01 BIXOLON

- 9 -

Function:

Form feed (in page mode)

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This commands prints all data collected in the printer buffer In page mode. After completion of printing, the printer is

returned to standard mode.

Remarks:

■The printer is returned to standard mode after completion of printing.

■This command works in page mode enabled by ESC L.

■If the paper is positioned at the print starting position, this command is ignored, not performing actual paper feeding

operation.

Differences:

None

SRP-E300/302

Ver. 1.01 BIXOLON

- 10 -

Function:

Print and carriage return

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This command prints the data. With auto line feed enabled, it performs printing and one line feeding same as LF.

Differences:

None
