BIXOLON SRP-B300 Manuel d'instructions

Network Connection Manual

SRP-B300

THERMAL RECEIPT PRINTER

Ver. 1.00

http://www.bixolon.com

Ver. 1.00

- 2 -

SRP B300

■

Table of Contents

1. Manual Information........................................................................................................3

2. Specifications ................................................................................................................3

3. How to Connect..............................................................................................................4

4. Ethernet Test by using Windows Test Page................................................................6

5. Factory Reset...............................................................................................................13

6. Troubleshooting...........................................................................................................15

Ver. 1.00

- 3 -

SRP B300

1. Manual Information

This Network manual provides information on the connection of network with the printer.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and

quality of all our products. In following, product specifications and/or user manual content

may be changed without prior notice.

2. Specifications

CATEGORIES

FEATURE

IMPLEMENTATION

LAN

Specification Interface 10/100 Base-T All in one(Auto detection)

Protocol

DHCP Client, HTTP, ARP, ICMP, IPv4 ,TCP, UDP

Ver. 1.00

- 4 -

SRP B300

3. How to Connect

1) Checking Network Setting

After the printer has finished booting, open the printer cover and press and hold the FEED

button for 5 seconds. This will cause the interface setting confirmation mode.

Then add the paper, close the cover, and check that the following message is printed.

If the above message is printed, select Mode 1, and you will see the following LAN data.

(To select Mode 1, press the Feed button once quickly/ once long.)

Checking Interface Setting

0: Exit

1: LAN Information Print

2: LAN Factory Reset and Reboot Printer

3 or more: None

Select Modes by Feed button control

as below.

Step 1. Short-press as many times as

The mode number to choose.

Step 2. Long-press over 1 second.

*e.g. To choose Mode 2, press Feed

Button 3 times(short-short-long)

Feed Button

Cover Open Lever

Ver. 1.00

- 5 -

SRP B300

2) LAN Setting Values

Classification

Item

Remarks

Input Range

Network

Inactivity Time

TCP connection hold time

0~3600 integer

IP Assignment

Method IP Assignment Method DHCP/Manual

IP Address

Printer IP

IP Address

Subnet Mask Subnet mask IP Address

Gateway

Default Gateway

IP Address

For changing network setting values using Net configuration tool, Refer to ‘Net

configuration tool manual’.

Ver. 1.00

- 6 -

SRP B300

4. Ethernet Test by using Windows Test Page

You can use the Windows printer driver as shown below when there is no test program.

Operating systems that allow you to use the Windows printer driver are Windows, XP,

Server 2003, VISTA, 2008 Server, 7, 8, 10.

[Note]

- You can download the latest version of Windows driver from our home page.

(www.bixolon.com)

1) Double-click the Windows Driver installation file.

2) Click Install

Ver. 1.00

- 7 -

SRP B300

3) Select Installation and click Next.

4) Select Model Name and click Next

Ver. 1.00

- 8 -

SRP B300

5) Select Ethernet and click Add TCP/IP Port

6) Enter the IP address and port number, and then click Next.

Ver. 1.00

- 9 -

SRP B300

7) Click Next

8) Click Next

Ver. 1.00

- 10 -

SRP B300

9) Click Next

10) Click Finish
