BIRD O2 Manuel utilisateur

O2RECEVER

O2TRANSMITTER

Important Safety Instructions

CAUTION

This equipent has been tested and found to comply with

the limits for a Class B digital device pursuant to part 15

⑴This device may not cause harmful interference

of FCC rules.Operation is subject to the following two

conditions:

⑵This device must accept any interference received

including interference that may cause undesired

operation.

WARNING : TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT DISASSEMBLE.

NO USER-SERVICEABLE PARTS

WARNING : TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE THE

APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISKOF ELECTRIC SHOCK

DO NOT OPEN

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

Warning: Changes or modifcations not expressly

approved in writing by B-bird may void the users

authority to operate this equipment.

RF Exposure Statement: This transmitter must not be

co-located or operated in conjunction with any other

antenna or transmitter.

the antenna used for this transmitter must be installed

to provide a separation distance of at least 20cm from

all persons. end users must be provided with

transmitter operation conditions for satisfying RF

exposure compliance

Note: This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and,

if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio

or television reception, which can be determined by

turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

- Connect the equipment into an outlet on a circuit

different from that to which thereceiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

1.Observe all instructions carefully in the O2 manual.

2.Do not to perform service operations beyond those

described in the O2 Manual. Services required when

the apparatus has been damaged in any way, such as:

is dropped or the enclosure is damaged

3.Do not place near heat sources, such as radiators,

heat registers, or appliances which produce heat.

4.Guard against objects or liquids entering the device.

Do not use or place unit near water.

5.Clean only with a damp cloth.

6.Only use attachments/accessories specified by the

manufacturer.

WARNING: BEFORE USING YOUR B-BIRD O2

DIGITAL WIRELESS SYSTEM,

CAREFULLY READ THE OPERATING

INSTRUCTIONS.

IMPORTANT SAFETY INSTRUCTIONS

PLEASE THESE INSTRUCTIONS

IN A SAFE PLACE

PRODUCT INTRODUCTION

B-BIRD O2 guitar system features digital wireless

technology that delivers incredible audio quality, simple

setup, and is extremely reliable for any gigging

musicians. It delivers a full 20 Hz - 20K Hz frequency

response, so you’ll hear your guitar tone in great detail

with only 5ms of latency. This wireless system operates

at 2.4GHz ISM band for crystal clear broadcasting

ensuring the integrity of your signal on stage and covers

100 feet of range without any signal dropout. The li-ion

batteries help makes the O2 wireless system

environmentally friendly that can last up to 5 hours per

charge. The chassis is made out of a durable ABS plastic

that can withstand the rigors of touring and the harshest

of climates. This wireless is a perfect fit for any pedal

board thanks to its simplistic, and compact design. So,

go wireless with the B-BIRD O2 system. It’ll declutter the

stage and offers freedom in motion

7.Prolonged listening at high volume levels may cause

irreparable hearing loss and/or damage. Always be

sure to practice “safe listening.”

PACKAGE DETAILS

O2 Guitar Transmitter*1

O2 Guitar Receiver*1

USB cable*1

Manual*1

Range >100 feet Line-0-site outdoors.*

Latency <5ms

Frequency Response 20-20K Hz,+1dB/-3dB

THD + Noise <0.05%(1K Hz @-10dbFS)

Dynamic Range >103dB A weighted

Operating Band 2.4G Hz ISM Worldwide

Operating Temperature -10 C to 50 C

Sample Rate 24bit/48K Hz uncompressed

digital transmission

*Note:

Actual range is dependent on RF environment,

including reflections, interference and absorption

Auto sleep/wake up mode:The transmitter will turn to sleep

mode if there is no signal input for 10 seconds.

SYSTEM SPECIFICATION

QUICK START DIAGRAM

1.Transmitter plugs into the Guitar (you instruments),

the receiver plugs into the effects pedal, AMP, Audio,

etc.

2.Turn on the Transmitter and the receiver, the A B C D

LED will indicate how much volume of the battery,

each LED means about 25% of the battery volume.

for example,if A B C D LED all light on,it means

about 100% full volume left,and the like if only A LED

lights on means about 25% of the battery volume left.

if the A LED turn red and flashing,it means the battery

O2TRANSMITTER

O2RECEIVER

is in low volume and you have to charge.

3.Channel choosing,O2 systems’pre-set channel is

3.Charging, put the USB plug into the transmitter and

channel A,after showing battery volume the A LED will

flash,it indicates making pairs,if transmitter and receiver

connected successfully the channel LED will stop

flashing and turn solid green. if environment interuption

happens, you can click the “C” button to choose

receiver meanwhile, the A B C D LED will light on

orderly according to the batteries’ volume.

another channel.

1.Power

– Slide Switch to turn on/off

TRANSMETER/RECEIVER

BASIC OPERATION

2.Channel Select - Align TRANSMITTER and

RECEIVER channels.

O2TRANSMITTER

O2RECEIVER
