BIPAC 5100S

ADSL Modem/Router

with Single Ethernet Port

User’s Manual

Table of Contents

Chapter 1 ....................................................................................... 5

1.1 Introducing the BIPAC 5100S................................................... 5

1.2 Features of the BIPAC 5100S .................................................. 5

1.3 Applications for the BIPAC 5100S ............................................ 8

Chapter 2 ....................................................................................... 9

2.1 Web Configurator Overview .....................................................9

2.2 Accessing the BIPAC 5100S Web Configurator ....................... 9

2.3 Navigating the BIPAC 5100S Web Configurator..................... 10

2.4 Configuring Password ............................................................ 11

2.5 Resetting the BIPAC 5100S ................................................... 11

Chapter 3 ..................................................................................... 12

3.1 Wizard Setup Introduction ...................................................... 12

3.2 Encapsulation......................................................................... 12

3.3 Multiplexing ............................................................................13

3.4 VPI and VCI............................................................................ 13

3.5 Wizard Setup Configuration: First Screen .............................. 13

3.6 IP Address and Subnet Mask ................................................. 14

3.7 IP Address Assignment........................................................... 15

3.8 Nailed-Up Connection (PPP).................................................. 16

3.9 NAT.........................................................................................16

3.10 Wizard Setup Configuration: Second Screen ....................... 16

3.11 DHCP Setup ......................................................................... 21

3.12 Wizard Setup Configuration: Third Screen ........................... 21

3.13 Wizard Setup Configuration: Connection Tests .................... 23

3.14 Test Your Internet Connection .............................................. 23

Chapter 4 ..................................................................................... 24

4.1 LAN Overview.........................................................................24

4.2 DNS Server Address ..............................................................24

4.3 DNS Server Address Assignment........................................... 25

4.4 LAN TCP/IP............................................................................ 25

4.5 Configuring LAN .....................................................................27

Chapter 5 ..................................................................................... 29

5.1 WAN Overview ....................................................................... 29

5.2 PPPoE Encapsulation ............................................................ 29

5.3 PPTP Encapsulation...............................................................29

5.4 Traffic Shaping........................................................................ 30

5.5 Configuring WAN Setup .........................................................30

Chapter 6 ..................................................................................... 35

6.1 NAT Overview......................................................................... 35

6.2 SUA (Single User Account) Versus NAT................................. 38

6.3 SUA Server............................................................................. 38

6.4 Selecting the NAT Mode.........................................................40

6.5 Configuring SUA Server ......................................................... 40

6.6 Configuring Address Mapping ................................................ 41

6.7 Editing an Address Mapping Rule .......................................... 43

Chapter 7 ..................................................................................... 45

7.1 Dynamic DNS......................................................................... 45

7.1.1 DYNDNS Wildcard .............................................................. 45

7.2 Configuring Dynamic DNS...................................................... 45

Chapter 8 ..................................................................................... 47

8.1 Configuring Time Zone ........................................................... 47

Chapter 9 ..................................................................................... 49

9.1 Remote Management Overview ............................................. 49

9.2 Telnet ...................................................................................... 50

9.3 FTP.........................................................................................50

9.4 Web ........................................................................................ 50

9.5 Configuring Remote Management.......................................... 50

Chapter 10 ................................................................................... 52

10.1 Universal Plug and Play Overview ....................................... 52

10.2 Cautions with UPnP.............................................................. 52

10.3 Installing UPnP in Windows Example................................... 53

10.4 Using UPnP in Windows XP Example.................................. 56

Chapter11 .................................................................................... 59

11.1 Maintenance Overview .........................................................59

11.2 System Status Screen .......................................................... 59

11.3 DHCP Table Screen.............................................................. 62

11.4 Diagnostic Screens...............................................................63

11.5 Firmware Screen .................................................................. 66

Appendix ..................................................................................... 68

A.1 Using LEDs to Diagnose Problems........................................ 68

A.2 Telnet...................................................................................... 69

A.3 Web Configurator................................................................... 69

A.4 Login Username and Password ............................................. 70

A.5 LAN Interface ......................................................................... 70

A.6 WAN Interface........................................................................ 70

A.7 Internet Access ...................................................................... 71

A.8 Remote Management............................................................. 71

A.9 Remote Node Connection...................................................... 72

Product Support and Contact Information .................................... 72

Chapter 1

Getting to Know the BIPAC 5100S

This chapter describes the key features and applications of BIPAC 5100S.

1.1 Introducing the BIPAC 5100S

The BIPAC 5100S integrates high-speed 10/100Mbps auto-negotiating LAN interface and a

high-speed ADSL port into a single package. The BIPAC 5100S is ideal for high-speed Internet

browsing and making LAN-to-LAN connections to remote networks. By integrating DSL and

NAT, the BIPAC 5100S provides super-fast Internet access to multiple users at minimum cost.

The BIPAC 5100S is a bridge/router and includes two models, one for ADSL over POTS (Plain

Old Telephone System) and one for ADSL over ISDN (Integrated Synchronous Digital

System).

The web browser-based Graphical User Interface provides easy management and is totally

independent of the operating system platform you use.

1.2 Features of the BIPAC 5100S

The following sections describe the features of the BIPAC 5100S.

 High Speed Internet Access

The BIPAC 5100S ADSL router can support downstream transmission rates of up to 8 Mbps

and upstream transmission rates of 1 Mbps.

 PPPoE Support (RFC2516)

PPPoE (Point-to-Point Protocol over Ethernet) emulates a dial-up connection. It allows your

ISP to use their existing network configuration with newer broadband technologies such as

ADSL. The PPPoE driver on the BIPAC 5100S is transparent to the computers on the LAN,

which see only Ethernet and are not aware of PPPoE thus saving you from having to manage

PPPoE clients on individual computers.

 Network Address Translation (NAT)

Network Address Translation (NAT) allows the translation of an Internet protocol address used

within one network (for example a private IP address used in a local network) to a different IP

address known within another network (for example a public IP address used on the Internet).

 Universal Plug and Play (UPnP)

Using the standard TCP/IP protocol, the BIPAC 5100S and other UPnP enabled devices can

dynamically join a network, obtain an IP address and convey its capabilities to other devices

on the network.

 10/100M Auto-negotiation Ethernet/Fast Ethernet Interface

This auto-negotiation feature allows the BIPAC 5100S to detect the speed of incoming

transmissions and adjust appropriately without manual intervention. It allows data transfer of

either 10 Mbps or 100 Mbps in either half-duplex or full-duplex mode depending on the

Ethernet network.

 Dynamic DNS Support

With Dynamic DNS support, you can have a static hostname alias for a dynamic IP address,

allowing the host to be more easily accessible from various locations on the Internet. You must

 Multiple PVC (Permanent Virtual Circuits) Support

The BIPAC 5100S supports up to 8 PVC’s.

 ADSL Standards

♦ Full-Rate (ANSI T1.413, Issue 2; G.dmt (G.992.1) with line rate support of up to 8

Mbps downstream and 1 Mbps upstream.

♦ G.lite (G.992.2) with line rate support of up to 1.5Mbps downstream and 512Kbps

upstream.

♦ Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.994.1

and G.996.1 (for ISDN only); G.991.1;G.lite (G992.2)).

♦ Supports OAM F4/F5 loop-back, AIS and RDI OAM cells.

♦ ATM Forum UNI 3.1/4.0 PVC.

♦ Supports up to 8 PVCs (UBR, CBR, VBR).

♦ Multiple Protocols over AAL5 (RFC 1483).

♦ PPP over AAL5 (RFC 2364).

♦ PPP over Ethernet (RFC 2516).

 DHCP Support

DHCP (Dynamic Host Configuration Protocol) allows individual clients (computers) to obtain

TCP/IP configuration at start-up from a centralized DHCP server. The BIPAC 5100S has

built-in DHCP server capability enabled by default. It can assign IP addresses, an IP default

gateway and DNS servers to DHCP clients. The BIPAC 5100S can now also act as a surrogate

DHCP server (DHCP Relay) where it relays IP address assignment from the actual real DHCP

server to the clients.

 IP Alias

IP Alias allows you to partition a physical network into logical networks over the same Ethernet

interface. The BIPAC 5100S supports three logical LAN interfaces via its single physical

Ethernet interface with the BIPAC 5100S itself as the gateway for each LAN network.

 IP Policy Routing (IPPR)

Traditionally, routing is based on the destination address only and the router takes the shortest

path to forward a packet. IP Policy Routing (IPPR) provides a mechanism to override the

default routing behavior and alter the packet forwarding based on the policy defined by the

network administrator.

 Protocol Support

♦ PPP (Point-to-Point Protocol) link layer protocol.

- PPP over PAP (RFC 1334).

- PPP over CHAP (RFC 1994).

♦ RIP I/RIP II

♦ IGMP Proxy

♦ ICMP support

♦ MIB II support (RFC 1213)

♦ PPPoE feature

- PPPoE idle time out

- PPPoE dial on demand

 Networking Compatibility

The BIPAC 5100S is compatible with major ADSL DSLAM (Digital Subscriber Line Access

Multiplexer) providers.

 Multiplexing

The BIPAC 5100S supports VC-based and LLC-based multiplexing.

 Encapsulation

The BIPAC 5100S series supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5),

RFC 1483 encapsulation over ATM, MAC encapsulated routing (ENET Encapsulation) as well

as PPP over Ethernet (RFC 2516).

 Network Management

♦ Embedded Web Configurator

♦ CLI (Command Line Interpreter)

♦ SNMP manageable

♦ DHCP Server/Client

♦ Built-in Diagnostic Tools

♦ Syslog

♦ TFTP/FTP server, firmware upgrade and configuration backup/support supported

 Diagnostics Capabilities

♦ The BIPAC 5100S can perform self-diagnostic tests. These tests check the integrity

of the following circuitry:

- FLASH memory

- ADSL circuitry

- RAM

- LAN port

 Filters

The BIPAC 5100S's packet filtering functions allows added network security and management.

 Ease of Installation

The BIPAC 5100S is designed for quick, intuitive and easy installation.

 Housing

The BIPAC 5100S's all new compact and ventilated housing minimizes space requirements

making it easy to position anywhere in your busy office.

1.3 Applications for the BIPAC 5100S

The BIPAC 5100S is the ideal high-speed Internet access solution. The BIPAC 5100S

supports the TCP/IP protocol, which the Internet uses exclusively. It is compatible with all

major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers. A DSLAM is a rack

of ADSL line cards with data multiplexed into a backbone network interface/connection (for

example, T1, OC3, DS3, ATM or Frame Relay).

Chapter 2

Introducing the Web Configurator

This chapter describes how to access and navigate the web configurator.

2.1 Web Configurator Overview

The embedded web configurator allows you to manage the BIPAC 5100S from anywhere

through a browser such as Microsoft Internet Explorer or Netscape Navigator. Use Internet

Explorer 6.0 and later or Netscape Navigator 7.0 and later versions with JavaScript enabled. It

is recommended that you set your screen resolution to 1024 by 768 pixels

2.2 Accessing the BIPAC 5100S Web Configurator

Step 1. Make sure your BIPAC 5100S hardware is properly connected (refer to the Compact

Guide or Read Me First).

Step 2. Prepare your computer/computer network to connect to the BIPAC 5100S (refer to the

Compact Guide or Read Me First).

Step 3. Launch your web browser.

Step 4. Type "192.168.1.254" as the URL.

Step 5. An Enter Network Password window displays. Enter the user name (“admin” is the

default), password (“admin” is the default) and click OK.

Step 6. You should now see the Site Map screen.

2.3 Navigating the BIPAC 5100S Web Configurator

The following summarizes how to navigate the web configurator from the Site Map screen.

Screens vary slightly for different BIPAC 5100S models.

 Click Wizard Setup to begin a series of screens to configure the BIPAC 5100S for the first

time.

 Click a link under Advanced Setup to configure advanced BIPAC 5100S features.

 Click a link under Maintenance to see BIPAC 5100S performance statistics, upload

firmware and back up, restore or upload a configuration file.

 Click SITE MAP to go to the Site Map screen.

 Click Logout in the navigation panel when you have finished a BIPAC 5100S

management session.

Autres manuels pour BiPAC 5100S

Table des matières

Autres manuels Billion Routeur réseau

Billion

Billion BiPAC 5200S Series Manuel utilisateur

Billion

Billion BiPAC 7800NEXL Manuel utilisateur

Billion

Billion BiPAC 8500 Manuel utilisateur

Billion

Billion BIPAC 7100G Manuel utilisateur

Billion

Billion myGuard 7500GL Manuel utilisateur

Billion

Billion BiPAC 7402NX Manuel utilisateur

Billion

Billion BiPAC 9800 Manuel utilisateur

Billion

Billion BiPAC 7300 Manuel utilisateur

Billion

Billion BiPAC 5200S Series Manuel utilisateur

Billion

Billion BiPAC 7401VGP Manuel utilisateur

Billion

Billion BiPAC 7404VGOX Manuel utilisateur

Billion

Billion BiPAC 7100SV Manuel utilisateur

Billion

Billion BiPAC 7202 Manuel utilisateur

Billion

Billion 400G Instructions d'utilisation

Billion

Billion BiPAC 7401VP Manuel utilisateur

Billion

Billion BiPAC 7404VGP Manuel utilisateur

Billion

Billion BiPAC 7404V series Manuel utilisateur

Billion

Billion BiPAC 7404V series Manuel utilisateur

Billion

Billion BiPAC 8200N Manuel utilisateur

Billion

Billion BiPAC 7800(N) Manuel utilisateur

Billion

Billion BiPAC 7300N Manuel utilisateur

Billion

Billion BiPAC 7402NX Manuel utilisateur

Billion

Billion BiPAC 7404V series Manuel utilisateur

Billion

Billion BiPAC 4700AZ Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

LevelOne

LevelOne FBR-1416 Manuel utilisateur
