2
FUNCTION AND NAME
6
11
11
5
5
2
2
4
CAUTION FOR SAFETY
FUNCTION AND NAME
CONNECTION
PC SOFTWARE
PC SOFTWARE WINDOW
PC SOFTWARE
OPERATION INSTRUCTION
ANY TROUBLES ?
SPECIFICATIONS
CONTENTS
WARNING This shows: Using this product with disregarding cautions might call for death or injury.
This shows: Using this product with disregarding cautions might call for people to be
harmed and goods to be damaged.
CAUTION
CAUTION FOR SAFETY
WARNING
●
Making use of this product under the circumstances that a smoke, an abnormal smell, an irregular sound coming out, it may cause
a fire and an electric shock. In this case, switch off the product, and take AC plug out of the outlet right away. Bring it to the shop for
repair.
●
In case water or foreign substances get into product, switch off right away, and take AC plug out of outlet, and consult with the repair shop,
otherwise, it may cause a fire or an electric shock.
●
Re-assembling this product is strictly prohibited, otherwise, it may cause a fire or an electric shock.
●
Do not take the cover out, otherwise, it may cause an electric shock. Inspection, repair should be done in the repair shop.
●
This product can no way be used in the bathroom, otherwise, it may cause a fire, or an electric shock.
●
Pay attention for water not to go into or get wet. Or it may cause a fire or an electric shock.
●
This product can be used only with AC220V - AC240V, otherwise it may cause a fire or receive an electric shock.
●
This product is not designed for built-in installation: Do not place the product in an enclosed place such as a bookcase or a rack.
●
Be careful for AC plug, or outlet not to get dust or to get wet, or it may cause a fire.
●
When this product is not used for a longer period, power supply plug should be taken out of outlet.
●
In case the thunder is generated near-by, take power supply plug out of outlet right away, or it may cause a fire or an electric shock.
●
If this product needs to be moved, switch off first, and then take power supply plug out, or it may damage cord, and may cause
a fire or an electric shock.
●
Do not put this product near cooking counter or damp supply outlet, or it may cause a fire or an electric shock.
CAUTION
●
Do not put this product on unstable desk, it may cause damage or injury when dropped.
●
Do not leave this product for a longer period such as in the cars where all windows are shut, or place where direct sunshine hits,
or it may damage each part of this product, and may cause a fire.
FUNCTION
●48kHz sampling rate，32-bit floating point DSP arithmetic process，24-bit AD/DA convert.
●2 independent MIC processor, 5 MIC input can be connected, with independent gain control, noise gate,
optional types LPF and HPF, 15 band PEQ (parameter can be adjusted and saved), optional 8 class feedback killer.
●MIC effect with master volume control, limiter, ECHO with 5 band PEQ( can be low/high cut), effect can be chosen，
stereo and mono, dual effect can be chosen，delay, repeat, pre delay and liveliness parameter can be adjusted
separately; REVERB with 5 band PEQ (can be low/high cut), decay, predelay, liveliness adjust, and direct sound
effect processor.
●Music channel with master volume control, limiter, noise gate, optional types low/high cut，15 band PEQ(parameter
can be adjusted and saved), key shift. 3 stereo music input, BGM and VOD, AUX with single input volume control，automatic
and manual switching mode can be chosen, 1 optical input and 1 coaxial.
●5.1 channel output:：L/R output, center output, surround output, Sub woofer output.
●Output with independent volume control, mute, delay, balance, compressor (parameter can be adjusted)，10 band PEQ
(Can be Low/high cut).
●Center output with independent volume control, mute, delay, compressor (parameter can be adjusted)，10 band PEQ
(Can be low/high cut).
●Surround output with independent volume control, mute, delay, compressor (parameter can be adjusted)，10 band PEQ
(Can be low/high cut).
●Sub woofer output with independent volume control, mute, delay, compressor (parameter can be adjusted)，10 band PEQ,
optional types low cut, high cut, delay.
●Output channel with dance music and sing setting function, auto and manual mode can be chosen. In the mode of
automatic mode, when opening the MIC, it enter singing mode; when closing the MIC, it enter dance music mode.
●2 MIC process channel can connect with different style MIC, such as Wireless MIC, Wire MIC, console MIC.
different curves with different modifies, let the MIC tone be the perfect.
This "Caution for safety" shows various kinds of pictures in order to be used safely and correctly and to prevent from
damaging other people, and their property. Please read with full understanding, and carefulness.
