BeWAN ADSL USB ST Manuel utilisateur
User’s guide
for Windows 98 and Me
The information in this manual is subject to change without notice.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR ANY PARTIAL NON-
COMPLIANCE BETWEEN THIS MANUAL AND THE PRODUCT WHICH IT DESCRIBES,
NOR FOR ANY ACCIDENTAL DAMAGE RESULTING FROM THE USE OF THE ABOVE.
The manual and the provided Software are protected by Copyright laws and cannot be copied or
distributed in any manner or for any purpose whatsoever. This manual is governed by the provisions
and conditions displayed in the installation program, which you must accept before using it. The use
of the Software and its Documentation is mono-product, and solely for personal usage. Any usage
for commercial purposes is strictly forbidden. Any violation of these rules can result in legal
proceedings, and the person in question will be held economically responsible for any prejudice or
loss suffered by the copyright holder.
Copyright 2002-2003, BeWAN systems. All rights reserved.
December 2003 edition.
Similarly, the product names indicated in this manual for identification purposes may be
commercial brands, registered or not by their respective companies.
BeWAN ADSL USB ST with Windows 98 and Me 3
Table of contents
Foreword.................................................................................................... 4
Box contents .........................................................................................................................4
Technical assistance .............................................................................................................4
Adapter technical documentation .........................................................................................5
Usage precautions.................................................................................................................5
Location .......................................................................................................................................5
Upkeep and maintenance.............................................................................................................5
Cables ..........................................................................................................................................6
BeWAN ADSL USB ST installation ......................................................... 7
Connecting the adapter to the PC and ADSL filter ..............................................................7
Installation of the drivers......................................................................................................8
With Windows 98 .........................................................................................................................8
With Windows Me ......................................................................................................................10
Adapter indicator lights ......................................................................................................12
Summary of the installed elements.....................................................................................12
Devices installed ........................................................................................................................12
The adapter utilities ...................................................................................................................13
Verification and configuration of the ADSL parameters.................... 14
ADSL line synchronisation ................................................................................................14
Elements to verify in the event of non-synchronisation .............................................................15
Verifying the VPI and VCI.................................................................................................16
Changing the profile ...........................................................................................................17
Use of an already existing profile..............................................................................................17
Creation of a new profile ...........................................................................................................18
Connection to the Internet ..................................................................... 21
Establishing the connection ................................................................................................21
Using the connection ..........................................................................................................22
Ending the connection ........................................................................................................22
Uninstalling the drivers .......................................................................... 23
Appendix.................................................................................................. 24
ANSI codes of ADSL product manufacturers....................................................................24
BeWAN ADSL USB ST with Windows 98 and Me 4
Foreword
The BeWAN ADSL USB ST adapter allows you to connect to the Internet or to other ADSL
services. Before using it, you will require a subscription with an ADSL service provider and an
Internet service provider using ADSL.
Box contents
The packaging of the BeWAN ADSL USB ST should contain the following elements:
• a BeWAN ADSL USB ST adapter guaranteed for 2 years,
• a BeWAN ADSL CD-ROM containing:
− the adapter drivers and utilities,
− the documentation in PDF format.
• a USB cable used to connect the adapter to the computer,
• a RJ11 cable for connecting the adapter to the ADSL filter (which is connected to the telephone
jack),
• an ADSL filter (only for France),
• a start-up guide,
• a warranty registration card for the BeWAN ADSL USB ST adapter.
Note: should any of these elements be missing or damaged, contact your reseller or the BeWAN
systems client services.
Technical assistance
The BeWAN ADSL USB ST adapter and its documentation are designed to be as simple as
possible, so that they can be used not only by professionals but also by the individual user at home.
Once you have installed the BeWAN ADSL USB ST adapter, we advise you to register your
product on the BeWAN systems website. It is essential if you would like to enjoy the benefits of the
after-sale service. Refer to the instructions provided on the warranty card.
Follow the step-by-step instructions in this User’s guide.
If a problem arises:
• If you are not sure that you have installed the BeWAN ADSL USB ST adapter software
correctly, don’t hesitate to uninstall it and start the installation again from the beginning.
• If the problems persist, write down the actions you perform and the results they produce. Then
contact your dealer and provide this information. Your dealer will either assist you directly or
put you in contact with the appropriate service if unable to solve the problem.
Note: for information about the BeWAN systems technical assistance service, consult the BeWAN
systems web site (http://www.bewan.com).
BeWAN ADSL USB ST with Windows 98 and Me 5
Adapter technical documentation
The BeWAN ADSL USB ST User’s guide contains practical information that will allow you to
rapidly install and use the BeWAN ADSL USB ST adapter with Windows 98 or Me.
In the BeWAN ADSL USB ST adapter User’s guide, we assume that you are already familiar with
the Windows user interface, commands and utilities. We will therefore not go over these points. If
necessary, please refer to the Windows manual or the Windows on-line help.
Prior knowledge of telecommunications is not necessary when using the BeWAN ADSL USB ST
adapter.
Usage precautions
Carefully read the following safety instructions before installing or using the BeWAN
ADSL USB ST. The usage instructions must be followed exactly.
Location
• Avoid using, placing or storing the adapter in areas which are exposed to intense light or high
temperatures, or close to sources of heat.
High temperatures can damage the adapter. The maximum temperature cannot not exceed 40°C.
• Avoid installing the adapter in a humid or dusty area.
• Keep the adapter in a secure and stable location.
Serious damage could result if the adapter falls.
• Keep the adapter out of the reach of children.
Upkeep and maintenance
• Do not open, disassemble or modify any part of the adapter.
Any disassembly or modification could result in a strong electric discharge. Internal inspections,
modifications and repairs must imperatively be carried out by accredited and qualified
technicians.
Opening the adapter or any internal modification will void the warranty.
• Before cleaning the adapter, disconnect its power supply.
• When cleaning the adapter, do not use certain chemical products which could damage plastic
materials. Do not use substances containing alcohol, benzene, paint thinner or other flammable
products. The use of these products can result in a fire.
• Do not bring the adapter into contact with water or other liquids.
No liquid must get inside the adapter. If the outside of the adapter comes into contact with a
liquid, wipe it using a soft and absorbent cloth. If a liquid or other substance gets inside the
adapter, disconnect the cables. If you continue using adapter, there is the risk of a fire or
electrical discharge.
BeWAN ADSL USB ST with Windows 98 and Me 6
Cables
• Only use the supplied accessories.
• Make sure that the cables are laid out such that no one can trip over them or walk on them.
• Do not run the cables through a passage or in an area where they may be pinched.
• When disconnecting the cables, hold the solid part.
Pulling on the flexible part of the cable can damage the insulation or strip the wire, thus creating
a risk of fire or electrical discharge.
• Immediately discontinue using the adapter if any smoke is seen to come from it.
BeWAN ADSL USB ST with Windows 98 and Me 7
BeWAN ADSL USB ST installation
This chapter contains a detailed description of the installation procedure for the BeWAN ADSL
USB ST adapter. We recommend that you follow the installation steps in order.
Before beginning, deactivate any software that might disrupt the installation procedure, such as
anti-virus products. Close all open applications.
Connecting the adapter to the PC and ADSL filter
You do not need to turn off the PC in order to connect the BeWAN ADSL USB ST. USB
technology allows “hot” plugging and unplugging of peripheral devices. To connect the adapter to
the PC and the ADSL filter, refer to the diagram below and proceed as follows:
1. The ADSL filter provided in the box must be connected to your telephone line. Retrieve the
ADSL (RJ11/RJ11) cable which is also provided in the package. Connect one end to the ADSL
filter and the other to the BeWAN ADSL USB ST adapter’s RJ11 socket.
Note: for the proper operation of your installation, we recommend that you place a filter on
each telephone jack which is connected to the same line and to which a telephone is connected.
2. Locate the USB cable. Connect one end to one of the USB ports on your PC, and the other end
to the BeWAN ADSL USB ST.
Levels of electric security:RJ11 Connector: TNV1
USB Connector: SELV
Fuse: 5A / 125V
BeWAN ADSL USB ST with Windows 98 and Me 8
Installation of the drivers
The installation of the BeWAN ADSL USB ST drivers takes place by automatic detection.
With Windows 98
Note: depending on your initial configuration, your Windows CD-ROM may be required during the
driver installation phase with Windows 98.
1. When first connecting to the PC, Windows indicates that it has found a new hardware device
(the BeWAN ADSL USB ST adapter).
The Add New Hardware Wizard is automatically launched. To begin installing the drivers,
click on Next.
2. Select Search for the best driver for your device (Recommended), and then click on Next.
Then insert the BeWAN ADSL CD-ROM in your drive.
Note: once the CD-ROM has been inserted, the driver installation program may launch
automatically. Pay no attention to this. Close the autorun window and continue the installation
using the Add New Hardware Wizard.
BeWAN ADSL USB ST with Windows 98 and Me 9
3. Check the Specify a location box, and then click on Browse.... Select the letter of your CD-
ROM drive, and then indicate the following path (supposing that your CD-ROM is drive D):
D:\Usb\Drivers\All.
Note: this indicates the folder containing the driver information (.INF file).
Click on OK and then on Next.
4. The Wizard indicates that it is ready to install the best driver for the device. Click on Next.
5. Carefully read the licence contract, and then click on I agree. The driver is then installed and
the system updates your configuration.
Note: if this is the first time that you install a communications device, Windows will ask you,
during the driver configuration, for information about your site. Enter the area code for your
region. After entering this information, click on Close.
6. The driver is then installed and the system updates your configuration.
BeWAN ADSL USB ST with Windows 98 and Me 10
With Windows Me
1. When first connecting to the PC, Windows indicates that it has found a new hardware device
(the BeWAN ADSL USB ST adapter). The Add New Hardware Wizard is automatically
launched.
2. Select Specify the location of the driver (Advanced), and then click on Next. Then insert the
BeWAN ADSL CD-ROM in your drive.
Note: once the CD-ROM has been inserted, the driver installation program may launch
automatically. Pay no attention to this. Close the autorun window and continue the installation
using the Add New Hardware Wizard.
3. Select Search for the best driver for your device (Recommended). Check the Specify a
location box, and then click on Browse. Select the letter of your CD-ROM drive, and then
indicate the following path (supposing that your CD-ROM is drive D): D:\Usb\Drivers\All.
Note: this indicates the folder containing the driver information (.INF file).
Click on OK and then on Next.
Table des matières
Manuels Modem populaires d'autres marques
Davicom
Davicom DM562AP Manuel utilisateur
EpiValley
EpiValley TATA indicom SXC-1080 Manuel utilisateur
Zte
Zte WiMAX Manuel utilisateur
Intelimax
Intelimax MA-2060 Manuel utilisateur
SMC Networks
SMC Networks D3CM1604V Manuel d'utilisation et d'entretien
Telstra
Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur
US Robotics
US Robotics 3453C Manuel utilisateur
MaxTech
MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur
Zte
Zte MF823 Manuel utilisateur
Four-Faith
Four-Faith F1403 Manuel utilisateur
Sierra Wireless
Sierra Wireless AIRLINK MP595W Manuel utilisateur
Gemtek
Gemtek WiMAX WIXFBR-103 Manuel utilisateur
