Remove the power source from the system that controls the passerelle.
Install the receiver/adaptor far away from heat sources and electromagnetic disturbances.
Select the appropriate connector cable out of the two that are supplied (see figs. Band C),
based on whether the boat is fitted with a transom or retractable passerelle:
Option 1: to control a transom passerelle connected to a 4 button control panel
(see
fi g . E) you must use the connector cable shown in fi g . Bwith 4 PINs.
The Bluetooth Receiver / Adaptor must be open and the DIP switch must be turned ON.
Option 2: to control a retractable passerelle connected to a 6 button control panel
(see
fi g . F) you must use the connector cable shown in fi g . Cwith 6 PINs.
The Bluetooth Receiver / Adapter has the DIP-switch default to OFF .
Disconnect the cable connected to the control panel from the electronic junction box
(see fi g . D) and connect it directly to the (see fi g . A).
Take the connector fi g . Bor C, connect it first to the and then to the control panel
socket with the same number of PINs (4 or 6) inside the electronic control unit (fi g . D).
Take note of the password on the label attached to the front of the
Power the circuit board with the electronic junction
box line stabilised at 12/24 volts.
Restore power to the system.
Activate the device’s bluetooth.
Open the App on your device.
Click Settings from the dropdown menu in the top
left-hand corner.
Choose and set an unlock code which
you will also use in the future.
Deactivate the Demo mode and tick “Start in Command View”.
Click “Set Device Code” and insert the 5 digit security code
shown on the label.
Click “Select device” and select the device that corresponds to the name shown
on the label: e.g. Name: Besenzoni1006.
Click the Dropdown menu button.
Click Command and then the screen to start the App.
The commands to control the passerelle will appear in the next screen.
In order to correctly control the passerelle, you must press and hold the selected
command, otherwise an Error message will show up on the device’s screen.
To restart the controlling operation, press and hold the command again.
INSTALLATION PROCEDURE ACTIVATION PROCEDURE
NOTE SETTINGS
Settings: by selecting Launch Commands when you next open the App, once you have
inserted your unlock code, you will have immediate access to the commands section.
Controlling the passerelle via the App still allows you to use the remote control that
you have been supplied with.
PROCEDURE FOR RESETTING MEMORIZED DEVICES:
1) Open the lid of the by removing the 4 screws
2) Press the S1 button indicated in the image for 2 seconds
until the blue LED goes out
3) Close the receiver cover. S1
blue LED
