BenQ 0.3 Wall Mount Manuel utilisateur

BenQ America Corp.

15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: (949) 255-9500 www.BenQ.us

Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.

Specifications subject to change without notice.

Education Deal Registration – http://promotions.benq.us/education/

B2B Deal Registration - http://promotions.benq.us/dealregistration/

Fast and Easy Installation to Keep Things Lookin’ Great!

Designed to provide an easy and quick solution to mount a BenQ short-throw projector, this

installer-friendly wall mount is smartly constructed with premium steel and aluminum to provide

the strongest hold and stylishly polished with a pristine white nish to keep any room lookin’

great! Together with an adjustable tilt angle of up to ± 10 degrees, you’ll get to enjoy the most

exible viewing support for just about any setting!

*Custom specications may vary by model. Please refer to the specication chart to review each model in detail.

Wall Mount for

BenQ Short

Throw Projector!

Wall Mount 12-20-11-BQus

Ultra Short Throw Wall Mount (0.3 Throw Ratio, P/N 5J.J3A10.001)

Ultra Short Throw Wall Mount (0.4 Throw Ratio, P/N 5J.J4V10.001)

Short Throw Wall Mount (0.6 Throw Ratio, P/N 5J.J4R10.001)

Guide sheet for hole drilling

Wall Mount for BenQ Short Throw Projector

Ultra Short Throw Wall Mount (0.3 Throw Ratio, P/N 5J.J3A10.001)

Connection plate A

Steel/Aluminum alloy

Kg (lbs)

18.19”

+/-10˚

Rotation angle

26.46 lbs (12kg)

+/-10°

4.33” x 8.46” x 21.97”

Material

Weight

Size (W x H x L)

Maximum distance from wall

Load

Screw

Tilt angle

4.33”

11.46”

7.36”

8.46”

21.97”

Max: 18.19” Min: 15.56”

7-Ø5

6.44”

3.94”

AConnection plate

Steel/Aluminum alloy

Kg (lbs)

27.76”

+/-10˚

Rotation angle

26.46 lbs (12kg)

+/-10°

4.33” x 8.46” x 31.61”

Material

Weight

Size (W x H x L)

Maximum distance from wall

Load

Screw

Tilt angle

4.33”

11.46”

7.36”

8.46”

31.6”

Max: 27.76” Min: 20.08”

7-Ø5

6.44”

3.94”

Ultra Short Throw Wall Mount (0.4 Throw Ratio, P/N 5J.J4V10.001)

Short Throw Wall Mount (0.6 Throw Ratio, P/N 5J.J4R10.001)

BConnection plate

Steel/Aluminum alloy

Kg (lbs)

50”

+/-10˚

Rotation angle

26.46 lbs (12kg)

+/-10°

4.33” x 8.46” x 53.86”

Material

Weight

Size (W x H x L)

Maximum distance from wall

Load

Screw

Tilt angle

4.33”

10”

2.68”

8.46”

53.86”

Max: 50” Min: 32.68”

9-Ø5

7.87”

3.53”

Connection plate A Mark A ==> MX880UST

Mark B ==> MX850UST / MW851UST

Connection plate B

Lens Direction Lens Direction

Connection plate A Connection plate B

Mark A ==> MP772ST / MP776ST / MP782ST / MX810ST / MW811ST / MX812ST / MX813ST

Mark B ==> MW814ST / LX60ST / LW61ST

Mark C ==> MP780ST / MW860USTi / MP780ST+

Guide sheet for hole drilling Please visit www.benq.com for the latest guide sheet for hole drilling
