Bender PEM735 Manuel utilisateur

Manual

PEM735 Measuring case

Measuring and demonstration case

PEM735-measuring_case_D00240_00_M_XXEN/12.2015 B 9830 0014

©Bender GmbH & Co. KG

Reprinting only with permission

of the publisher.

Subject to change!

Bender GmbH & Co. KG

P. O. Box 1161 • 35301 Gruenberg • Germany

Londorfer Str. 65 • 35305 Gruenberg • Germany

Tel.: +49 6401 807-0

Fax: +49 6401 807-259

E-Mail: [email protected]

www.bender.de

Photos: Bender archives

Tabe of Contents

PEM735-measuring_case_D00240_00_M_XXEN/12.2015

1. Function and safety ................................................................................ 5

2. Content of the measuring case ............................................................. 6

3. Connecting the measuring case ........................................................... 7

3.1 Front plate ............................................................................................................ 8

3.2 Wiring panel side ............................................................................................... 9

4. Current measurement ......................................................................... 11

4.1 Application of the Rogowski coils ............................................................. 12

4.1.1 Settings on the case ....................................................................................... 13

4.1.2 Mounting Rogowski coils ............................................................................. 14

4.1.3 Settings on the PEM735 ................................................................................ 14

4.2 Application of AUX transformers ............................................................... 15

4.2.1 Settings on the case ....................................................................................... 16

4.2.2 Mounting AUX transformers ....................................................................... 16

4.2.3 Settings PEM735 .............................................................................................. 16

4.3 Use of 3 Rogowski coils and 1 AUX transformer .................................. 17

4.3.1 Settings on the case ....................................................................................... 17

4.3.2 Mounting transformer ................................................................................... 17

4.3.3 Settings PEM735 .............................................................................................. 17

5. Voltage measurement ......................................................................... 18

5.1 Overview material for voltage measurement ....................................... 18

6. Digital inputs and relay outputs ....................................................... 19

6.1 Digital inputs DI1, DI2, DIC ........................................................................... 19

6.2 Relay outputs RO1…2 ................................................................................... 19

7. Network .................................................................................................. 20

Table of Contents

4PEM735-measuring_case_D00240_00_M_XXEN/12.2015

8. Technical data ........................................................................................ 21

9. Ordering information ........................................................................... 23

INDEX ............................................................................................................ 25

Function and safety

PEM735-measuring_case_D00240_00_M_XXEN/12.2015

1. Function and safety

The PEM735 measuring and demonstration case is used for

mobile measurements to analyse the voltage quality accord-

ing to DIN EN 50160 (measurement according to IEC 61000-

4-30 class A).

For the use of this measuring case, specialist knowledge is

required.

It is essential to follow the existing safety regulations!

About this manual

In the schematic presentation, the elements belonging to the Rogowski coils are de-

picted in pink and all elements belonging to the AUX transformers are depicted in

green.

Risk of fatal injury from electric shock!

Incorrect wiring of the measuring voltage cables may cause a short-circuit

of the installation, arcs and high short-circuit currents.

The secured side of the measuring voltage cable (longer plug) must be

connected to the installation!

Risk of fatal injury from electric shock!

AUX transformers may not be operated as an

open circuit on the secondary side!

Connected AUX transformers must be short-

circuited with a jumper wire when not in use!

DANGER

Rogowski

Content of the measuring case

6PEM735-measuring_case_D00240_00_M_XXEN/12.2015

2. Content of the measuring case

 Universal measuring device PEM735 (IP address 192.168.0.10)

 Integrated WLAN router (IP address 192.168.0.254; admin/admin)

 4 flexible Rogowski coils and transducers for current measurement 100…4000 A

 1 current transformer clamp C112 (1000 A; 5 kHz)

 1 current transformer clamp C148 (configurable 250/500/1000 A; 1 kHz)

 5 cables with fuses for voltage measurement

 Safety test probes (crocodile clips, magnetic test probes, test probes for use with

push-wire terminals)

 Trolley

 Case can be locked (padlock not included)

Abb. 2.1: Content of the measuring case

Connecting the measuring case

PEM735-measuring_case_D00240_00_M_XXEN/12.2015

3. Connecting the measuring case

For your safety, consider the sequence of the work steps:

1. Configure measuring case mechanically (insert jumper wires for the trans-

formers used, adjust transducers for Rogowski coils)

2. Install measuring current transformer

3. Commission measuring case

4. Configure PEM735

5. Install measuring voltage cables

The measuring case is operated with 230 V, 50 Hz. The connecting cable is included.

Connecting the measuring case

8PEM735-measuring_case_D00240_00_M_XXEN/12.2015

3.1 Front plate

The case contains the PEM735 connected to the front plate, a router, the transducers for

the Rogowski coils and the jumper wires to configure the transformers being used.

Fig. 3.1: Front plate

Legend front plate

No. Description

1Overview of the DIP switch settings for the transducers of the Rogowski coils

2Transducers for the Rogowski coils

3Jumper wire slots to configurate the measuring current transformers in use

4Slots for replacement jumper wires

5Universal measuring device PEM735

Rogowski

kvarh

kWh

PEM735

LINETRAXX®

ENTER ESC

W3 W4W1 W2

Connecting the measuring case

PEM735-measuring_case_D00240_00_M_XXEN/12.2015

3.2 Wiring panel side

At the side of the measuring case you can find the

 Power supply of the measuring case

 Voltage transformer inputs

 Measuring current transformer inputs

 Network connection input

 Digital inputs

 Relay outputs

Fig. 3.2: Wiring panel side

Ethernet

AUX

Rogowski

RO24

RO23

RO14

RO13

DI2

DI1

DIC

Connecting the measuring case

10 PEM735-measuring_case_D00240_00_M_XXEN/12.2015

Legend wiring panel side

No. Description

1 On/off switch of the measuring case

2 Measuring voltage inputs

3 Power supply socket for measuring case

4 Ethernet connection socket

5 Measuring current transformer inputs

6 Digital inputs and relay outputs

7 Connection Rogowski coils
