Global Technical Operations
gto.gnresound.com
Lautrupbjerg 7 • DK-2750 Ballerup • Denmark
E-Mail: [email protected]
Technical Manual
Beltone
Paris Platform BTE
Doc 0176160 rev. I
Page 2 of 19
Not subject to issue control when printed
Table of Contents
Form-Factor-Matrix..............................................................................................................3
Colour Overview..................................................................................................................4
Part List ......................................................................................................................... 5-10
Disassemble Procedure ....................................................................................................11
Replacing Toggle Cap .......................................................................................................12
Replacing Top HSG, Module, PB & Mic Cover..................................................................13
Replacing Bottom HSG with ID Plate ................................................................................14
Service & Postponement Procedure .................................................................................15
Connecting the Programming Adaptor ..............................................................................16
Programming Adaptor Clip ................................................................................................17
Test Equipment..................................................................................................................18
Testing ..............................................................................................................................19
Doc 0176160 rev. I
Page 3 of 19
Not subject to issue control when printed
Form-Factor-Matrix
Platform Product Name Model Data Sheet
Paris 60 BTE REACH 66 RCH66D 16649700
IDENTITY 66 IDT66D 16765400
Paris 70 BTE
REACH 76 RCH76D 16649800
REACH TBR (Tinnitus) 76 TBR76 16871900
IDENTITY 76 IDT76D 16765500
Paris 80 BTE REACH 86 RCH86D 16649900
IDENTITY 86 IDT86D 16765600
This Technical Manual serves to outline the service & postponement procedure for products listed in the form-factor-matrix below:
PARIS 60 PARIS 70 PARIS 80
Doc 0176160 rev. I
Page 4 of 19
Not subject to issue control when printed
RUBY
RED
PRECIOUS
WHITE
MAJESTIC
SILVER
PRECIOUS
BLACK
DOVE BLUE CHROME ROSE PINK BRONZE
BEIGE LIGHT GREY GREY BROWN CHARCOAL STONE SOFT BEIGE SOFT GREY SOFT STONE
Colour Overview
Doc 0176160 rev. I
Page 5 of 19
Not subject to issue control when printed
Description PARIS 60 PARIS 70 PARIS 80
CHILDLOCK, BLUE 16165801 15966401 15966401
CHILDLOCK, RED 16165800 15966400 15966400
THIN TUBE ADAPT 16187000 16187000 N/A
PIN Ø0.6 (Front) 15344200 16059700 16059600
PIN Ø0.6 (Rear) 16059800 15168000 16342400
PIN Ø0.6 (Bat door) 16059700 16059700 15344300
HOOK FILTER, 4 PCS 16166700 16166700 N/A
TONE TUBE ADULT (no lt) 16186700 16186700 16186700
TONE TUBE BABY (no lt) 16186900 16186900 16186900
TONE TUBE CHILD (no lt) 16186800 16186800 16186800
TONE TUBE ADULT (w/lt) 17044100 17044100 N/A
TONE TUBE BABY (w/lt) 17044300 17044300 N/A
TONE TUBE CHILD (w/lt) 17044200 17044200 N/A
PB CAP, SINGLE 15967300 15967300 15967300
PB CAP, DOUBLE N/A 15967400 15967400
AUDIO BOOT 18330400 18330500 18330600
PARIS 70/80
PB CAPS
(single & double)
PARIS 60
PB CAP (single)
4 pcs Hook Filter
p/n 16166700
Hook lter is to be mounted in
tone tubes for Paris 60 & 70 only
Tone tubes for PARIS 80 must
always be without lter
Part List
Colour markers
Doc 0176160 rev. I
Page 6 of 19
Not subject to issue control when printed
Description Part No
PROG. ADAPTOR 18041400
TEST FIXTURE 16695100
TEST FRAME 16902800
CS44 PROGRAMMING CABLE (R) 9022 907 69019
CS44 PROGRAMMING CABLE (L) 9022 907 69029
CLIP,PROGRAMMING ADAPTOR,RED 17736900
CLIP,PROGRAMMING ADAPTOR,BLUE 17736901
MEASSUREMENT TOOL 15200800
PIN REMOVAL TOOL 15502500
TOGGLE REMOVER (Paris 70/80) 16167000
Service modules are none serviceable at local site. Instead defective service modules must be returned to Global Repair Site
Part List
Service Modules (ASM FRAME, PROGRAMMED):
PARIS 60 PARIS 70 PARIS 80
RCH66D 16911600 RCH76D 16911800 RCH86D 16962000
IDT66D 16911700 IDT76D 16911900 IDT86D 16962100
TBR76 16912000
Pin removal tool
Measurement tool 15200800 for
both left and right side
Doc 0176160 rev. I
Page 7 of 19
Not subject to issue control when printed
HI Colour
Description
PARIS 60/70/80
Mic Cover
PARIS 60/70/80
Actuator PB
PARIS 70/80
Toggle VC
PARIS 70/80
VC Cover
PARIS 60
Batt Door
PARIS 70/80
Batt Door
BEIGE 16186100 16960100 16187500 16381900 16386400 16387400
GREY 16186101 16960101 16187501 16381901 16386401 16387401
LIGHT GREY 16186102 16960102 16187502 16381902 16386402 16387402
BROWN 16186103 16960103 16187503 16381903 16386403 16387403
CHARCOAL 16186104 16960104 16187509 16381910 16386419 16387419
STONE 16186105 16960105 16187505 16381905 16386405 16387405
SOFT BEIGE 16186100 16960100 16187500 16381900 16386406 16387406
SOFT GREY 16186101 16960101 16187501 16381901 16386407 16387407
SOFT STONE 16186105 16960105 16187505 16381905 16386408 16387408
PRECIOUS BLACK 16186106 16960106 16187506 16381906 16386409 16387409
PRECIOUS WHITE 16186107 16960107 16187507 16381909 16386410 16387410
MAJESTIC SILVER 16186121 16960107 16187507 16381909 16386411 16387411
BRONZE 16186106 16960106 16187506 16381906 16386412 16387412
DOVE BLUE 16186121 16960107 16187507 16381909 16386413 16387413
RUBY RED 16186121 16960107 16187507 16381909 16386414 16387414
ROSE PINK 16186121 16960107 16187507 16381909 16386415 16387415
CHROME 16186121 16960107 16187507 16381909 16386416 16387416
Note:
The description in left column is the colour description for the HI & Replacement Kits. In some cases an e.g. transparent Mic cover is used in vari-
ous HI colours and is therefore listed more than one time
Separate HSG parts are not nano coated
Part List - Housing Parts
Doc 0176160 rev. I
Page 8 of 19
Not subject to issue control when printed
HI Colour
Description
PARIS 60
HSG Bottom
PARIS 70
HSG Bottom
PARIS 80
HSG Bottom
PARIS 60
HSG Top
PARIS 70
HSG Top
PARIS 80
HSG Top
BEIGE 16184400 16184500 16184600 16187700 16187200 16187900
GREY 16184401 16184501 16184601 16187701 16187201 16187901
LIGHT GREY 16184402 16184502 16184602 16187702 16187202 16187902
BROWN 16184403 16184503 16184603 16187703 16187203 16187903
CHARCOAL 16184404 16184504 16184604 16187704 16187204 16187904
STONE 16184405 16184505 16184605 16187705 16187205 16187905
Note:
Only the above HSG parts are available as separate
spare parts. Parts in other colours must be ordered as
a replacement kit. The description in left column is the
colour description for the HI & Replacement Kits.
Separate HSG parts are not nano coated HSG Bottom HSG Top
Part List - Housing Parts
Doc 0176160 rev. I
Page 9 of 19
Not subject to issue control when printed
Replacement Kit - colour PARIS 60 PARIS 70 PARIS 80
BEIGE 16400000N 16400100N 16400200N
GREY 16400001N 16400101N 16400201N
LIGHT GREY 16400002N 16400102N 16400202N
BROWN 16400003N 16400103N 16400203N
CHARCOAL 16400004N 16400104N 16400204N
STONE 16400005N 16400105N 16400205N
SOFT BEIGE 16400006N 16400106N N/A
SOFT GREY 16400007N 16400107N N/A
SOFT STONE 16400008N 16400108N N/A
PRECIOUS BLACK 16400009N 16400109N N/A
PRECIOUS WHITE 16400010N 16400110N N/A
MAJESTIC SILVER 16400011N 16400111N N/A
BRONZE 16400012N 16400112N N/A
DOVE BLUE 16400013N 16400113N N/A
RUBY RED 16400014N 16400114N N/A
ROSE PINK 16400015N 16400115N N/A
CHROME 16400016N 16400116N N/A
Replacement kit contains:
- Top-housing
- Bottom housing
- Battery door
- Push-button cap/actuator
- VC toggle (PARIS 70/80)
- VC cover (PARIS 70/80)
- Mic Cover
- Housing Pins
Replacement kits are nano coated
Mounting the Replacement Kits:
Please refer to Doc 0173460:
WORKING INSTRUCTIONS,REPLACEMENT KITS, BELTONE PARIS BTE PLATFORM
Part List - Replacement Kit (nano coated)
Doc 0176160 rev. I
Page 10 of 19
Not subject to issue control when printed
THIN TUBE BLISTER PACKS
(5 tubes & 3 cleaning wires) Part No
THIN TUBE 2,0A,R,BLSTR 18628600
THIN TUBE 2,0B,R,BLSTR 18628700
THIN TUBE 2,1A,R,BLSTR 18628800
THIN TUBE 2,1B,R,BLSTR 18628900
THIN TUBE 2,2A,R,BLSTR 18629000
THIN TUBE 2,2B,R,BLSTR 18629100
THIN TUBE 2,3A,R,BLSTR 18629200
THIN TUBE 2,3B,R,BLSTR 18629300
THIN TUBE 2,-1B,R,BLSTR 18629400
THIN TUBE 2,0A,L,BLSTR 18629500
THIN TUBE 2,0B,L,BLSTR 18629600
THIN TUBE 2,1A,L,BLSTR 18629700
THIN TUBE 2,1B,L,BLSTR 18629800
THIN TUBE 2,2A,L,BLSTR 18629900
THIN TUBE 2,2B,L,BLSTR 18630000
THIN TUBE 2,3A,L,BLSTR 18630100
THIN TUBE 2,3B,L,BLSTR 18630200
THIN TUBE 2,-1B,L,BLSTR 18630300
THIN TUBE DOMES
Description Bag
(10 pcs)
Blister Pack
(8 pcs)
DOME,THNTUB/REC,SZ5,SM 18500800 18607100
DOME,THNTUB/REC,SZ7,MDM 18500900 18607200
DOME,THNTUB/REC,SZ10,LGE 18501000 18607300
DOME,THNTB/REC,TULIP,STD 18501100 18607400
DOME,THNTUB/REC,PWR,SM 18265100 18607500
DOME,THNTUB/REC,PWR,MDM 18265200 18607600
DOME,THNTUB/REC,PWR,LGE 18265300 18607700
Part List - Thin Tubes & Domes
