Belkin FSU234ea Manuel utilisateur

Hi-Speed USB 2.0

4-Port Hub

Connect up to 4 Hi-Speed USB 2.0 or 1.1 devices

User Manual

F5U234ea

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 1

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 2

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 3

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 4

INTRODUCTION

Congratulations and thank you for purchasing the Belkin Hi-Speed USB

2.0 4-Port Hub (the Hub). The Hub provides four downstream USB ports

that offer backward-compatible, Plug-and-Play connectivity with all USB

devices, including USB 1.1 (or low- and full-speed) devices, as well as

with USB 2.0 (or high-speed) devices. This includes such peripherals as

scanners, printers, mass-storage devices, and high-resolution cameras.

The Hub is self-powered, which allows the cascading of devices with

additional hubs, so that up to 127 USB devices may be connected to a

single port.

The Hub is uniquely designed to allow the user to position the four

downstream ports toward the back of the desktop for efficient cable

management, or to the front of the desktop for easier port access. The

Hub also provides a status LED for each individual port and a master

power LED.

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 1

OVERVIEW

Features

• Compliant with Universal Serial Bus specification 2.0

(data rate 1.5/12/480Mbps)

• Backward-compatible with Universal Serial Bus specification 1.1

(data rate 1.5/12Mbps)

• Compatible with Windows® 98 SE, Me, 2000, and XP

• Approved by USB Implementers Forum (USB-IF)

• Supports Plug-and-Play specifications

• Supports “hot swapping” of USB devices

• Over-current detection and protection

• Individual port-status indicator LEDs

• Four 480Mbps downstream ports

• Fully compatible with USB 1.1 and USB 2.0 devices

• Compact, slim-line design

• Multiple hubs may be stacked on top of one another

Package Contents

• Hi-Speed USB 2.0 4-Port Hub

• AC Power Adapter

• User Manual

• USB device cable

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 2

OVERVIEW

Technical Specifications

Upstream Ports (1)

Downstream Ports (4)

Power Mode Self-powered/bus-powered

Per-Port Voltage DC +5V

Per Port Current Self-Powered Mode: 500mA (max)

Bus-Powered Mode: 100mA (max)

(Ports one and two only)

Operating Temperature 5º C ~ 40º C

Storage Temperature -20º C ~ 60º C

Enclosure ABS

Power Supply

Output: DC 5V, 2.1A

Plug Size: 3.5mm (outer)

1.0mm (center)

Plug Polarity: Center Positive

Main Power LED Color Definitions:

Off Not operational

Red Operational

Port Status LED Color Definitions:

Off Not operational, or no device

connected

Green Fully operational

Amber Over-current condition

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 3

INSTALLATION

Important Note: Please do not connect any USB devices to the Hub until

instructed to do so in step 4 of this installation

procedure.

1. Plug the AC adapter into a wall outlet, or surge suppressor. Plug the

DC connector into the DC Power Jack found on the side of the Hub.

Important Note: The Hub may be used without the power supply when

connecting devices that draw 100mA of current or less,

however, only port 1 and port 2 will be functional.

2. Plug the flat end of the provided USB device cable into the

downstream port of your computer or downstream port of another

hub, then plug the mini 6-pin connector of the device cable into the

upstream port on the rear of the Hub.

Important Note: The Hub must be connected to a USB 2.0-compliant host

in order to function in high-speed mode (480Mbps data

rate). If the Hub is connected to a USB 1.1-compliant

host, it will operate only in low-speed or full-speed mode

(1.5Mbps/12Mbps).

3. Windows will now detect your Hub and install the required driver

support. (The Windows “Install New Hardware Wizard” may prompt

you to provide your Windows Installation CD to complete the driver

installation process).

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 4

INSTALLATION

Important Note: High-speed hub drivers are included with most USB 2.0

PCI upgrade cards, and are pre-installed along with the

PCI card drivers. If you purchased an upgrade card prior

to the release of high-speed hub support, please check

with your PCI card vendor for an updated USB 2.0 driver.

The Belkin USB 2.0 driver supports all competitive cards

based on the NEC host controller with the exception of

Adaptec. The most recent Belkin driver is available at

www.belkin.com.

4. Plug the USB-A connector of the USB device, or an additional hub,

into any of the downstream ports of the Hub.

Important Note: When moving a device from one port on the Hub to

another, it may be necessary to reinstall the USB drivers

for that device.

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 5

INFORMATION

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC

COMPATIBILITY

We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our sole

responsibility that the product:

F5U234

to which this declaration relates:

Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

CE Declaration of Conformity

We, Belkin Corporation, declare under our sole responsibility that the F5U234, to which this

declaration relates, is in conformity with Generic Emissions Standard EN 55022:1998 Class B,

EN50081-1 and with Generic Immunity Standard EN50082-1

Belkin Corporation Limited Lifetime Product Warranty

Belkin Corporation warrants this product against defects in materials and workmanship for its

lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no

charge provided it is returned during the warranty period, with transportation charges prepaid,

to the authorized Belkin dealer from whom you purchased the product. Proof of purchase may

be required.

This warranty does not apply if the product has been damaged by accident, abuse, misuse, or

misapplication; if the product has been modified without the written permission of Belkin; or

if any Belkin serial number has been removed or defaced.

THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,

WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY

AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

No Belkin dealer, agent, or employee is authorized to make any modification, extension, or

addition to this warranty.

BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING

BUT NOT LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING

OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.

P74386ea_F5U234ea_uk 08-09-2003 11:13 Page 6
