Belkin F5U624 Manuel utilisateur

FireWire 800 3-Port Hub

Connect 3 FireWire devices for speeds up to 800Mbps

F5U624

User Manual

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . .2

Power Mode Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

INTRODUCTION

Congratulations and thank you for purchasing the Belkin FireWire

800 3-Port Hub (the Hub). The Belkin FireWire 800 3-Port Hub works

with computers running Windows® 98 SE, Me, 2000, XP,

or Power Macintosh® computers running Mac OS® 9.0 and above. For

use with DV multimedia devices such as camcorders and webcams,

and with such FireWire® devices as drives, scanners, and printers,

the Hub provides three, peer-to-peer FireWire ports that support

data transfers of up to 800Mbps.

It acts as a FireWire repeater, so you can place devices up to

an additional 15 feet (4.5 meters) apart. Devices connected to the

Hub with a 9-pin to 9-pin bilingual FireWire 800 cable, or a 6-pin to

9-pin FireWire cable, will be able to draw power from the Hub.

Please read this manual thoroughly prior to installation to

familiarize yourself with the Hub’s unique features and benefits.

INTRODUCTION

Package Contents

• FireWire 800 3-Port Hub

• 9-pin to 9-pin bilingual FireWire cable

• 12-volt, 1.25-Amp power supply

• User Manual

Features

• Supports the Open Host Controller Interface standard (OHCI)

• Three 9-pin bilingual FireWire ports

• Operates in self-powered or bus-powered modes

• Includes a FireWire repeater feature. Extend length of

FireWire chain by up to 15 feet (4.5 meters).

Technical Specifications

• Transport Speeds Supported: 100/200/400/800Mbps

Note: To operate in 800Mbps mode, your computer must be equipped

with a built-in FireWire 800 port or a FireWire 800 PCI upgrade card.

• Power Mode: Self-powered or bus-powered

• Operation Temperature: 41° F–104° F (5° C–40° C)

• Stock Temperature: -4° F–219° F (-20° C–60° C)

• Enclosure: ABS Plastic

• Power Supply: Input: 100–240VAC

• Output: DC 12V–1.25A (15W max)

• Power Supply Polarity: Center positive

• LED Functions:

Amber—Indicates that power supply only is connected

Green—Indicates that the Hub is connected to a ready FireWire port

POWER MODE OPTIONS

The FireWire 800 3-Port Hub supports either self-powered or bus-powered

modes of operation. Bus-powered mode is usually sufficient when using

FireWire devices that provide their own power. When using the Hub with mul-

tiple bus-powered FireWire devices or on a laptop computer, it is recommend-

ed that the Hub be operated in self-powered mode.

Self-powered mode

Hub is powered by external AC adapter (12V/1.25A max)

Bus-powered mode

Hub is powered by FireWire bus, through your computer connection (8–40V/1A

max)

The Hub will automatically operate in bus-powered mode if the power supply

is not used.

INSTALLATION

Self-powered mode

1. Plug AC adapter into a 110V AC outlet, then plug the adapter cord

into the Hub.

2. Connect the Hub to an available FireWire port on your computer. If you

are connecting the Hub to a 6-pin FireWire port, use a 6-pin to 9-pin

FireWire cable. If you are connecting the Hub to a 9-pin FireWire 800 port,

use the provided 9-pin bilingual to 9-pin bilingual FireWire 800 cable.

3. Connect your FireWire devices to the Hub using the cable supplied with

each device. If your device did not include a cable, or the cable has been

lost, please visit belkin.com, or your local retailer to obtain a quality

Belkin replacement cable.

4. Place the Hub in a convenient location on your desktop.

The Hub is now ready for use.

Bus-powered mode

1. Connect the Hub to an available FireWire port on your computer. If you

are connecting the Hub to a 6-pin FireWire port, use a 6-pin to 9-pin

FireWire cable. If you are connecting the Hub to a 9-pin FireWire 800 port,

use the provided 9-pin bilingual to 9-pin bilingual FireWire 800 cable.

2. Connect your FireWire devices to the Hub using the cable supplied with

each device. If your device did not include a cable, or the cable has been

lost, please visit belkin.com, or your local retailer to obtain a quality

Belkin replacement cable.

3. Place the Hub in a convenient location on your desktop.

The Hub is now ready for use.

Note: To use the Belkin FireWire 800 3-Port Hub, your computer must be

equipped with a built-in FireWire host adapter, or with a FireWire host adapter

upgrade card. Make sure your host adapter is properly installed and recognized

by your operating system before installing the Hub

INFORMATION

FCC Statement

DECLARATION OF CONFORMITY WITH FCC RULES FOR

ELECTROMAGNETIC COMPATIBILITY

We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under

our sole responsibility that the product:

F5U624

to which this declaration relates:

Complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

CE Declaration of Conformity

We, Belkin Corporation, declare under our sole responsibility that the F5U624, to which this decla-

ration relates, is in conformity with Generic Emissions Standard EN 55022:1998 Class B,

EN50081-1 and with Generic Immunity Standard EN50082-1 1992.

Belkin Corporation Limited Lifetime Product Warranty

Belkin Corporation warrants this product against defects in materials and workmanship for its life-

time. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge

provided it is returned during the warranty period, with transportation charges prepaid, to the

authorized Belkin dealer from whom you purchased the product. Proof of purchase may be required.

This warranty does not apply if the product has been damaged by accident, abuse, misuse, or

misapplication; if the product has been modified without the written permission of Belkin; or if any

Belkin serial number has been removed or defaced.

THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS, WHETHER ORAL

OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED

WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE.

No Belkin dealer, agent, or employee is authorized to make any modification, extension,

or addition to this warranty.

BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING

FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT

LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING OR

REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.

All trade names are registered trademarks of respective manufacturers listed. FireWire, Mac OS, and Power

Macintosh are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.

P74325

Belkin Components B.V.

Starparc Building • Boeing Avenue 333

1119 PH Schiphol-Rijk • The Netherlands

Tel: +31 (0) 20 654 7300

Fax: +31 (0) 20 654 7349

Belkin Components, Ltd.

Express Business Park • Shipton Way

Rushden • NN10 6GL • United Kingdom

Tel: +44 (0) 1933 35 2000

Fax: +44 (0) 1933 31 2000

Belkin Corporation

501 West Walnut Street

Compton • CA • 90220 • USA

Tel: 310.898.1100

Fax: 310.898.1111

Belkin, Ltd.

7 Bowen Crescent • West Gosford

NSW 2250 • Australia

Tel: +61 (0) 2 4372 8600

Fax: +61 (0) 2 4372 8603

Belkin Tech Support

US: 310.898.1100 ext. 2263

800.223.5546 ext. 2263

Europe: 00 800 223 55 460

Australia: 1800 666 040

Hub FireWire 800 à 3 Ports

Branchez 3 périphériques FireWire et obtenez un

débit jusqu’à 800 Mbps

F5U624

Manuel de l'utilisateur

TABLE DES MATIÈRES

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contenu de l’emballage . . . . . . . . . . . . . . . . . . . . . . . .2

Caractéristiques . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . .2

Options du Mode d’alimentation . . . . . . . . . . . . . . . . . . . .3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
