Belkin® Secure 2/4 port DisplayPort

KVM Switch User Manual

User Manual

F1DN102P 2-port Displayport, Single-Head + CAC + DCU

F1DN104P 4-port Displayport, Single-Head + CAC + DCU

F1DN104W 4-port Displayport, Dual-Head + CAC + DCU

F1DN104Q 4-port Displayport, Quad-Head + CAC + DCU

Document Number 8820-00776 Rev. A00

TABLE OF CONTENTS

SECTIONSTable of Contents 12345678SECTIONS 12345678Table of Contents

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Operating the KVM Switch ............................... 17

Common Access Card (CAC) Configuration and Operation ... 18

Troubleshooting ........................................ 19

Information............................................. 22

Reporting Belkin Product Security Vulnerability ......... 25

Introduction ............................................. 1

Package Contents ..................................... 1

Safety Precautions ..................................... 2

Overview................................................ 3

Security Features ...................................... 3

Other Features ........................................ 5

Equipment Requirements ............................... 6

System Requirements .................................. 7

Unit Display Diagrams .................................. 8

Specifications........................................ 12

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Pre-Configuration .................................... 14

Connection and Installation............................. 15

Color Code Chip Installation ............................ 16

INTRODUCTION

SECTIONSTable of Contents 12345678SECTIONSTable of Contents 12345678

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Thank you for purchasing this Belkin Secure DisplayPort KVM. This

Switch is designed for use in secure environment installations. The

Switch offers safe centralized control, which prevents unintended

data transfer between computers running at different security levels.

The Switch provides the highest security safeguards and features that

meet today’s Information Assurance (IA) computing requirements.

Belkin Secure DisplayPort KVM is especially challenging in terms of

security as DisplayPort is a very robust protocol by nature which is

capable of transferring various types of information, such as USB and

Ethernet other than display. Belkin has developed this unique Secure

KVM switch with the highest possible security in mind, assuring no

leakage of information between connected computers through any

channels including DP dedicated channels.

This User Manual provides all the details you’ll need to install and

operate your new Switch, in addition to expert troubleshooting

advice—in the unlikely event of a problem.

Package Contents

• Belkin Secure DisplayPort KVM

• 12V 1.5A DC Power Supply

• Interchangeable Port Color Chips

• Port-Naming Labels

• User Manual

Important: This product is equipped with always-on active

anti-tamper system. Any attempt to open the enclosure

may activate the anti-tamper system and render the unit

permanently inoperable. If the unit’s enclosure appears

disrupted or if all the port LEDs flash continuously, please call

Belkin Technical Support at (800) 282-2355 .

Important Security Note:

If you are aware of potential security vulnerability while

installing or operating this product, we encourage you to

gov_securit[email protected]

Please note: Belkin Secure KVMs cannot be upgraded, serviced

or fixed.

SECTIONSTable of Contents 12345678SECTIONSTable of Contents 12345678

INTRODUCTION

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Safety Precautions

Please read the following safety precautions carefully before using

the product:

• Before cleaning, disconnect the product from the AC power source

• Be sure not to expose the product to excessive humidity.

• Do not store or use for extensive period of time in extreme thermal

conditions—it may shorten product lifetime.

• Be sure to install the product on a clean secure surface.

• Do not place the DCU cable in a path of foot traffic.

• If the product is not used for a long period of time, remove the

KVM’s wall-mount power supply from the mains jack.

• If one of the following situations occurs, get the product checked by

a qualified service technician:

o Liquid penetrates the product’s case.

o The product is exposed to excessive moisture or water.

o The product is not working well even after carefully following the

instructions in this user’s manual.

o The product has been dropped or is physically damaged.

o The product has obvious signs of breakage or loose

internal parts.

o AC Power plug or cable overheated, broken, or damaged.

• The product should be stored and used only in temperature and

humidity controlled environments as defined in the product’s

environmental specifications.

• The product contains an internal battery. Battery is non-replaceable.

Never attempt to replace battery as any attempt to open product

enclosure would permanently damage the product.

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

The Belkin Secure DisplayPort KVM is the most advanced and

secure commercially available KVM Switch available today. Below is a

summary of all the security features incorporated into the Switch.

Protected DisplayPort Channel

Belkin Secure DisplayPort KVM switch includes safety mechanisms

to protect DisplayPort channels and preventing leakage of information

between connected computers and the DisplayPort display.

Dedicated Processors

The Switch features a dedicated processor per computer port. This

keeps each computer running on different security levels physically

separated and secure at all times, and prevents any unintended data

leakage between computers.

No Memory Buffer

The Switch does not have a memory buffer and does not have the

ability to store data. This prevents any keystrokes or other data

input from being unintentionally transferred when switching between

computers, ensuring the integrity of data.

Non-Reprogrammable Firmware

The Switch features custom firmware that is not reprogrammable,

preventing the ability to tamper with the KVM logic.

Unidirectional Data Paths

Optical diodes used in USB data paths provide high isolation and

prevent data leakage.

Heavy Duty Aluminum Enclosure

The Belkin Secure DisplayPort KVM uses one-piece aluminum

enclosure to protect the product from physical tampering and to

minimize radiated electromagnetic emissions that can be snooped or

intercepted.

Active Always-On Anti-Tampering

Active always-on chassis anti-tampering system prevents the Belkin

Secure DisplayPort KVM electronic circuitry from being accessed and

tampered with by permanently disabling the product once tampering

is detected.

Tamper-Evident Label

A holographic security tamper-evident label is placed on the

enclosure to provide a visual indication if the Switch has been opened

or compromised.

Security Features

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Tamper-Proof Hardware

All integrated circuits are soldered directly to the printed circuit board

to prevent tampering with the components.

Protected Display Information

Protected DDC/EDID emulation prevents software weaknesses that

can cause data leakage while maintaining compatibility with the

console display.

USB Device Detection

Storage and other unsafe USB devices are rejected when connected

to the Switch. Only mouse, keyboard, and CAC reader data are

passed through.

Secure Packaging

“Tear away” packaging ensures secure delivery of the Switch as it is

routed to the end user. The recyclable packaging also breaks down

flat, simplifying the cleanup process.

EAL 4+ Evaluation (Canada)

The Belkin Secure DisplayPort KVM switch was evaluated in Canada

to EAL 4+ level and is listed on the Common Criteria Portal

Tamper-Proof Hardware

All integrated circuits are soldered directly to the printed circuit board

to prevent tampering with the components.

Protected Display Information

Protected DDC/EDID emulation prevents software weaknesses that

can cause data leakage while maintaining compatibility with the

console display.

USB Device Detection

Storage and other unsafe USB devices are rejected when connected

to the Switch. Only mouse, keyboard, and CAC reader data are

passed through.

Secure Packaging

“Tear away” packaging ensures secure delivery of the Switch as it is

routed to the end user. The recyclable packaging also breaks down

flat, simplifying the cleanup process.

EAL 4+ Evaluation (Canada)

The Belkin Secure DisplayPort KVM switch was evaluated in Canada

to EAL 4+ level and is listed on the Common Criteria Portal

Bloomberg Keyboard Support

The Belkin Secure DisplayPort KVM supports the Bloomberg

Keyboard through the Console PS/2 Keyboard jack.

Other Features

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Equipment Requirements

Cables

Belkin highly recommends you use Belkin Display Port/USB KVM

Cable Kits for your Switch to help ensure superior performance.

These cables offer the highest quality possible to ensure optimal data

and video transmission. One Cable Kit is required per connected

computer.

Belkin DP to DP KVM Cable Kits with audio:

F1D9019b06 – 6ft (1.8m)

F1D9017b10 – 10ft (3m)

Belkin CAC USB A/B Cables

F1D9013b06 – 6 ft. (1.8m)

F1D9013b10 – 10 ft. (3m)

F1D9013b15 – 15 ft. (4.6m)

Belkin Smart Cables

F1D9011b06 (USB to DVI-I Smart Cable, 6’)

F1D9017b06 (DP to DVI Smart Cable, 6’)

Belkin DP to DVI Cables

F2CD002b06-E (DP to DVI)

Note: Due to USB and DisplayPort signal limitations, the cable length

cannot exceed 15 feet (4.6m).

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Operating-System (OS) Platforms

The Switch is compatible with computers running on, but not limited

to, the following OS platforms:

• Windows® 2000

• Windows XP (Home/Professional)

• Windows 2003 Server

• Windows 7

• Windows 8

• Windows Vista®

• Red Hat® Linux®

• Other Linux distributions

• Mac OS® X v10.3 and higher

Keyboards

• USB-compatible or keyboard + mouse composite device (keyboards

with built-in USB hubs are not supported).

Mice

• USB-compatible (non-composite)

Monitors

• Digital displays with Display Port 1.1 and 1.2 signals

Common Access Card Readers

• USB-compatible CAC or Smart Card Readers

Desktop Controller Unit

The Belkin Secure DisplayPort KVM Switch is compatible with the

following types of Remote Desktop Controller device:

• DCU device connected to the switch DCU port.

• DCU must be connected through

Belkin RJ14 custom cable standard: Belkin Part Numbers:F1D9026-06

(CABLE, RJ14, 6P6C, 26AWG, UNSHIELDED, DCU CABLE, 6’),

F1D9026-50 (CABLE, RJ14, 6P6C, 26AWG, UNSHIELDED, DCU

CABLE, 50’) and higher LAN cable.

System Requirements

Do not connect DCU to anything but Belkin Secure KVMs via

supplied RJ14 custom cable.

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Unit Display Diagram, Front View

IMPORTANT

NOTICE:

If for any reason

the tamper-evident

seal is missing,

appears disrupted,

or looks different

than the example

shown here, please

call Belkin Technical

Support at (800)

282-2355.

(F1DN104P model shown)

OVERVIEW

SECTIONSTable of Contents 123456782

Belkin® Secure 2/4 port DisplayPort KVM Switch User Manual

Back View

(F1DN104P model shown)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Belkin Changer

Belkin

Belkin F1DN102KVM-UN-3 Manuel utilisateur

Belkin

Belkin OmniView F1DG102P Manuel utilisateur

Belkin

Belkin OmniView F1DS102P Manuel technique

Belkin

Belkin OmniView F1DS102J Manuel utilisateur

Belkin

Belkin F1DN108C Manuel utilisateur

Belkin

Belkin F5L009 - Network USB Hub Manuel utilisateur

Belkin

Belkin F5D5131-16 - 10/100 Switch Manuel utilisateur

Belkin

Belkin F1DN116KVM-UN-4 Manuel utilisateur

Belkin

Belkin F1DN108K-3 Manuel utilisateur

Belkin

Belkin F4U006 - Travel USB Hub Manuel utilisateur

Belkin

Belkin OmniView F1DL102P Manuel utilisateur

Belkin

Belkin F1DN102B Manuel utilisateur

Belkin

Belkin F1DN104B-3 Manuel utilisateur

Belkin

Belkin OmniView Dual-User PRO3 Manuel utilisateur

Belkin

Belkin F1DN104K-3 Manuel utilisateur

Belkin

Belkin OmniView F1DD102U Manuel utilisateur

Belkin

Belkin OmniView Secure F1DN104U Manuel utilisateur

Belkin

Belkin Switch Manuel utilisateur

Belkin

Belkin HI-SPEED USB 2.0 EXTERNAL DRIVE ENCLOSURE Manuel utilisateur

Belkin

Belkin OmniView F1DB102P2ea Manuel utilisateur

Belkin

Belkin KVM for Mac mini Manuel utilisateur

Belkin

Belkin OmniView Dual-User PRO3 Manuel utilisateur

Belkin

Belkin OmniView SOHO F1DD102L Manuel utilisateur

Belkin

Belkin F5U416 - Clip-On Hub Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
