Belkin F9L1004 Manuel utilisateur

User Manual

F9L1004 8820xx00894xx Rev. A00

ExtEndEd RangE USB WiRElESS n adaptER

SURF N300 XR

English

TABLE OF CONTENTS

1. Introduction ............................................ 1

Benefits of a Home Network.................................... 1

Advantages of a Wireless Network .............................. 2

Placement of your Wireless Networking Hardware for

Optimal Performance ......................................... 3

2. Overview .............................................. 7

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Applications and Advantages................................... 8

Product Specifications ........................................ 9

System Requirements........................................ 10

Package Contents ........................................... 10

3. Installing and Setting up the Adapter .................... 11

A — Installation Process for Windows Vista and 7 ................ 11

B — Installation Process for Windows XP ....................... 18

Connecting to a Secure Wi-Fi Network.......................... 16

4. Troubleshooting ....................................... 22

5. Information ........................................... 30

European Compliance Statement:..............................34

Belkin International, Inc., Limited 2-Year Product Warranty ........35

Thank you for purchasing the Belkin N300 High Gain Wireless USB Adapter. With its adjustable high-gain antenna, you

can connect farther and faster than standard adapters. Now you can take advantage of this great new technology and

gain the freedom to network your home and office computers wirelessly. This Adapter allows you to connect a notebook

or desktop computer to your network. Please be sure to read through this User Manual completely, and pay special

attention to the section titled, “Placement of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

 •Shareonehigh-speedInternetconnectionwithallthecomputersinyourhome

 •Shareresources,suchasfiles,andharddrivesamongalltheconnectedcomputersinyourhome

 •Shareasingleprinterwiththeentirefamily

 •Sharedocuments,music,video,anddigitalpictures

 •Store,retrieve,andcopyfilesfromonecomputertoanother

 •Simultaneouslyplaygamesonline,checkInternetemail,andchat

INTRODUCTION

Advantages of a Wireless Network

 •Mobility –you’ll no longer need a dedicated “computer room”—now you can work on a

networked laptop or desktop computer anywhere within your wireless range

 •Easy installation–BelkinEasyInstallationWizardsmakesetupsimple

 •Flexibility – set up and access printers, computers, and other networking devices from anywhere in your home

 •Easy expansion – the wide range of Belkin networking products let you expand your

network to include devices such as printers and gaming consoles

 •No cabling required – you can spare the expense and hassle of retrofitting Ethernet cabling throughout the home or office

 •Widespread industry acceptance – choose from a wide range of interoperable networking products

INTRODUCTION

Placement of your Wireless Networking Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer is to your wireless router (or access point). Typical indoor operating

rangeforyourwirelessdevicesisbetween100and200feet.Inthesameway,yourwirelessconnectionandperformancewilldegrade

somewhat as the distance between your wireless router (or access point) and connected devices increases. This may or may not

be noticeable to you. As you move farther from your wireless router (or access point), connection speed may decrease. Factors that

can weaken signals simply by getting in the way of your network’s radio waves are metal appliances or obstructions, and walls.

Ifyouhaveconcernsaboutyournetwork’sperformancethatmightberelatedtorangeorobstructionfactors,try

moving the computer to a position between five and 10 feet from the wireless router (or access point) in order to see if

distanceistheproblem.Ifdifficultiespersistevenatcloserange,pleasecontactBelkinTechnicalSupport.

Note: While some of the items listed below can affect network performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating at its maximum effectiveness, this checklist may help.

INTRODUCTION

1. Placement of your Wireless Router (or Access Point)

Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

 •Ensurethatyourwirelessrouter’s(oraccesspoint’s)

antennas are parallel to each other, and are positioned

vertically(towardtheceiling).Ifyourwirelessrouter(or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

 •Inmultistoryhomes,placethewirelessrouter(or

access point) on a floor that is as close to the center

of the home as possible. This may mean placing the

wireless router (or access point) on an upper floor.

 •Trynottoplacethewirelessrouter(oraccess

point)nearacordless2.4GHzphone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:

 •Refrigerators

 •Washersand/ordryers

 •Metalcabinets

 •Largeaquariums

 •Metallic-based,UV-tintedwindows

 •Microwaves

Ifyourwirelesssignalseemsweakinsomespots,makesure

that objects such as these are not blocking the signal’s path

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

Iftheperformanceofyourwirelessnetworkisimpairedafter

attending to the above issues, and you have a cordless phone:

 •Trymovingcordlessphonesawayfromthewirelessrouter

(or access point) and your wireless-enabled computers.

 •Unplugandremovethebatteryfromanycordlessphonethat

operatesonthe2.4GHzband(checkmanufacturer’sinformation).

Ifthisfixestheproblem,yourphonemaybeinterfering.

 •Ifyourphonesupportschannelselection,changethechannel

on the phone to the farthest channel from your wireless network

as possible. For example, change the phone to channel 1 and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

See your phone’s user manual for detailed instructions.

 •Ifnecessary,considerswitchingtoa

900MHzor5GHzcordlessphone.

4. Choose the “Quietest” Channel for your Wireless Network

Inlocationswherehomesorofficesareclosetogether,such

as apartment buildings or office complexes, there may be

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experiment with more than one of the available channels in

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secureconnectionstypicallyrequireausernameandpassword,and

are used where security is important. Secure connections include:

 •VirtualPrivateNetwork(VPN)connections,often

used to connect remotely to an office network

 •The“BringYourOwnAccess”programfromAmerica

Online(AOL),whichletsyouuseAOLthroughbroadband

providedbyanothercableorDSLservice

 •Mostonlinebankingwebsites

 •Manycommercialwebsitesthatrequireauser

name and password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPNorAOLsoftware,orbyre-loggingintothesecurewebsite.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

IfyoucontinuetohavedifficultywithSecureConnections,

VPNs,andAOL,pleasereviewsteps1–4intheprevious

pages to be sure you have addressed these issues.

These guidelines should allow you to cover the maximum possible

area with your wireless router. Should you need to cover an even wider

area,wesuggesttheBelkinWirelessRangeExtender/AccessPoint.

For more information regarding our networking products,

visitourwebsiteatwww.belkin.com/networking

or call Belkin Technical Support.

Product Features

The Adapter complies with the IEEE 802.11n specification to

communicate with other 802.11n-compliant wireless devices at up to

300Mbps*. The Adapter is also compatible with 802.11g devices at

54Mbps as well as 802.11b products at 11Mbps. The Adapter operates

on the same 2.4GHz frequency band as 802.11b/g Wi-Fi®products.

 •2.4GHzISM(Industrial,Science,andMedical)bandoperation

 •USB2.0interface,foroperationinvirtuallyany

computerwithaUSB2.0bus-powerport

 •Adjustablehigh-gainantennaforgreaterrange

 •WPA,WPA2,64-bitWEP(WiredEquivalent

Privacy),or128-bitencryption

 •Wirelessaccesstonetworkedresources

 •Datarateofupto300Mbps*(802.11n),54Mbps

(802.11g),or11Mbps(802.11b)

 •Easyinstallationanduse

 •LEDpowerandnetworklink/activityindicator

OVERVIEW

Applications and Advantages

 •Wirelessroamingwithalaptoparoundthehomeoroffice

Offersthefreedomofnetworkingwithoutcables

 •Connectionratesofupto300Mbps*

Providesimmediatehigh-speedwirelessconnectivity

athome,work,andhotspotlocationswithout

compromising the use of existing 802.11b/g products

 •Compatibilitywith802.11b/gproducts

TheAdapterisbackward-compatiblewith

existingWi-Fi(IEEE802.11b/g)products

 •Difficult-to-wireenvironments

Enablesnetworkinginbuildingswithsolidorfinished

walls,oropenareaswherewiringisdifficulttoinstall

 •Frequentlychangingenvironments

Adapts easily in offices or environments that

frequently rearrange or change locations

 •SOHO(SmallOffice/HomeOffice)networkingneeds

  Providestheeasyandquick,smallnetwork

installationSOHOusersneed

 •MicroEnclosure

The Adapter has been designed to fit neatly into

yourcomputer’sUSBportandsitnicelyontheside

oftheportwithoutblockinganyotherports.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Belkin Adaptateur

Belkin

Belkin F5U103 Manuel utilisateur

Belkin

Belkin G+MIMO Manuel utilisateur

Belkin

Belkin F5U022 Manuel utilisateur

Belkin

Belkin F5D5050 Manuel utilisateur

Belkin

Belkin F5D7051 Manuel utilisateur

Belkin

Belkin PUREIAV RemoteTV 5GHz Wireless TV Adapter Manuel utilisateur

Belkin

Belkin F8T003 Manuel utilisateur

Belkin

Belkin F5D4081 v1_8820ea00632 Manuel utilisateur

Belkin

Belkin F1DN002A Manuel utilisateur

Belkin

Belkin DUAL-BAND Wi-Fi Manuel utilisateur

Belkin

Belkin F5D4078 Manuel utilisateur

Belkin

Belkin F5L043-DL Manuel utilisateur

Belkin

Belkin F5U257 Manuel utilisateur

Belkin

Belkin F5D4076 - Gigabit Powerline HD Starter Manuel utilisateur

Belkin

Belkin SURF N300 Manuel utilisateur

Belkin

Belkin F5U103 Manuel utilisateur

Belkin

Belkin F8T013UK Manuel utilisateur

Belkin

Belkin Bluetooth USB Adapter F8T013 Manuel utilisateur

Belkin

Belkin VideoBus II F5U208-MAC Manuel utilisateur

Belkin

Belkin Play F7D4101 Manuel utilisateur

Belkin

Belkin Bluetooth USB Adapter F8T012 Manuel utilisateur

Belkin

Belkin F5U011 Manuel utilisateur

Belkin

Belkin BASIC F7D1101 Manuel utilisateur

Belkin

Belkin F8T001 Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
