Belkin F5L043-DL Manuel utilisateur

Auto/Air Power Adapter for Dell Inspiron Mini 9

User Manual

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 1 1/12/09 3:22:51 PM

Introduction

Thank you for purchasing the Belkin Auto/Air Power Adapter for Dell. This Adapter allows you

to power Dell Inspiron™Mini 9 laptops from a car or airplane. It’s easy to connect the Adapter

to the cigarette lighter assembly (CLA) in most automobiles as well as many commercial

aircraft (an Empower®plug is provided for use in aircraft that feature Empower ports).

Product Registration and Warranty

For terms and conditions, to activate your warranty, and to register your

Auto/Air Power Adapter for Dell, please visit www.belkin.com/registration.

Important Safety Information

Before use, please read the following important safety information.

Following these simple guidelines will ensure trouble-free operation and optimal

performance of the Auto/Air Power Adapter for Dell and compatible electronic devices.

1. Avoid pulling on the cords and cables. Always grip plugs firmly when unplugging

from power source and when disconnecting cables. Never force the tip into an

electronic device.

2. Before use, completely review this guide.

3. For indoor use only. Avoid exposure to external heat sources; direct, prolonged sunlight;

dust; corrosive chemicals; and moisture.

4. It is normal for power adapters to become warm during use.

Avoid touching the device during use. Avoid placing in direct sunlight or near heat-

sensitive materials.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 2 1/12/09 3:22:51 PM

Important Safety Information

5. Do not drop or subject the Adapter to undue shock.

6. Do not place anything on top of the Adapter.

7. Always use the supplied cables and connectors as shown. Use of cables, connectors,

or accessories not supplied with this product constitutes misuse and may result in injury

or damage.

8. Do not attempt to service or disassemble. The unit is not user-serviceable. Attempting

to disassemble or service the unit can result in electrical hazard, including death from

exposure to high voltage. If you experience problems with the unit, discontinue use and

contact Belkin for assistance. Attempting to open or service the unit voids all warranties,

express or implied.

Using the Belkin Auto/Air Power Adapter for Dell

Simply insert the CLA in the socket provided onboard the aircraft or in your vehicle.

If the aircraft features Empower outlets, remove the cigarette lighter assembly to expose

the Empower plug and insert the Empower plug into socket. Power will now be supplied

to your laptop.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 3 1/12/09 3:22:51 PM

Technical Specifications

Input Voltage 12–15 VDC

Output Voltage 19.5 VDC

Output Current 2.3 Amps max

Output Power 45 Watts max

Unit Dimensions 64 x 42.5 x 30mm

Weight 175g

Total Length 1650mm

Storage Temperature -40° to 70° C

Operating Temperature 0° to 40° C

Relative Humidity (non-condensing) 95%, max

Built-in Circuit Protection Over voltage, under voltage, over current,

short circuit, over temperature

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 4 1/12/09 3:22:52 PM

Compatibility

The Auto/Air Power Adapter only works with the Dell Inspiron Mini 9.

Troubleshooting

If your device is not charging or operating properly, take the following steps:

1. Disconnect the Adapter from its power source.

2. Verify that the laptop is compatible with the Adapter.

(The Adapter is only compatible with the Dell Inspiron Mini 9.)

NEVER force a power tip into an electronic device.

3. Reconnect the Auto/Air Power Adapter to the laptop. Check that all connections

are secure.

4. Note that if the green power-indicator LED does not light, it may have simply burned out.

5. If you are still experiencing problems, please contact Belkin.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 5 1/12/09 3:22:52 PM

Information

CE Declaration of Conformity

We, Belkin International, Inc., declare under our sole responsibility that the F5L043-DL, to

which this declaration relates, is in conformity with Generic Emissions Standard EN 55022

and with Generic Immunity Standard EN 55024.

Belkin International, Inc., Limited Lifetime Product Warranty

What this warranty covers.

Belkin International, Inc. (“Belkin”) warrants to the original purchaser of this Belkin product

that the product shall be free of defects in design, assembly, material, or workmanship.

What the period of coverage is.

Belkin warrants the Belkin product for the lifetime of the product.

What will we do to correct problems?

Product Warranty.

Belkin will repair or replace, at its option, any defective product free of charge (except for

shipping charges for the product). Belkin reserves the right to discontinue any of its products

without notice, and disclaims any limited warranty to repair or replace any such discontinued

products. In the event that Belkin is unable to repair or replace the product (for example,

because it has been discontinued), Belkin will offer either a refund or a credit toward the

purchase of another product from Belkin.com in an amount equal to the purchase price of

the product as evidenced on the original purchase receipt as discounted by its natural use.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 6 1/12/09 3:22:52 PM

Information

What is not covered by this warranty?

All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon

Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product

has been improperly installed, altered in any way or tampered with. The Belkin Product Warranty does

not protect against acts of God such as flood, lightning, earthquake, war, vandalism, theft, normal-use

wear and tear, erosion, depletion, obsolescence, abuse, damage due to low voltage disturbances (i.e.,

brownouts or sags), non-authorized program, or system equipment modification or alteration.

How to get service.

To get service for your Belkin product you must take the following steps:

1. Contact Belkin Ltd. Express Business Park, Shipton Way, Rushden, NN10 6GL, United Kingdom,

Attn: Customer Service, or call +44 (0) 1933 35 2000, within 15 days of the Occurrence.

Be prepared to provide the following information:

a. The part number of the Belkin product.

b. Where you purchased the product.

c. When you purchased the product.

d. Copy of original receipt.

2. Your Belkin Customer Service Representative will then instruct you on how to

forward your receipt and Belkin product and how to proceed with your claim.

Belkin reserves the right to review the damaged Belkin product. All costs of shipping the Belkin

product to Belkin for inspection shall be borne solely by the purchaser. If Belkin determines, in its sole

discretion, that it is impractical to ship the damaged equipment to Belkin, Belkin may designate, in its

sole discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment.

The cost, if any, of shipping the equipment to and from such repair facility and of such estimate shall be

borne solely by the purchaser. Damaged equipment must remain available for inspection until the claim

is finalized. Whenever claims are settled, Belkin reserves the right to be subrogated under any existing

insurance policies the purchaser may have.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 7 1/12/09 3:22:52 PM

Information

Country Number Internet adress

AUSTRIA 08 - 20 20 07 66 http://www.belkin.com/uk

BELGIUM 07 07 00 073 http://www.belkin.com/nl

CZECH REPUBLIC 23 900 04 06 http://www.belkin.com/uk

DENMARK 701 22 403 http://www.belkin.com/uk

FINLAND 00800 - 22 35 54 60 http://www.belkin.com/uk

FRANCE 08 - 25 54 00 26 http://www.belkin.com/fr

GERMANY 0180 - 500 57 09 http://www.belkin.com/de

GREECE 00800 - 44 14 23 90 http://www.belkin.com/uk

HUNGARY 06 - 17 77 49 06 http://www.belkin.com/uk

ICELAND 800 8534 http://www.belkin.com/uk

IRELAND 0818 55 50 06 http://www.belkin.com/uk

ITALY 02 - 69 43 02 51 http://www.belkin.com/it/support/tech

LUXEMBOURG 34 20 80 8560 http://www.belkin.com/uk

NETHERLANDS 0900 - 040 07 90

€0.10 per minute http://www.belkin.com/nl

NORWAY 815 00 287 http://www.belkin.com/uk

POLAND 00800 - 441 17 37 http://www.belkin.com/uk

PORTUGAL 707 200 676 http://www.belkin.com/uk

RUSSIA 495 580 9541 http://www.belkin.com/uk

SOUTH AFRICA 0800 - 99 15 21 http://www.belkin.com/uk

SPAIN 902 - 02 43 66 http://www.belkin.com/es/support/tech

SWEDEN 07 - 71 40 04 53 http://www.belkin.com/se/support/tech

SWITZERLAND 08 - 48 00 02 19 http://www.belkin.com/uk

UNITED KINGDOM 0845 - 607 77 87 http://www.belkin.com/uk

OTHER COUNTRIES +44 - 1933 35 20 00

You can find additional support information on our website www.belkin.com

through the tech-support area. If you want to contact technical support by

phone, please call the number you need from the list below*.

*Local rates apply

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 8 1/12/09 3:22:53 PM

8820-00019uk

Belkin Tech Support

Europe: www.belkin.com/support

Belkin Ltd.

Express Business Park, Shipton Way

Rushden, NN10 6GL, United Kingdom

+44 (0) 1933 35 2000

+44 (0) 1933 31 2000 fax

Belkin SAS

130 rue de Silly

92100 Boulogne Billancourt, France

+33 (0) 1 41 03 14 40

+33 (0) 1 41 31 01 72 fax

Belkin GmbH

Hanebergstraße 2,

80637 Munich, Germany

+49 (0) 89 143405 0

+49 (0) 89 143405 100 fax

Belkin B.V.

Boeing Avenue 333

1119 PH Schiphol-Rijk, Netherlands

+31 (0) 20 654 7300

+31 (0) 20 654 7349 fax

Belkin Iberia

C/ Anabel Segura, 10 planta baja, Of. 2

28108, Alcobendas, Madrid, Spain

+34 91 791 23 00

+34 91 490 23 35 fax

Belkin Italy & Greece

Via Carducci, 7

Milan 20123, Italy

+39 02 862 719

+39 02 862 719 fax

are registered trademarks of respective

manufacturers listed.

8820-00019-F5L043-DL_AAir_MAN_uk-prt.indd 9 1/12/09 3:22:54 PM
