USB Serial Adapter

User Manual

F5U103

P73309

Compatible Devices

MODEM.CPL, a component of Windows®98. The easiest solution to this

problem is to attach the USB Serial Adapter to either the root hub (a USB port

on the back of your PC) or to a hub that is connected to the root hub.

6.0. Using the Adapter on a Belkin BusStation™

The USB Serial Adapter can be used as a module to the Belkin BusStation™

(Part No. F5U100). To connect the adapter, simply remove the sleeve and slide

the adapter into one of the BusStation™bays as shown below. For more details

about the BusStation™, please check the BusStation™user manual or visit our

Web site at www.belkin.com.

Belkin Components has made their best effort to ensure that all the information

contained in this document is accurate and reliable. However, the information is

subject to change without notice. No responsibility is assumed by Belkin

Components for the use of this information, or for infringements of patents or

other rights of third parties.

sleevesleeve

BusStation™

5. Troubleshooting

5.1. Port unavailable

If the installation of the USB Serial Adapter has been completed but the port is

unavailable to applications, follow the instructions below to diagnose the

problem:

1. Check the LEDs on the USB Serial Adapter.

• If the red light is on steady, skip to the next section.

• If there are no lights on, check to make sure the device

has been properly plugged in.

• If the center, green LED is blinking steadily, the device has not been

configured properly. This can happen if the wrong drivers have been

installed for your operating system. If the wrong drivers have been

installed or if you are not sure, follow the instructions in section 3.3,

Uninstalling the USB Serial Adapter Drivers, and reinstall the software.

2. Check to make sure no other applications are using the COM port.

3. If you have enabled DOS Box support, make sure that no other

applications are using the Windows®name for the COM port or the DOS

name for the COM port (see section 4.4 Using the USB Serial Adapter

with DOS Applications).

5.2. Communications Garbled

If you are using the USB Serial Adapter to communicate between two

computers over a serial cable, make sure that the communications settings are

the same on each computer. For instance, if one computer is set up for 9600-

baud, 8 data bits, no parity, one stop bit and hardware handshaking, errors

can occur if the settings on the other device do not match.

5.3. Modem not detected/illegal operation in MODEM.CPL

It is possible that a modem attached to the USB Serial Adapter will not be

detected or a problem will occur in MODEM.CPL if more than one USB hub is

between the USB Serial Adapter and the root hub. This is a known problem in

1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2. Device Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.1. Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.2. Data Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.3. Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.4. Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.5. Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.6. LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.7. Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

3.1. Installing Windows®98 Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

3.2. Installing Windows®95 Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3.3. Adding DOS Box Support (Optional) . . . . . . . . . . . . . . . . . . . . . . . .5

3.4. Uninstalling the USB Serial Adapter Drivers . . . . . . . . . . . . . . . . . .6

4. Using the USB Serial Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . .6

4.1. Serial Plug-and-Play Device Detection . . . . . . . . . . . . . . . . . . . . . .6

4.2. Adding Non-Plug-and-Play (Legacy) Devices . . . . . . . . . . . . . . . . .7

4.3. LED Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4.4. Using the USB Serial Adapter With DOS Applications . . . . . . . . . . .7

5. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

5.1. Port Unavailable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

5.2. Communications Garbled . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

5.3. Modem Not Detected/Illegal Operation In MODEM.CPL . . . . . . . . . . .9

6. Using the Adapter on a Belkin BusStation™. . . . . . . . . . . . . . . .9

1. Introduction

The USB Serial Adapter provides a standard serial interface to a PC equipped

with USB without requiring an add-in card. By default, the USB Serial Adapter

installs without taking up any resources. In this mode, most standard Windows®

applications can communicate with the device without using IRQ or memory

location resources. The USB Serial Adapter supports communication speeds of

up to 230Kbps. The device can also be easily set up to support DOS

applications that require specific resources.

2. Device Specifications

2.1. Environmental Conditions

0 to 70˚C (32 to 158˚F)

Humidity 10 to 90%, non-condensing

2.2. Data Rate

Runs at a maximum baud rate of 230Kbps

2.3. Operating Systems

Windows®98, Windows®95 Rev. B

2.4. Power Consumption

Powered from USB Bus

Normal Operation: ~70µA

Suspend: ~300mA

2.5. Dimensions

1.25" H x 4.25" W x 3.75" L

2.6. LEDs

Red: Power

Green: Transmit and Receive

2.7. Compliance

FCC Class B, USB specification v 1.0 and 1.1

4.2. Adding Non-Plug-and-Play (Legacy) Devices

Non-Plug-and-Play devices must be added through the “Add New Hardware

Wizard” in the “Control Panel”. Using this wizard, follow the installation

instructions that came with your device.

4.3. LED Indicator Lights

There are three LEDs on the USB Serial Adapter. When the device is installed,

the center, green LED will remain blinking until the installation is complete. If the

installation is successful, the red LED will remain on, indicating power. When

the device is plugged in after installation, the lights will blink one at a time in

sequence from the red LED to the green LED, then back. When the device has

fully initialized and is ready to work, the red power LED will remain on. During

normal usage, the two green LEDs indicate data being transmitted and

received.

4.4. Using the USB Serial Adapter With DOS Applications

To enable the USB Serial Adapter to work with DOS applications, follow the

instructions in section 3.2 Adding DOS Box Support. You can

choose a different name for DOS than what is used for Windows®. You

may need to do this if the USB Serial Adapter has been installed as

COM5 or higher, since many DOS applications will only use COM1-COM4. For

instance, if you are adding DOS Box support to COM7, you can choose to have

DOS applications use the device as COM2 instead, if COM2 is not already in

use. COM7 would still be available for use with Windows®applications, but both

COM2 and COM7 refer to the same physical device. Therefore, while a DOS

application is using COM2, COM7 will be unavailable to Windows®applications

and vice-versa.

4. Using the USB Serial Adapter

3.4. Uninstalling the USB Serial Adapter Drivers

1. Unplug all USB Serial Adapter devices from the USB ports.

2. Open the “Control Panel” and double-click on “Add/Remove Programs”.

3. On the Install/Uninstall page, click on “USB Serial Adapter”

software from the list box and click “Add/Remove”.

4. You can choose to uninstall the USB Serial Adapter driver and

installation files, the mouse driver and installation files, or both. Choose

whatever you would like to remove (a check mark will appear in the box

next to each item to be uninstalled) and click “OK”.

5. A list of activities will appear in the “Results:” box. Click “Done” to exit

the uninstaller.

4. Using the USB Serial Adapter

4.1. Serial Plug-and-Play Device Detection

A Plug-and-Play device, such as a modem, can be detected in one of

two ways:

1. Attach the serial device to the USB Serial Adapter. Unplug the cable

and plug the USB B connector to the USB Serial Adapter.

2. Attach the serial device to the USB Serial Adapter.

Note: The DB9 and MiniDIN8 port cannot be used at the same time.

Connect only one device to either port. Do not attempt to connect

devices on each port at the same time.

3. Right-click the “My Computer” icon on your desktop.

4. Click “Properties” from the menu that appears.

5. Click the “Device Manager” tab on the System Properties page.

6. Click “Refresh”.

Your Plug-and-Play device should be detected and you may be asked for a

device driver if it has not been previously installed. Follow the instructions that

came with your serial device to complete the installation.

3. Installation

3.1. Installing Windows®98 Drivers

1. Insert the CD labeled “USB Serial Adapter Installation” into your CD

drive (typically drive D:\).

2. Insert the flat (type A) connector into an available USB port on your PC

or USB hub attached to your PC.

3. Insert the square connector (type B) into the USB Serial Adapter device.

You will see “Add New Hardware Wizard”.

4. Click “Next”.

5. When asked “What do you want Windows®to do?”, choose “Search”

for the best driver for your device. (Recommended) Click “Next”.

6. To search for new drivers, click on “Specify location” and in the path

type your CD-ROM driver letter and Win®98 path (typically: D:\Win®98).

Click “Next”.

7. The final dialog says “Windows®has finished installing the software

that your new hardware device requires”. Click “Finish”.

A new COM port will automatically be installed. Follow the instructions below to

determine the name of the new COM port.

1. Right-click the “My Computer” icon on your desktop.

2. Click “Properties” from the menu that appears.

3. Click on the “Device Manager” tab on the “System Properties’ page.

Click on the “+” next to “Ports (COM & LPT)”.

You will see a list of ports. One of the ports will be labeled “USB Comm Port

(COM name)” where “COM name” is the name of the new COM port. This name

will be used in applications.

3.2. Installing Windows®95 Drivers

1. Insert the CD labeled “USB Serial Adapter Installation” into your CD

drive (typically drive D:\).

2. Insert the flat (type A) connector into an available USB port on your PC

or USB hub attached to your PC.

3. Insert the square connector (type B) into the USB Serial Adapter device.

You will see “Add New Hardware Wizard”.

4. Click “Next”.

5. When asked “What do you want Windows®to do?”, choose “Search”

for the best driver for your device (Recommended). Click “Next”.

6. Windows®will then state it could not find drivers for this device. Click on

“Other Locations”.

7. In the path, type your CD-ROM drive letter and Win®95 path (typically

D:\Win®95) and click “OK”.

8. Click “Finish”.

9. Windows®will then state, “The disk labeled USB to Serial Disk #1 is

now required”. Click “OK”.

10. Where it states “copy file from”, type your CD-ROM drive letter and

path (typically D:\Win®95) and click “OK”.

11. Windows®will then finish the installation for you.

A new COM port will automatically be installed. Follow the instructions below to

determine the name of the new COM port.

1. Right-click the “My Computer” icon on your desktop.

2. Click “Properties” from the menu that appears.

3. Click on the “Device Manager” tab on the “System

Properties” page.

Click on the “+” next to “Ports” (COM & LPT).

You will see a list of ports. One of the ports will be labeled “USB Comm Port

(COM name)” where “COM name” is the name of the new COM port. This name

will be used in applications.

Autres manuels pour F5U103

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Belkin Adaptateur

Belkin

Belkin F5D4075 - Powerline AV+ Starter Manuel utilisateur

Belkin

Belkin F3H1381REVISED Manuel utilisateur

Belkin

Belkin OmniView F1DE083 Manuel utilisateur

Belkin

Belkin DUAL-BAND Wi-Fi Manuel utilisateur

Belkin

Belkin P73366-A Manuel utilisateur

Belkin

Belkin VideoBus II F5U208-MAC Manuel utilisateur

Belkin

Belkin Bluetooth USB Adapter F8T012 Manuel utilisateur

Belkin

Belkin USB VIDEOBUS P73261 Manuel utilisateur

Belkin

Belkin F8T031 - Bluetooth Wireless USB Printer Adapter Print... Manuel utilisateur

Belkin

Belkin F5U116 Manuel utilisateur

Belkin

Belkin F5D4078 Manuel utilisateur

Belkin

Belkin F8T003 Manuel utilisateur

Belkin

Belkin F6D4050 Manuel utilisateur

Belkin

Belkin F5D7330 Instructions d'installation et d'entretien

Belkin

Belkin Bluetooth USB Adapter F8T012 Manuel utilisateur

Belkin

Belkin Surf/Share F7D2101 Manuel utilisateur

Belkin

Belkin USB ADB Adapter F5U118-UNV Manuel utilisateur

Belkin

Belkin F5U004 Manuel utilisateur

Belkin

Belkin F9L1004 Manuel utilisateur

Belkin

Belkin F5U514 Manuel utilisateur

Belkin

Belkin F5U257 Manuel utilisateur

Belkin

Belkin F5U103-MAC Manuel utilisateur

Belkin

Belkin F5U002-BLU Mode d’emploi

Belkin

Belkin G+MIMO Manuel utilisateur

Manuels Adaptateur populaires d'autres marques

PCB Piezotronics

PCB Piezotronics 090B274 Manuel utilisateur

Auvidea

Auvidea J20 Manuel du produit

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuel utilisateur

Akribis

Akribis ITF-21-BISS-MIT Manuel utilisateur

Tenda

Tenda W54U Manuel utilisateur

ROHO

ROHO AGILITY Manuel utilisateur

PROLiNK

PROLiNK WN2001 Manuel utilisateur

Hawking

Hawking HUF2 Manuel utilisateur

Airlink101

Airlink101 AWLC4030 Manuel utilisateur

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuel utilisateur

Philips

Philips SWA4554S/10 Manuel utilisateur

JVC

JVC TS-C9D2B Manuel d'instructions

NETGEAR

NETGEAR A6100 Manuel utilisateur

D-Link

D-Link DWA-121 Manuel utilisateur

Philips

Philips SWA2037 Manuel utilisateur

Basalte

Basalte 0610-20 Manuel utilisateur

Yealink

Yealink EHS40 Manuel utilisateur

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuel utilisateur
