GRAPHIC EQUALIZER EQ700

Ultimate 7-Band Graphic Equalizer

Thank you for showing your condence in us by purchasing the BEHRINGER GRAPHIC EQUALIZER EQ700.

This high-quality stompbox is specically designed to provide complete tone control and eliminate

unwanted feedback. It allows 7-band sound shaping and feedback elimination from 100 Hz to 6.4 kHz

with a powerful 15 dB boost/cut per band.

1. Controls

(1) The 7-band EQ faders allow to boosting/cutting single frequency ranges from

100 Hz to 6.4 kHz at ±15 dB.

(2) The LEVEL fader adjusts the output level. It can be used to achieve eective volume “boost”

or “cut.”

(3) This LED illuminates when the EQ is activated. It also serves as a battery level indicator.

(4) Use the footswitch to activate/deactivate the EQ.

(5) Use this ¼" TS IN connector to plug in the instrument cable.

(6) The ¼" TS OUT connector sends the signal to your amp.

Use the DC IN connection at the front of the unit to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery,

press the hinges with a ballpen and remove the pedal cover. Be careful not to scratch the unit.

◊ The EQ700 has no on/o switch. As soon as you insert the jack into the in connector,

the EQ700 begins running. When not using the EQ700, remove the jack from the

in connector. This extends the life of the battery.

The SERIAL NUMBER is located at the bottom.

(2)

(6)

(1) (3)

(5)

(4)

GRAPHIC EQUALIZER EQ700

TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE

MUSIC GROUP (MUSIC-GROUP.COM). ALLTRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS

WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHERWHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.

COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS

ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR

IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OFTHIS MANUAL MAY BE REPRODUCED OR TRANSMITTED IN ANY FORM

OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUTTHE EXPRESS

Tortola, BritishVirgin Islands

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories.

Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,

especially when power supply cord or plug is damaged.

3. Warranty

Please register your new BEHRINGER equipment right after your purchase by visiting

http://behringer.com and read the terms and conditions of our warranty carefully.

4. Specications

Connector ¼" TS

Impedance 500 kΩ

Out

Connector ¼" TS

Impedance 1 kΩ

Power Supply

9 V𝌂, 100 mA regulated

BEHRINGER PSU-SB

PSU-SB-CN 220 VAC adaptor China

BEHRINGER

PSU-SB-EU 230 VAC adaptor Europe

BEHRINGER

PSU-SB-JP 100 VAC adaptor Japan

BEHRINGER

PSU-SB-SAA 240 VAC adaptor Australia

BEHRINGER

PSU-SB-UK 240 VAC adaptor UK

BEHRINGER

PSU-SB-UL 115 VAC adaptor USA

BEHRINGER

Power connector 2 mm DC jack,

negative center

Battery 9 V type 6LR61

Power consumption 30 mA

Physical/Weight

Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"

(H x W x D) approx. 54 x 70 x 123 mm

Weight approx. 0.73 lbs / 0.33 kg

BEHRINGER is constantly striving to maintain the

highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing

products without prior notice. Specifications and appearance

may therefore differ from those listed or shown.
